COMPONENTS INCLUDED IN 0G4141E
1
0F1823CST03
1
ENCL H/G CONTROL PANEL
2
0F1824AST03
1
COVER CONTROL PANEL
3
0F2606
1
HINGE CONTINUOUS H-PANEL
4
036261
7
RIVET POP .125 X .275 SS
5
0F5763
1
ASSY PROGRAMMED H-100
6
0F1732
1
DECAL FUSES LOCATED INSIDE
7
0E9764
1 FT.
RAIL SNAPTRACK PCB HOLDER BULK
8
0F1958
1
PLATE HARNESS CLAMP
9
0F2256
1
ASSY PCB PWR AVR W/AMP HEADER
10
029673
1
DIO BRIDGE 25A 600V
11
049226
5
WASHER LOCK M5
12
079224
2
SCREW PPHM M5-0.8 X 30 SS
13
051713
5
WASHER FLAT M5
14
0F5886
2
SCREW HHPM M5-0.8 X 12
15
043182
1
WASHER LOCK M3
16
051714
1
NUT HEX M3-0.5 G8 YEL CHR
17
052777
1
WASHER FLAT M3
18
051716
3
NUT HEX M5-0.8 G8 CLEAR ZINC
19
043180
3
WASHER FLAT M4
20
0C3990
3
SCREW PHTT M4-0.7 X 10 ZYC
21
0F4333
1
CONN DUST CAP W/CHAIN DB9
22
0F5883
1
WASHER FLAT M3.5
23
0F5884
1
SCREW PHTT M3.5-0.6 X 10
24
055014
10
SCREW PPHM M4-0.7 X 8 BLK OX
25
022264
10
WASHER LOCK #8-M4
26
0G3546
1
DECAL WRN BATT CHRG 12/24V BI
27
0F5752A
1
RES WW 10R 5% 15W QK CONN
28
0G3648
1
M5-0.8 CAPTIVE PANEL KNLD HD
29
0F6305
2
SEAL COVER 3.18 X 12.7 X 382
30
0F6305A
1
SEAL COVER 3.18 X 12.7 X 283
31
0G4329
1
HARNESS H-PNL INTEGRATED SW (NOT SHOWN)
COMPONENTS INCLUDED IN WIRE HARNESS
A
0F1263
1
ADPTR RH SIDE WICKMANN 178.6191
B
0F1262
4
HOLDER FUSE WICKMANN 178.6150
C
0F1264
1
ADPTR LH SIDE WICKMANN 178.6192
D
0E9049B
2
ASSY PCB G-PANEL RELAY 12VDC
E
055911
1
BLOCK TERM 20A 12 X 6 X 1100V
COMPONENTS NOT INCLUDED IN 0G4141E OR WIRE HARNESS
50
056739
1
RELAY CONTACTOR 12VDC
51
022287
2
SCREW HHC 1/4-20 X 3/4 G5
52
022473
4
WASHER FLAT 1/4-M6 ZINC
53
022097
2
WASHER LOCK M6-1/4
54
022127
2
NUT HEX 1/4-20 STEEL
55
0E7403B
1
FUSE ATO TYPE 10 AMP (RED)
56
0E7403C
1
FUSE ATO TYPE 15 AMP (BLUE)
57
0F7473
1
DECAL H-100 RELAY BD 12V RB1
58
0J7646
1
DECAL CONTROL BOX FUSES
59
0F5461
1
DECAL CPL 5.4/6.8L TB3
60
0C2323
2
SCREW PHTT #6-32 X 5/8 ZYC
61
0C2699
2
SCREW PHTT #6-32 X 3/8 ZYC
62
0F6145
A/R
SEAL WEATHER .45" DIA
63
0F2627
1
PLATE COVER H PANEL
64
049226
4
WASHER LOCK M5
65
051713
4
WASHER FLAT M5
66
091526
4
SCREW PPHM M5-0.8 X 12 ZNC
67
-
REF.
DPE BREAKER SEE DRAWING 0F9280
68
043182
REF.
WASHER LOCK M3
69
051714
REF.
NUT HEX M3-0.5 G8 YEL CHR
70
052777
REF.
WASHER FLAT M3
71
-
REF.
BOOST RESISTOR SEE DRAWING 0F9280
72
0E3161
1
ASSY PCB BOSCH GOV DRIVER
73
036939
2
SCREW PPHM #10-32 X 1-1/4
74
023897
2
WASHER FLAT #10 ZINC
75
022152
2
WASHER LOCK #10
76
022158
2
NUT HEX #10-32 STEEL
