Swann Automobile Alarm Easy Setup Manual

A
Package Contents
Monitor
Packaging
Extension Cables x 4
Power
Security
Supply
Stickers
C
Swann Communications • Toll Free Technical Support: USA - 1-800-627-2799, 1-877-274-3695, Australia - 1300 13 8324 • Email: tech@swann.com.au
Retail Security Kit - Easy Setup Guide
B
Cameras x 4
Manual
2
1
1. Channel Indicator
2. Select Button -
Change channels/cameras
3. Mode Button -
Auto mode switches
between cameras and
Manual displays 1 camera
1
3
4 5 6
Front Control Panel
4. Time Dial -
Length of time between
changing cameras
5. Volume Dial
6. Monitor Power Button
7. Power Indicator
3 5 6
2 4
7
Rear Control Panel
1. Power Supply Input - 4. V-Hold Dial -
Use only provided Controls / adjusts
power supply with this rolling image
product
5. Brightness Control Dial -
2. Camera Extension Brightens or darkens
Cable Inputs image
3. Video and Audio 6. Contrast Control Dial -
Output to VCR Intesifies darker or lighter
images
