Related Manuals for Kodak PPS800
Summary of Contents for Kodak PPS800
- Page 1 KODAK Portable Power Station ppS800 user manual please read this manual carefully before operating the product. please keep this manual with you for further reference.
-
Page 2: Table Of Contents
CONTENTS Set includeS introduction Safety inStructionS tranSportation Get to know your kodak ppS800 wall charGinG 6.1. pV (Solar panel) charGinG 6.2. diSplay technical SpecificationS uSinG the kodak ppS800 troubleShootinG frequently aSked queStionS (faq) StoraGe and downtime maintenance SerVice life of lithium ion batterieS... -
Page 3: Set Includes
1. SET INCLUDES Item Quantity kodak portable power Station ppS800 ac charger user manual user manual Portable Power Station ppS800... -
Page 4: Introduction
(ip32). with 756 watt-hours of stored energy, you can keep appliances, or electronic devices running for hours. the kodak ppS800 portable power Station is designed to keep you powered up while travelling in your rV, during emergencies involving power outages, or camping with the family at the lake. -
Page 5: Safety Instructions
2. SAFETY INSTRUCTIONS observe these instructions to ensure safe usage. Explanation of symbols this symbol together with noncompliance may very likely lead DANGER means to serious injury or death. this symbol together with noncompliance may lead WARNING means to serious injury or death. this symbol together with noncompliance may lead CAUTION means... - Page 6 DANGER Do NOT disassemble, repair or modify the unit or the battery. doing so may result in electric shock, fire, etc. Do NOT place the unit close to or in a fire or expose it to heat. Keep out of direct sunlight. doing so may result in fire or injuries.
- Page 7 WARNING Use and store the unit only in a clean and dry environment. Do not use and store in dusty and wet environment. failure to do so may result in a short circuit, smoke or fire if metal dust or small metallic parts come in contact with the connections.
- Page 8 CAUTION if rust, peculiar odors, overheating or other abnormal circumstances are observed, stop using the unit immediately and contact the dealer or our customer service center. The unit complies with all legal requirements for transport of dangerous goods. the capacity of the lithium battery pack in the unit exceeds 100 wh. based on international standards: if this unit is to be sent by airplane, it must be transported in accordan- ce with iata standard packaging.
-
Page 9: Transportation
4. TRANSPORTATION 1. Carry the unit using the handle on top of the product. ATTENTION ATTENTION keep the unit away from take extra care to ensure that the unit is never other objects when moving. allowed to fall to the ground. 2. -
Page 10: Get To Know Your Kodak Pps800
5. GET TO KNOW YOUR KODAK PPS800 Button and connector explanations a. on/off switch b. lcd screen c. wall charging port d. Solar charging port e. uSb ports cigarette lighter port G. 6mm ports (dc6514) h. ac power switch ac indicator ac output (type f) k. -
Page 11: Wall Charging
6. WALL CHARGING before use or storage, plug your kodak ppS800 into the wall until it is fully charged. if the display shows less than 20% capacity, plug it into a power source, like an ac outlet or a solar panel as soon as possible. -
Page 12: Technical Specifications
7. TECHNICAL SPECIFICATIONS General Information rated battery capacity 756wh (25.2V, 30ah) weight 7,6 kg (16.7 lbs) 349 x 160 x 285 mm | 13.7 x 6.3 x 11.2 inch dimensions operating temperature -10 - 55 °c (14 - 131 °f) at 10-90% relative humidity Suitable storage temperature 0 - 40 °c (32 - 113 °f) international protection class... -
Page 13: Using The Kodak Pps800
LED Flashlight kodak ppS800 has an integrated led flashlight. it has 5 lighting modes: high bright (100% power), eco mode (50% power), energy saving mode (25% power), emergency flash and SoS signal. -
Page 14: Troubleshooting
(total loads ~500w) please turn off kodak ppS800 over temperatue protection and restart after cooling down please send back to the dealer/... -
Page 15: Frequently Asked Questions (Faq)
2. How do I know if my KODAK PPS800 is charged? to check the charge level of your kodak ppS800, refer to the digital indicator display. the battery icon indicates the battery status of total charge remaining. kodak ppS800 can be used until it is empty but we recommend to recharge when the level is below 20%. -
Page 16: Storage And Downtime Maintenance
Gasoline, thinner, kerosene, petroleum, etc. have the characteristics of solvents. Do not use. 4. Failure failure to maintain your kodak ppS800 by following these steps can result in battery damage which will void the product warranty. 12. SERVICE LIFE OF LITHIUM ION BATTERIES Charge, supply current between -10 - 55 °C (14 - 131 °F). -
Page 17: Disposal And Recycling
13. DISPOSAL AND RECYCLING Lithium ion battery as soon as the end of the battery‘s service life is reached, the entire lithium ion battery can be recycled. do not open or disassemble the unit. Electric device old electric devices may not be disposed together with normal household waste. according to the directive 2012/19/eu, the device must be disposed of in a controlled manner at the end of its service life. -
Page 18: Warranty And Customer Service
14. WARRANTY AND CUSTOMER SERVICE Contact distributor for technical support / customer service europe [Gbt Gmbh] an Gut nazareth 18a telephone: e-mail: 52353 düren +49 (0) 2421 / 20 85 60 info@gbt-international.com Germany uSa/canada [delta millenium inc.] 216 route 206 Suite 1 toll-free: e-mail: hillsborough, nJ 08844... - Page 20 © 2019 Gbt Gmbh an Gut nazareth 18a, 52353 düren, Germany | phone: 02421 / 20856-0 the kodak trademark, logo and trade dress are used under license from kodak. all information contained in this document is subject to change without notice.
