iHome iWBT5 Instruction Manual

iHome iWBT5 Instruction Manual

Bluetooth dual alarm clock radio with apple watch charging
Hide thumbs
Table of Contents

Advertisement

Quick Links

Model: iWBT5
Instruction manual - US English
Size: 102 x 150 mm
Warranty
Cover
Date: Jan 23, 2019
Mat'l: 100gsm paper (WF)
Color: Black text on white background
Model: iWBT5
Bluetooth Dual Alarm Clock
Radio with
Apple Watch™ Charging
QUESTIONS? Visit www.ihome.com

Advertisement

Table of Contents
loading

Related Manuals for iHome iWBT5

Summary of Contents for iHome iWBT5

  • Page 1 Model: iWBT5 Instruction manual - US English Size: 102 x 150 mm Warranty Cover Date: Jan 23, 2019 Mat’l: 100gsm paper (WF) Color: Black text on white background Model: iWBT5 Bluetooth Dual Alarm Clock Radio with Apple Watch™ Charging QUESTIONS? Visit www.ihome.com...
  • Page 2 W E L C O M E Thank you for choosing the iWBT5 from iHome. This user guide will get you up and running quickly and provide helpful hints to maximize enjoyment. For more information about this and other iHome products, please visit www.ihome.com...

  • Page 3: Top Panel

    F E A T U R E S & F U N C T I O N S Top panel Talk/End Call Power On/O Button Button Alarm 1 Button Sleep Button Alarm 2 Button Apple Watch Voice/Play/ Magnetic Pause/Presets Charging Module Button Mode Button Microphone...

  • Page 4: C O N N E C T I N G A C A D A P T E R

    Display Time Display Bluetooth Indicator Alarm Indicators AM Indicator Low Backup PM Indicator Battery Indicator Wake-To/Mode Indicators Alarm Time/Date Display (Bluetooth/Tone/FM Radio) C O N N E C T I N G A C A D A P T E R This unit operates on AC power using the included 100V-240V universal AC adaptor.

  • Page 5: Backup Battery

    B A C K U P B A T T E R Y The iWBT5 ships with a CR2450 battery installed for backup to provide continuous alarm operation and clock settings in the event of a power failure. Remove the pull tab from the battery compartment on the bottom of the unit before use.

  • Page 6: Setting The Time

    SETTING THE TIME: TIME SYNC & MANUAL TIME SETTING DST SWITCH This unit has a Daylight Saving Time (DST) Switch on the bottom of the unit. By default, the switch is set to Auto and will automatically adjust the time at the start and end of Daylight Saving Time.

  • Page 7: Setting And Using The Alarms

    SETTING AND USING THE ALARMS Setting the alarms This unit has two alarms which are set the same way. Instructions below use “alarm button” to mean Alarm 1 Button to set alarm 1 and Alarm 2 Button to set alarm 2. You can wake to your Bluetooth device, FM radio or to the built-in buzzer alarm.
  • Page 8 S E T T I N G A N D U S I N G T H E A L A R M S (C o n t i n u e d ) 6. Press the Alarm Button to exit and confirm alarm settings. An alarm icon will appear on the display, indicating that the alarm is set and armed.

  • Page 9: Listening To Fm Radio

    L I S T E N I N G T O F M R A D I O Extend FM antenna for best reception. Tunin g a nd P l ay i ng the Radio Power Button to turn on the unit, then press and Press and release the release the Mode Button as needed to cycle through BT and FM radio modes.

  • Page 10: Using The Speakerphone

    DEVICES Pairing is the set-up process to introduce your Bluetooth-capable device to the iWBT5. Once your device is paired, the iWBT5 can recognize it and you can play your audio through it. 1. Press and hold the Bluetooth Pairing Button located on the back of the unit for 3 seconds.
  • Page 11 Usin g t he Voi ce Cont rol feature NOTE: The unit must be powered on and linked to an iOS or Android Bluetooth device to use Voice Control. Press and hold the Button for 2 seconds and wait for beep to activate voice control with Siri or Google Assistant. Voice control requires an active internet connection on connected Bluetooth device with iOS 10 and Android 6 and later.

  • Page 12: S N O O Z E / D I M M E R O P E R A T I O N

    flashes, then press the + and – Buttons on the unit to adjust the snooze time to 1 - 29 minutes. 2. Press the Snooze/Dimmer Button on the iWBT5 after the alarm sounds. The alarm will be silenced and will come on again in about 9 minutes (default).

  • Page 13: Troubleshooting

    T R O U B L E S H O O T I N G Symptom Possible reason Solution Unit won’t turn AC adaptor isn't Plug the AC adaptor into a plugged into a working working wall socket and plug wall socket or not the connector into the supply plugged into the...

  • Page 14: Important Safety Instructions

    IM PO R TA N T SA FE T Y I N ST RU CT I ONS When used in the directed manner, this unit has been designed and manufactured to ensure your personal safety. However, improper use can result in potential electrical shock or fire hazards. Please read all safety and operating instructions carefully before installation and use, and keep these instructions handy for future reference.
  • Page 15 IMP O R TA N T SAF E T Y I NST RU CTI ON S (CO N TI N U E D) 11. Damage Requiring Service – The unit should be serviced by qualified service personnel when: A. the power supply cable or plug has been damaged. B.

  • Page 16: Fcc Radiation Exposure Statement

    FCC I n for m at i o n Model: iWBT5 FCC ID: EMOIWBT5 FCC Radiation Exposure Statement IC: 986B-IWBT5 This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device complies with Part 15 of the FCC Rules, operation is subject to the...

  • Page 17: Limited 1-Year Warranty

    LI MI TE D 1 Y E A R WARRA NTY iHome Products, a division of SDI Technologies Inc. (hereafter referred to as SDI), warrants this product to be free from defects in workmanship and materials, under normal use and conditions, for a period of one (1) year from the date of original purchase.
