I N S T A L L A T I O N
Universal Pitch-Adjustable Wall Mount
For Flat Panel Display PLP-91/D
Your new Wall Mount (PLP-91/D) is a quick disconnect
mounting system with adjustability between 0 and
15 degrees pitch. The optional lateral shift bracket
(PAC-125) allows 4" lateral shift on either side of a 16"
center stud or spans a 24" on center stud system.
Once the Universal Flat Panel Display Wall Mount
Bracket is attached to your display, simply attach the
mount securely on a wall, lock the display in place using
the convenient Q-latch, and attach your audio/video
cables.
The PLP-91/D is virtually invisible when your display is
mounted.
BEFORE YOU BEGIN
• Caution: To prevent damage to the PLP-91/D, which could affect or void the Factory warranty, and to the equipment
that will be attached to it, thoroughly study all instructions and illustrations before you begin the installation. Pay par-
ticular attention to the "Important Warnings and Precautions" on Page 1.
• The mount is designed to be installed using wall studs or supporting framework. The fasteners used to anchor the mount must
be capable of supporting five times the total weight of the equipment.
• The maximum weight to be installed on the Universal Pitch-Adjustable Wall Mount is 125 pounds (56.7 Kg).
I N S T R U C T I O N S
Secures Display
Sony Electronics Inc. 8805-000087
1 Sony Drive
Park Ridge, NJ 07656
201-930-1000
www.sony.com/displaysystems
Can Be Used to
Lock Display
Advertisement
Related Manuals for Sony PLP-91/D
Summary of Contents for Sony PLP-91/D
-
Page 1: Before You Begin
BEFORE YOU BEGIN • Caution: To prevent damage to the PLP-91/D, which could affect or void the Factory warranty, and to the equipment that will be attached to it, thoroughly study all instructions and illustrations before you begin the installation. Pay par- ticular attention to the “Important Warnings and Precautions”... -
Page 2: Table Of Contents
Installation Instructions IMPORTANT WARNINGS AND PRECAUTIONS! WARNING: A WARNING alerts you to the possibility of serious injury or death if you do not follow the instructions. CAUTION: A CAUTION alerts you to the possibility of damage or destruction of equipment if you do not follow the corre- sponding instructions. -
Page 3: Dimensional Drawing
Installation Instructions 1 9/16" 11/16" 15 3/4" 2" INTERFACE BRACKETS ADD APPROXIMATELY 1/2" TO DEPTH 16" 10 1/2" 8" 5/16" DIMENSIONAL DRAWING Pitch-Adjustable Mount PLP91/D Tighten this screw to lock tilt in place 1 5/16" 17" 1 1/2"... -
Page 4: Install Mount
Installation Instructions INSTALL MOUNT Install the mount as follows: Determine the exact mounting location prior to installation and draw a level line to indicate the desired height for the top of the mounting plate. WARNING: Improper installation can result in serious per- sonal injury! Make sure that the structural framework can support a weight factor five times the total weight of the equipment. -
Page 5: Parts
Installation Instructions PARTS Description MOUNT FLAG, Extended SCREW, 10-24X1/2, FH WASHER, Nylon Table 1: Parts NUT, Nylock, 10-24 FLAG, Locking SCREW, 10-24X1/2, Phillips Pitch-Adjustable Mount PLP91/D Description... - Page 6 PLUS THE EQUIPMENT BEING MOUNTED. IF IT CANNOT SUPPORT THIS WEIGHT, THE STRUCTURE MUST BE REINFORCED. THE MAXIMUM WEIGHT TO BE INSTALLED ON THE MOUNT IS 125 POUNDS (56.7 KG). Figure 2 Figure 3 Sony Electronics Inc. 8805-000185 1 Sony Drive Park Ridge, NJ 07656 201-930-1000 www.sony.com/displaysystems...
- Page 7 2. Place Nylon spacers over mounting holes on back of screen. 3. Attach mounting brackets to the display using the M5 screws for 32” screen or M6 for 42” and 50” screens (see Figure 4 & Figure 5). With the aid of another person, lift your display up to the mount, aligning buttons of mounting brackets with slots in the mount.
