SERVICE MANUAL
Ver 1.0 2003. 06
• CMT-HP7 is composed of following models.
As for the service manual, it is issued for each component
model, then, please refer to them.
COMPONENT MODEL NAME
COMPACT DISK DECK
RECEIVER SYSTEM
SPEAKER SYSTEM
SPECIFICATIONS
General
Power requirements
North American model:
120 V AC, 60 Hz
European and Russian models:
230 V AC, 50/60 Hz
Australian model:
230 – 240 V AC, 50/60 Hz
Argentine model:
220 V AC, 50/60 Hz
Mexican model:
120 V AC, 60 Hz
Saudi Arabian model:
120 – 127/220 or 230 – 240
V AC, 50/60 Hz
Adjustable with voltage
selector
Other models:
120 V, 220 V or 230 – 240
V AC, 50/60 Hz
Adjustable with voltage
selector
Power consumption
European and Russian models:
100 watts
0.35 watts (at the Power
Saving Mode)
Other models:
100 watts
Dimensions (w/h/d)
Approx. 199 252 400
mm
Mass
Approx. 7.0 kg
Supplied accessories:
Remote Commander (1)
Batteries (2)
AM loop antenna (1)
FM lead antenna (1)
Speaker pads (8)
Design and specifications are subject to change
without notice.
Sony Corporation
9-877-348-01
2003F16-1
Home Audio Company
© 2003.06
Published by Sony Engineering Corporation
CMT-HP7
HCD-HP7
SS-CHP7
×
×
CMT-HP7
PARTS LIST
Part No.
Description
ACCESSORIES
************
1-477-716-11 COMMANDER, STANDARD(RM-SRG440)
1-501-374-72 ANTENNA, LOOP (AM)
1-754-243-11 ANTENNA (FM)(US, CND)
1-793-184-22 CONNECTOR (F TYPE ADAPTOR)(FM)
4-228-953-01 COVER, BATTERY (FOR RM-SRG440)
4-246-667-11 MANUAL, INSTRUCTION (ENGLISH)
4-246-667-21 MANUAL, INSTRUCTION (FRENCH)(CND)
4-246-667-31 MANUAL, INSTRUCTION (FRENCH, SPANISH)
4-246-667-41 MANUAL, INSTRUCTION (GERMAN, DUTCH, ITALIAN)(AEP)
4-246-667-51 MANUAL, INSTRUCTION (SWIDISH, POLISH)(AEP)
4-246-667-61 MANUAL, INSTRUCTION (TRADITIONAL CHINESE)(E3, TW)
4-246-667-71 MANUAL, INSTRUCTION (KOREAN)(KR)
4-246-667-81 MANUAL, INSTRUCTION (RUSSIAN)(RU)
4-247-352-11 MANUAL, INSTRUCTION (ENGLISH, THAI)(TH)
4-972-322-01 FOOT (Y)
• Abbreviation
AUS : Australian model.
CND : Canadian model.
E2
: 120 V AC area in E model.
E3
: 240 V AC area in E model.
KR : Korean model.
MX : Mexican model.
RU : Russian model.
TH : Thai model.
TW : Taiwan model.
MICRO HI-FI COMPONENT SYSTEM
US Model
Canadian Model
AEP Model
UK Model
E Model
Australian Model
Remark
(AEP, UK, RU, E2, E3, KR, TW, TH, MX, AUS)
(US, CND, AEP, UK, RU, E2, E3, TW, AUS)
(AEP, E2, E3, MX)
