- Page 1 CLIMATE CONTROL IBIS4 IB36H401RI, IB36H401RIY Air conditioning roof unit Installation Manual...
-
Page 3: Table Of Contents
IBIS4 Explanation of symbols Original instructions Please read this instruction manual carefully before installation and start-up, and store it in a safe place. If you pass on the device to another person, hand over this instruction manual along with it. Table of contents Explanation of symbols . -
Page 4: Safety And Installation Instructions
Safety and installation instructions IBIS4 Safety and installation instructions Please observe the prescribed safety instructions and stipulations from the vehicle manufacturer and service workshops. The manufacturer accepts no liability for damage in the following cases: • Faulty assembly or connection •... -
Page 5: Target Group For This Instruction Manual
IBIS4 Target group for this instruction manual • Do not make any alterations or conversions to the device. • Never drive through automatic car washes when the roof air conditioner is mounted. • If faults occur in the refrigerant circuit, the system must be checked by a spe- cialist company and repaired properly. -
Page 6: Scope Of Delivery
Scope of delivery IBIS4 Scope of delivery No. in Quantity Description fig. 1 Roof air conditioner Roof plate Air distribution box (ADB) ADB centre cover Duct sections Cable connectors Long fastening bolts Remote control (with batteries) Accessories Available as accessories (not included in the scope of delivery): Description Duct section Additional duct sections to allow fitment to thicker roof... -
Page 7: Intended Use
IBIS4 Intended use Intended use The IBIS4 air conditioner is designed for installation on the roof of a caravan or recreational vehicle to provide reverse cycle heating and cooling. The device is intended for vehicles with roofs that are from 20 to 100 mm thick. The device must be installed so that it is within ±10°... -
Page 8: Installation
Installation IBIS4 Installation CAUTION! Beware of injury The roof air conditioner may only be installed by qualified personnel. The fol- lowing information is intended for technicians who are familiar with the guide- lines and safety precautions to be applied. Note on installation Read this installation manual completely before installing the roof air conditioner. - Page 9 IBIS4 Installation Note on transport • Pay attention to the orientation of the up arrows on the carton. Do not install the unit if it has been upside down for any period of time (fig. 4 A). • Always have someone help you carry the roof air conditioner. •...
- Page 10 Installation IBIS4 • Make sure no combustible objects are stored or installed near the air outlet. A distance of at least 50 cm should be kept. • Make sure that there are no objects within the vehicle which could obstruct the attachment of the air outlet unit or the cooled air from flowing through the swivelling air distribution nozzles.
- Page 11 IBIS4 Installation Making a new opening 1112 See fig. 5 ➤ Select an area at the centre on the roof between two longitudinal supports. ➤ Mark the position and size of the opening (preferably 400 x 400 mm or optionally 360 x 360 mm). See fig.
- Page 12 Installation IBIS4 See fig. 7 ➤ Before installation, check whether the roof hole needs reinforcing. ➤ If needed, remove the foam according to the width of your reinforcing rails (not in scope of delivery) (A). ➤ Fit the reinforcing rails (B). ➤...
- Page 13 IBIS4 Installation See fig. 8 ➤ Remove all screws and fixtures of the existing roof hatch or air conditioner. ➤ Take out the roof hatch or air conditioner. See fig. 9 ➤ Remove the sealant around the opening using a scraper or similar tool.
- Page 14 Installation IBIS4 See fig. 0 NOTICE! Observe the sealant manufacturer’s instructions. ➤ Seal the screw holes and recesses with a flexible non-hardening butyl sealing compound (e.g. SikaLastomer-710, Selleys Butyl Mastic, Bostik ezycaulk butyl sealant, or similar products). Laying the connecting cables DANGER! Danger of electrocution Make sure there is no voltage at electrically operated components before car- rying out work on them!
- Page 15 IBIS4 Installation See fig. b ➤ Orientate roof frame based on opening size. ➤ Fit the roof frame into the roof opening ➤ Seal around the roof frame with flexible non-hardening butyl sealing com- pound (e.g. SikaLastomer-710, Selleys Butyl Mastic, Bostik ezycaulk butyl sealant, or similar products).
- Page 16 Installation IBIS4 Attaching the roof air conditioner See fig. d ➤ Use the corners of the front of the base pan to help align the unit with the roof plate.
- Page 17 IBIS4 Installation Electrical connection ye/gn ye/gn AC-N AC-L COMU bk wh ye/gn ye/gn ye/gn ye/gn Item Description 220 – 240 Vw mains Evaporator plate Communication wire Heatsink metal net Condenser plate Reversing valve Inverter compressor Fan evaporator Fan condenser Out air sensor Evaporator sensor Condenser sensor Discharge sensor...
- Page 18 Installation IBIS4 See fig. f Mains voltage cable ➤ Connect the roof air conditioner with the mains voltage supply. Connect the cables (1) to a cable connector (2). Communication cable ➤ Pull out the filter slightly to create a gap for the communication cable (3). ➤...
- Page 19 IBIS4 Installation See fig. g ➤ Stack the duct sections and place against the roof thickness: the duct height should match the roof height. Or use the below table as a guide: Roof thickness Number of duct sections 18 – 28 mm 28 –...
- Page 20 Installation IBIS4 A 2.5±0.3 Nm See fig. h NOTICE! Risk of damage Tighten to the specified torque. Do not overtighten! ➤ Tighten the screws using a torque spanner and a fastening torque of 2.5 Nm ±0.3 Nm. Communication cable ➤ Connect the communication 4 pin plug into the socket on the side of the display (2) in the ADB.
-
Page 21: Technical Data
IBIS4 Technical data Technical data Contains fluorinated greenhouse gases. Hermetically sealed equipment. IBIS4 IB36H401RI, IB36H401RIY Compressor capacity: 3600 W Cooling capacity based on ISO 5151: 2625 W Heating capacity based on ISO 5151: 3017 W Rated input voltage: 220 – 240 Vw/ 50 Hz Rated current in cooling mode: 6.9 A Rated current in heating mode:... - Page 24 YOUR LOCAL YOUR LOCAL YOUR LOCAL DEALER SUPPORT SALES OFFICE dometic.com/dealer dometic.com/contact dometic DOMETIC GROUP AB...
