Emerson KTM OM-2 GRATITE Installation And Operation Manual

KTM OM-2 GRATITE
INSTALLATION AND OPERATION MANUAL
Before installation these instructions must be fully read and understood
Please read through this manual completely
before operating the valves.
OM-2 Gratite Seat Ball Valves are usable for toxic
or high temperature/high pressure fluid.
Please use the valves according to warnings and
cautions described in this document. Failure to
do so could result in an accident due to wrong
storage, installation, operation, maintenance and
disassembling and/or serious damage.
Please keep this manual in a handy place for
immediate reference; be sure to provide it to
purchaser, contractor, piping designer, user,
operator or maintenance technician.
SELECTION GUIDE
Example:
Valve codes
EB11 ASME 150 EB12 ASME 300
JIS10K
JPI 150
Sub-codes
G
Gratite Seat
Body codes
31 32
CF8 / SCS13A
Trim codes
CC Standard trim materials
Flange codes
A15 J10
ASME 150
A30 J20
ASME 300
Size
15 mm ~ 200 mm (½" ~ 8")
Emerson.com/FinalControl
SEAT BALL VALVES
®
The contents of this manual is effective as of
August 2007.
KTM reserves the right to discontinue the
manufacture of, change or modify design
and/or construction of any KTM product during
the manufacturing procedure, without incurring
any obligation to accept for credit, to replace or
furnish or install such changes or modifications
on products previously or subsequently sold.
This document is subject to changes without
notice.
1 SAFETY PRECAUTIONS
Precautions for using KTM valves safely are
highlighted with the following two warning
signs according to the level of danger posed.
Please read the postscript carefully to ensure
safety and prevent any damage before starting
to use the product.
WARNING
A potentially hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION
A potentially hazardous situation which, if not
avoided, may result in minor or moderate injury.
EB11 G
JIS20K
JPI 300
62
CF8M / SCS14A WCB / SCPH2
P013 JPI 150
JIS10K
P033 JPI 300
JIS20K
© 2017 Emerson. All Rights Reserved.
31 CC A15 15
VCIOM-02453-EN 19/04
