2. M.2 slot
The M.2 slot allows you to install M.2 devices such as M.2 SSD modules.
• For 3 Gen AMD Ryzen™ Processors:
rd
‑ M .2_1 supports PCIE 4.0 x4 and SATA mode M Key design and type 2242 / 2260 /
2280 storage devices.
‑ M .2_2 supports PCIE 4.0 x4 and SATA mode M Key design and type 2242 / 2260 /
2280 / 22110 storage devices.
• For 2
nd
Graphics Processors:
‑ M .2_1 supports PCIE 3.0 x4 and SATA mode M Key design and type 2242 / 2260 /
2280 storage devices.
‑ M .2_2 supports PCIE 4.0 x4 and SATA mode M Key design and type 2242 / 2260 /
2280 / 22110 storage devices.
The M.2 SSD module is purchased separately.
ROG CROSSHAIR VIII FORMULA
Gen AMD Ryzen™ / 2 and 1
nd
Gen AMD Ryzen™ with Radeon™ Vega
st
1-17
