Page 1 NH300WHXEA NH200WHXES NH300WHXES Air to Water Heat Pump -Hydro Unit installation manual imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register DB98-32659A(1) NH080PHXEAHydro unit_IM_E 32659-1.indd 2010-07-28 ｿﾀﾈﾄ 8:59:56...
Page 2: Table Of Contents
Contents Safety precautions ..............3 ...
Page 3: Safety Precautions
 This manual explains how to install an indoor unit with a split system with two SAMSUNG units. The use of other types of units with different control systems may damage the units and invalidate the warranty.
Page 4 Safety precautions (Continued) OWER SUPPLY LINE FUSE OR CIRCUIT BREAKER  Always make sure that the power supply is compliant with current safety standards. Always install the air to water heat pump in compliance with current local safety standards.  Always verify that a suitable grounding connection is available. ...
Page 5: Product Specifications
Product specifications Accessories Installation Manual(1) User’s Manual(1) Pattern Sheet(1) Service Valve(2) Wall Mounting Bracket(1) Remote Controller Wire(1x15m) Temperature sensor for Cover Controller (1) Ring band (1) DHW Tank(1x15m) (1) NH080PHXEAHydro unit_IM_E 32659-1.indd 2010-07-28 ｿﾀﾈﾄ 8:59:11...
Page 6 Product specifications (Continued) Specifications Type Unit NH080PHXEA NH160PHXEA Power Source V/Hz 1P, 230, 50 1P, 230, 50 Operating Range °C 0~32 0~32 Cool °C 5~25 5~25 Operating Range [Water] Heat °C 15~55 15~55 Heating Capacity Flow rate kg/min 17.0 20.5 23.0...
Page 7 Components interchangeability Duct Wall mounted Air to Water unit Remark Indoor unit Subsidiary materials Slim Duct Vivace Neo-Forte Hydro Unit Capacity 2.2~5.6kW 2.2~7.1kW 2.2~7.1kW 8/16kW MXD-A13K116A ≤3.6kW 1room + ≥5.6kW 1room MXD-A13K200A ≤3.6kW x 2room MXD-A16K200A ≥5.6kW x 2room EEV Kit MXD-A13K216A ≤3.6kW 2room + ≥5.6kW 1room Requisite...
Page 8: Typical Application Examples
When the SAMSUNG Air-to-Water Heat Pump system is used in series with another heat source (e.g. gas boiler). Ensure that the return water temperature not exceed 55°C. SAMSUNG shall not be held liable for any damage resulting from not observing this rule.
Page 9 Application 3: Space heating + water heating Outdoor Indoor Room Controller 45°C Supply Header  Our Supply Range Return Header Radiators or Convectors [Application #3] Room Thermosat & [Application #2] Actuators DHW Tank Thermostatic & Load Balancing Valves Pump #1 Load Pump #2 40°C...
Page 10: Main Components
Main components Name Note Air vent 3/8” BSPP male 3/8” Backup heater thermal fuse Thermal cut out 94°C (+0, -6°C) Backup heater thermostat Disc. 65°C ±4°C Backup Heater Element Incoloy 800, 4/6kW, 230V AC 50Hz Drain Hose Flow switch 12/16LPM ±1.5LPM Water pump 1P-230V-50Hz, 46LPM x 54kPa Manometer...
Page 11: Functional Diagram
Functional diagram Ref' In Ref' Out Water Out Water In Note Service valve(R) Strainer Flow switch Heat exchanger EEV kit Backup heater Pressure relief valve Air-vent valve Water pump Expansion tank Manometer Service valve(L) Water temp. sensor 1 Water temp. sensor 2 Water temp.
Page 12: Dimensional Drawing
Dimensional drawing 510.0 314.6 125.0 104.0 103.7 78.5 131.7 NH080PHXEAHydro unit_IM_E 32659-1.indd 2010-07-28 ｿﾀﾈﾄ 8:59:20...
Page 13: Installing The Unit
Installing the unit Installation of the indoor unit The indoor unit should be installed indoors and meet the following conditions.  Installation site should be sheltered from frost.  In area with suitable space for servicing.  A place with adequate ventilation. ...
Page 14 Installing the unit (Continued) Mounting the indoor unit Handle  A minimum of two people should lift the unit by the handles and not by the drain pan or pipe work.  Drill 6 holes from the pattern sheet for fixing the wall bracket and unit. After completing holes, detach the pattern sheet.
Page 15: Pipe Work
Pipe work Refrigerant pipe work For all guide lines, specifications regarding refrigerant pipe work between the indoor unit and the outdoor unit, please follow the outdoor unit installation manual. Gas pipe (O.D.) Liquid pipe (O.D.) Tightening Torque Final Torque Indoor unit 15.9mm(5/8 inch) 9.5mm(3/8 inch) 400kg·cm...
Page 16 Pipe work (Continued) Water pipe work The hydro unit is equipped with components listed on the table below. The hot and cold water supply connections are clearly marked on the unit with labels. And service valves are provided. Whole water plumbing system including Hydro unit shall be installed by a qualified technician and must comply with all relevant European and national regulations.
Page 17 Flushing and air-purging When filling water, the following start-up procedure should be followed. 1. All system components and pipes must be tested for the presence of leaks. 2. Preparation of a make-up water assembly or Flushing unit is recommended for installation and service. 3.
Page 18 Pipe work (Continued) The water volume and expansion vessel pressure The unit is equipped with an expansion vessel of 8 litres which has a default pre-pressure of 1 bar. To ensure correct operation of the unit, the pre-pressure of the expansion vessel might need to be adjusted and the minimum and maximum water volume must be checked.
Page 19 Setting the pre-pressure of the expansion vessel When it is required to change the default pre-pressure of the expansion vessel(1 bar), keep in mind the following guidelines:  Use only dry nitrogen to set the expansion vessel pre-pressure.  Inappropriate setting of the expansion vessel pre-pressure will lead to malfunction of the system. Therefore, the pre-pressure should only be adjusted by a licensed installer.
Page 20 Pipe work (Continued) Charging water After installation is completed the following procedures shall be used to charge water into the hydro unit.  Connect water lines to water connections of hydro unit.  The air-vent valve shall be opened at least 2 turns and drain valves shall be closed.
Page 21 Pressure relief valve A pressure relief valve is integrated on heater vessel of hydro unit and shall work in abnormal condition for protecting the hydro unit.  The pressure relief valve will operate releasing the pressure by flowing out some water through the drain hose.
Page 22: Wiring Work
Wiring work  Field-supplied electrical components such as power switch, circuit breakers, wires, terminal blocks, etc must be properly chosen with compliance with national legislation or regulation.  Switch off the power supply before making any connections.  All field wiring and components must be installed by a licensed electrician. ...
Page 23 Wiring diagram NH080PHXEAHydro unit_IM_E 32659-1.indd 2010-08-04 ｿﾀﾀ・9:34:10...
Page 24: Cover
Wiring work (Continued) Selecting solderless ring terminal  Select a solderless ring terminal of a connecting power cable based on a nominal dimensions for cable.  Cover a solderless ring terminal and a connector part of the power cable and then connect it. Silver solder Nominal Nominal...
Page 25 Types of allowable current Conductors of supply cord shall have a nominal cross-sectional area not less than that shown in the table below. Minimum cross-sectional area of conductors Rated current of appliance (A) Nominal cross-sectional area (mm ≤0.2 Tinsel cord ≤0.2 and ≤3 Exterior connection >3 and ≤6...
Page 26 Wiring work (Continued) Connection of the power supply and communication cable Description No. of wires Max. A Thickness Supply Scope 4.0mm H05RN-F Main power 2+ground Field supply (230V~, Input) or H07RN-F 0.75mm H05RN-F Communication 7Vdc data or H07RN-F 2 wires for communication cable, 1 phase 3 wires(230V ~) for power supply 1 phase 230V~ Earth cable Circuit breaker...
Page 27 Connecting the power terminal  Connect the cables to the terminal board using the solderless ring terminal.  Use certified and reliable cables.  Connect the cables with the torque chart as below.  If the terminal is loose, fire may occur caused by arc. If the terminal is connected too firmly, the terminal may be damaged.
Page 28 Model Heater capacity (kW) ELCB capacity (A) NH080PHXEA NH160PHXEA DHW tank(200 or 300)  Circuit Breaker(ELCB, ELB, MCCB etc.)s written above are already included in the hydro unit. ❈ ELCB : Earth leakage circuit breaker...
Page 29 Connection of the thermostat Description No. of wires Max. A Thickness Supply Scope Room Thermostat for 22mA > 0.75mm Field supply (230V~, Input) weather control Process Thermostat 1 Thermostat 2 1. Before the installation, hydro unit should be turned off. N L C1 H1 Thermostat 2.
Page 30 Wiring work (Continued) Connection of the 3-way valve Description No. of wires Max. A Thickness Supply Scope 0.75mm H05RN-F Diverting type 3way valve 22mA Field supply (230V~, Output) or H07RN-F 3-way diverting valve for water tank -Diverting type - 230V AC When water pass to floor heating When water pass to water tank Process...
Page 31: Troubleshooting
Troubleshooting If the unit has some problem to work properly, the LED on hydro unit will flash and some error codes will be dis- played on the controller. The following table described the explanation of error codes on the LCD display. Thermistor ...
Page 32 Troubleshooting (Continued) Communication Display Explanation Abnormal communication B/W Wired remote controller & Hydro unit Communication tracking error B/W Wired remote controller & Hydro unit FRAM Read/Write Error(Wired remote controller data error) E601, E604 E654 • Wrong data transmit B/W micom & IC07(eeprom) NH080PHXEAHydro unit_IM_E 32659-1.indd 2010-07-28 ｿﾀﾈﾄ...
Page 33 Water Out Water In E911 • Water pump ON ( Flow S/W off ) Water flow >16 LPM(NH160PHXEA) >12 LPM(NH080PHXEA) • Water pump ON ( Flow S/W off ) : NOT enough water flow Water flow <16 LPM(NH160PHXEA) <12 LPM(NH080PHXEA) E912 •...
Page 34: Dhw Tank
DHW tank Safety information (Before installing an DHW Tank, please read this manual thoroughly to ensure that you know how to safely and efficiently install a new appliance.) • If you don’t follow the safety precautions, you may get the risk of serious wound WARNING or death.
Page 35 General information  SAMSUNG Eco Heating system with SAMSUNG DHW tank is designed to withstand SAMSUNG durability and reliability requirements. We cannot guarantee neither good operation nor reliability of total system with other brand tanks.  The piping, valves and system configuration of DHW tank system should be followed a relevant local or national regulations.
Page 36 DHW tank (Continued) Main components Standard Solar Connected Note Note Top and bottom dome (pressure vessel) Anode 200 ltr Cylinder (pressure vessel) Anode 300 ltr Outer casing Recirculation dip tube Base Thermistor pocket Heating element 2.6kW,1x240V Hole for Conduit/Cable gland Heating element head Electric box lid O-ring for immersion heater...
Page 37 Outlook diagram Standard Solar Connected Note Hot water connection Threaded thermistor hole Flow inlet connection Return outlet connection Cold water connection Flow inlet connection from solar panel Flow outlet connection to solar panel NH080PHXEAHydro unit_IM_E 32659-1.indd 2010-07-28 ｿﾀﾈﾄ 8:59:49...
Page 38 DHW tank (Continued) Accessories Leg (3) Anode bar (1) Conduit (1) NH080PHXEAHydro unit_IM_E 32659-1.indd 2010-07-28 ｿﾀﾈﾄ 8:59:50...
Page 39 Water tank specifications Detailed information for the DHW Tank are described in the following table. There are 4 types of DHW tank by size and operating ways. Standard Solar Connected Unit NH200WHXEA NH300WHXEA NH200WHXES NH300WHXES Material quality AISI 444 / DIN 1.4521 Pressure vessel Volume capacity litres...
Page 40 DHW tank (Continued) Space requirements Positions of water inlet and outlet pipe are affected by the layout of DHW Tank. The layout of pipes and other components except DHW tank are the responsibility of installers. The DHW Tank must be laid out in accordance with the illustrations as below to prevent any water leakage and malfunction.
Page 41 Piping diagram The product must be installed without any water leakage. Please verify that the DHW tank and other components are properly installed and reinstall them if necessary. - Use certified components and the correct tools. - Keep adequate space for the installing. OVERVIEW Field supply Field installation...
Page 42  For the reliable performance and durability, all parts as listed below ,including a relief valve, an expansion vessel, a drain valve and pressure reducing valve , should be installed according to each national or regional standards. They are not supplied by SAMSUNG. - Pressure relief valve (9 bar)
Page 43 Wiring diagram  T urn on the DHW tank and hydro unit after completing electric wiring works.  D o not disassemble the wirings out of the unit while the unit is operating.  C ircuit breaker shall be installed for safety and maintenance . Make sure of a earthing.
Page 44 DHW tank (Continued) Switch box layout DHW tank temp. (Default, 15m) CN53(Red) ELCB 1P, 230V~ 50Hz To DHW tank NH080PHXEAHydro unit_IM_E 32659-1.indd 2010-07-28 ｿﾀﾈﾄ 8:59:53...
Page 45 Electrical connections Procedure  S witch off the power supply before making any connections.  U se a thermal grease in thermistor pocket after installing electric connections. Connections to be made in the electrical box of DHW tank 1. Connect the booster heater power supply and thermal protection cable. 2.
Page 46 DHW tank (Continued) Power connection 1 phase 230V~ Circuit breaker Earth cable (U-Trap) Power cable Communication cable between indoor and outdoor units Earth Communication cable F1 F2 1 phase 1 phase Hydro unit 230V~ 230V~ DHW Tank Water circuit connection 1.
Page 47 Troubleshooting IMPORTANT: All maintenance or repair work must be executed by an approved installer. Problem Possible cause Solution Check if there is any power on the power No power supply to the water heater supply terminal on the thermostat. Hot water is not coming out. The thermostat may be set too high and Reduce thermostat setting by 5°C and press cause the fuse or safety cut-off to operate.
Page 48 NH080PHXEAHydro unit_IM_E 32659-1.indd 2010-07-28 ｿﾀﾈﾄ 8:59:55...
