- Page 1 查询SLVU030供应商 捷多邦，专业PCB打样工厂，24小时加急出货 TPS6021x Evaluation Module Regulated 3.3 V, 100 mA Charge Pump With UltraLow Operating Current User’s Guide August 2000 Power Management Products...
- Page 2 IMPORTANT NOTICE Texas Instruments and its subsidiaries (TI) reserve the right to make changes to their products or to discontinue any product or service without notice, and advise customers to obtain the latest version of relevant information to verify, before placing orders, that information being relied on is current and complete. All products are sold subject to the terms and conditions of sale supplied at the time of order acknowledgment, including those pertaining to warranty, patent infringement, and limitation of liability.
- Page 3 Related Documentation From Texas Instruments Preface Read This First About This Manual This user’s guide describes evaluation module (EVM) TPS60210EVM-167. This EVM helps to evaluate the performance of the regu- lated low-ripple charge pump dc/dc converter TPS60210. The EVM has the dimension of a 14-pin dual inline package and the board is a single-layer board.
-
Page 5: Table Of Contents
Running Title—Attribute Reference Contents Description of the EVM ............Physical Data and Setup of the EVM . -
Page 7: Description Of The Evm
Chapter 1 Description of the EVM The Texas Instruments TPS60210 charge pump is a regulated voltage dou- bler. The TPS60210 delivers 3.3-V output voltage (V ) from a 1.8-V to 3.6-V input voltage (V ). The output current (I ) is 100 mA minimum, for an input volt- age (V ) of 2.0 V or higher. - Page 8 The TPS60210 EVMs can also be used to evaluate the other devices of this family (TPS60211, TPS60212, and TPS60213). For that purpose, replace the integrated circuit. For the TPS60211 and TPS60213, the LBI resistors should be removed and LBI connected to GND. The LBO pullup resistor works as power good (PG) pullup, and the LBO pad gives the PG signal.
-
Page 9: Physical Data And Setup Of The Evm
Chapter 2 Physical Data and Setup of the EVM This section shows the schematic, the layout, and setup of the EVM. The layout of a charge pump circuit is critical; therefore, the given layout can be used as a reference and helps to reduce design and evaluation time. Topic Page Schematic of the EVM... -
Page 10: Schematic Of The Evm
C3, C4 EMK316BJ225KL–T Taiyo Yuden Input and output capacitors 100 nF Filter capacitor for the LBI input signal TPS60210 Texas Instruments 402 kΩ E96-Series LBI input voltage adjustment 576 kΩ E96-Series LBI input voltage adjustment 1 MΩ Pullup for the open drain output LBO 1 MΩ... - Page 11 Schematic of the EVM R4 is the pullup resistor for the SNOOZE pin, therefore, the device operates in normal mode. Applying a logic low level to the SNOOZE input, programs the device in snooze mode. Note: When the device is in snooze mode, be aware that the LBI and SNOOZE re- sistors (R1, R2, and R4) draw more current than the device itself.
-
Page 12: Layout Of The Evm
Layout of the EVM 2.2 Layout of the EVM Figure 2–2 and Figure 2–3 show the placement of the components and the layout of the EVM. The components and all signals are exclusively placed on the top layer of the PC board. Figure 2–4 shows the actual size of the board. Figure 2–2. -
Page 13: Setup Of The Evm
Setup of the EVM Table 2–2. Pin Assignment of the Board to a 14-Pin Dual-In-Line Socket Socket Pin Number Connected Signal Not connected 7, 8 SNOOZE 2.3 Setup of the EVM Follow these steps for proper operation of the EVM: 1) Connect a load to the output (between GND and OUT). -
Page 14: Evaluation Information
Evaluation Information 2.4 Evaluation Information Due to the pullup resistor R4 at SNOOZE of the EVM, the TPS60210 is enabled by default. To operate the device in snooze mode, drive the SNOOZE pin of the EVM to ground. By connecting a clock signal between 400 kHz and 800 kHz to the SNOOZE pin of the board, the device can be synchronized to an external clock.
