OWNER'S
MANUAL
COLOR TV/DVD
6520FDD
INSTRUCCIONES
EN ESPAÑOL INCLUIDAS.
As an E
S
NERGY
TAR
Partner, our company has
determined that this product meets
the E
S
®
guidelines for
NERGY
TAR
energy efficiency. E
S
NERGY
TAR
a U.S. registered mark.
SUPPLIED ACCESSORIES
Remote Control Unit
®
If you need additional assistance for set-up or operating after
reading owner's manual, please call TOLL FREE : 1-800-968-3429.
®
is
Or visit our WEB SITE at http://www.funai-corp.com
Please read before using this equipment
(20 inch)
NE207UD
Batteries
Owner's Manual
2 AA Batteries
Owner's Manual
0EMN02321
Advertisement
Table of Contents
Related Manuals for Sylvania 6520FDD
Summary of Contents for Sylvania 6520FDD
- Page 1 OWNER’S MANUAL COLOR TV/DVD 6520FDD INSTRUCCIONES EN ESPAÑOL INCLUIDAS. ® As an E NERGY Partner, our company has determined that this product meets the E ® guidelines for NERGY ® energy efficiency. E NERGY a U.S. registered mark. (20 inch)
-
Page 2: C Important Safeguards
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. - Page 3 EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECT RICAL CODE NEC - NATI O NAL EL ECTRI CAL CO DE S2 8 9 8 A 12.Power-Cord Protection-Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying par- ticular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.
-
Page 4: C Precautions
IMPORTANT COPYRIGHT INFORMATION Unauthorized copying, broadcasting, public perfor- mance and lending of discs are prohibited. This product incorporates copyright protection tech- nology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. -
Page 5: Location
LOCATION For safe operation and satisfactory performance of your TV/DVD, keep the following in mind when selecting a place for its installation: • Shield it from direct sunlight and keep it away from sources of intense heat. • Avoid dusty or humid places. •... -
Page 6: Table Of Contents
C IMPORTANT SAFEGUARDS ... . .2 C PRECAUTIONS ......4 LOCATION . -
Page 7: C Features
TV Mode • 181 channel capability PLL frequency synthesiz- er tuner with direct station call (A converter may be necessary to view scrambled cable channels.) • Infrared remote control • Trilingual on screen menu display selectable in English, Spanish, or French ¡... -
Page 8: Operating Controls And Functions
OPERATING CONTROLS AND FUNCTIONS TV/DVD FRONT PANEL REMOTE CONTROL POWER PICTURE SELECT CLOSE SLEEP +100 SKIP ZOOM PLAY STOP PAUSE SLOW DISPLAY ENTER SETUP TITLE RETURN CLEAR SEARCH MODE REPEAT AUDIO SUBTITLE MODE 1. Disc loading tray 2. VIDEO input Jack [page 11] Connect to the video output jack of a video camera or VCR. -
Page 9: Installing The Batteries
TV/DVD REAR VIEW 17. SLEEP Button [page 16] Press SLEEP to display the sleep timer and start the function. The shut off time can be determined by the number of times you press this button. (0, 30, 60, 90, or 120 minutes) 18. -
Page 10: C Preparation For Use
PREPARATION FOR USE ANTENNA/CABLE CONNECTIONS Satellite Box or Cable Box O UT (Not supplied) From Cable System 75-ohm Coaxial Cable (Not supplied) Note to CATV system installer: This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building as close to the point of cable entry as practical. -
Page 11: Connecting To External Input Jacks
CONNECTING TO EXTERNAL INPUT JACKS When you watch a program recorded on an another source (VCR or video camera), use the audio/video input jacks on the front of the TV/DVD. Connect the audio/video output jacks of another source to the AUDIO L/R and VIDEO jacks of this TV/DVD. -
Page 12: Connecting To A Dolby Digital Decoder (For Dvd)
CONNECTING TO A DOLBY DIGITAL DECODER (for DVD) If using this TV/DVD to play a DVD disc in a 5.1 channel Dolby Digital surround format, the TV/DVD out- puts a DOLBY DIGITAL Data stream from its COAXIAL digital audio out jack. By hooking the player up to a Dolby Digital decoder, you can enjoy a more convincing, realistic ambience with powerful and high-quality surround sound as enjoyed in movie theaters. -
Page 13: Tv Section
You can program the tuner to scan all the channels you receive in your area. NOTE: Channel memory programming is NOT needed when connected to a cable box or satellite box. Just select the TV/DVD channel selector to the output channel of the cable box or satellite box (Ex CH3). Then select the channel to be viewed on the Cable Box or Satellite Box. -
Page 14: Channel Set Up Again
CHANNEL SET UP AGAIN Select “CHANNEL SET UP” Press SETUP on the remote control. Press K or L to point to “CHAN- NEL SET UP”. Then, press ENTER. Begin auto preset Press K or L to point to “AUTO PRESET”. Then, press ENTER. The tuner scans and memorizes all the active channels in your area. -
Page 15: C Tv Operation
WATCHING A TV PROGRAM Turn on the TV/DVD Press POWER to turn on the TV/DVD. Select the channel number Press CHANNEL(CH.) K or L to select your desired channel number or press Number on the remote con- trol. Note for using the Number on the remote control: ¡... -
Page 16: Sleep Timer
SLEEP TIMER The Sleep Timer function enables you to shut off the power without pressing POWER after a desired time period. Set “SLEEP TIMER” Press SLEEP on the remote control. You may change the sleep time with pressing SLEEP on the remote control repeatedly. -
Page 17: V-Chip Set Up
V-CHIP SET UP V-CHIP enables parents to prevent their children from watching inappropriate material on TV. V-CHIP reads the ratings for programming (except for news and sports programs, unedited movies on premium cable channels, and Emergency Broadcast System signals), then denies access to programming if the program’s rating meets the limitations you select. -
Page 18: Mpaa Rating Set Up
MPAA RATING SET UP Make sure ... • TV/DVD power must be turned on. Select “V-CHIP SET UP” Press SETUP on the remote control. Press K or L to point to “V-CHIP SET UP”. Then, press ENTER. Enter 4-digit access code Press Number on the remote con- trol. -
Page 19: Dvd Section
PLAYABLE DISCS The following discs can be played back on this TV/DVD. ¡ ¡ DVD video DVD-R/RW* ¡ ¡ DVD+R/RW* Audio CD ¡ ¡ CD-R/RW* MP3* * Depending on the types or the writing method of the medium some discs can not be played. •... -
Page 20: C Playing A Disc
BASIC PLAYBACK Getting started ¡ Turn on the power of amplifier and any other com- ponents, if necessary. Press POWER. ¡ The power will turn on. Press OPEN/CLOSE to open disc loading tray. Place the chosen disc in the tray, with the label facing up. -
Page 21: Resume
RESUME During playback, press STOP. ¡ Resume message will appear on the TV screen. Press PLAY, playback will resume from the point at which playback was stopped. ¡ To cancel resume, press STOP twice. ¡ If turn off the TV/DVD, resume function will be cancelled. -
Page 22: C Search Function
TRACK SEARCH There are three ways to begin playback on an Audio CD at a specific Track. Using Number on the remote control Press Number to enter the desired Track number. ¡ Playback will start at the selected track. ¡ For single digit tracks (1-9), press a single number (eg. -
Page 23: C Special Playback Function
SPECIAL PLAYBACK FUNCTION REPEAT REPEAT is available only during playback. REPEAT TITLE / CHAPTER To activate the repeat function, press REPEAT during playback. ¡ The repeat mode changes as described below every time you press the button. CHAPTER TITLE (current chapter repeat) (current title repeat) NOTES ¡... -
Page 24: C Playing A Mp3 Disc
MP3 PLAYBACK When a CD with MP3 files is in the TV/DVD, the MP3 menu will appear on the TV screen in stop mode. In stop mode, press Arrow ( the desired group track. ¡ If a group is selected, press or ENTER to go on to the track selection screen. -
Page 25: C Changing The Settings
CHANGING THE SETTINGS SUBTITLE LANGUAGE The DVD allows you to select a language for subtitles during DVD disc (if available) playback. Press SUBTITLE during playback. Press SUBTITLE repeatedly to select your desired subtitle language. ¡ The subtitle language will be displayed on the dis- play bar at the top of the screen. -
Page 26: C The On-Screen Information
THE ON-SCREEN INFORMATION You can check the information about the current disc by pressing DISPLAY on the remote control. For DVD-Vs Press DISPLAY during playback to show current Chapter. ¡ The elapsed and remaining playing time of the current chapter will be displayed. Press DISPLAY again to show current Title. -
Page 27: C Changing The Dvd Setup Items
CHANGING THE DVD SETUP ITEMS Language options are not available with some discs. Press SETUP twice in STOP mode so that the DVD SETUP menu appears. ¡ If the menu does not appear, press PLAY, STOP, then SETUP twice. QUICK SETUP TV MODE 4:3 LETTER BOX DOLBY DIGITAL... -
Page 28: Display Setting
DISPLAY SETTING You can change certain aspects of the DVD display screens and on-screen messages on the TV screen. Press SETUP twice in STOP mode so that the DVD SETUP menu appears. ¡ If the menu does not appear, press PLAY, STOP, then SETUP twice. -
Page 29: Parental Control
Parental Control limits the disc viewing that exceed your settings. (with a password or playback will stop.) This feature allows you to prevent discs with alterna- tive scenes from being played by your children. PARENTAL LEVEL Parental Level allows you to set the rating level of your DVD discs. -
Page 30: Troubleshooting Guide
TROUBLESHOOTING GUIDE If the TV/DVD does not perform properly when operated as instructed in this Owner’s Manual, check the player, consulting the following checklist. Problem No power. The TV/DVD does not respond to the remote control. TV Mode Problem No Picture or Sound Bars On Screen Picture Distorted or Blurred Picture Rolls Vertically... -
Page 31: Dvd Mode
Closed Caption Problem My TV is showing captions that are misspelled. My TV will not show the text in its entirety or there is a delay of what is being said. My captions are scrambled with white boxes on the TV screen. My program guide listed a TV show •... -
Page 32: C Maintenance
CABINET CLEANING • Wipe the front panel and other exterior surfaces of the TV/DVD with a soft cloth immersed in luke- warm water and wrung dry. • Never use a solvent or alcohol. Do not spray insec- ticide liquid near the TV/DVD. Such chemicals may cause damage and discoloration to the exposed surfaces. -
Page 33: C Specifications
GENERAL SPECIFICATIONS CRT : 20 inch in-line gun, 90˚ deflection tube Television system: NTSC-M TV Standard Closed caption system: §15.119/FCC Channel coverage: VHF: 2 ~ 13 UHF: 14 ~ 69 CATV: 2 ~13, A ~ W, W+1 ~ W+84, A-5 ~ A-1, 5A Tuning System: 181 channel frequency synthesized... -
Page 34: Limited Warranty
FUNAI CORP. will repair this SYLVANIA product, free of charge in the USA in the event of defect in materials or workmanship as follows: DURATION: PARTS: FUNAI CORP. will provide parts to replace defective parts without charge for one (1) year from the date of original retail purchase.
