Summary of Contents for Zotac ZBOX PRO ZP-CI330NANO
- Page 2 ZOTAC. Products and corporate names mentioned in this manual may be registered trademarks or copyrights of their respective companies, and are used for identification purposes only.
-
Page 3: Table Of Contents
Table of Contents Specifications ----------------------------------------------------------------------------------------------------3 Safety instructions----------------------------------------------------------------------------------------------5 Package contents -----------------------------------------------------------------------------------------------6 Getting to know your ZP-CI330NANO --------------------------------------------------------------------7 Front view -----------------------------------------------------------------------------------------------------7 Rear view ------------------------------------------------------------------------------------------------------8 Installing hardware inside ZP-CI330NANO -------------------------------------------------------------9 Installing an M.2 SSD module ----------------------------------------------------------------------------14 Installing a memory module -------------------------------------------------------------------------------16 Installing a hard disk drive ---------------------------------------------------------------------------------18 Installing the L-shaped mountings ------------------------------------------------------------------------20 Installing your ZP-CI330NANO to a monitor -----------------------------------------------------------21 Setting up your ZP-CI330NANO ----------------------------------------------------------------------------23... -
Page 4: Specifications
Specifications Microprocessor Support • Intel Celeron N3160, Quad-core 1.6 Ghz/2.24 Ghz, 2 MB cache Operating Systems • Supports Windows 10 64-bit Onboard Graphics Support • Intel HD Graphics 400 • HDMI 1.4 (max resolution: 3840x2160 @30Hz, 2560x1600 @60Hz) • VGA (max resolution: 1920x1200 @60 Hz) System Memory Support •... -
Page 6: Safety Instructions
Safety instructions ZP-CI330NANO is designed and tested to meet the latest standards of safety for information technology equipment. However, to ensure your safety, it is important that you read the following safety instructions. Read and follow all instructions in the documentation before you operate your system. ™... -
Page 7: Package Contents
Package contents Thank you for choosing our ZP-CI330NANO. The following illustration displays the package contents of your new ZP-CI330NANO. If any of the below items is damaged or missed, contact your retailer. • 1 x ZP-CI330NANO • 1 x L-shaped mounting kit •... -
Page 8: Getting To Know Your Zp-Ci330Nano
Getting to know your ZP-CI330NANO Front view 2 3 4 1. Power button The power button turns the mini-PC ON and OFF. 2. Power LED The Power LED is always ON when power is on. 3. SATA status LED The SATA LED blinks when data is being written onto or read from the SATA. 4. -
Page 9: Rear View
Rear view 1. VGA port The VGA port supports connection to analog monitors and displays. 2. WiFi antenna connector The WiFi antenna connector supports the included WiFi antenna. 3. Ethernet port The eight-pin RJ-45 LAN port supports standard Ethernet cable for connections to local area networks (LAN) with speeds of 10/100/1000Mbps. -
Page 10: Installing Hardware Inside Zp-Ci330Nano
Installing hardware inside ZP-CI330NANO Before installing hardware, please follow the instructions below to remove the cover of your ZP-CI330NANO. 1. Remove the four screws of L-shaped mounting kit. 2. Remove the L-shaped mounting kit. - Page 11 3. Remove the four screws of bottom cover. 4. Remove the bottom cover.
- Page 12 3. Remove the four screws of rear cover. 4. Remove the two screw locks of HDMI ports with a 5mm screwdriver.
- Page 13 5. Remove the screw lock of power input with a 10mm screwdriver. 6. Remove the two screws securing the hard disk drive bracket, and remove the hard disk drive bracket.
- Page 14 7. Remove the six screws securing the board as shown below. 8. Take out the board of the ZP-CI330NANO as shown below.
-
Page 15: Installing An M.2 Ssd Module
Installing an M.2 SSD module 1. Turn over the board, and remove the VGA cable. 2. Insert the M.2 SSD module into the socket. - Page 16 3. Gently press down on the M.2 SSD module, and install the screw to secure the M.2 SSD module. 4. Install the board into the box with screws.
-
Page 17: Installing A Memory Module
Installing a memory module 1. Insert the memory module into the socket. 2. Gently press down on the memory module until it is locked by the arms of the socket. - Page 18 3. If you want to install two memory modules, please repeat the step 2. When installing only one SO-DIMM, please put it on the lower slot. ...
-
Page 19: Installing A Hard Disk Drive
Installing a hard disk drive 1. Install the hard disk bracket onto a 2.5-inch SATA hard disk drive /SSD with two screws. 2. Insert the hard disk drive /SSD into the socket and gently slide into the connector. - Page 20 3. Reinstall the screws for the hard disk bracket. 4. Reinstall the bottom cover for the ZP-CI330NANO.
-
Page 21: Installing The L-Shaped Mountings
Installing the L-shaped mountings Locate the bottom cover upwards, and take out the L-shaped mounting kit and shipped screws. Install the L-shaped mountings to the bottom cover with screws. -
Page 22: Installing Your Zp-Ci330Nano To A Monitor
Installing your ZP-CI330NANO to a monitor You can also install your ZP-CI330NANO to the back of a monitor. To do so: Unscrew and remove the bottom cover. Install the VESA mounting kit to the bottom cover with four screws as shown below. - Page 23 Reinstall the bottom cover to the ZP-CI330NANO. Install the ZP-CI330NANO to the monitor. Mechanical Loading Stability - Mounting of the equipment on the backside of the monitor should be lay this equipment on a reliable surface when install. A drop or fall could cause injury.
-
Page 24: Setting Up Your Zp-Ci330Nano
Setting up your ZP-CI330NANO Please connect your peripherals before using your ZP-CI330NANO. 1. Connecting a VGA display Connect the VGA connector to the VGA port. 2. Connecting the WiFi antenna Connect the WiFi antenna to the WiFi antenna connector. 3. Connecting to a network device Connect one end of a network cable to the LAN port on the system rear panel and the other end to a network hub, switch or router. - Page 25 4. Connecting to USB 2.0 devices Connect USB 2.0 devices such as keyboards, mice, cameras and hard disk drives. 5. Connecting to an HDMI display Connect one end of an HDMI cable to an HDTV or monitor, and the other end to the HDMI port on the system rear panel.
-
Page 26: Installing Drivers And Software
Installing drivers and software Installing an operating system The ZP-CI330NANO does not ship with an operating system preinstalled. The user must install the operating system before the ZP-CI330NANO can be used. The following operating systems are supported: • Windows 10 64-bit Follow the instructions below to install an operating system: Attach external DVD drive via USB 3.0 or 2.0 ports. -
Page 27: Using Your Zp-Ci330Nano
• Ethernet PCIE Driver • Trusted Execution Engine • Wireless Network Driver • CardReader Driver • USB Charger (optional) Note: If you want to use high-amperage USB charging for smartphones and tablets, please install the driver USB Charger driver. Each driver must be installed individually to ensure proper operation of the ... -
Page 28: Configuring Audio Output
Configuring audio output Follow the steps below to enable audio output when connecting the ZP-CI330NANO to a TV or receiver via HDMI/DP/VGA adapter. Access the Sound settings via the system Control Panel. Under Playback devices, click the display device that corresponds with your audio compatible display. - Page 29 291-MB391-00...
