Rinnai Infinity EF 24 Operation Manual

Rinnai Infinity EF 24 Operation Manual

Continuous flow water heaters
Hide thumbs Also See for Infinity EF 24:
Table of Contents

Advertisement

Quick Links

See also: Installation Manual
Operation guide
Continuous flow

water heaters

For Rinnai continuous flow water heaters manufactured from 2010 onwards
(serial number 09.12-xxxxxx)

Advertisement

Table of Contents
loading

Related Manuals for Rinnai Infinity EF 24

Summary of Contents for Rinnai Infinity EF 24

  • Page 1: Water Heaters

    Operation guide Continuous flow water heaters For Rinnai continuous flow water heaters manufactured from 2010 onwards (serial number 09.12-xxxxxx)
  • Page 2 Local regulations and municipal building codes Installation, servicing and repair shall be carried out only by authorised personnel. Internal Rinnai continuous flow water heaters must be installed with a Rinnai approved flue system. Not suitable as a spa or swimming pool heater.

  • Page 3: Table Of Contents

    About your water heater Warning about water General safety General information General controller information Universal controller (Compact) Kitchen Deluxe controller Bathroom Deluxe controller Troubleshooting Service record Draining your water heater Installer details Limited warranty Proof of purchase...

  • Page 4: About Your Water Heater

    The installer needs to leave the checklist, and operation guide with you. Important The Rinnai Infinity water heater requires power to prevent damage in freezing conditions. DO NOT disconnect the power if there is a likelihood of freezing without draining the water heater. Instructions for draining the water heater can be found at the back of this guide.

  • Page 5: Warning About Hot Water

    Hot water at 65 °C, a common water temperature in New Zealand, can severely burn a child in less than half a second. At 55 °C, preset temperature for domestic Rinnai continuous flow water heaters, it takes half a minute.

  • Page 6: General Safety

    General safety Do not: Keep flammable materials, spray cans, • Touch the unit fuel containers, pool cover or the flue chemicals, trees, outlet shrubs etc. well clear of the flue outlet. • Insert objects into HOT! the flue outlet 6 | Continuous Flow Water Heater Operation Guide 04-12...

  • Page 7: General Information

    Servicing The Rinnai continuous flow appliance is connected to the water heaters are factory preset Rinnai has a service and spare parts electric power supply. to a temperature limit of 55 °C , network with personnel who are excluding one commercial model, fully trained and equipped to give the Infinity HD200 external.

  • Page 8: General Controller Information

    General controller information To clean your water While hot water controller, use a soft outlets are open the damp cloth and mild set temperature may detergent. be lowered BUT not raised above 43 °C. DO NOT use solvents. Transfer of priority Max.
  • Page 9 Ignition problems shown in the table below. If the water heater fails to ignite, the ‘In Use’ indicator will not Rinnai controllers illuminate. The water heater will not attempt re-ignition until water Universal (Compact), flow is stopped for a few seconds temperature selection only and then restarted.

  • Page 10: Universal Controller (Compact)

    Universal controller (Compact) WATER HEATER 'In Use' INDICATOR Indicates that a water heater is in operation and delivering hot water. DIGITAL MONITOR Indicates the temperautre selected. Error message will flash in event of fault. TRANSFER BUTTON HOT WATER TEMPERATURE Used to transfer control priority CONTROL BUTTONS between the controllers.

  • Page 11: Kitchen Deluxe Controller

    Kitchen Deluxe controller The Kitchen Deluxe controller is not water resistant, avoid direct exposure to water or steam as these conditions may cause damage. WATER TEMPER ATURE SHOWER SAVER / DIGITAL INDICATOR BATH FILL INDICATOR MONITOR Indicates the selected hot water Indicates that the Shower Saver / Bath fill function is operating.

  • Page 12: Bathroom Deluxe Controller

    Bathroom Deluxe controller Avoid getting water directly into the speaker as this may cause damage. WATER TEMPERATURE WATER VOLUME INDICATOR SHOWER SAVER INDICATOR / BATH FILL BUTTON Indicates Shower Saver/Bath Fill volume selected. Indicates the selected hot water Used to selected Shower Saver/Bath Fill temperatures.
  • Page 13 Setting the sound options button once and the ‘Transfer’ amount of water delivered, the button will illuminate. ‘Shower Saver/Bath Fill’ will reset Voice prompts are only available itself back to normal operation when Bathroom Deluxe controllers when turned on again. are installed.
  • Page 14 When the shower saver/bath fill operation finishes Once the shower saver/bath fill operation finishes, the following occurs: Flow from the shower/bath hot water tap stops. 2. ‘Shower Saver/Bath Fill’ button will flash. 3. Kitchen Deluxe Controller (if fitted) ‘Bath’ indicator will flash.

  • Page 15: Troubleshooting

    With controllers or status monitor Your Rinnai continuous flow water heater has a self diagnostic capability. If a fault occurs, an error code will flash on the digital monitor (if you have water controllers) or status monitor (selected models only). This assists with diagnosing the fault and may enable you to overcome a problem without a service call.
  • Page 16 Excessive noise or vibration from the water heater Service call Faults caused by insufficient gas supply, insufficient water supply, gas quality, water quality, installation errors or operation errors are not covered by the Rinnai warranty. 16 | Continuous Flow Water Heater Operation Guide 04-12...

  • Page 17: Service Record

    Service record Model:_____________________________________ Serial Number:______________________________ For domestic use Rinnai recommends servicing every three years. For commercial use annual servicing is recommended. Service 1 Date Service 2 Date Company Company Address Address Phone Phone Contact Contact Comments Comments Service 3 Date...
  • Page 18 Service record - parts replaced 18 | Continuous Flow Water Heater Operation Guide 04-12...

  • Page 19: Draining Your Water Heater

    These instructions are intended building. Refer to picture on as a guide only. Rinnai will not next page. accept liability for issues arising Check the water heater and pipes from the use of this information.
  • Page 20 Line drawing showing the different connections Photos highlighting connections that need to underneath a continuous flow unit be drained Hot water Hot water Water outlet drain plug filter Water drain plug* Condensate Cold water trap drain plug* inlet * Condensate trap and water drain plugs—EF models only.

  • Page 21: Installer Details

    Installer details Company name: Installer name: Address: Phone: Mobile: Certificate of compliance number for installation: Signed: Date: Installer, please remember to complete and leave the commissioning checklist with the owner. Continuous Flow Water Heater Operation Guide 04-12 | 21...

  • Page 22: Limited Warranty

    Rinnai brings you peace of mind with a: Rinnai warranty Rinnai offers you real peace of mind with comprehensive warranty plans covering parts and labour. For full details on Rinnai product warranties go to www.rinnai.co.nz/warranty.html. This warranty is applicable to all Rinnai continuous flow water heaters installed from 2010. All terms of the warranty are effective from the date of installation.

  • Page 23: Proof Of Purchase

    Proof of purchase RECORD YOUR DETAILS ATTACH YOUR PROOF OF OF PURCHASE BELOW: PURCHASE HERE: Retailer: Retailer address: Date of purchase: Product details: Please keep these details in a safe place for future reference. Continuous Flow Water Heater Operation Guide 04-12 | 23...
  • Page 24 Experience our innovation Rinnai.co.nz 0800 746 624 U278-2778(01) http://www.youtube.com/rinnainz 060 00012 31314 7...
