  • Page 1 A+ Server AS-2113S-WN24RT USER’S MANUAL Revision 1.0...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
  • Page 3 SuperServer AS-2113S-WN24RT. Installation and maintenance should be performed by experienced technicians only. Please refer to the AS-2113S-WN24RT specifications page on our website for updates on supported memory, processors and operating systems (http://www.supermicro.com).

  • Page 4: Table Of Contents

    Preface Contents Chapter 1 Introduction 1.1 Overview ..........................8 1.2 Unpacking the System ......................8 1.3 System Features ........................9 1.4 Server Chassis Features ....................10 Control Panel ........................10 Front Features ........................11 Rear Features ........................11 1.5 Motherboard Layout ......................12 Quick Reference Table ......................13 Chapter 2 Server Installation 2.1 Overview ..........................16 2.2 Preparing for Setup ......................16 Choosing a Setup Location ....................16...
  • Page 5 AS-2113S-WN24RT User's Manual Chapter 3 Maintenance and Component Installation 3.1 Removing Power ........................24 3.2 Accessing the System ......................24 3.3 Motherboard Components ....................25 Processor Installation ......................25 3.4 Memory Support and Installation ..................32 Memory Support ......................32 DIMM Module Population ....................33 DIMM Installation ......................34 DIMM Removal .........................34...
  • Page 6 Preface 5.4 IPMI ............................63 Chapter 6 UEFI BIOS 6.1 Introduction .........................64 Starting the Setup Utility ....................64 6.2 Main Setup .........................65 6.3 Advanced ..........................67 6.4 IPMI ............................81 6.5 Event Logs .........................84 6.6 Security ..........................86 6.7 Boot ............................89 6.8 Save & Exit .........................91 6.9 BIOS Update Using IPMI ....................93 Appendix A BIOS Codes Appendix B Standardized Warning Statements for AC Systems...
  • Page 7 AS-2113S-WN24RT User's Manual Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 8: Overview

    Chapter 1 Introduction 1.1 Overview This chapter provides a brief outline of the functions and features of the AS-2113S-WN24RT. The AS-2113S-WN24RT is based on the H11SSW-NT motherboard and the SC216BTS-R1K23WBP chassis. In addition to the motherboard and chassis, several important parts that are included with the system are listed below.

  • Page 9: System Features

    Chapter 1: Introduction 1.3 System Features The following table provides you with an overview of the main features of the AS-2113S-WN24RT. Please refer to Appendix C for additional specifications. System Features Motherboard H11SSW-NT Chassis SC216BTS-R1K23WBP Single EPYC 7000 series processor...

  • Page 10: Server Chassis Features

    AS-2113S-WN24RT User's Manual 1.4 Server Chassis Features Control Panel There are two buttons located on the front of the chassis: a power on/off button and a UID button. In addition there are five LEDs. The locations of these buttons and LEDs on the control panel are described below.

  • Page 11: Front Features

    Chapter 1: Introduction Front Features The SC216BTS-R1K23WBP is a 2U chassis See the illustration below for the features included on the front of the chassis. Figure 1-2. Chassis Front View Front Chassis Features Item Feature Description Drive Bays Drive bays for 2.5" hot-swap drives Control Panel Server control panel.

  • Page 12: Motherboard Layout

    AS-2113S-WN24RT User's Manual 1.5 Motherboard Layout Below is a layout of the H11SSW-NT with jumper, connector and LED locations shown. See the table on the following page for descriptions. For detailed descriptions, pinout information and jumper settings, refer to Chapter 4.

  • Page 13: Quick Reference Table

    Chapter 1: Introduction Quick Reference Table Jumper Description Default Setting UID SW Unit ID switch (push-button toggle switch ON/OFF) JBT1 Clear CMOS Open (Normal) JWD1 Watch Dog control Pins 1-2 (Reset) JDBG1 Debug Mode Pins 1-2 (Normal) JPL1 LAN Enable/Disable Pins 1-2 (Enabled) Description Status...
  • Page 14 AS-2113S-WN24RT User's Manual Connector Description LAN1, LAN2 Back panel LAN1, LAN2 connectors Back panel VGA port NVME 0~15 NVMe slots 1~15 Note: Jumpers, connectors, switches, and LED indicators that are not described in the preceding table are for manufacturing testing purposes only.
  • Page 15 Chapter 1: Introduction H11SSW IPMI LAN RJ45 AMD SP3 Rev. 1.01 Rear USB 3.0 10Gb LAN 10Gb LAN RJ45 RJ45 Rear SXB1 SXB2 USB 3.0 COM1 RX 0-7 RX 15-8 COM2 ASM1042 ASM1042 TX 0-7 TX 15-8 USB controller USB controller CPU P0 [0] TX 0-15 RX 0-15...

  • Page 16: Chapter 2 Server Installation

    AS-2113S-WN24RT User's Manual Chapter 2 Server Installation 2.1 Overview This chapter provides advice and instructions for mounting your system in a server rack. If your system is not already fully integrated with processors, system memory etc., refer to Chapter 4 for details on installing those specific components.

  • Page 17: Server Precautions

    Chapter 2: Server Installation • In single rack installations, stabilizers should be attached to the rack. In multiple rack in- stallations, the racks should be coupled together. • Always make sure the rack is stable before extending a server or other component from the rack.

  • Page 18: Circuit Overloading

    AS-2113S-WN24RT User's Manual Circuit Overloading Consideration should be given to the connection of the equipment to the power supply circuitry and the effect that any possible overloading of circuits might have on overcurrent protection and power supply wiring. Appropriate consideration of equipment nameplate ratings should be used when addressing this concern.

  • Page 19: Installing The Rails

    Chapter 2: Server Installation 2.3 Installing the Rails There are a variety of rack units on the market, which may require a slightly different assembly procedure. The following is a basic guideline for installing the system into a rack with the rack mounting hardware provided.

  • Page 20: Releasing The Inner Rail

    AS-2113S-WN24RT User's Manual Releasing the Inner Rail Releasing Inner Rail from the Outer Rails 1. Identify the left and right outer rail assemblies as described on the previous page. 2. Pull the inner rail out of the outer rail until it is fully extended as illustrated below.

  • Page 21: Installing The Outer Rails On The Rack

    Chapter 2: Server Installation Installing the Outer Rails on the Rack Installing the Outer Rails 1. Press upward on the locking tab at the rear end of the middle rail. 2. Push the middle rail back into the outer rail. 3.

  • Page 22: Standard Chassis Installation

    AS-2113S-WN24RT User's Manual Standard Chassis Installation Installing the Chassis into a Rack 1. Confirm that the inner rails are properly installed on the chassis. 2. Confirm that the outer rails are correctly installed on the rack. 3. Pull the middle rail out from the front of the outer rail and make sure that the ball- bearing shuttle is at the front locking position of the middle rail.
  • Page 23 Chapter 2: Server Installation Ball-Bearing Shuttle Figure 2-5. Installing the Server into a Rack Note: Figure is for illustrative purposes only. Always install servers to the bottom of a rack first.

  • Page 24: Chapter 3 Maintenance And Component Installation

    AS-2113S-WN24RT User's Manual Chapter 3 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. Installation or replacement of most components require that power first be removed from the system.

  • Page 25: Motherboard Components

    Check that the plastic socket dust cover is in place and none of the socket pins are bent— otherwise, contact your retailer. • Refer to the Supermicro website for updates on CPU support. • Graphics in this manual are for illustration. Your components may look slightly different.
  • Page 26 AS-2113S-WN24RT User's Manual Installing the Processor Begin by removing power from the system as described in Section 3.1. 1. Use a Torx T20 driver to loosen the screws holding down Force Frame in the sequence of 3-2-1. The screws are numbered on the Force Frame next to each screw hole.
  • Page 27 Chapter 3: Maintenance and Component Installation 2. The spring-loaded Force Frame will raise up after the last screw (#1) is removed. Gently allow it to lift up to its stopping position. Figure 3-3. Raising the Force Frame 3. Lift the Rail Frame up by gripping the lift tabs near the front end of the rail frame. While keeping a secure grip of the Rail Frame, lift it to a position so you can do the next step of removing the External Cap.
  • Page 28 AS-2113S-WN24RT User's Manual 4. Remove the External Cap from the Rail Frame by pulling it upwards through the rail guides on the Rail Frame. Remove the PnP Cover Cap. External Cap PnP Cover Cap Figure 3-5. Removing the External Cap 5.
  • Page 29 Chapter 3: Maintenance and Component Installation Note: You can only install the CPU inside the socket in one direction with the handle at the top. Make sure that it is properly inserted into the CPU socket before closing the Rail Frame plate.
  • Page 30 AS-2113S-WN24RT User's Manual Screw 3 Screw 2 Screw 1 Figure 3-8. Securing the Force Frame 10. Secure the screws in the order 1-2-3, tightening each to 16.1 kgf-cm (14 lbf-in) of torque using a Torx T20 driver. The Force Frame secures both the Rail Frame and CPU Package.
  • Page 31 Chapter 3: Maintenance and Component Installation Un-installing the Processor and Heatsink 1. Remove the heatsink. 2. Clean the thermal grease left by the heatsink on the CPU package lid to limit the risk of it contaminating the CPU package land pads or contacts in the socket housing. 3.

  • Page 32: Memory Support And Installation

    AS-2113S-WN24RT User's Manual 3.4 Memory Support and Installation Note: Check the Supermicro website for recommended memory modules. Important: Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Memory Support The H11SSW-NT supports Up to 2 TB of ECC DDR4 2666 MHz speed, RDIMM/LRDIMM/3DS/ NVDIMM memory in sixteen slots.

  • Page 33: Dimm Module Population

    JUSB1 USB0/1 (3.0) USB2/3 Chapter 3: Maintenance and Component Installation (3.0) IPMI_LAN JM2_1 JM2_2 JPG1 JPB1 JUART3 JUART2 JUART1 JPL1 JSXB1B DIMM Module Population JCPLD1 JDBG1 JWD1 There is no specific order or sequence required when installing memory modules. However, PWR_OK JTPM1 microSD...

  • Page 34: Dimm Installation

    AS-2113S-WN24RT User's Manual DIMM Installation 1. Push the release tabs outwards on both ends of the DIMM slot to unlock it. 2. Align the key of the DIMM module with the receptive point on the memory slot. 3. Align the notches on both ends of the module against the receptive points on the ends of the slot.

  • Page 35: Pci Expansion Card Installation

    Chapter 3: Maintenance and Component Installation PCI Expansion Card Installation The AS-2113S-WN24RT can accommodate one low-profile add-on card in the PCI expansion slot on the serverboard. Installing Add-on Card 1. Begin by removing the shield for the PCI slot you wish to populate. Make sure that the card you are installing is supported by the slot.

  • Page 36: Motherboard Battery

    AS-2113S-WN24RT User's Manual Figure 3-13. Installing Riser Card to Bracket Motherboard Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Replacing the Battery Begin by removing power from the system as described in Section 3.1 and removing the...

  • Page 37: Chassis Components

    Chapter 3: Maintenance and Component Installation 3.5 Chassis Components Hard Drives Up to 24 hot-swap 2.5" hard drives are supported by the chassis. The hard drives are mounted in drive carriers to simplify their installation and removal from the chassis. (Both procedures may be done without removing power from the system.) Removing a Hot-Swap Drive Carrier 1.

  • Page 38: Hard Drive Carrier Indicators

    Figure 3-16. Mounting a Drive in a Carrier Figure 3-17. Installing a Drive Carrier into its Bay Note: Enterprise level hard disk drives are recommended for use in Supermicro chassis and servers. For information on recommended HDDs, visit the Supermicro website at http://www.

  • Page 39: Installing The Rear 2.5" Hard Drive--Sc216B Only

    Chapter 3: Maintenance and Component Installation Figure 3-18. Drive Bays: Logical Configuration Installing the Rear 2.5" Hard Drive--SC216B Only The SC216BTS model chassis supports an optional hard drive cage for two additional 2.5" hot-swappable hard drives. The hard drive cage installs in the rear of the chassis next to the power supply.
  • Page 40 AS-2113S-WN24RT User's Manual 3. Place the hard drive cage into the chassis. Secure the front of the hard drive cage to the chassis by fastening one screw inside the opening of the hard drive cage as illustrated. 4. Secure the top of the hard drive cage to the chassis frame with two screws, fastened at the upper edge of the hard drive cage above the opening of the hard drive cage.

  • Page 41: System Cooling

    Chapter 3: Maintenance and Component Installation System Cooling Three 8-cm hot-swap chassis fans provide the cooling for the AS-2113S-WN24RT. It is very important that the top cover of the chassis is properly installed in order for the cooling air to circulate properly through the chassis and cool the components.

  • Page 42: Air Shrouds

    AS-2113S-WN24RT User's Manual Air Shrouds Air shrouds concentrate airflow to maximize fan efficiency. The AS-2113S-WN24RT air shrouds do not require screws for installation. Installing the Main Air Shroud Begin by removing power from the system as described in Section 3.1.

  • Page 43: Installing An M.2 Solid State Drive

    Chapter 3: Maintenance and Component Installation Installing an M.2 Solid State Drive Note: There are some thermal limitations with M.2 drives. Please contact Supermicro Support before installing an M.2 device. The motherboard can accommodate an M.2 solid state drive (SSD). The M.2 socket supports NVMe PCI-E 3.0 x2 (32 Gb/s) SSD cards in the 2280 or 22110 form factors.

  • Page 44: Power Supply

    AS-2113S-WN24RT User's Manual Power Supply The AS-2113S-WN24RT has two redundant, hot-plug 1200 Watt power supplies. The power modules are hot-swappable, enabling them to be replaced without powering down the system. These power supplies are auto-switching capable, allowing them to automatically sense and operate at a 100v to 240v input voltage.
  • Page 45 Chapter 3: Maintenance and Component Installation Release Tab Figure 3-23. Replacing a Power Supply Module...

  • Page 46: Chapter 4 Motherboard Connections

    AS-2113S-WN24RT User's Manual Chapter 4 Motherboard Connections This section describes the connections on the motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A serverboard layout indicating component locations may be found in Chapter 1.

  • Page 47: Headers And Connectors

    It enables the motherboard to deny access if the TPM associated with the hard drive is not installed in the system. Please go to the following link for more information on TPM: http://www.supermicro.com/manuals/other/TPM.pdf. Trusted Platform Module Header...
  • Page 48 AS-2113S-WN24RT User's Manual Disk-On-Module Power Connector (JSD1 & JSD2) The Disk-On-Module (DOM) power connector at JSD1 provides 5V power to a solid-state DOM storage device connected to one of the SATA ports. See the table below for pin definitions. DOM Power...
  • Page 49 Chapter 4: Motherboard Connections USB Ports (USB0~USB4, USB 6/7) A total of seven USB ports are supported on the motherboard. Four are located on the back panel, USB 0/1, and USB 2/3 (both are USB 3.0 compliant). There are also three ports located on the motherboard, two are on one header, USB 6/7 (3.0) and the remaining one is on a 3.0 "Type A"...
  • Page 50 AS-2113S-WN24RT User's Manual Sensor Header (JSEN1) This header (JSEN1) allows BMC to monitor thermal inlet temperature. A special module is required. Please contact Supermicro to purchase the module for this header. Refer to the table below for pin definitions Intel Sensor Header...
  • Page 51 Chapter 4: Motherboard Connections Power SMB Header (PWRI2C) The Power System Management Bus (I2C) header monitors power supply, fan and system temperatures. See the table below for pin definitions. Power SMB Header Pin Definitions Pin# Definition Clock Data PWR Fail Ground +3.3V SGPIO Headers (SGPIO1, SGPIO2, SGPIO3)
  • Page 52 AS-2113S-WN24RT User's Manual 3.3V PWR LED 3.3V Stby HDD LED 3.3V Stby NIC1 Link LED 3.3V Stby NIC2 Link LED UID LED 3.3V Stby 3.3 V Power Fail LED Reset Reset Button Ground Power Button Ground Figure 4-1. JF1: Control Panel Pins Power Button The Power Button connection is located on pins 1 and 2 of JF1.
  • Page 53 Chapter 4: Motherboard Connections Power Fail LED The Power Fail LED connection is located on pins 5 and 6 of JF1. Refer to the table below for pin definitions. Power Fail LED Pin Definitions (JF1) Pins Definition 3.3V PWR Supply Fail UID LED The UID LED is on pins 7 and 8 of JF1.
  • Page 54 AS-2113S-WN24RT User's Manual NMI Button The non-maskable interrupt button header is located on pins 19 and 20 of JF1. Refer to the table below for pin definitions. NMI Button Pin Definitions (JF1) Pins Definition Control Ground Power LED The Power LED connection is located on pins 15 and 16 of JF1. Refer to the table below for pin definitions.

  • Page 55: Ports

    Chapter 4: Motherboard Connections 4.3 Ports Rear I/O Ports See the figure below for the locations and descriptions of the various I/O ports on the rear of the motherboard. Figure 2-1. I/O Port Locations and Definitions Rear I/O Ports Description Description Description COM Port...
  • Page 56 AS-2113S-WN24RT User's Manual Universal Serial Bus (USB) Ports There are four USB 3.0 ports (USB 0/1, 2/3) on the I/O back panel.. Back Panel USB 3.0 Port Pin Definitions Pin# Definition Pin# Definition VBUS Power USB 2.0 Differential Pair Ground...

  • Page 57: Jumpers

    Chapter 4: Motherboard Connections 4.4 Jumpers Explanation of Jumpers To modify the operation of the motherboard, jumpers are used to choose between optional settings. Jumpers create shorts between two pins to change the function associated with it. Pin 1 is identified with a square solder pad on the printed circuit board. See the motherboard layout page for jumper locations.
  • Page 58 AS-2113S-WN24RT User's Manual LAN1/2 Enable/Disable Change the setting of jumper JPL1 to enable or disable the LAN1 and LAN2 Ethernets ports.. The default setting is Enabled. LAN1/2 Enable/Disable Jumper Settings Jumper Setting Definition Pins 1-2 Enabled Pins 2-3 Disabled Watch Dog JWD controls the Watch Dog function.

  • Page 59: Led Indicators

    Chapter 4: Motherboard Connections 4.5 LED Indicators LAN Port LEDs The motherboard's Ethernet ports has two LED indicators. The Activity LED is green and indicates connection and activity. The Link LED may be green, orange/amber, or off to indicate the speed of the connection. Refer to the tables below for more information. Link LED, Connection Link, Speed Indicator Activity LED...
  • Page 60 AS-2113S-WN24RT User's Manual Onboard Power OK LED (LED6) LED6 is an onboard power OK LED. When this LED6 is lit, it means the system is turned on and all the system power rails are ready. When the system is turned off or any one of the system power rails fail, this LED will turn off.

  • Page 61: Chapter 5 Software

    You must first configure RAID settings (if using RAID) before you install the Windows OS and the software drivers. To configure RAID settings, please refer to the RAID Configuration User Guides posted on our website at www.supermicro.com/support/manuals. Installing the Windows OS for a RAID System 1.

  • Page 62: Driver Installation

    The Supermicro website contains drivers and utilities for your system at https://www. supermicro.com/wftp/driver. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard. Download this file to create a DVD of the drivers and utilities it contains.

  • Page 63: Superdoctor 5

    5.3 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 64: Chapter 6 Uefi Bios

    AS-2113S-WN24RT User's Manual Chapter 6 UEFI BIOS 6.1 Introduction This chapter describes the AMIBIOS™ Setup utility for the H11SSW-NT motherboard. The BIOS is stored on a chip and can be easily upgraded using a flash program. Note: Due to periodic changes to the BIOS, some settings may have been added or deleted and might not yet be recorded in this manual.

  • Page 65: Main Setup

    Note: The time is in the 24-hour format. For example, 5:30 P.M. appears as 17:30:00. The date's default value is 01/01/2015 after RTC reset. Supermicro H11SSW-NT BIOS Version This item displays the version of the BIOS ROM used in the system.
  • Page 66 AS-2113S-WN24RT User's Manual CPLD Version This item displays the CPLD version of the BIOS ROM used in the system. Memory Information Total Memory This item displays the total size of memory available in the system.

  • Page 67: Advanced

    Chapter 6: UEFI BIOS 6.3 Advanced Use the arrow keys to select Boot Setup and press <Enter> to access the submenu items. Warning: Take caution when changing the Advanced settings. An incorrect value, a very high DRAM frequency, or an incorrect DRAM timing setting may make the system unstable.
  • Page 68 AS-2113S-WN24RT User's Manual Bootup NumLock State Use this feature to set the Power on state for the <Numlock> key. The options are Off and On. Wait For "F1" If Error Use this feature to force the system to wait until the 'F1' key is pressed if an error occurs.
  • Page 69 Chapter 6: UEFI BIOS PSP Firmware Versions  This section displays the Platform Security Processor (PSP) firmware versions. PSP Directory Level 1 (Fixed) • PSP Recovery BL Ver • SMU FW Version • ABL Version • APCB Version • APOB Version •...
  • Page 70 AS-2113S-WN24RT User's Manual CPU Configuration  SMT Mode Use this setting to specify Simultaneous Multithreading. Options include Off for 1T single thread and Auto for 2T two-thread if your system is capable of it. Core Performance Boost This setting is used to configure for Core Performance Boost. Options include Auto and Disabled.
  • Page 71 Chapter 6: UEFI BIOS NB Configuration  Determinism Slider Use this setting to configure the Determinism Slider. Options include Auto, Power and Performance. cTDP Control Use this setting to configure the cTDP Control. Options include Manual and Auto. IOMMU Use this setting to enable/disable IOMMU. Options include Enabled, Disabled and Auto. ACS Enable Use this setting to enable/disable ACS.
  • Page 72 AS-2113S-WN24RT User's Manual CPU1 Memory Information  These sections are for informational purposes. They will display some details about the detected memory according to each CPU on the motherboard, such as: • Detected Size (per slot, in MB) • Current Speed (MT/s) ACPI Settings ...
  • Page 73 Chapter 6: UEFI BIOS Change SOL Settings This feature specifies the base I/O port address and the Interrupt Request address of a serial port specified by the user. Select Auto to allow the BIOS to automatically assign the base I/O and IRQ address. The options are Auto, (IO=2F8h; IRQ=3;); (IO=3F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;);...
  • Page 74 AS-2113S-WN24RT User's Manual Parity A parity bit can be sent along with regular data bits to detect data transmission errors. Select Even if the parity bit is set to 0, and the number of 1's in data bits is even. Select Odd if the parity bit is set to 0, and the number of 1's in data bits is odd.
  • Page 75 Chapter 6: UEFI BIOS Console Redirection Settings Terminal Type This feature allows the user to select the target terminal emulation type for Console Redirection. Select VT100 to use the ASCII Character set. Select VT100+ to add color and function key support. Select ANSI to use the Extended ASCII Character Set. Select VT-UTF8 to use UTF8 encoding to map Unicode characters into one or more bytes.
  • Page 76 AS-2113S-WN24RT User's Manual Recorder Mode Select Enabled to capture the data displayed on a terminal and send it as text messages to a remote server. The options are Disabled and Enabled. Resolution 100x31 Select Enabled for extended-terminal resolution support. The options are Disabled and Enabled.
  • Page 77 Chapter 6: UEFI BIOS  Console Redirection Settings Out-of-Band Mgmt Port The feature selects a serial port in a client server to be used by the Microsoft Windows Emergency Management Services (EMS) to communicate with a remote host server. The options are COM1, COM2 (Disabled), and AMT SOL.
  • Page 78 AS-2113S-WN24RT User's Manual SR-IOV Support If the system has SR-IOV capable PCI-E devices, this setting will Enable or Disable the Single Root IO Virtualization Support for the system. PCIe Spread Spectrum Use this setting to Enable or Disable PCI-E Spread Spectrum for your system.
  • Page 79 Chapter 6: UEFI BIOS Onboard LAN2 Option ROM Use this setting to select which firmware function is to be loaded for onboard LAN2 on the system. Options include Disabled and Legacy. NVMe0~NVMe23 OPROM Use this setting to select which firmware is to be loaded for the specified NVMe OpROM on the system.
  • Page 80 AS-2113S-WN24RT User's Manual SATA Configuration This section displays the detected SATA devices installed on the system. ASMedia SATA Controller This setting enables or disables the on chip SATA controller. The options are Enabled, Disabled or Auto. Hot Plug This setting enables or disables the on chip SATA hot plug feature. The options are Enabled, Disabled.

  • Page 81: Ipmi

    Chapter 6: UEFI BIOS 6.4 IPMI This tab allows you to configure the following IPMI settings for the system. Use this feature to configure Intelligent Platform Management Interface (IPMI) settings. BMC Firmware Revision This item indicates the IPMI firmware revision used in your system. IPMI Status (Baseboard Management Controller) This item indicates the status of the IPMI firmware installed in your system.
  • Page 82 AS-2113S-WN24RT User's Manual Erasing Settings Erase SEL Select Yes, On next reset to erase all system event logs upon next system reboot. Select Yes, On every reset to erase all system event logs upon each system reboot. Select No to keep all system event logs after each system reboot. The options are No, Yes, On next reset, and Yes, On every reset.
  • Page 83 Chapter 6: UEFI BIOS Station IP Address This item displays the Station IP address for this computer. This should be in decimal and in dotted quad form. Subnet Mask This item displays the sub-network that this computer belongs to. The value of each three- digit number separated by dots should not exceed 255.

  • Page 84: Event Logs

    AS-2113S-WN24RT User's Manual 6.5 Event Logs This tab allows the user to configure the following event logs settings for the system. Change SMBIOS Event Log Settings  This feature allows the user to configure SMBIOS Event settings. Enabling/Disabling Options SMBIOS Event Log Select Enabled to enable SMBIOS (System Management BIOS) Event Logging during system boot.
  • Page 85 Chapter 6: UEFI BIOS When Log is Full Select Erase Immediately to immediately erase all errors in the SMBIOS event log when the event log is full. Select Do Nothing for the system to do nothing when the SMBIOS event log is full. The options are Do Nothing and Erase Immediately. SMBIOS Event Log Standard Settings Log System Boot Event Select Enabled to log system boot events.

  • Page 86: Security

    AS-2113S-WN24RT User's Manual 6.6 Security This tab allows you to configure the following security settings for the system. Administrator Password Press Enter to create a new, or change an existing Administrator password. Note that if the Administrator Password is erased, the User Password will be cleared as well.
  • Page 87 Chapter 6: UEFI BIOS Secure Boot This option allows you specify when the Platform Key (PK) is enrolled. When enabled, the System Mode is user deployed, and the CSM function is disabled. Options include Enabled and Disabled. Secure Boot Mode Use this item to select the secure boot mode.
  • Page 88 AS-2113S-WN24RT User's Manual Append Key Select Yes to add the KEK from the manufacturer's defaults list to the existing KEK. Select No to load the KEK from a file. The options are Yes and No.  Authorized Signatures Set New Key Select Yes to load the database from the manufacturer's defaults.

  • Page 89: Boot

    Chapter 6: UEFI BIOS 6.7 Boot Use this tab to configure Boot Settings: Boot Mode Select Use this item to select the type of device that the system is going to boot from. The options are LEGACY, UEFI, and DUAL. The default setting is DUAL. Legacy to EFI Support This option Enables or Disables the system to boot to an EFI OS after the boot failed from the legacy boot order.
  • Page 90 AS-2113S-WN24RT User's Manual  UEFI Application Boot Priorities This feature allows the user to specify which UEFI devices are boot devices. • UEFI Boot Order #1  NETWORK Drive BBS Priorities This feature allows the user to specify which UEFI network drive devices are boot devices.

  • Page 91: Save & Exit

    Chapter 6: UEFI BIOS 6.8 Save & Exit Select the Save & Exit tab to enter the Save & Exit BIOS Setup screen. Discard Changes and Exit Select this option to quit the BIOS Setup without making any permanent changes to the system configuration, and reboot the computer.
  • Page 92 AS-2113S-WN24RT User's Manual Default Options Restore Defaults To set this feature, select Restore Defaults from the Save & Exit menu and press <Enter>. These are factory settings designed for maximum system stability, but not for maximum performance. Save as User Defaults To set this feature, select Save as User Defaults from the Exit menu and press <Enter>.

  • Page 93: Bios Update Using Ipmi

    6.9 BIOS Update Using IPMI If necessary, the system BIOS can be updated using IPMI. Documentation on IPMI is available at http://www.supermicro.com/products/nfo/IPMI.cfm. 1. Download the BIOS file using the link on the server web page. Unzip and save it. 2. Access the IPMI web interface. Enter the IP address and log in. The default username and password are ADMIN/ADMIN.
  • Page 94 AS-2113S-WN24RT User's Manual Start Button Clear Checkboxes Verify Date Figure 6-3. Start Upgrade Dialog 6. In the Start Upgrade dialog, make sure the three checkboxes are not checked, and verify the date of the BIOS file you uploaded before proceeding.

  • Page 95: Appendix A Bios Codes

    When BIOS performs the Power On Self Test, it writes checkpoint codes to I/O port 0080h. If the computer cannot complete the boot process, a diagnostic card can be attached to the computer to read I/O port 0080h (Supermicro p/n AOC-LPC80-20). For information on AMI updates, please refer to http://www.ami.com/products/.

  • Page 96: Appendix B Standardized Warning Statements For Ac Systems

    Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 97 Appendix B: Standardized Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
  • Page 98 AS-2113S-WN24RT User's Manual . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬...
  • Page 99 Appendix B: Standardized Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
  • Page 100 AS-2113S-WN24RT User's Manual Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
  • Page 101 Appendix B: Standardized Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告...
  • Page 102 AS-2113S-WN24RT User's Manual ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ ‫انطاقت قبم‬ ‫انىصىل إىن امنناطق انداخهيت نههيكم نتثبيج أو إ ز انت مكىناث الجهاز‬ 경고! 시스템에 부품들을 장착하거나 제거하기 위해서는 섀시 내부에 접근하기 전에 반드시 전원...
  • Page 103 Appendix B: Standardized Warning Statements Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !‫אזהרה‬ .‫צוות מוסמך בלבד רשאי להתקין, להחליף את הציוד או לתת שירות עבור הציוד‬ ‫واملدربيه...
  • Page 104 AS-2113S-WN24RT User's Manual Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial,...
  • Page 105 Appendix B: Standardized Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
  • Page 106 AS-2113S-WN24RT User's Manual ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제...
  • Page 107 Appendix B: Standardized Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
  • Page 108 AS-2113S-WN24RT User's Manual Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
  • Page 109 Appendix B: Standardized Warning Statements ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
  • Page 110 AS-2113S-WN24RT User's Manual ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다. Waarschuwing Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.
  • Page 111 Appendix B: Standardized Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 112 AS-2113S-WN24RT User's Manual Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
  • Page 113 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
  • Page 114 ‫.قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح‬ ‫ لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحي‬UL ‫ وأ‬CSA ‫( ةمالع لمحت يتلاو‬UL/CSA) ‫ لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عم‬Supermicro.
  • Page 115 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...

  • Page 116: Appendix C System Specifications

    AS-2113S-WN24RT User's Manual Appendix C System Specifications Processors Single EPYC 7000 series processor in an SP3 socket Note: Please refer to the motherboard specifications pages on our website for updates to supported processors. Chipset SoC chipset BIOS 128 Mb SPI AMI BIOS Flash EEPROM ®...
  • Page 117 Appendix C: System Specifications Regulatory Compliance Electromagnetic Emissions: FCC Class A, EN 55032 Class A, EN 61000-3-2/3-3, CISPR 32 Class A Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11) Safety: CSA/EN/IEC/UL 60950-1 Compliant, UL or CSA Listed (USA and Canada), CE Marking (Europe) Other: VCCI-CISPR 32 and AS/NZS CISPR 32 Environmental: Directive 2011/65/EU and Directive 2012/19/EU...

  • Page 118: Appendix D Uefi Bios Recovery

    Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update.
  • Page 119 USB flash drive with FAT16 or FAT32 format and rename the file to SUPER.ROM. Note: If you cannot locate the "SUPER.ROM" file in your driver disk, visit our website at www.supermicro.com to download the correct BIOS image into a USB flash device and rename it "SUPER.ROM".
  • Page 120 SUPERMICO BIOS Update: https://www.youtube.com/watch?v=S8z6iOEHGwY * If the BIOS flash recovery fails, contact our RMA Department to have the BIOS chip reprogrammed. This will require shipping the board to Supermicro for repair. Submit your RMA request at https://www.supermicro.com/support/rma Please make sure to follow all instructions when returning the motherboard.
