Speco CVC-6246IHR Owner's Manual

40 line color dome camera intensifier series wall & ceiling mountable
Hide thumbs Also See for CVC-6246IHR:
Table of Contents

Advertisement

Quick Links

See also: Instruction Manual , User Manual
CVC-6246iHR
540 Line Color Dome Camera
Intensifier Series
Wall & Ceiling Mountable
Please read this manual thoroughly before operation and keep
it handy for further reference.

Advertisement

Table of Contents
loading

Related Manuals for Speco CVC-6246IHR

Summary of Contents for Speco CVC-6246IHR

  • Page 1 CVC-6246iHR 540 Line Color Dome Camera Intensifier Series Wall & Ceiling Mountable Please read this manual thoroughly before operation and keep it handy for further reference.
  • Page 3 WARNING & CAUTION CAUTION The lighting flash with an arrowhead symbol, within an equilateral triangle is Intended to alert the user to the presence of un-insulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (serving) instructions...

  • Page 4: Table Of Contents

    Contents Package Contents Precautions Camera Installation Internal Components Features...
  • Page 5 Operating Your Camera SET UP SET UP LENS SHUTTER SPEED CONTROL BACK LIGHT AUTO GAIN (AGC) WHITE BALANCE REDUCE NOISE INTENSIFIER CAMERA TITLE DAY/NIGHT/SYNC MOTION DETECTION PRIVACY REVERSE DETAIL DEFAULT/RETURN Troubleshooting Specifications / Dimensions Warranty...

  • Page 6: Package Contents

    PACKAGE CONTENTS • Please make sure that the following items are included in the package: 1 CVC-6246iHR Camera 2 Mounting Screws 1 Video test Connector 1 Power Adaptor Lead Please leave this manual with the end-user for future reference.

  • Page 7: Precautions

    PRECAUTIONS • THIS DOME CAMERA SHOULD BE ONLY INSTALLED BY QUALIFIED PERSONNEL • TO PREVENT A FIRE OR ELECTRICAL HAZARD PLEASE USE PROPER POWER CABLE • THE DOME COVER SHOULD BE TREATED WITH CARE. DO NOT CELAN THE COVER WITH AN ABRAISIVE CLEANING MATERIAL - PLEASE USE A SOFT CLOTH OR TISSUE TO CLEAN THE DOME COVER •...

  • Page 8: Camera Installation

    CAMERA INSTALLATION CONNECT POWER CABLE 1. WHEN USING 12 VOLTS DC (constant voltage 600 mA) POWER INPUT:RED CONNECT CENTER:(+) POWER SUPPLY 2. WHEN USING 24 VOLTS AC (40 Volt Amps) -CONNECT ACCESSORY CABLE TO THE POWER JACK AND CONNECT 24V AC TO THE LEAD POWER RED(+) CONNECT...

  • Page 9: Internal Components

    INTERNAL COMPONENTS 1. Mechanical (1) DC AUTO-IRIS LENS Adjust between TW (TELE  WIDE) to set the angle (focal length) Set the focus by adjusting ∞N NOTE: BOTH OF THE ABOVE ADJUSTMENTS GET LOCKED INTO POSITION THROUGH THE USE OF "LOCKING HANDLES". (2) JOY STICK TO SET THE OSD (ON SCREEN DISPLAY) , PRESS THE JOY STICK FOR ONE SECOND AND SET AS DESCRIBED...
  • Page 10 2. Joy Stick Video Test Terminal RIGHT LEFT DOWN Push the Joy stick for one second, and the OSD appears on the screen. Move the Joy Stick up, down, left & right to control the OSD functions.

  • Page 11: Features

    Features When the image is in front of strong background lighting, your camera allows you to get a clear image. INTENSIFIER 1/3 inch high density CCD and digital processor permit high quality pictures to be captured in very low light conditions. High Resolution Horizontal resolution of 540 TV lines is achieved by using a SONY Double Speed CCD with...
  • Page 12 All camera functions are menu driven for easy use Dynamic Noise Reduction The Intensifier camera has a DSP chip that can remove image noise efficiently showing clean images in low light conditions. ELECTRONIC DAY/NIGHT The Intensifier camera can show color pictures in all lighting conditions, or you can have it automatically switch to a B/W picture in low light conditions MANUAL / AUTO IRIS LENS...

  • Page 13: Operating Your Camera

    Operating your camera OSD Function SETUP MENU LENS TYPE ●DC ●MANUAL SHUTTER TYPE ●OFF ●F/L ●MANUAL WHITE BALANCE ●ATW ●AWC MANUAL● ●OFF ●LOW ●MIDDLE ●HIGH AUTO GAIN ●OFF ●LOW ●MIDDLE ●HIGH REDUCE NOISE ●OFF ●LOW ●MIDDLE ●HIGH INTENSIFIER ●AUTO ●OFF NEXT PAGE ●CAMERA TITLE ●DAY/NIGHT ●SYNC ●MOTION DET ●PRIVACY ●REVERSE...

  • Page 14: Setup

    Operating your camera – SETUP 1. Press the SET button (JOYSTICK) to access the SETUP mode. SET UP menu is displayed on the monitor screen. 2. Select the desired feature using the UP or DOWN button. Each time you press the UP or DOWN button, the arrow indicator moves up or down.
  • Page 15 Operating your camera – SETUP LENS 1) Setting up the LENS Select the lens type by pressing the RIGHT button. ① On the SETUP menu screen, move the arrow indicator to the lens using the UP or DOWN button. ② Select the desired feature using the LEFT or RIGHT button.
  • Page 16 Operating your camera – SETUP LENS ▶When DC LENS selected, press SET button to control the BRIGHTNESS.
  • Page 17 2) Shutter status and speed control You can control brightness of the screen by the shutter speed. ① Press the SET button to display the setup menu and move the arrow indicator to ‘SHUTTER’ using the UP or DOWN button. ②...
  • Page 18 Operating your camera – SETUP SPEED CONTROL. ② ▶MANUAL : When setting the shutter speed manually. You can select speed from ‘1/60’ to ‘1/200,000’sec...
  • Page 19 ▶ELC : You can control the BRIGHTNESS. ③When completed, press ‘SET’ Notes Avoid pointing the camera directly at a fluorescent lamp When the SHUTTER menu is set to FLK mode, the INTENSIFIER will not work.
  • Page 20 Operating your camera – BACKLIGHT 3) SLC (Speco Light Compensation) - BACKLIGHT A built-in SR chip provides intelligent light level control to overcome severe Backlight conditions. ① Press the SET button to display the SETUP menu and move the arrow indicator to ‘BACKLIGHT’...
  • Page 21 4) AUTO GAIN CONTROL (AGC) AGC allows a brighter picture in low light conditions. Higher GAIN level will yield a brighter screen but you might notice an increase in noise. ① Press the SET button to display the SETUP menu and move the arrow indicator to ‘AGC’...

  • Page 22: White Balance

    Operating your camera – WHITE BALANCE 5) WHITE BALANCE ① Press the SET button to display the SETUP menu and move the arrow indicator to ‘WHITE BALANCE’ using the UP or DOWN button. ② Set ‘WHITE BAL.’ to the desired mode using LEFT or RIGHT button. ▶...
  • Page 23 ▶MANUAL : To fine adjust, select the Manual mode. You can increase or decrease the red or blue factor while monitoring the difference on the screen. Set to ‘MANUAL’ mode and press the SET button. Increase or decrease the value for RED(R-Gain) and BLUE(B-Gain), watching the color of the picture, and press the SET button when you obtain the best color.

  • Page 24: Reduce Noise

    Operating your camera – REDUCE NOISE 6) REDUCE NOISE (Dynamic Noise Reduction) DNR reduces the noise on the screen. ① Press the SET button to display the SETUP menu and move the arrow indicator to ‘DNR’ using the UP or DOWN button. ②...

  • Page 25: Intensifier

    Operating your camera – INTENSIFIER 7) INTENSIFIER Allows you to get clear images under night or low light conditions ① Press the SET button to display the SETUP menu and move the arrow indicator to ‘INTENSIFIER’ using the UP or DOWN button. ②...

  • Page 26: Camera Title

    Operating your camera – CAMERA TITLE ① 8) NEXT PAGE ① Press the SET button to display the SETUP menu and move the arrow indicator to ‘SENCE UP’ using the UP or DOWN button. ② SET ‘NEXT PAGE’ to the desired mode using the LEFT or RIGHT button. (A) CAMERA TITLE ①...
  • Page 27 Operating your camera – CAMERA TITLE ② ③ Press SET button to access the SETUP mode. ④ You can enter up to 15 characters. a. Move the cursor to character-enter location by using the LEFT or RIGHT button. b. Select the desired character by using the UP or DOWN button. c.
  • Page 28 Operating your camera – COLOR / SYNC B) COLOR You can choose color and B/W mode electronically. ① Press the SET button to display the SETUP menu and move the arrow indicator to ‘SENCE UP’ using the UP or DOWN button. ②...
  • Page 29 C) SYNC Two SYNCHRONIZATION modes are available INTERNAL and EXTERNAL LINE-LOCK ① Press the SET button to display the setup menu and move the arrow indicator to ‘SYNC’ using the UP and DOWN button. ② SET to the desired mode using the LEFT or RIGHT button. ▶...

  • Page 30: Motion Detection

    Operating your camera – MOTION DETECTION D) Whenever your camera detects motion, THE WORDS “motion detected’ will appear on the screen. ① Press the SET button to display the setup menu and move the arrow indicator to ‘MOTION DET’ using the UP and DOWN button. ②...
  • Page 31 Max. Min.

  • Page 32: Privacy

    Operating your camera – PRIVACY E) PRIVACY To mask an area that you want to be private. ① Press the SET button to display the setup menu and move the arrow indicator to ‘PRIVACY’ using the UP and DOWN button. ②...

  • Page 33: Reverse

    Operating your camera – REVERSE F) REVERSE ① Press the SET button to display the setup menu and move the arrow indicator to ‘REVERSE’ using the UP and DOWN button. ② SET ‘REVERSE’ to the desired mode using the LEFT or RIGHT button. ▶OFF : Deactivation ▶ON : Reverse the image RIGHT or LEFT.

  • Page 34: Detail

    Operating your camera – DETAIL F) DETAIL ① Press the SET button to display the setup menu and move the arrow indicator to ‘DETAIL’ using the UP and DOWN button. ② SET ‘DETAIL’ to the desired mode using the LEFT or RIGHT button. ▶OFF : Deactivation ▶ON : DETAIL control mode (level 0~31) When the level is up, the sharpness will increase.
  • Page 35 Operating your camera – DEFAULT / PAGE 1 G) DEFAULT : Use to reset your camera to FACTORY DEFAULT SETTING. H) PAGE 1 : PAGE 1 : Save the setting of NEXT PAGE function, and then move to SET UP menu.

  • Page 36: Troubleshooting

    Troubleshooting If you have trouble operating your camera, refer to the following Problem Nothing appears on the screen. The image on the screen is dim. The image on the screen is dark. The camera is not working properly, and the surface of the camera is not.
  • Page 37 Problem The color of the ● Check that you have properly set the picture is not matched. The image on the ● Is the camera facing to direct sunlight or fluorescent screen flickers. L/L mode isn’t ● Have you connected your camera to DC power able to be selected.
  • Page 38 Motion Detection On Screen Display ( O.S.D ) PRIVACY Function Operational Temperature Operational Humidity CVC-6246IHR DC 12V & AC 24v ( Dual Voltage ) 230mA(DC) / 3.8W(AC) 1/3”, SONY SUPER HAD CCD, 811(H) x 508(V) , 1/3” CCD 768(H) x 494(V) , 1/3” CCD DC AUTO IRIS VAROFOCAL 2.8~11mm...
  • Page 39 DIMENSIONS * SIDE VIEW * TOP VIEW...

  • Page 40: Warranty

    WARRANTY...
  • Page 41 200 New Highway Amityville, NY 11701 631-957-8700 www.specotech.com VER. 070817 This manual is based on the date as shown in the right and specifications are subject to Change without notice for quality improvement.
