Getting Started
Before using your Cisco Unified Wireless IP Phone 7920, you need to do the following:
• Checking Shipment Completeness, page 8
• How to Use this Guide, page 8
• Safety Warnings, page 9
• Battery Safety Notices, page 11
• Installing and Removing the Battery, page 12
• Charging the Phone and the Battery, page 13
Checking Shipment Completeness
Check to make sure that all items are present in the Cisco Unified Wireless IP Phone 7920 box.
The package should contain the following:
• Cisco Unified Wireless IP Phone 7920
• Standard battery (Cisco part number: CP-BATT-7920-STD)
• Power supply (Cisco part number: CP-PWR-7920SE-NA)
• Regulatory Compliance and Safety Information for the Cisco Unified Wireless IP Phone 7920
Inform your system manager or supplier if any items are missing.
How to Use this Guide
This guide provides you with an overview of the features that are available on your phone. For
information about common tasks, refer to the following table. Contact your system administrator if
you have problems or need more information about your phone.
If you want to...
Review safety information
Install the battery
Charge the battery
Use your phone
8
Then...
See the "Safety Warnings" section on page 9.
See the "Installing and Removing the Battery" section on page 12.
See the "Charging the Phone and the Battery" section on page 13.
Start with the "Overview of the Cisco Unified Wireless IP Phone
7920" section on page 15.
78-16631-01
