- Page 1 Si241320 REMOVAL PROCEDURE S E R V I C E M A N U A L 1.5 HP Class Outdoor Unit Non-Inverter Pair Type...
-
Page 2: Outdoor Unit
Service Manual Removal Procedure Outdoor Unit Applicable Models Cooling Only R13NUV2S... - Page 3 Si241320 Table of Contents 1. Procedure to Remove Panels and Fan Motor.........2 2. Procedure to Remove El. Compo. Box ...........8 3. Procedure to Remove Sound Blanket.............9 4. Procedure to Remove Compressor............10 Removal Procedure...
-
Page 4: Procedure To Remove Panels And Fan Motor
Procedure to Remove Panels and Fan Motor Si241320 1. Procedure to Remove Panels and Fan Motor Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Procedure Points Step 1. Features Handle Take care not to cut your finger by the fins of the heat... - Page 5 Si241320 Procedure to Remove Panels and Fan Motor Step Procedure Points 2. Remove the panels. Top panel Loosen the 3 screws (front, right, left) and lift the top panel. Disconnect the The fan motor is united with connector for fan motor. the front panel.
- Page 6 Procedure to Remove Panels and Fan Motor Si241320 Step Procedure Points 3. Remove the fan motor. The screw has reverse winding. Unscrew the washer- fitted nut (M10) of the propeller fan with a spanner. Propeller fan Remove the propeller Align mark of the fan.
- Page 7 Si241320 Procedure to Remove Panels and Fan Motor Step Procedure Points Loosen the fixing hooks Put the lead wire through the and release the lead back of the motor when wire. reassembling. (so as not to be entangled with the propeller fan) Lead wire Propeller fan...
- Page 8 Procedure to Remove Panels and Fan Motor Si241320 Step Procedure Points Loosen the 2 screws to remove the fan motor fixing frame. Fan motor fixing frame 4. Remove the right side panel. Loosen the 2 screws on the rear side. Loosen the 4 screws on the right side.
- Page 9 Si241320 Procedure to Remove Panels and Fan Motor Step Procedure Points Loosen the screw and lift the connection port to remove. When reassembling, make sure to fit the hook. Removal Procedure...
-
Page 10: Procedure To Remove El. Compo. Box
Procedure to Remove El. Compo. Box Si241320 2. Procedure to Remove El. Compo. Box Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Procedure Points Step Remove the top panel. Disconnect the connector for fan motor. -
Page 11: Procedure To Remove Sound Blanket
Si241320 Procedure to Remove Sound Blanket 3. Procedure to Remove Sound Blanket Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Procedure Points Step Remove the outer panels. Remove the el. compo. box. -
Page 12: Procedure To Remove Compressor
Procedure to Remove Compressor Si241320 4. Procedure to Remove Compressor Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Procedure Points Step 1. Remove the compressor. Unscrew the nut of the compressor. - Page 13 Si241320 Procedure to Remove Compressor Step Procedure Points Lift the compressor up and remove it. Removal Procedure...
- Page 14 Revision History Month / Year Version Revised contents 01 / 2013 Si241320 First edition...
- Page 15 Improper installation can result in water or refrigerant leakage, electrical shock, fire or explosion. Use only those parts and accessories supplied or specified by Daikin. Ask a qualified installer or contractor to install those parts and accessories. Use of unauthorised parts and accessories or improper installation of parts and accessories can result in water or refrigerant leakage, electrical shock, fire or explosion.
