Page 2: Specifications
Overview: The GS2065 provides primary or backup GSM/GPRS communication for the PC9155 2-way wireless security suite Specifications: Dimensions : 3.937"x5.875"x0.625" (100mmx150mmx15mm) Weight : 68 g Input Voltage : 10 to 13.8 V (from the PC-Link header) Current Draw : 100 mA at 12V (400 mA during the GSM transmission) - Page 3 Overview: The TL265GS is an Internet and GSM/GPRS Dual-Path alarm communicator for the PC9155 2-way wireless security suite Specifications: Dimensions : 3.937"x5.875"x0.75" (100mmx150mmx18mm) Weight : 78 g Input Voltage : 10 to 13.8 V (from the PC-Link header) Current Draw : 100 mA at 12V (400 mA during the GSM transmission) Operating Environment : 40 to 104 F (5 to 40 C) Features: Fully redundant Internet and GSM/GPRS dual-path alarm communication...
-
Page 4: Summary Of Installation Steps
Batteries for WT5500 2-way wireless keypad Screwdriver Prior to installing a GS2065 and TL265GS, contact your monitoring station to determine if it is a master reseller or visit www.connect24.com and become an authorized dealer. In both instances, you will acquire a Profile Number, Installer ID Number and an Installer Password. - Page 5 Step 1 – Initialize an account via Connect 24 Website (www.connect24.com) Login to Connect 24 website by using Installer ID and Password and initialize an account Select Profile Number Select Product Module Enter SIM card number Enter DNIS number (if necessary) Enter Account Code Select Supervisory Type (if necessary) Enable DHCP (if necessary)
- Page 6 Step 1 – 1 Select Profile Number Select Profile...
- Page 7 Step 1 – 2 Select Product Module Select Module Number...
- Page 8 Step 1 – 3 Enter SIM card number Enter SIM Number...
- Page 9 Step 1 – 4 Enter DNIS number (if necessary) Enter Account Code Select Supervisory Type (if necessary) Enable DHCP (if necessary) Note: If DHCP is not selected, manual entries of the IP Address, Subnet Mask Address and Gateway Address are required (next page). Enter DNIS Enter Account Code DHCP Option...
- Page 10 Step 1 – 5 (only available if DHCP is not selected) Enter IP Address (TL265GS only) Enter Subnet Mask Address (TL265GS only) Enter Gateway Address (TL265GS only) IP Address Subnet Mask Gateway...
- Page 11 Step 1 – 4 Select Rate Plan Rate Plan...
- Page 12 Step 2 – Install and wire the communicator to the control panel (on-site) GS2065/TL265GS: See details in product manual for PC9155 control panel...
- Page 13 Step 3 – Load the programming and test for best signal strength location Ensure the SIM card is inserted Power up the control panel The communicator will be programmed by loading the pre-programmed configuration from Connect 24 automatically Check Green LEDs. You must achieve full or medium signal strength. See details in product manual If signal strength is poor, must relocate the control panel or use an external extension antenna kits...
- Page 14 Step 4 – Program communication options on the control panel via keypad GS2065/TL265GS with PC9155 control panel [301], [302], [303], [305] Program Communication Path • DCAA - Internal (Ethernet 1, Ethernet 2, GPRS 1, GPRS 2) • DCBB - Ethernet Receiver 1 •...
- Page 15 Step 5 – Test communicator 1. Disconnect incoming phone line from TIP and RING on the control panel 2. Verify that LED 2 is on, this indicate that the unit is active 3. Create an alarm transmission 4. Verify alarm transmission by calling monitoring station 5.
- Page 16 Communicator Controlled Call Routing – Backup (dual-path) – Redundant (dual-path) Required Programming Panel Sections [301], [302],[303] and [305] •Any of them could be programmed as DCAA Communicator Sections [005] Option [4] ‐ Primary and backup path [ON]: GPRS path primary, Ethernet path backup [OFF]: Ethernet path primary, GPRS path backup Option [5] ‐...
- Page 17 Backup Mode 2: Ethernet Primary, 2 Receivers TX 1 Ethernet Receiver 1 IP Receiver 1 Ethernet Receiver 2 Tx 1 failed, Tx2 Tx 2 failed, TX3 GPRS Receiver 1 IP Receiver 2 Tx 3 failed, Tx4 GPRS Receiver 2 Backup Mode 3: GPRS Primary, 4 Receivers Tx 2 failed, TX3 Ethernet Receiver 1...
- Page 18 Backup Mode 4: GPRS Primary, 2 Receivers Ethernet Receiver 1 Tx 2 failed, TX3 IP Receiver 1 Ethernet Receiver 2 TX 1 GPRS Receiver 1 Tx 3 failed, Tx4 IP Receiver 2 GPRS Receiver 2 Tx 1 failed, Tx2 Redundant Mode 1: 4 Receivers –...
- Page 19 Redundant Mode 2: 2 Receivers – (Redundancy between GSM/GPRS path and Ethernet/Internet path) Ethernet Receiver 1 TX 1, Ethernet path IP Receiver 1 Ethernet Receiver 2 TX1, GPRS path GPRS Receiver 1 TX1 failed, TX 2 via Ethernet path IP Receiver 2 GPRS Receiver 2 TX 1 failed, TX 2 via GPRS path...
- Page 20 PC9155 Panel Controlled Call Routing Backup (triple‐path) Panel section [383] – Options [2],[3] and [4] enabled Panel section [380], Option [6] disabled Redundant (triple‐path) Panel sections [351] – [376] Options enabled Alternate (triple‐path) Panel section [380] – Option [6] enabled Required Programming Panel Sections [301], [302],[303] and [305] •...
- Page 21 PC9155 Panel Controlled Call Routing –Redundant: Panel Sections [351] – [376] Options enabled TX 1 Example Phone Line path Phone Line Receiver 1 [301] [301] 1‐800‐xxxxxxx 1‐800‐xxxxxxx TX 1 Ethernet Receiver 1 IP Receiver 2 [302] [302] D C B B D C B B [303] [303]...
