User Manual
SMX2219
55.88cm
22" LED FHD TV
BEFORE USING THIS PRODUCT READ THE INSTRUCTION AND CONSERVE FOR FUTURE REFERENCE, IF AN INCREASING
CORD BECOMES A FULL OR PARTIAL DAMAGE, DO NOT ATTEMPT TO REPAIR IT GO TO THE SERVICE CENTER MARKED IN
YOUR GUARANTEE; WITH A SPECIALIST TECHNICIAN, OR, WITH YOUR MANUFACTURER.
.
IMPORTED BY:
CTM DIGITAL S.A. de C.V.
Av. Lago Zurich No. 219, 12th floor, Plaza Carso Building, Col. Amplicon Granada, 11529
Mexico, Mexico City. Tel. (55) 4124-0114
ELECTRICAL SPECIFICATIONS: 100-240 See 50/60 Hz 70W
THE REMOTE CONTROL USES 2 "AAA" TYPE BATTERIES OF 1.5 V DC each (3 Vcc)
1
Advertisement
Table of Contents
Related Manuals for Sansui SMX2219
Summary of Contents for Sansui SMX2219
- Page 1 User Manual SMX2219 55.88cm 22” LED FHD TV BEFORE USING THIS PRODUCT READ THE INSTRUCTION AND CONSERVE FOR FUTURE REFERENCE, IF AN INCREASING CORD BECOMES A FULL OR PARTIAL DAMAGE, DO NOT ATTEMPT TO REPAIR IT GO TO THE SERVICE CENTER MARKED IN YOUR GUARANTEE;...
-
Page 2: Safety Information
Safety information High voltages are used in the CAUTION operation of this product, to avoid the risk of electric shock, do not remove the back cover of the TV. Please go to the RISK OF ELECTRIC SHOCK qualified personnel for service. DO NOT OPEN The use of controls, adjustments or carrying out procedures other than those specified here, may cause dangerous... - Page 3 Important security 1. Read these instructions. 2. Keep this instruction manual. 3. Follow all warnings. 4. Follow all instructions. 5. Do not use this equipment near water. 6. Clean only with soft and dry cloth. 7. Do not block the ventilation slots. Install according to the manufacturer's instructions.
-
Page 4: Important Security Instructions
Important security instructions Installing the TV on the wal 1. First, put the TV on a flat table, on which you must put something soft to prevent the panel from being scratched or damaged. 2. Use the screwdriver to remove the 4 screws that hold the base of the TV (the direction of the arrows, reference image 1) and, remove the base (guard the screws and the base carefully). -
Page 5: Connection Terminals
TV buttons and connection TV buttons Note: The following is a functional diagram only, the arrangement and position of the buttons between the different models, may vary. : To turn on / off the TV. SOURCE: To select the external input signal. MENU: To show the main MENU and confirm the selected menu option. - Page 6 Installation and Connection of the TV TV installation Put the TV in a firm place, which must support the weight of the TV. To avoid risks, please do not expose the TV to hot or humid places (as well as near lights, candles heaters), and do not block the ventilation on the back of the TV.
-
Page 7: Operation Of The Remote Control
Remote Control Operation of the remote control POWER NUMERIC BUTTONS Turn on or off (standby) the TV Press 0-9 to select a channel directly when it is watching TV. Mute The channel changes after 2 Press to suspend the sound， seconds. - Page 8 Installation of the batteries in the remote control 1. Open the back cover. 2. Use AAA batteries. When inserting the batteries, make sure that the polarity is correct, that is, that the "+" marks are oriented as indicated in the compartment. 3.
-
Page 9: Initial Setup
Initial Setup Connect the antenna cable (Air or Cable) to the RF input terminal of your TV "RF-ln". Select the Language Press the ◄/► buttons to select the language you want for the menu and messages. Press the ▼ / ▲ buttons to select go to the next step "and press the ENTER / ► button to continue. - Page 10 Initial Setup Automatic channel search (Auto Sean) Press the ◄ / ► buttons to select the type of antenna (Air or Cable). ▼ / ▲ Press the buttons to select go to the next step "and press the ENTER / ► button to continue.
-
Page 11: Input Signal Selection
Input Signal Selection Press the SOURCE button to display the list of signal input sources. Press the ▼ / ▲ buttons or the SOURCE button to select the signal input source you want. Press the ENTER button to enter the source of selected signal. -
Page 12: Sound Menu
Operation of the Main Menu Picture Menu (Picture) Press the MENU button to enter the main menu. Press the ◄ / ► buttons to select the menu. Press the ▼ button to enter. Press the MENU button again to exit or return to the previous menu. Press the ▼... -
Page 13: Setting Menu
Press the ▼ / ▲ buttons to select between Sound Mode / Bass / Treble / Balance / MTS / Sound Languages / Digital Audio Output / Surround Sound / AVL. Press the ▼ button to enter. Press the ◄ / ► buttons to make the adjustment. Press the MENU button again to exit or return to the previous menu. - Page 14 Lock menu (Lock) Press the MENU button to enter the main menu. Press the ◀/▶ buttons to select the menu. Press the ▼ button to enter. Press the MENU button again to exit or return to the previous menu. Press the ◄ / ► buttons to select between Change Password / Key Lock / Lock System / Input Block / USV Canada / RRT To Adjust / Reset RRT Press the ENTER / ▼...
-
Page 15: Channel Menu
Channel Menu Press the MENU button to enter | Main menu. Press the ◄ / ► buttons to select the menu. Press the ▼ button to enter. Press the MENU button again to exit or return to the previous menu. Press the ◄... - Page 16 PC Menu Press the SOURCE button to select the PC source. Press the MENU button to enter the main menu. Press the ◄ / ► buttons to select the Settings menu. Press the ▼ button to select PC Settings. Press the ◄ / ► buttons to select between H-Pos / V-Pos / Clock / Phase / Automatic. Press the ENTER / ▼...
- Page 17 Operation of Media (USB) Note: Before operating the MEDIA menu, connect a USB device, then press the SOURCE button to select the Media Input Source. ▼ Press the ▲ / buttons to select Media in the Input Source menu, then press ENTER to enter, as shown below: Press the ◄...
- Page 18 Operation of Media (USB) Photos Press the ◄ / ► buttons to select PHOTO in the main menu, then press ENTER to enter. Press the ◄ / ► buttons to select the file you want to view, then press the button ENTER to enter.
- Page 19 Operation of Media (USB) Repeat all: Press the ◄ / ► buttons to select the Repeat option..press the ENTER button to select Repeat none / all / 1. Music (Music): Press the "◄ / ►" buttons to select Music, press the ENTER button to play the music background.
- Page 20 Operation of Media (USB) MULTIMEDIA USB REPRODUCTION FORMATS (Music / Photo) Categories Ext file Decoder Notes Multimedia Music *. MP3 MPEG1 Audio LAYER1II Frequency Radio [kHz] (Does not correspond MP3 Pro) 32 / 44.1 / 48 Bit size [Kbit / s]: 32/40/48/56/64/80/96/112/128 / 160/192/224/256/320 / VBR Photo...
- Page 21 Faults Guide It does not turn on Check that the AC power cord of the TV is connected. If the continuous problem, disconnect the TV and connect it again after 60 seconds and try to turn on the TV again. The received The cause of double image or ghosts is caused by tall signal is not...
- Page 22 (PC mode) Horizontal Adjust the horizontal Audio sound in the main menu to interference lines clean the horizontal lines. (PC mode) The image is very Adjust the contrast or brightness level in the main menu. light or very dark (PC mode) The PC function Check the computer settings if the resolution is does not respond...
- Page 23 User Manual...
