DSC SKYROUTE max Quick Install Manual

Hide thumbs Also See for SKYROUTE max:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual
WARNING
You must be enrolled with Connect 24 before
activating this unit. Call 1-888-251-7458 in the
U.S. or 1-888-955-5583 in Canada
Installation
Manual
Version 1.1

Advertisement

Table of Contents
loading

Related Manuals for DSC SKYROUTE max

Summary of Contents for DSC SKYROUTE max

  • Page 1 WARNING You must be enrolled with Connect 24 before activating this unit. Call 1-888-251-7458 in the U.S. or 1-888-955-5583 in Canada Installation Manual Version 1.1...

  • Page 2: Table Of Contents

    1.2 Skyroute max Transceiver Glossary of Terms ..2 6.13 Connection Diagram ..........7 6.14 Wiring Skyroute max to a DSC Control Panel ..10 Section 2 - What’s New on Version 1.1 6.15 Supervised Power Supply Connection ....10 2.1 Downloading Support ..........
  • Page 3 The Skyroute max will automatically restart, and default to the new setting. SELECT THE CELLULAR CHANNEL - Section [006] The Skyroute max is defaulted for Channel B. If you require Channel A (see the SID List for the channel of the Cellular Service Provider in your area), perform the following: •...

  • Page 4: Skyroute Max Max

    A 10 digit decimal number used for registrations and pages. Warning Page Only use the antenna provided by DSC / Sur-Gard. The use A transmission that is sent from the Cellemetry Gateway to of any other type will invalidate the warranty and may be the Cellemetry radio.

  • Page 5: Section 3 - What Is It

    • Extension Kits available: Cellemetry service. Events are transmitted from the Skyroute LAE – 3 The 3 Foot Antenna Kit for Skyroute max max transceiver via the Cellemetry network to the clearing house Transceiver and then to the central station in a fast, reliable manner.

  • Page 6: Section 5 - What Do I Do Before Installing A Skyroute Max Max ? Max

    CONNECT 24 is your Skyroute max Cellemetry service provider. If you have not yet enrolled as a Skyroute max dealer, you must do so at least 1 business day before your first Skyroute max installation. Note: If you do not have the numbers required below, please call Connect 24 at 1-888-251-7458 “Dealer Note: If you do not have the numbers required below, please call Connect 24 at 1-888-251-7458 “Dealer...

  • Page 7: Section 6 - Installing A Skyroute Max Max

    Combus black), you can quickly determine a location where your signal strength is strong prior to installing the unit. The Skyroute max does not have to be active to show signal strength. unit. The Skyroute max does not have to be active to show signal strength.

  • Page 8: Antenna Relocation Diagram

    • The BELL+ and BELL- terminals on the control panel secondary communication paths - shall not power other devices. The DSC Listed model 1. Compatible Listed control unit’s land line to central PC4702BP bell/siren module shall be used. Refer to station (primary).

  • Page 9: Installation

    It is mandatory that the power be removed from the system This terminal is used to power the cellemetry modem of the Skyroute max . This connects to the BELL + on the before any wiring changes are performed on the Skyroute max module.
  • Page 10 Standard Connection with PC4020CF / Partner P-16128 (Commercial Fire Applications) 8 8 8 8 8...
  • Page 11 Battery Lead and AC Power Lead Routing for UL Listed Commercial Fire Systems 9 9 9 9 9...

  • Page 12: Wiring Skyroute Max To A Dsc Control Panel

    UL Listed. A UL1481 Listed power supply 12V/1.5A is not UL Listed. A UL1481 Listed power supply 12V/1.5A is not UL Listed. A UL1481 Listed power supply 12V/1.5A terminal of the Skyroute max unit. The wire run must not (e.g (e.g (e.g...

  • Page 13: Section 7 - Programming And Activating A Skyroute Max Max Max

    [030] through [047]. code of ‘FF’ and all events that you do not want • This enables the Skyroute Max to send all Alarm, Alarm communicated must be programmed with a reporting Restoral, Tamper, Tamper Restoral, Maintenance code of ‘00’...

  • Page 14: Programming Options

    7.3.3 Transmitting and Receiving • To activate the Skyroute max module in Home mode: LED4 on the Skyroute max module will blink once (1) to 1. Select a channel, A or B, in address [006] (Option 1 or 2) indicate the cellular tower has received the signal. It will 2.

  • Page 15: Section 8 - Skyroute Max Max Max Programming With Pc4020 Max

    Default I_____I____I *Entering 00 will cause a software default of the Skyroute max to Full reporting . *Entering 22 will cause a software default of the Skyroute max to Generic reporting. *Entering FF will cause a restart of the Skyroute max transceiver.

  • Page 16: Advanced Programming

    8.2 Advanced Programming OPTIONAL Sub-sections [030] to [047] will disable groups of reporting codes. Default 22 - Generic, Default 00 - Full [030] System Event (Partition 0) Transmission Options Section A Generic Full Option ON Option OFF Reporting Reporting I_____I Option 1 Alarms Disabled...
  • Page 17 [034] Partition 2 Transmission Options Section A Generic Full Option ON Option OFF Reporting Reporting I_____I Option 1 Alarms Disabled I_____I Option 2 Alarm Restorals Disabled I_____I Option 3 Tampers Disabled I_____I Option 4 Tamper Restorals Disabled I_____I Option 5 Closings Disabled I_____I...
  • Page 18 [038] Partition 4 Transmission Options Section A Generic Full Option ON Option OFF Reporting Reporting I_____I Option 1 Alarms Disabled I_____I Option 2 Alarm Restorals Disabled I_____I Option 3 Tampers Disabled I_____I Option 4 Tamper Restorals Disabled I_____I Option 5 Closings Disabled I_____I...
  • Page 19 [042] Partition 6 Transmission Options Section A Generic Full Option ON Option OFF Reporting Reporting I_____I Option 1 Alarms Disabled I_____I Option 2 Alarm Restorals Disabled I_____I Option 3 Tampers Disabled I_____I Option 4 Tamper Restorals Disabled I_____I Option 5 Closings Disabled I_____I...
  • Page 20 [046] Partition 8 Transmission Options Section A Generic Full Option ON Option OFF Reporting Reporting I_____I Option 1 Alarms Disabled I_____I Option 2 Alarm Restorals Disabled I_____I Option 3 Tampers Disabled I_____I Option 4 Tamper Restorals Disabled I_____I Option 5 Closings Disabled I_____I...

  • Page 21: Section 9 - Testing

    There is a 1-minute delay between each signal sent by the Skyroute max transmitter. For example: If you trip 3 zones and you have the Skyroute max mode programmed to send the alarm and restoral reporting codes for each zone (6 signals in total), it will take about 5 minutes for all the signals to go through.

  • Page 22: Section 10 - Troubleshooting

    Section 10 - Troubleshooting Problem: • LED5 is blinking 2 times - Radio is not powered Solution: • Make sure that BELL(+) on the panel is connected to BELL IN on the Skyroute max module. • Perform a default on the Skyroute max module.

  • Page 23: For Your Records

    For Your Records Location ___________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ Skyroute max max MIN Number __________________________________________________ Rate Plan __________________________________________________________________ Central Station _____________________________________________________________ Account Number ___________________________________________________________ Test Time and Day __________________________________________________________ Additional Notes ___________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________...

  • Page 24: Appendix A - Reporting Codes For Sia And Contact Id

    Appendix A - Reporting codes for SIA and Contact ID / e l / e l . t s t l u t l u . t s . t s t i t o i i i t r o i t .

  • Page 25: Appendix B - Zone Alarms

    Appendix B - Zone Alarms a i l f i t t i t o i i f i t f i t t i t o i i y f i t i t o i i t i t o i i t i t o i i...

  • Page 26: Appendix C - Zone Trouble/Tampers

    Appendix C - Zone Trouble/Tampers a i l t i t o i i t i t o i i y f i o l f t i t o i i i v r t i t o i i i v r t i t o i i...

  • Page 27: Appendix D - Zone Faults

    Appendix D - Zone Faults a i l t i t o i i t i t o i i y f i o l f t i t o i i i v r t i t o i i i v r t i t o i i...
  • Page 28 Any type of tampering whether intentional or unintentional such as masking, to any claim by or against DSC, the limitations and disclaimers contained here shall be to the painting, or spraying of any material on the lenses, mirrors, windows or any other part of the greatest extent permitted by law.
