Operation and Maintenance Instructions
ZH Series Large Bore Lathes
Models GH-2680ZH; GH-26120ZH
Model GH-2680ZH shown
For ZH-Series Lathes Parts List and Electrical Diagrams, see document M-321860-1
WALTER MEIER (Manufacturing) Inc.
427 New Sanford Road
LaVergne, Tennessee 37086
Part No. M-321860
Ph.: 800-274-6848
Revision A 11/2011
www.jettools.com
Copyright © 2011 Walter Meier (Manufacturing) Inc.

Advertisement

Table of Contents
loading

Related Manuals for Jet ZH Series

Summary of Contents for Jet ZH Series

  • Page 1 This .pdf document is bookmarked Operation and Maintenance Instructions ZH Series Large Bore Lathes Models GH-2680ZH; GH-26120ZH Model GH-2680ZH shown For ZH-Series Lathes Parts List and Electrical Diagrams, see document M-321860-1 WALTER MEIER (Manufacturing) Inc. 427 New Sanford Road LaVergne, Tennessee 37086 Part No.

  • Page 2: Warranty And Service

    Walter Meier is consistently adding new products to the line. For complete, up-to-date product information, check with your local Walter Meier distributor, or visit waltermeier.com. WARRANTY JET products carry a limited warranty which varies in duration based upon the product (MW = Metalworking, WW = Woodworking). WHAT IS COVERED? This warranty covers any defects in workmanship or materials subject to the exceptions stated below.

  • Page 3: Table Of Contents

    13.15 Shear Pin Replacement ......................28 13.16 Steady Rest Adjustment ......................28 13.17 Follow Rest Adjustment ......................28 14.0 Troubleshooting the ZH Series Lathes ..................29 15.0 Lubrication Schedule and General Maintenance................30 16.0 Reference Tables ......................... 31 16.1 Inch Lead And Feed ........................31 16.2 Special Inch Lead And Feed ......................

  • Page 4: Safety Warnings

    3.0 Safety warnings Read and understand the entire owner’s manual before attempting assembly or operation. Read and understand the warnings posted on the machine and in this manual. Failure to comply with all of these warnings may cause serious injury. Replace the warning labels if they become obscured or removed.
  • Page 5 21. Give your work undivided attention. Looking around, carrying on a conversation and “horse-play” are careless acts that can result in serious injury. 22. Maintain a balanced stance at all times so that you do not fall or lean against moving parts. Do not overreach or use excessive force to perform any machine operation.

  • Page 6: Specifications

    4.0 Specifications Model Number ................GH-2680ZH ........GH-26120ZH Stock Number ..................321860 ..........321890 General Capacities: Maximum Swing over Bed ............. 26” (660 mm) ........26” (660 mm) Maximum Swing over Cross Slide ........16-1/2” (420 mm) ......... 16-1/2” (420 mm) Maximum Swing Through Gap ..........
  • Page 7 GH-2680ZH GH-26120ZH Gearbox: Number of Longitudinal Feeds ..............65 ............65 Range of Longitudinal Feeds .. 0.0023 – 0.0937 in./rev. (0.063-2.52 mm/rev) ..0.0023 – 0.0937 (0.063-2.52 mm) Number of Cross Feeds ................63 ............63 Range of Cross Feeds .... 0.0010 – 0.0404 in/rev. (0.027-1.07 mm/rev) ..0.0010 – 0.404 (0.027-1.07 mm) Number of Inch Threads .................

  • Page 8: Dimensions And Mounting Hole Centers

    5.0 Dimensions and mounting hole centers Figure 1 80 inch 120 inch Lathe Size (GH-2680ZH) (GH-26120ZH) 2560mm (100.8 in.) 3565mm (140.4 in.) 3495mm (137.60 in. ) 4500mm (177.2 in.) 1721.5mm (67.8 in) Table 1...

  • Page 9: General Description And Nomenclature

    6.0 General description and nomenclature Figure 2 – General Description (GH-2680ZH shown) The ZH series lathe operates on a centralized explanation of controls. The electrical box is gear system. The motor power is transferred mounted to the rear of the headstock.
  • Page 10 Steady Rest Cross Slide (H). The cross-slide is mounted on the saddle and used for cross feed The ZH series lathes are provided with small operations. It moves on a dovetailed slide and large steady rests (T). A steady rest serves which can be adjusted for play by means of as a support for shafts on the free tailstock end.

  • Page 11: Unpacking

    Round Nut Spanner, 170-210 mm – E Change Gears – 63T, 69T, 78T, 90T – F NOTE: Optional accessories are available for JET Lathes, such as Taper Attachment, Collet Closer and Digital Read Out. Contact your dealer or Walter Meier (Manufacturing) Inc., for more information.

  • Page 12: Installation

    8.1 Leveling the lathe 8.0 Installation It is imperative that the lathe be on a level plane; that is, where headstock and tailstock center 1. Finish removing all crate material from points remain aligned throughout the tailstock around lathe. travel, with the bed ways absent of twist and 2.

  • Page 13: Chuck Preparation

    transit. Clean all parts thoroughly with 8.3 Chuck Preparation solvent. Also clean spindle camlocks. Read and understand all 4. Cover all chuck jaws and the scroll inside directions for chuck preparation. Failure to the chuck with #2 lithium tube grease. Cover comply may cause serious injury and/or the spindle, camlocks, and chuck body with damage to the lathe.

  • Page 14: Maintenance/Lubrication

    Failure to comply may cause serious damage to the lathe. The ZH series lathe is shipped with oil in the reservoirs. Coolant is not included. Use clean lubricants and check levels often, including before each working shift.
  • Page 15 One-shot Lube System: Pull knob (I, Figure 12) and hold for several seconds to allow oil to fill the pump from the apron reservoir. Then release the knob which will push the oil through various oil lines to lubricate the ways below the saddle.

  • Page 16: Coolant Preparation

    9.1 Coolant Preparation 13. Leadscrew, Feed Rod, and Direction Control Axle – Slide the cover on the right Follow local regulations side bracket (Figure 15) to expose the oil and/or coolant manufacturer’s recommend- port and fill with SAE 20W oil daily. The oil is dations for use, care and disposal.

  • Page 17: Conversion To 460 Volt Operation

    IMPORTANT: The lathe must be wired properly 1. Main Motor: Open lower panel at rear of and phased correctly. The spindle must rotate lathe beneath the gearbox, and change the counterclockwise (as viewed from the tailstock wires in the junction box on the main motor, end) while the feed rod must rotate clockwise according to the diagram on the junction box (as viewed from the tailstock end).

  • Page 18: Basic Controls

    11.0 Basic Controls Figure 21 – Coolant pump access (GH-26120ZH) 3) Tilt the plate until you can reach the coolant pump junction box through the top opening in the bed. Follow the diagram on the coolant pump to change the leads. 4) Properly orient the pump, and secure Figure 23 –...
  • Page 19 3. Feed Direction Lever (F, Figure 23): 5. Carriage Lock (J, Figure 25): Located on Located on front of headstock. Moving the top right of carriage. Turn clockwise to lock, lever changes direction of feed. Center counterclockwise to unlock. position is neutral. Carriage lock must be move feed...
  • Page 20 feed direction lever. Rapid 18. Tailstock Quill Traverse Handwheel (V, longitudinal movement disengages Figure 27): Rotate clockwise to advance the carriage handwheel. However, the cross quill and counterclockwise to retract it. Fully slide handwheel should be disengaged retract it to eject a center or drill chuck. (pull it out) before using rapid feed.

  • Page 21: Operation

    • Avoid long workpiece extensions, as parts 12.0 Operation may bend or fly off (see figure 30). Use rests or the tailstock for support. The operator should consult shop manuals such as “Machinery’s Handbook” for cutting speeds and feeds appropriate to specific workpieces. Correct feed depends upon the material to be cut, cutting operation, tool type, chucking rigidity, depth of cut, and desired surface quality.

  • Page 22: Spindle Speed

    12.4 Thread Cutting 12.2 Spindle Speed Threading is performed in multiple passes, with Twelve speeds are available by placing the first an initial cutting depth of about 0.2 mm, and speed lever (E , Figure 32) in one of four decreasing depth in succeeding cuts.

  • Page 23: Adjustments

    NOTE: When a special thread must be cut that one turn, and tighten front gib screw a quarter is not found on the chart, move thread change turn. Rotate the handwheel to check the play. Repeat as needed until slide moves freely control lever (G , Figure 32) to position, and...

  • Page 24: Tailstock Adjustments

    13.3 Tailstock Adjustments 13.4 Gap Section The tailstock can be offset to cut shallow tapers 1. To remove the gap section (A, Figure 41), up to 5° angle. See Figure 39. remove four socket head bolts (B) and two socket bolts at the ends of the rails (C). 1.

  • Page 25: Brake Strap

    3. Loosen upper hex nut (A, Figure 42). Place scrap piece of wood under motor to act as lever. Lift motor up and block temporarily. 4. Remove belts. Install new belts onto pulleys. 5. Lift up on motor and remove temporary blocking.

  • Page 26: Aligning Tailstock To Headstock

    13.8 Aligning Tailstock to Headstock Headstock and Tailstock have been aligned at the factory and should not require attention. If future adjustment should ever be needed, proceed as follows. (Make sure that twist in the lathe bed is not contributing to the problem – refer to section 8.1, Leveling the Lathe.) 1.

  • Page 27: Apron Feed Clutch

    positioning pin. The tool post will rise slightly. 13.12 Apron Feed Clutch This raised distance should remain the same after repeated tool changes. The feed transmission begins with the feed rod to the apron, through feed clutch to worm, To clamp the tool post, turn the lever clockwise through the gear drives, to longitudinal or cross until it tightens.

  • Page 28: Shear Pin Replacement

    cross slide movement, the nut needs adjusting 2. Loosen the knurled handle (B) at the side (Refer to Figure 51). until it can be pivoted out of the slot. 1. Remove dust cover (3). 3. Loosen the three lock knobs (C), and back off the fingers (D) using the knurled handles.

  • Page 29: Troubleshooting The Zh Series Lathes

    14.0 Troubleshooting the ZH Series Lathes Table 2 Trouble Probable Cause Remedy Verify incoming power, main leads, main No electrical power, or wiring incorrect. switch is on. Emergency stop switch is pressed. Rotate switch clockwise to release. End gear cover open, limit switch Close cover.

  • Page 30: Lubrication Schedule And General Maintenance

    Regularly scheduled maintenance is crucial to ensure a long service life for your machine. The schedule below shows general cleaning, lubrication points and coolant replacement information for the ZH Series Lathes. Push stop button and power off before lubricating. Follow local regulations for disposal of used coolant/lubricants. Minimize direct skin contact with lubricants and coolants, and wear eye protection when pouring coolant in case of splash.

  • Page 31: Reference Tables

    16.0 Reference Tables 16.1 Inch Lead And Feed Table 4 = metric threads = inch threads m = modular threads DP = diametral threads 16.2 Special Inch Lead And Feed Table 5...

  • Page 32: Speed Selection Lever Positions

    16.3 Speed Selection Lever Positions Table 6 Lever Position Spindle Speeds (RPM) white white blue blue yellow yellow 1200 1600 17.0 Electrical – 230 volt to 460 volt Conversion Figure 53...

  • Page 33: Change Gear Diagram

    18.0 Change Gear Diagram Figure 54...
  • Page 34 NOTES...
  • Page 35 NOTES...
  • Page 36 WALTER MEIER (Manufacturing) Inc. 427 New Sanford Road LaVergne, Tennessee 37086 Phone: 800-274-6848 www.waltermeier.com...
  • Page 37 This .pdf document is bookmarked Parts List and Electrical Diagrams ZH Series Large Bore Lathes Models GH-2680ZH; GH-26120ZH Model GH-2680ZH shown For ZH-Series Lathes Operation and Maintenance Instructions, see document M-321860 WALTER MEIER (Manufacturing) Inc. 427 New Sanford Road LaVergne, Tennessee 37086 Part No.
  • Page 38 Walter Meier is consistently adding new products to the line. For complete, up-to-date product information, check with your local Walter Meier distributor, or visit waltermeier.com. WARRANTY JET products carry a limited warranty which varies in duration based upon the product (MW = Metalworking, WW = Woodworking). WHAT IS COVERED? This warranty covers any defects in workmanship or materials subject to the exceptions stated below.
  • Page 39 2.0 Table of Contents 1.0 Warranty and Service ............................. 2 2.0 Table of Contents ............................3 3.0 Bed Assembly I – Exploded View ....................... 4 3.1 Bed Assembly I – Parts List ........................5 4.0 Bed Assembly II – Exploded View ......................6 4.1 Bed Assembly II –...

  • Page 40: Bed Assembly I - Exploded View

    3.0 Bed Assembly I – Exploded View...

  • Page 41: Bed Assembly I - Parts List

    3.1 Bed Assembly I – Parts List Index No. Part No. Description Size 1 ....C6266C12701C ..... Splash Guard (80” ZH only) ...... 80” ......... 1 ....C6266C12701D ..... Traveling Splash Guard (120” ZH only) 24” ........1 2 ....TS-1503011 ....Hex Socket Cap Screw ......M6x8 ......8 3 ....

  • Page 42: Bed Assembly Ii - Exploded View

    4.0 Bed Assembly II – Exploded View...

  • Page 43: Bed Assembly Ii - Parts List

    28 ..... TS-1540041 ....Hex Nut ............ M6 ......... 1 29 ..... TS-1482041 ....Hex Cap Screw ........M6x20 ......1 30 ..... JETLOGO-1 ....JET Nameplate (not shown) ............1 31 ..... STRIPE-1-3/4 ....Stripe (not shown) ..............per ft.

  • Page 44: Headstock Assembly I - Exploded View

    5.0 Headstock Assembly I – Exploded View...

  • Page 45: Headstock Assembly I - Parts List

    5.1 Headstock Assembly I – Parts List Index No. Part No. Description Size 1 ....C6266C02502 ....Headstock Cover ................1 2 ....C6266C02501 ....Rubber Mat ..................1 3 ....C6140W02835 ....Flat Head Countersunk Screw ............1 4 ....
  • Page 46 Index No. Part No. Description Size 55 ..... GB819-M5x10 ....Cross Recessed Hd Countersunk Screw M5x10 ......2 56 ..... GB819-M6x14 ....Cross Recessed Hd Countersunk Screw M6x14 ......2 57 ..... GB818-M6x8 ....Cross Recessed Pan Head Screw .... M6x8 ......2 58 .....

  • Page 47: Headstock Assembly Ii - Exploded View

    6.0 Headstock Assembly II – Exploded View...

  • Page 48: Headstock Assembly Ii - Parts List

    6.1 Headstock Assembly II – Parts List Index No. Part No. Description Size 1 ....C6266CHA01 ....Chain ............12.7 x 58 ....... 1 2 ....GB894.1-16 ....Circlip for Shaft......... 16 mm ......1 3 ....C6140W02808 ....Chain Wheel .................. 2 4 ....
  • Page 49 Index No. Part No. Description Size 57 ..... TS-1522021 ....Socket Set Screw ........M5x8 ......1 58 ..... C6266C02773 ....Screw ..................... 1 59 ..... TS-2360121 ....Flat Washer..........12 mm ......1 60 ..... C6140W02826 ....Tightening Wheel ................1 61 .....

  • Page 50: Headstock Assembly Iii - Exploded View

    7.0 Headstock Assembly III – Exploded View...

  • Page 51: Headstock Assembly Iii - Parts List

    7.1 Headstock Assembly III – Parts List Index No. Part No. Description Size 1 ....C6266C08501 ....Back Cover ..................1 2 ....TS-1502031 ....Hex Socket Cap Screw ......M5x12 ......3 3 ....C6266C08706 ....Upper Hinge ................... 2 4 ....

  • Page 52: Headstock Assembly Iv - Exploded View

    8.0 Headstock Assembly IV – Exploded View...

  • Page 53: Headstock Assembly Iv - Parts List

    8.1 Headstock Assembly IV – Parts List Index No. Part No. Description Size 1 ....C6140W02752-1/2 ..Round Nut ..................1 2 ....TS-1523011 ....Hex Socket Set Screw ......M6x6 ......1 3 ....C6140W02752-2/2 ..Clamping Piece ................1 4 ....
  • Page 54 Index No. Part No. Description Size 59 ..... GB893.1-47 ....Circlip ............47 mm ......2 60 ..... BB-6005......Ball Bearing..........6005 ......2 61 ..... C6266C02104 ....Sleeve .................... 1 62 ..... C6266C02726 ....Gear....................1 63 ..... GB1096-8x12 ....Flat Key............ 8x12 mm ....... 1 64 .....

  • Page 55: Headstock Assembly V - Exploded View

    9.0 Headstock Assembly V – Exploded View...

  • Page 56: Headstock Assembly V - Parts List

    9.1 Headstock Assembly V – Parts List Index No. Part No. Description Size 1 ....TS-1505031 ....Hex Socket Cap Screw ......M10x25 ......1 2 ....C6266C02108 ....Back Flange Cover ................. 1 3 ....GB119-6x8 ....Pin ............6x8 mm ......1 4 ....

  • Page 57: Gear Assembly - Exploded View

    10.0 Gear Assembly – Exploded View 10.1 Gear Assembly – Parts List Index No. Part No. Description Size 1 ....C6266C08708 ....Splash Guard ................. 1 2 ....GB818-M6x8 ....Screw ............M6x8 ......2 3 ....C6266C08702 ....Gear (in.) ..........2m82T ......1 4 ....

  • Page 58: Gear Box Assembly I - Exploded View

    11.0 Gear Box Assembly I – Exploded View 11.1 Gear Box Assembly I – Parts List Index No. Part No. Description Size 1 ....C6140W05504 ....Upper Cover ................... 1 2 ....TS-1534032 ....Cross Recessed Pan Head Screw .... M6x10 ......14 3 ....

  • Page 59: Gear Box Assembly Ii - Exploded View

    12.0 Gear Box Assembly II – Exploded View...

  • Page 60: Gear Box Assembly Ii - Parts List

    12.1 Gear Box Assembly II – Parts List Index No. Part No. Description Size 1 ....C6140W05109 ....Sliding Block .................. 7 2 ....C6140W05A701..... Shaft ....................2 3 ....C6140W05A105..... Ratio Change Rocker ..............1 4 ....C6140W05709 ....Rocker Shaft .................. 2 5 ....
  • Page 61 Index No. Part No. Description Size 58 ..... C6140W05715 ....Cover ..................... 1 59 ..... C6140W05A724..... Positioning Disc ................1 60 ..... C6140W05A113..... Lever Support ................1 61 ..... C6140W05308 ....Handle Panel ................. 1 62 ..... C6140W05A307..... Handle Panel ................. 1 63 .....

  • Page 62: Gear Box Assembly Iii - Exploded View

    13.0 Gear Box Assembly III – Exploded View...

  • Page 63: Gear Box Assembly Iii - Parts List

    13.1 Gear Box Assembly III – Parts List Index No. Part No. Description Size 1 ....GB5783-M12x20 .... Hexagon Head Bolt ........M12x20 ......1 2 ....GB851-A12x40 ....Split Washer ..........A12x40 ......1 3 ....C6140W05A730..... Shaft (I) ..................1 4 ....
  • Page 64 Index No. Part No. Description Size 60 ..... G51-1-B-25x40x7 ... Oil Seal ............ B-25x40x7 mm ....1 61 ..... C6140W05120 ....Shaft Connector ................1 62 ..... C6140W05126 ....Bearing Cover ................1 63 ..... BB-6304......Ball Bearing..........20x52x15....... 1 64 .....

  • Page 65: Saddle And Cross Slide Assembly - Exploded View

    14.0 Saddle and Cross Slide Assembly – Exploded View...

  • Page 66: Saddle And Cross Slide Assembly - Parts List

    14.1 Saddle and Cross Slide Assembly – Parts List Index No. Part No. Description Size 1 ....C6266C04101A ..... Saddle ................... 1 2 ....GB73-M10x16 ....Slotted Set Screw ........M10x16 ......1 3 ....C614W04503 ....Wipe Plate..................1 4 ....
  • Page 67 Index No. Part No. Description Size 55 ..... C6266C04304YA ... Nut (inch threads) ................1 56 ..... GB1096-5x40 ....Flat Key............ 5x40 mm ....... 1 57 ..... C6266C04701A ..... Lead Screw (inch threads) .............. 1 58 ..... 51103 ......Thrust Bearing.......... 17x30x9 ......2 59 .....

  • Page 68: Brake Assembly - Exploded View

    15.0 Brake Assembly – Exploded View...

  • Page 69: Brake Assembly - Parts List

    15.1 Brake Assembly – Parts List Index No. Part No. Description Size 1 ....C6266C22705 ....Brake Belt ..................1 2 ....GB70-M6x14 ....Hex Socket Cap Screw ......M6x14 ......4 5 ....C6266C22704 ....Bolt ....................1 6 ....

  • Page 70: Tool Post And Compound Rest Assembly - Exploded View

    16.0 Tool Post and Compound Rest Assembly – Exploded View...

  • Page 71: Tool Post And Compound Rest Assembly - Parts List

    16.1 Tool Post and Compound Rest Assembly – Parts List Index No. Part No. Description Size 1 ....C6266C04104 ....Revolving Plate ................1 2 ....TS-1540081 ....Hex Nut ............ M12 ....... 4 3 ....C6266C04706 ....Compound Screw ................4 4 ....

  • Page 72: Apron Assembly I - Exploded View

    17.0 Apron Assembly I – Exploded View...

  • Page 73: Apron Assembly I - Parts List

    17.1 Apron Assembly I – Parts List Index No. Part No. Description Size 1 ....C6266C06101 ....Apron Casting ................1 2 ....TS-1524051 ....Socket Set Screw ........M8x20 ......1 3 ....C6266C06506 ....Gasket ................... 3 4 ....
  • Page 74 Index No. Part No. Description Size 63 ..... C6266C06715 ....Oil Purifier ..................1 64 ..... C6266C06107 ....Pump ..................... 1 65 ..... GB65-M6x12 ....Slotted Socket Cap Screw ......M6x12 ......3 66 ..... G51-2A-20x2.4 ....O-Ring ............. 20x2.4 mm ....1 67 .....

  • Page 75: Apron Assembly Ii - Exploded View

    18.0 Apron Assembly II – Exploded View...

  • Page 76: Apron Assembly Ii - Parts List

    18.1 Apron Assembly II – Parts List Index No. Part No. Description Size 1 ....C6140W06738 ....Cap ....................1 2 ....GB6172-M12 ....Hex Flat Nut ..........M12 ....... 1 3 ....GB78-M12x60 ....Hex Set Screw ......... M12x60 ......1 4 ....
  • Page 77 Index No. Part No. Description Size 57 ..... C6140W06717 ....Shaft ....................1 58 ..... C6140W06104 ....Interlocking Block ................1 59 ..... GB117-5x30....Taper Pin ..........5x30 mm ....... 1 60 ..... C6140W06718 ....Shaft ....................1 61 .....

  • Page 78: Apron Assembly Iii - Exploded View

    19.0 Apron Assembly III – Exploded View...

  • Page 79: Apron Assembly Iii - Parts List

    19.1 Apron Assembly III – Parts List Index No. Part No. Description Size 1 ....C6140W06751 ....Gear....................1 2 ....GB71-M6x8....Slotted Set Screw ........M6x8 ......2 3 ....C6140W06309 ....Sleeve .................... 1 4 ....C6140W06752 ....Gear....................1 5 ....

  • Page 80: Apron Assembly Iv - Exploded View

    20.0 Apron Assembly IV – Exploded View...

  • Page 81: Apron Assembly Iv - Parts List

    20.1 Apron Assembly IV – Parts List Index No. Part No. Description Size 1 ....GB1155-10 ....Oil Cup ............. 10 mm ......1 2 ....C6266C11703 ....Handle ................... 1 3 ....C6266C11305 ....Label ....................1 4 ....

  • Page 82: Tailstock Assembly I - Exploded View

    21.0 Tailstock Assembly I – Exploded View...

  • Page 83: Tailstock Assembly I - Parts List

    21.1 Tailstock Assembly I – Parts List Index No. Part No. Description Size 1 ....1440R03105 ....Nut ....................1 2 ....TS-1504041 ....Hex Socket Cap Screw ......M8x20 ......7 3 ....1860R03710A ....Lead Screw ..................1 4 ....

  • Page 84: Tailstock Assembly Ii - Exploded View

    22.0 Tailstock Assembly II – Exploded View...

  • Page 85: Tailstock Assembly Ii - Parts List

    22.1 Tailstock Assembly II – Parts List Index No. Part No. Description Size 1 ....C6140W03110 ....Nut ....................1 2 ....GB6171-M20x1.5 ... Hex Nut ............ M20x1.5 ......1 3 ....TS-1550111 ....Flat Washer..........20 mm ......1 4 ....

  • Page 86: Steady Rest Assembly (Small And Large) - Exploded View

    23.0 Steady Rest Assembly (Small and Large) – Exploded View...

  • Page 87: Steady Rest Assembly (Small) - Parts List

    23.1 Steady Rest Assembly (Small) – Parts List Index No. Part No. Description Size 1 ....GB4141.29-12 ....A-Type Knurled Handle ......12 mm ......3 2 ....GB117-4x25....Pin ............4x25 mm ....... 3 3 ....C6140W10702 ....Screw ..................... 3 4 ....

  • Page 88: Follow Rest Assembly - Exploded View

    24.0 Follow Rest Assembly – Exploded View 24.1 Follow Rest Assembly – Parts List Index No. Part No. Description Size 1 ....GB4141.29-12 ....A-Type Knurled Handle ......12 mm ......2 2 ....GB117-4x25....Pin ............4x25 mm ....... 2 3 ....

  • Page 89: Coolant And Work Light Assembly - Exploded View

    25.0 Coolant and Work Light Assembly – Exploded View 25.1 Coolant and Work Light Assembly – Parts List Index No. Part No. Description Size 1 ....RT-001C ......Rubber Tube ..........ID 1/2" x 2280 ....1 2 ....TS-2205201 ....Hex Cap Screw ........M5x20 ......4 3 ....

  • Page 90: Travel Stop Assembly - Exploded View

    26.0 Travel Stop Assembly – Exploded View 26.1 Travel Stop Assembly – Parts List Index No. Part No. Description Size 1 ....C6266C26A102 ..... Left Support ................... 1 2 ....GB118-10x40 ....Pin ............10x40 mm ..... 4 3 ....TS-1504081 ....Hex Socket Cap Screw ......M8x40 ......4 4 ....

  • Page 91: Small Carriage Stop - Exploded View

    27.0 Small Carriage Stop – Exploded View 27.1 Small Carriage Stop – Parts List Index No. Part No. Description Size 1 ....TS-1492031 ....Hex Cap Screw ........M12x35 ......2 2 ....C6266C01112 ....Clamping Plate ................1 3 ....

  • Page 92: Chuck Guard Assembly - Exploded View

    28.0 Chuck Guard Assembly – Exploded View 28.1 Chuck Guard Assembly – Parts List Index No. Part No. Description Size 1 ....GH1640ZX19701 ... Protection Guard ................1 2 ....ZX-19501E ....Protection Guard Visual Glass ............1 3 ....

  • Page 93: Toolbox, Accessories, And Attachments

    25 ..... ZX-OP-15 ...... Cross Point Screw Driver * ............. 1 26 ........... Open End Wrench Set * ......17-19, 19-22 mm ... 1 27 ..... ZX-OP-10 ...... Touchup Paint Can (JET White) * ........... 1 28 ..... ZX-OP-09 ...... Oil Gun * ..................1 29 .....

  • Page 94: Electrical Components

    30.0 Electrical Components...

  • Page 95: Electrical Diagram

    30.1 Electrical Diagram...

  • Page 96: Electrical Components - Parts List

    30.2 Electrical Components – Parts List Index No. Part No. Description Model Size M1....* ....Main Motor ......Y132M-4TH/B3 ..10HP, 3PH, 230/460V ..1 M2 ....* ....Coolant Pump ....AB-12TH ....1/8HP, 3PH, 230/460V ..1 M3 ....
