LASER product. This marking is located on the rear exterior. Notice for the customer in the countries applying EU Directives The manufacturer of this product is Sony Corporation, 1-7-1 Konan, Minato-ku, Tokyo, 108-0075 Japan. The Authorized Representative for EMC and product safety is Sony Deutschland GmbH, Hedelfinger Strasse 61, 70327 Stuttgart, Germany.
Page 3
CD standard and may not be playable by this product. “WALKMAN” and “WALKMAN” logo are registered trademarks of Sony Corporation. MICROVAULT is a trademark of Sony Corporation. ATRAC, ATRAC3, ATRAC3plus and their logos are trademarks of Sony Corporation.
Table of Contents Guide to parts and controls ... 5 Information on the display ... 9 Getting Started Hooking up the system securely ...10 Setting the clock ...12 Basic Operations Playing a CD/MP3 disc ...13 Listening to the radio ...14 Listening to music of an USB device ...15 Using optional audio...
Guide to parts and controls This manual mainly explains operations using the remote, but the same operations can also be performed using the buttons on the unit having the same or similar names. Unit Front panel Top panel Continued...
Page 6
Remote / (power) button (page 12, 21, Press to turn on the system. STANDBY indicator (page 18, 22) Lights up when the system is turned off. USB MEMORY indicator Lights up when an optional USB device (Digital music player or USB storage media) is connected.
Page 7
Unit: CD (play/pause) button (page 13) Press to select the CD function. Press to start or pause playback of a disc. Remote: CD button (page 13) Press to select the CD function. Remote: (play) button, (pause) button Press to start or pause playback.
Page 8
REPEAT/FM MODE button (page 13, 15, 16) Press to listen to a disc, a single track or file repeatedly. Press to select the FM reception mode (monaural or stereo). Battery compartment lid (page 11) CLEAR button (page 19) Press to delete a pre-programmed track or file.
Information on the display Play/Pause Tuner reception mode (page 14) Tuner reception (page 14) DSGX (page 18) Text information Audio format Play mode (page 13, 16) Timer (page 21) DAB service reception Lights up when secondary service is received.
Getting Started Hooking up the system securely DAB external antenna (not supplied) Right speaker Left speaker FM/DAB lead antenna (Extend it horizontally.) Connect white side. 75-ohm coaxial cable with F male type connector (not supplied) White side for North American model ...
Page 11
DAB antenna With a DAB external antenna (not supplied), you can obtain higher DAB broadcast sound quality. We recommend that you use the supplied FM/DAB lead antenna only temporarily until you install a DAB external antenna. When carrying this system Remove a disc to protect the CD mechanism.
To run the DAB Automatic Scan When you turn on the system for the first time after you purchase the system, DAB Automatic Scan starts automatically and creates a list of available services. If you want to run the DAB Automatic Scan again, perform the procedure below.
Basic Operations Playing a CD/MP3 disc Select the CD function. Press CD Place a disc. Press on the unit, and place a disc with the label side up on the disc tray. To close the disc tray, press the unit again.
Notes on playing MP discs Do not save other types of files or unnecessary folders on a disc that has MP3 files. Folders that have no MP3 files are skipped. MP3 files are played back in the order that they are recorded onto the disc.
To reduce static noise on a weak FM stereo station Press FM MODE repeatedly until “MONO” appears to turn off stereo reception. Notes on listening to DAB stations When tuning in a DAB station, it may take a few seconds before you hear any sound.
Page 16
Select the USB function. Press USB Connect an optional USB device (Digital music player or USB storage media) to the port as shown below. USB device (Digital music player or USB storage media) When USB cable connection is necessary, connect the USB cable supplied with the USB device to be connected.
Notes on the USB device Do not connect the system and the USB device through a USB hub. With some connected USB devices, after an operation is performed, there may be a delay before it is performed by this system. ...
Adjusting the sound To add a sound effect Press Generate a DSGX more dynamic sound (Dynamic Sound Generator X-tra) Set the sound effect to select “BASS” or “TREBLE, ” and then press +/ repeatedly to adjust the level. Changing the display Change information on ...
Other Operations Creating your own program (Program Play) Use buttons on the remote to create your own program. Select the desired function. Press CD to select the CD function. Press USB to select the USB function. Press PLAY MODE repeatedly until “PGM”...
Presetting radio stations You can preset your favorite radio stations and tune them in instantly by selecting the corresponding preset number. Use buttons on the remote to preset stations. Tune in the desired station (see “Listening to the radio” (page 14)).
Using the Timers The system offers two timer functions. If you use the Play Timer with the Sleep Timer, the Sleep Timer has priority. Sleep Timer: You can fall asleep to music. This function works even if the clock is not set.
Find your problem in the checklist below, and take the indicated corrective action. If the issue persists, contact your nearest Sony dealer. If the STANDBY indicator flashes Immediately unplug the power cord, and check the following items. If your system has a voltage...
Page 23
(USB) port . Make sure there is no problem with the USB device. If this display pattern persists, contact your nearest Sony dealer. There is no sound. The USB device is not connected correctly. Turn off the system, then...
Page 24
USB cable to avoid picking up noise. Connect a commercially available external antenna. Consult your nearest Sony dealer if the supplied AM antenna has come off the plastic stand. Turn off nearby electrical equipment.
Complete!: The preset operation ended normally. Invalid: You pressed an invalid button. LOCKED: The disc tray does not open. Contact your nearest Sony dealer. No Disc: There is no disc in the system, or you have loaded a disc that cannot be played.
USB device ATRAC AD: An ATRAC Audio Device is connected. Error: The USB device could not be recognized or an unknown device is connected. Invalid: You have made an invalid or currently prohibited operation. No Device: No USB device is connected or the connected USB device has been stopped.
Page 27
On safety Completely disconnect the power cord (mains lead) from the wall socket (mains) if it is not going to be used for an extended period of time. When unplugging the unit, always grip the plug. Never pull the cord itself. ...
Specifications Main unit Amplifier section DIN power output (rated): 40 + 40 watts (6 ohms at 1 kHz, DIN) Continuous RMS power output (reference): 50 + 50 watts (6 ohms at 1 kHz, 10% THD) Music power output (reference): 50 + 50 watts (6 ohms at 1 kHz, 10% THD) Inputs: AUDIO IN (stereo mini jack): voltage 250 mV, impedance...
Playable USB devices You can play back the following Sony USB devices on this system. Other USB devices cannot be played back on this system. Verified Sony digital music player (as of January 2007) Product name Model name ® NW-E103 / E105 /...
