Summary of Contents for NETGEAR ReadyNAS RR4360X
- Page 1 Installation and Quick Start ReadyNAS RR4360S RR4360X...
-
Page 2: Table Of Contents
Contents Package Contents ....................... 3 Prepare the Installation Site ..................3 Install the System in a Rack ..................4 Precautions ......................4 Rack Installation ..................... 5 Install Cable Management ................... 6 Install Disks ........................7 Basic Setup ........................9 Reformat Disks ......................10 Additional Information .....................11... -
Page 3: Package Contents
Package Contents Important: Read all safety warnings in the hardware manual for your system before connecting the system to the power supply. Your package contains the following items: • RR4360 chassis including 60 disk trays • Rack mount rail kit •... -
Page 4: Install The System In A Rack
Install the System in a Rack Use the rack-mount hardware included with your ReadyNAS or your expansion disk array to install it in a rack. Note that the left and right rails are not identical. The left rail is marked with a sticker bearing the letter L, and the right rail is marked with a sticker bearing the letter R. -
Page 5: Rack Installation
Rack Installation Read these instructions in their entirety before you begin. Note: The rail ends require square holes in the rack. You cannot install the supplied rails using threaded rail holes. ¾ To install the system into a rack: 1. Using the left rail, pull the inner rail out of the outer rail until it is fully extended. The middle and outer rail might lock in the extended position. -
Page 6: Install Cable Management
Install Cable Management The cable management hardware folds when the unit is pushed toward the back of the rack, and straightens as the unit moves forward. If you attach the cables to the cable management hardware, the cables also fold or straighten as the unit is moved in the rack, which eliminates the tugging by the cables on the connectors on the unit. -
Page 7: Install Disks
If desired, you can later change the RAID settings manually. For information about RAID settings, including changing RAID settings, see the ReadyNAS OS 6 Software User Manual. A link to this manual is available at www.netgear.com/support/product/ReadyNAS_OS_6 or through a link in the product’s user interface. - Page 8 3. Insert your drives into the tool-less disk brackets supplied with the RR4360 server to hold your disks in the server. The figure shows the bracket tabs that align with the mounting holes in your drive. Note: The following figure illustrates how disk numbers are assigned based on their position in the chassis.
-
Page 9: Basic Setup
6. Wait for the Power LED to turn solid blue. 7. Visit www.netgear.com/raidar to download and install the NETGEAR RAIDar utility. Download RAIDar to a computer connected to the Internet and transfer the downloaded file to the computer on the same LAN as your ReadyNAS system. -
Page 10: Reformat Disks
10. 2. Install the previously formatted disks. For a list of supported disks, see the Hardware Compatibility List at kb.netgear.com/app/answers/detail/a_id/20641. For information about installing disks, see the hardware manual for your system. 3. Press and hold the Reset button. -
Page 11: Additional Information
The system shuts down gracefully. For more information about setting up, configuring, and using your system, see the software and hardware manuals for your system. Links to these manuals are available at www.netgear.com/support/product/ReadyNAS_OS_6 or through a link in the product’s user interface. - Page 12 We recommend that you use only official NETGEAR support resources. Trademarks © NETGEAR, Inc., NETGEAR and the NETGEAR Logo are trademarks of NETGEAR, Inc. Any non-NETGEAR trademarks are used for reference purposes only. Compliance For the current EU Declaration of Conformity, visit: http://kb.netgear.com/app/answers/detail/a_id/11621.
