Planning Information
Model W362418 (R) Pro Wall Hood
Model W362418
Model W362418R
– Rail Option
Wolf Pro 24" (610) deep wall hoods
are available in the classic stainless steel
finish. Rail option hoods (R) come with a
classic stainless steel decorative rail and
stand-offs. Optional platinum or brass
rails match dual fuel range bezels. Pro
wall hoods are sold as a shell only;
internal, in-line and remote blower
options are available
Dimensions in parentheses are in
millimeters unless otherwise specified.
9/06
Hand finished
craftsmanship
Backdraft damper
Stainless steel
baffle filters
Welded seams
and hemmed edges
Halogen lighting
Model W362418R shown with standard classic stainless steel
decorative rail, platinum or brass rail available as a sales accessory
W
olf Pro wall hoods provide the ultimate in
ventilation. With standard elements like heat sentry
and dual setting halogen lighting, Wolf elevates the
need for ventilation to an enjoyable perk.
Pro 24" (610) deep wall hoods are available in the
classic stainless steel finish. You also have the option
of a decorative rail. While a classic stainless steel rail
is standard on (R) models, platinum or brass rails are
available to match the bezels of our dual fuel ranges
and sealed burner rangetops.
Pro wall ventilation hoods are recommended for use
with all Wolf cooking appliances. For optimal perform-
ance, a Pro 27" (686) deep wall hood is recommended
for use with ranges and rangetops that contain a
charbroiler or griddle.
Classic stainless
steel finish
Decorative rail
(optional)
Recessed easy
access controls
Infinite speed
blower control
1
Advertisement
Related Manuals for Wolf W362418(R)
Summary of Contents for Wolf W362418(R)
- Page 1 Planning Information Model W362418 (R) Pro Wall Hood Backdraft damper Model W362418 Stainless steel baffle filters Model W362418R – Rail Option Welded seams and hemmed edges Wolf Pro 24" (610) deep wall hoods are available in the classic stainless steel finish.
- Page 2 Planning Information Model W362418 (R) Pro Wall Hood F E A T U R E S 36" (914) wide by 24" (610) deep wall ventilation hood with classic stainless steel finish Rail option hoods (R) come with a classic stainless steel decorative rail and stand-offs – optional platinum or brass rail to match dual fuel range and sealed burner rangetop bezels is available as a sales accessory...
- Page 3 Planning Information Model W362418 (R) Pro Wall Hood B L O W E R O P T I O N S 600 CFM Internal Blower 807614 900 CFM Internal Blower 805086 1100 CFM In-Line Blower 808332 900 CFM Remote Blower 801641 1200 CFM Remote Blower 801642...
- Page 4 Planning Information Model W362418 (R) Pro Wall Hood I N S T A L L A T I O N S P E C I F I C A T I O N S LOCATION OF ELECTRICAL 36" (914) WIDTH OF HOOD 30"...
- Page 5 Planning Information Model W362418 (R) Pro Wall Hood I N S T A L L A T I O N N O T E S Refer to the illustrations and specifications for overall dimensions and installation specifics. Wolf Pro wall ventilation hoods are recom- mended for use with any Wolf cooking appli- ance, and should be at least as wide as the cooking surface.
- Page 6 Planning Information Model W362418 (R) Pro Wall Hood D U C T I N G C O N S I D E R A T I O N S Wolf Pro 24" (610) deep wall hoods are shipped without the blower assembly. Internal, in-line or remote blower assemblies are available.
- Page 7 Planning Information Wolf Ventilation Recommendations W O L F B L O W E R A S S E M B L I E S A ventilation system must include a blower assembly. With a few exceptions where internal blowers are included, Wolf ventilation hoods and downdrafts are shipped without the blower assembly.
- Page 8 Planning Information Wolf Ventilation Recommendations P R O V E N T I L A T I O N C F M R E C O M M E N D A T I O N S Pro 24" (610) Deep Wall Hoods W302418 DF304 / R304 / SRT304 DF366 / R366 / SRT366 / RT366...
