- Page 1 TW218Ba Dual 18" Active Subwoofer TW Series Pro Loudspeaker System User Manual UM-TW218Ba-20131217 ver A...
- Page 2 SAFETY INSTRUCTIONS PLEASE READ THIS MANUAL FIRST Thanks for buying products. Read this manual first as it will help you operate the system properly. Please keep this manual for future reference. WARNING: This product must be installed by professionals. When using the hanging and rigging parts that are not appointed, please ensure the intensity of the structure comply with the local safety criterion.
-
Page 3: Table Of Contents
TW218Ba CONTENT TW Series Pro Loudspeaker System CONTENT INTRODUCTION Features Description Application AMPLIFIER MODULE Amplifier Module INSTALLATION Optional Accessories Installation Reference TECHNICAL SPECIFICATION Technical Sheet Frequency Response 2D Dimension Product information may be updated without notification, please visit www.elderaudio.com for... -
Page 4: Introduction
TW218Ba INTRODUCTION TW Series Pro Loudspeaker System TW218Ba Dual 18" Active Subwoofer Features × Light weight powered 2 18 subwoofer. " 4500W continuous Class D power module. Strong punch penetrating with impact. Superior heat dissipation and protection system. Master volume, high cut, phase select, power / peak indication available. -
Page 5: Amplifier Module
TW218Ba AMPLIFIER MODULE TW Series Pro Loudspeaker System Amplifier Module TW218Ba CAUTION DOUBLE 18" ACTIVE SUBWOOFER PHASE POWER PEAK VOLUME HIGH CUT LINE IN LINE OUT S/N: Elder Audio Manufacture Co.,Ltd. ~100V-120V 50/60Hz RATED POWER CONSUMPTION:600W 1. Volume control Overload indicator 2. -
Page 6: Installation
TW218Ba INSTALLATION TW Series Pro Loudspeaker System Optional Accessories Installation Reference 1. Mobile Caster 1. Stack Caster: φ100 *34mm 4pcs Screws: M8 *30 Hexagon 16pcs Spring washers: φ8 (Black) 16pcs Flat washers: φ8 (Black) 16pcs PE bag: 4pcs Carton: 1pc... -
Page 7: Technical Specification
TW218Ba TECHNICAL SPECIFICATION TW Series Pro Loudspeaker System Specification Frequency response(-3dB): 40Hz-200Hz 132dB/138dB(PEAK) Max.SPL: × Transducer: 18" Woofer Rated impedance: 4 Ohms XLR for input Connector: Input: Channel one (Mic/Line) balanced input Input impedance(line): 20Kohm balanced input, 2Kohm unbalanced input Input level: 0 dBV (0.775V rms, 1.0 V peak)Line-100Hz... -
Page 8: 2D Dimension
TW218Ba TECHNICAL SPECIFICATION TW Series Pro Loudspeaker System 2D Dimension Top view 567mm [22.3in] Side view Front view Back view Bottom view... - Page 9 Notes:...
- Page 10 www.beta3pro.com...
