Sony CMT-M70K Specifications

SERVICE MANUAL
Ver 1.0 2002.02
• CMT-M70/M70K are composed of following models.
As for the service manual, it is issued for each component model,
then, please refer to them.
COMPONENT MODEL NAME
COMPACT DISC DECK
RECEIVER SYSTEM
SPEAKER SYSTEM
SPECIFICATIONS
Power requirements
North American model: 120 V AC, 60 Hz
European model: 230 V AC, 50/60 Hz
Mexican model: 120 V AC, 60 Hz
Australian model: 230 V AC, 50/60 Hz
Thailand model: 220 V AC, 50/60 Hz
Other model: 110 - 120 V or 220 - 240 V AC, 50/60 Hz
Adjustable with voltage selector
Power consumption
European model: See the nameplate
0.5 W (in the standby mode)
Other model: See the nameplate
Dimensions (w/h/d): Approx. 159
parts and controls
Mass: Approx. 4.5 kg
Supplied accessories: Remote Commander (1)
AM loop antenna (1)
FM wire antenna (1)
Batteries (2)
Design and specifications are subject to change without notice.
Sony Corporation
9-873-632-01
2002B0500-1 Home Audio Company
C 2002.02 Published by Sony Engineering Corporation
CMT-M70/M70K
CMT-M70 CMT-M70K
HCD-M70
SS-CM70
217 315 mm incl. projecting
ACCESSORIES
Part No. Description
1-477-239-11 REMOTE COMMANDER (RM-S171)
1-501-374-11 ANTENNA, LOOP (AM)
1-501-659-61 ANTENNA (FM) (M70:US, CND, MX, SP, TH)
1-754-060-11 ANTENNA (FM) (M70:AEP, UK, AUS/M70K)
0 1-569-008-21 ADAPTOR, CONVERSION 2P (M70:SP)
4-230-866-01 COVER (BATTERY) (for RM-S171)
4-239-398-11 OPERATING INSTRUCTIONS (ENGLISH)
4-239-398-21 OPERATING INSTRUCTIONS (FRENCH, SPANISH)
4-239-398-31 OPERATING INSTRUCTIONS (FRENCH)
4-239-398-41 OPERATING INSTRUCTIONS (SPANISH) (M70:MX)
4-239-398-51 OPERATING INSTRUCTIONS (GERMAN, DUTCH,
4-239-398-61 OPERATING INSTRUCTIONS
4-239-399-11 OPERATING INSTRUCTIONS (DANISH, FINNISH)
4-239-399-21 OPERATING INSTRUCTIONS (PORTUGUESE)
4-239-399-31 OPERATING INSTRUCTIONS (RUSSIAN) (M70:AEP)
4-239-400-11 OPERATING INSTRUCTIONS (GREEK) (M70:AEP)
4-239-400-21 OPERATING INSTRUCTIONS (HUNGARIAN, CZECH)
4-239-400-31 OPERATING INSTRUCTIONS (TURKISH) (M70:AEP)
4-239-400-41 OPERATING INSTRUCTIONS (SLOVAKIAN)
4-240-943-11 OPERATING INSTRUCTIONS (KOREAN) (M70K)
4-240-943-21 OPERATING INSTRUCTIONS (ENGLISH, THAI)
Abbreviation
AUS : Australian model
CND : Canadian model
MX : Mexican model
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
MICRO Hi-Fi COMPONENT SYSTEM
US Model
Canadian Model
AEP Model
UK Model
Australian Model
CMT-M70
E Model
CMT-M70/M70K
Remark
(M70:US, CND, AEP, UK, AUS, SP)
(M70:AEP, SP)
(M70:US, CND)
ITALIAN, SWEDISH, POLISH) (M70:AEP)
(TRADITIONAL CHINESE) (M70:SP)
(M70:AEP)
(M70:AEP)
(M70:AEP)
(M70:AEP)
(M70:TH)
SP : Singapore model
TH : Thai model
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
