Front / Side view TV bu�on controls
ITEM
1 POWER LED
2 IR (Infrared Receiver)
3 VOL+/-
4 CH+/-
5 MENU
6 SOURCE
7 STANDBY
Rear view sockets
SOCKET
1 HDMI INPUTS
2 AV
3 HEADPHONE
4 USB
5 OPTICAL AUDIO OUTPUT
6 USB
7 COAX AUDIO OUTPUT
8 RJ45 (ETHERNET)
9 TV Aerial
DESCRIPTION
Illuminates Green when the TV is turned on.
Illuminates Red when the TV is in Standby.
Receives IR Signals from the remote control.
Do not block the sensor.
Adjusts the Volume
Selects channels
Displays the on screen display
Select from NETGEM/HDMI1/HDMI2/AV/USB
Turns the Television ON and OFF
DESCRIPTION
Connect to external devices via HDMI cable
Connect to external devices via AV cables
Connect to Headphones
Connect to a USB storage device and play media files
Digital audio output to sound system
For service and maintenance use only
Digital audio output to sound system
Connect to the internet
Connect to the domes�c aerial socket
