Page 1: Phone
QUICK GUIDE BASIC FUNCTION AUDIO/VISUAL SYSTEM VOICE COMMAND SYSTEM INFORMATION PERIPHERAL MONITORING SYSTEM PHONE NAVIGATION SYSTEM Toyota Entune APPENDIX/INDEX About the following equipment, see the “OWNER’S MANUAL”.  Fuel consumption  Vehicle customization settings C-HR_Navi_USA_OM10581U_17CY...
Page 2 Keep this manual in your vehicle at all times. The screens shown in this manual may differ from the actual screen of the sys- tem depending on availability of functions, Toyota Entune subscription status, and map data available at the time this manual was produced.
Page 3 Please be aware that all current vehicle navigation systems have certain limita- tions that may affect their ability to perform properly. The accuracy of the vehi- cle’s position depends on satellite conditions, road configuration, vehicle condition or other circumstances. For more information on the limitations of the system, refer to page 253.
Page 4 IMPORTANT INFORMATION ABOUT THIS MANUAL For safety reasons, this manual indicates items requiring particular attention with the following marks. WARNING ● This is a warning against anything which may cause injury to people if the warning is ignored. You are informed about what you must or must not do in order to reduce the risk of injury to yourself and others.
Page 5 HOW TO READ THIS MANUAL Name Description Operational An outline of the operation is explained. Outlines Main Operations The steps of an operation are explained. Related Operations A main operation’s supplementary operations are described. Information Useful information for the user is described. C-HR_Navi_USA_OM10581U_17CY...
Page 6 SAFETY INSTRUCTION SAFETY INSTRUCTION (ENTUNE AUDIO/ENTUNE (ENTUNE PREMIUM AUDIO) AUDIO PLUS) To use this system in the safest possible manner, follow all the safety tips shown To use this system in the safest possible below. manner, follow all the safety tips shown below.
Page 7 While driving, listen to the voice instruc- WARNING tions as much as possible and glance at the screen briefly and only when it is safe. ● For safety, the driver should not operate However, do not totally rely on voice guid- the system while he/she is driving.
Page 8: Table Of Contents
TABLE OF CONTENTS 2. CONNECTIVITY SETTINGS ... 43 QUICK GUIDE REGISTERING/CONNECTING A ® Bluetooth DEVICE ......43 1. BASIC FUNCTION......12 ® SETTING Bluetooth DETAILS ..... 48 BUTTONS OVERVIEW ......12 ® Wi-Fi Hotspot ........57 “Menu” SCREEN........14 Apple CarPlay™........61 HOME SCREEN ........
Page 9 VOICE COMMAND SYSTEM PHONE 1. VOICE COMMAND SYSTEM 1. PHONE OPERATION OPERATION ........ 126 (HANDS-FREE SYSTEM FOR CELLULAR PHONES) ....156 VOICE COMMAND SYSTEM....126 QUICK REFERENCE ......156 NATURAL LANGUAGE UNDERSTANDING......130 SOME BASICS ........157 COMMAND LIST ......... 131 PLACING A CALL USING ®...
Page 10 TYPE C: FUNCTION ACHIEVED BY USING DCM ........265 STARTING ROUTE GUIDANCE ..220 2. Toyota Entune OPERATION ..267 3. ROUTE GUIDANCE....... 225 Toyota Entune App Suite Connect ..267 ROUTE GUIDANCE SCREEN .... 225 TYPICAL VOICE GUIDANCE 3. SETUP........... 271 PROMPTS......... 231 Toyota Entune App Suite Connect ROUTE OPTIONS OPERATION ..
Page 11: Quick Guide
QUICK GUIDE BASIC FUNCTION 1. BUTTONS OVERVIEW ....12 2. “Menu” SCREEN ......14 3. HOME SCREEN ......16 STATUS DISPLAY......... 18 QUICK REFERENCE 1. “Setup” SCREEN ......20 NAVIGATION OPERATION 1. REGISTERING HOME ....22 2. REGISTERING FAVORITE DESTINATIONS ......23 3.
Page 12: Basic Function
1. BASIC FUNCTION 1. BUTTONS OVERVIEW BG051S C-HR_Navi_USA_OM10581U_17CY...
Page 13 Press to display the home screen. 16, 35 : This function is not made available in some countries or areas. : The Toyota Entune App Suite Connect screen may not be displayed when an Apple CarPlay connection is established. : Entune Premium Audio only...
Page 14: Menu" Screen
1. BASIC FUNCTION 2. “Menu” SCREEN Press the “MENU” button to display the “Menu” screen. Entune Audio/Entune Audio Plus Entune Premium Audio C-HR_Navi_USA_OM10581U_17CY...
Page 15 Select to display the destination screen. : This function is not made available in some countries or areas. : The Toyota Entune App Suite Connect screen may not be displayed when an Apple CarPlay connection is established. : The clock is not displayed on the screen for this vehicle. The clock is displayed on the instru- ment panel.
Page 16: Home Screen
1. BASIC FUNCTION 3. HOME SCREEN Press the “HOME” button to display the home screen. Multiple screens, such as the audio/visual system screen and hands-free screen, can be displayed simultaneously on the home screen. Selecting a screen will display it full screen. The home screen can be set to a four- way split screen, a three-way split screen or a two-way split screen.
Page 17 1. BASIC FUNCTION Three-way split screen Two-way split screen C-HR_Navi_USA_OM10581U_17CY...
Page 18: Status Display
1. BASIC FUNCTION STATUS DISPLAY ® The condition of the Bluetooth connection, as well as the level of cellular phone reception, the amount of cellular phone battery charge left, etc., are displayed on the status display. Icon Indicators Conditions (Gray) (Blue) No connection Poor...
Page 19 1. BASIC FUNCTION Icon Indicators Conditions Poor Excellent  The level of reception does not always correspond with the level displayed on the cellular phone. The level of reception may not The level of be displayed depending on the phone you have. reception When the cellular phone is out of the service area or in a place (Phone)
Page 20: Quick Reference
2. QUICK REFERENCE 1. “Setup” SCREEN Press the “MENU” button, then select “Setup” to display the “Setup” screen. The items shown on the “Setup” screen can be set. Entune Audio/Entune Audio Plus Entune Premium Audio C-HR_Navi_USA_OM10581U_17CY...
Page 21 ® Select to set Wi-Fi connection settings. 1, 2 Select to set Toyota Entune App Suite Connect settings. Select to set memory points (home, favorites entries, areas to avoid), 236, 243 or navigation details. Select to set traffic information settings.
Page 22: Navigation Operation
3. NAVIGATION OPERATION 1. REGISTERING HOME* Vehicles without a smart key system Search for your home. There are different kinds of methods to Turn the engine switch to the search for your home. (P.210) “ACC” or “ON” position. Vehicles with a smart key system Select “Enter”.
Page 23: Registering Favorite Destinations
3. NAVIGATION OPERATION 2. REGISTERING FAVORITE DESTINATIONS* Vehicles without a smart key system Select “OK”. Registration of favorite destinations is Turn the engine switch to the complete. “ACC” or “ON” position. Registering favorite destinations in a dif- Vehicles with a smart key system ferent way P.238 Turn the engine switch to AC-...
Page 24: Operation Flow: Route Guidance
3. NAVIGATION OPERATION 3. OPERATION FLOW: ROUTE GUIDANCE* Press the “MAP” button. BG052S Select Search for a destination. There are different kinds of methods to search for a destination. (P.210) Select “Go”. Select “OK”. Selecting routes other than the one recom- mended.
Page 25: Setting Home As The Destination
3. NAVIGATION OPERATION 4. SETTING HOME AS THE DESTINATION* Vehicles without a smart key system Turn the engine switch to the “ACC” or “ON” position. Vehicles with a smart key system Turn the engine switch to AC- CESSORY or IGNITION ON mode. Press the “MAP”...
Page 26: Function Index
4. FUNCTION INDEX 1. FUNCTION INDEX Map* Displaying maps Page Viewing the map screen Displaying the current position Viewing the current position vicinity map Changing the scale Changing the map orientation Displaying map options operation Displaying the estimated travel/arrival time to the destination Selecting the map mode Displaying traffic information Searching for destinations...
Page 27 4. FUNCTION INDEX Useful functions Information Page Displaying vehicle maintenance* Hands-free system (for cellular phone) Page ® Registering/connecting a Bluetooth phone ® Placing a call using the Bluetooth hands-free system ® Receiving a call using the Bluetooth hands-free system Voice command system Page Operating the system with your voice Peripheral monitoring system...
Page 28 C-HR_Navi_USA_OM10581U_17CY...
Page 29: Basic Function
BASIC FUNCTION ® 2. SETTING Bluetooth DETAILS ... 48 BASIC INFORMATION BEFORE ® Bluetooth SETTINGS SCREEN... 48 OPERATION ® CONNECTING A Bluetooth DEVICE ..........49 1. INITIAL SCREEN ......30 ® REGISTERING A Bluetooth 2. TOUCH SCREEN GESTURES ..32 DEVICE ..........
Page 30: Basic Information Before Operation
1. BASIC INFORMATION BEFORE OPERATION 1. INITIAL SCREEN Vehicles without a smart key system MAINTENANCE When the engine switch is turned to the INFORMATION* “ACC” or “ON” position, the initial screen will be displayed and the system will begin This system reminds users when to re- operating.
Page 31 1. BASIC INFORMATION BEFORE OPERATION RESTARTING THE SYSTEM When system response is extremely slow, the system can be restarted. Press and hold the “POWER/VOLUME” knob for 3 seconds or more. BG053S C-HR_Navi_USA_OM10581U_17CY...
Page 32: Touch Screen Gestures
1. BASIC INFORMATION BEFORE OPERATION 2. TOUCH SCREEN GESTURES Operations are performed by touching the touch screen directly with your finger. Operation method Outline Main use Touch Quickly touch and release Selecting an item on the screen once. BG058S Drag* Touch the screen with ...
Page 33: Touch Screen Operation
1. BASIC INFORMATION BEFORE OPERATION 3. TOUCH SCREEN OPERATION This system is operated mainly by the INFORMATION buttons on the screen. (Referred to as ● If the system does not respond to touch- screen buttons in this manual.) ing a screen button, move your finger away from the screen and then touch it again.
Page 34 1. BASIC INFORMATION BEFORE OPERATION Vehicles without a smart key system CAPACITIVE TOUCH SCREEN  If a capacitive touch screen button is BUTTONS being touched when the engine switch is turned to the “ACC” or “ON” position, the The operable areas of the capacitive button may not operate properly.
Page 35: Home Screen Operation
1. BASIC INFORMATION BEFORE OPERATION 4. HOME SCREEN OPERATION Check that “Customize Home Screen” On the home screen, multiple screens, is displayed. such as the audio/visual system screen and hands-free screen, can be displayed simultaneously. Press the “HOME” button. Check that the home screen is dis- played.
Page 36: Entering Letters And Numbers/List Screen Operation
1. BASIC INFORMATION BEFORE OPERATION 5. ENTERING LETTERS AND NUMBERS/LIST SCREEN OPERATION When searching by an address, name, Function etc., or entering data, letters and num- Select to change character types. bers can be entered via the screen. Select to enter characters in lower case or in upper case.
Page 37: List Screen
1. BASIC INFORMATION BEFORE OPERATION DISPLAYING PREDICTIVE LIST SCREEN TEXT CANDIDATES The list screen may be displayed after When text is input, the system predicts entering characters. the text that may complete the current- ly unconfirmed text and displays pre- DISPLAYING THE LIST dictive replacement candidates that match the beginning of the text.
Page 38 1. BASIC INFORMATION BEFORE OPERATION ■ SELECTING ALL ITEMS LIST SCREEN OPERATION Some lists contain “Select All”. If “Se- When a list is displayed, use the appro- lect All” is selected, it is possible to priate screen button to scroll through select all items.
Page 39 1. BASIC INFORMATION BEFORE OPERATION SORTING SEACHING A LIST The order of a list displayed on the Items are displayed in the list with the screen can be sorted in the order of most similar results of the search at the distance from the current location, top.
Page 40: Screen Adjustment
1. BASIC INFORMATION BEFORE OPERATION 6. SCREEN ADJUSTMENT The contrast and brightness of the INFORMATION screen display and the image of the ● When the screen is viewed through camera display can be adjusted. The polarized sunglasses, a rainbow pattern screen can also be turned off, and/or may appear on the screen due to optical changed to either day or night mode.
Page 41 1. BASIC INFORMATION BEFORE OPERATION ADJUSTING THE CONTRAST/ BRIGHTNESS The contrast and brightness of the screen can be adjusted according to the brightness of your surroundings. Select “General” or “Camera”. Select the desired item.  “Display (General)” screen only: Select “<” or “>” to select the desired dis- play.
Page 42: Display And The System
1. BASIC INFORMATION BEFORE OPERATION 7. LINKING MULTI-INFORMATION DISPLAY AND THE SYSTEM* The following functions of the system are linked with the multi-information display in the instrument cluster: • Phone • Navigation • Audio etc. These functions can be operated using multi-information display control switches on the steering wheel.
Page 43: Connectivity Settings
2. CONNECTIVITY SETTINGS ® 1. REGISTERING/CONNECTING A Bluetooth DEVICE Select “Yes” to register a phone. ® REGISTERING A Bluetooth PHONE FOR THE FIRST TIME To use the hands-free system, it is ® necessary to register a Bluetooth phone with the system. Once the phone has been registered, it is possible to use the hands-free sys- tem.
Page 44 2. CONNECTIVITY SETTINGS  A PIN-code is not required for SSP INFORMATION (Secure Simple Pairing) compatible ® ● If a cellular phone does not operate Bluetooth devices. Depending on the properly after being connected, turn the ® type of Bluetooth device being con- cellular phone off and on and then con- nected, a message confirming registra-...
Page 45: Registering A Bluetooth Audio Player For The First Time
2. CONNECTIVITY SETTINGS Select “Yes” to register an audio play- ® REGISTERING A Bluetooth AUDIO PLAYER FOR THE FIRST TIME Follow the steps in “REGISTERING A ® Bluetooth PHONE FOR THE FIRST ® TIME” from “STEP 5”. (P.43) To use the Bluetooth Audio, it is nec- essary to register an audio player with the system.
Page 46: Profiles
® the Bluetooth device function may not work properly. ● Refer to http://www.toyota.com/Entune/ in the United States, http://www.toyota.ca/entune in Canada, and http://www.toyotapr.com/entune in Puerto Rico, to find approved ® Bluetooth phones for this system.
Page 47 2. CONNECTIVITY SETTINGS Bluetooth is a registered trademark of Bluetooth SIG, Inc. C-HR_Navi_USA_OM10581U_17CY...
Page 48: Details
2. CONNECTIVITY SETTINGS ® 2. SETTING Bluetooth DETAILS Press the “MENU” button. ® Bluetooth SETTINGS SCREEN BG054S Select “Setup”. Function Page Select “Bluetooth”. ® Connecting a Bluetooth device and editing the Select the desired item to be set. 49, 52 ®...
Page 49: Connecting A Bluetooth Device
: Phone playback. ® ● Depending on the type of Bluetooth : Audio player device being connected, it may be nec- essary to perform additional steps on : Phone/Toyota Entune App Suite the device. ® ● When disconnecting Bluetooth Connect device, it is recommended to disconnect ...
Page 50 2. CONNECTIVITY SETTINGS ■ ® ■ AUTO CONNECTION MODE CONNECTING A Bluetooth VICE IN A DIFFERENT WAY To turn auto connection mode on, set From the phone top screen “Bluetooth Power” to on. (P.54) P.158 ® Leave the Bluetooth device in a loca- ®...
Page 51: Registering A Bluetooth Device
2. CONNECTIVITY SETTINGS ■ CONNECTING MANUALLY ® REGISTERING A Bluetooth DEVICE When the auto connection has failed or “Bluetooth Power” is turned off, it is ® Up to 5 Bluetooth devices can be reg- ® necessary to connect the Bluetooth istered.
Page 52: Deleting A Bluetooth ® Device
2. CONNECTIVITY SETTINGS ® ® DELETING A Bluetooth EDITING THE Bluetooth DEVICE DEVICE INFORMATION ® Display Bluetooth settings ® The Bluetooth device’s information screen. (P.48) can be displayed on the screen. The displayed information can be edited. Select “Remove Device”. ®...
Page 53 2. CONNECTIVITY SETTINGS CHANGING A DEVICE NAME Information ® The name of the Bluetooth device. Select “Device Name”. Can be changed to a desired name. (P.53) Enter the name and select “OK”. ® Select to set the Bluetooth audio INFORMATION player connection method.
Page 54: Setting Bluetooth ® System
2. CONNECTIVITY SETTINGS ® CHANGING “Bluetooth Power” SETTING Bluetooth SYSTEM Select “Bluetooth Power”. ® The Bluetooth settings can be con- When “Bluetooth Power” is on: firmed and changed. Vehicles without a smart key system ® Display Bluetooth settings ® The Bluetooth device is automatically screen.
Page 55 2. CONNECTIVITY SETTINGS ® ■ CHANGING Bluetooth DEVICE SETTING AUTOMATIC AUTOMATIC CONNECTION PRIOR- CONNECTION PRIORITY The automatic connection priority of Select “Preferred Phones” or “Pre- ® the registered Bluetooth devices can ferred Audio Players”. be changed. ® Select the desired Bluetooth device Select “Preferred Device Settings”.
Page 56 2. CONNECTIVITY SETTINGS EDITING THE SYSTEM Function INFORMATION Displays system name. Can be changed to a desired name. (P.56) Select “System Information”. ® PIN code used when the Bluetooth Select the desired item to be set. device was registered. Can be changed to a desired code.
Page 57: Wi-Fi ® Hotspot
Hotspot service subscription from Verizon Wire- ® Enable the Wi-Fi Hotspot function. less is required. Contact your Toyota dealer for details. (P.57) • This function is not made available in Enable the “Hide Access Point” func- some countries or areas.
Page 58 Hotspot function is enabled, the system checks for a valid Hotspot service subscription. If a Hotspot service subscription has not been started, start the Toyota En- tune App Suite Connect application to activate the service subscription. (If the Function Page...
Page 59 2. CONNECTIVITY SETTINGS CHECKING/CHANGING THE CHANGING THE ACCESS PASSWORD POINT NAME (SSID) Select “Password”. Select “Access Point Name”. Check that the following screen is dis- Enter the desired access point name played. (SSID) and select “OK”. ® SELECTING A Wi-Fi CONNECTION CHANNEL Select “Channel”.
Page 60: Wi-Fi Function Operating Hints
2. CONNECTIVITY SETTINGS ® Wi-Fi FUNCTION INFORMATION OPERATING HINTS ® ● Wi-Fi is a registered mark of the Wi-Fi ® Alliance ● If a connected device is taken out of the WARNING ® Wi-Fi connection area, the connection will be severed. ®...
Page 61: Apple Carplay
2. CONNECTIVITY SETTINGS 4. Apple CarPlay* Press the “MENU” button. Apple CarPlay allows some applica- tions, such as Map, Phone, and Music, to be used on the system. When an Apple CarPlay connection is established, Apple CarPlay compatible applications will be displayed on the system display.
Page 62  Use of the Apple CarPlay logo means that • Bluetooth phone a vehicle user interface meets Apple per- • Toyota Entune App Suite Connect formance standards. Apple is not respon- sible for the operation of this vehicle or its compliance with safety and regulatory standards.
Page 63: Troubleshooting
2. CONNECTIVITY SETTINGS TROUBLESHOOTING If you are experiencing difficulties with Apple CarPlay, check the following table. Symptom Solution Check if the device supports Apple CarPlay. Check if Apple CarPlay is enabled on the connected device. For details, refer to https://www.apple.com/ios/carplay/. Check if “Apple CarPlay”...
Page 64: Other Settings
3. OTHER SETTINGS 1. GENERAL SETTINGS Settings are available for language se- GENERAL SETTINGS lection, operation sounds, etc. SCREEN Press the “MENU” button. BG054S Select “Setup”.  If the general settings screen is not dis- played, select “General”. Select the desired items to be set. C-HR_Navi_USA_OM10581U_17CY...
Page 65 Select to turn the beep sound on/ (P.68) off. Select to update software versions. Select to change the unit of tem- For details, contact your Toyota perature. dealer. Select to change the unit of mea- Select to set software update set- sure for distance/fuel consumption.
Page 66 3. OTHER SETTINGS ■ TIME ZONE SYSTEM TIME SETTINGS A time zone can be selected and GMT Display the general settings screen. can be set. (P.64) Select “Time Zone”. Select “System Time”. Select the desired time zone. Select the desired items to be set. ...
Page 67 3. OTHER SETTINGS ■ MANUALLY SELECT LINKED SET- DRIVER SETTINGS TINGS The driver settings feature will allow Select “Manually Select Linked Set- the system to link some preferences tings”. (such as audio presets, screen theme, Select the desired phone. ® language, etc.) to a paired Bluetooth phone.
Page 68 Display the general settings screen. (P.64) When the automatic update check function is enabled, if a software up- Select “Delete Personal Data”. date is available from the Toyota En- Select “Delete”. tune center, a message will be displayed. Select “Yes” when the confirmation screen appears.
Page 69: Voice Settings
VOICE SETTINGS SCREEN Select to set the voice prompt inter- rupt on/off. Select to set the web search engine. The search engines are Toyota En- tune App Suite Connect applica- tions. (P.267) Select to reset all setup items. *: Entune Premium Audio only...
Page 70: Vehicle Settings
3. OTHER SETTINGS 3. VEHICLE SETTINGS Settings are available for mainte- Function Page nance, vehicle customization, etc. Select to set main- tenance. Press the “MENU” button. Select to set vehicle “OWNER’S customization. MANUAL” Select to set valet mode. Select to set dealer information.
Page 71: Maintenance
3. OTHER SETTINGS MAINTENANCE* INFORMATION ● When the vehicle needs to be serviced, When this system is turned on, the the screen button color will change to orange. maintenance reminder screen displays when it is time to replace a part or cer- tain components.
Page 72 3. OTHER SETTINGS Select “OK” after entering the condi- Select the desired items to be edited. tions. INFORMATION ● For scheduled maintenance information, refer to “Scheduled Maintenance Guide” or “Owner’s Manual Supplement”. ● Depending on driving or road conditions, the actual date and distance that main- tenance should be performed may differ from the stored date and distance in the Function...
Page 73: Valet Mode
 When valet mode activates, the system stops and a security code (4-digit num- ber) standby screen displayed. (P.74) INFORMATION ● If the 4-digit personal code is forgotten, please contact your Toyota dealer. C-HR_Navi_USA_OM10581U_17CY...
Page 74: Setting Dealer Information
3. OTHER SETTINGS IF THE VALET MODE HAS SETTING DEALER BEEN ACTIVATED INFORMATION* Enter the 4-digit personal code and se- Dealer information can be registered in lect “OK”. the system. If the vehicle alert screen is displayed, selecting the call dealer INFORMATION button on the screen will call the phone ●...
Page 75 3. OTHER SETTINGS EDITING DEALER OR CONTACT NAME Select “Edit” next to “Dealer” or “Con- tact”. Enter the name and select “OK”. EDITING PHONE NUMBER Select “Edit” next to “Phone #”. Enter the phone number and select “OK”. C-HR_Navi_USA_OM10581U_17CY...
Page 76: Audio/Visual System
AUDIO/VISUAL SYSTEM BASIC OPERATION RADIO OPERATION 1. QUICK REFERENCE ..... 78 1. AM/FM/SiriusXM (SXM) RADIO ... 85 OVERVIEW ..........85 2. SOME BASICS....... 79 PRESETTING A STATION ....88 TURNING THE SYSTEM ON AND CACHING A RADIO PROGRAM ... 88 OFF .............
Page 77 AUDIO/VISUAL SYSTEM MEDIA OPERATION SETUP 1. USB MEMORY....... 98 1. AUDIO SETTINGS ...... 114 OVERVIEW ........... 98 AUDIO SETTINGS SCREEN....114 2. iPod/iPhone......... 101 TIPS FOR OPERATING OVERVIEW ......... 101 THE AUDIO/VISUAL SYSTEM ® 3. Bluetooth AUDIO ...... 105 OVERVIEW ......... 105 1.
Page 78: Basic Operation
1. BASIC OPERATION 1. QUICK REFERENCE The audio control screen can be reached by the following methods: From the “AUDIO” button Press the “AUDIO” button. From the “MENU” button Press the “MENU” button, then select “Audio”. BG051S Function Page Using the radio 85, 97 Playing a USB memory Playing an iPod/iPhone...
Page 79: Some Basics
1. BASIC OPERATION 2. SOME BASICS This section describes some of the ba- TURNING THE SYSTEM ON sic features of the audio/visual system. AND OFF Some information may not pertain to your system. Vehicles without a smart key system Your audio/visual system works when the engine switch is in the “ACC”...
Page 80: Usb/Aux Port
Even if a USB hub is used to connect • Bluetooth audio more than two USB devices, only the • Toyota Entune App Suite Connect first two connected devices will be rec- ognized. ● If a USB hub that has more than two...
Page 81: Sound Settings
1. BASIC OPERATION TREBLE/MID/BASS SOUND SETTINGS How good an audio program sounds is Display the audio control screen. largely determined by the mix of the (P.79) treble, mid and bass levels. In fact, dif- Select “Sound”. ferent kinds of music and vocal pro- grams usually sound better with Select the desired item to be set.
Page 82 1. BASIC OPERATION FADER/BALANCE AUTOMATIC SOUND LEVELIZER (ASL) A good balance of the left and right ste- reo channels and of the front and rear The system adjusts to the optimum vol- sound levels is also important. ume and tone quality according to ve- hicle speed compensate...
Page 83: Audio Screen Adjustment
1. BASIC OPERATION SCREEN ADJUSTMENT AUDIO SCREEN ADJUSTMENT The contrast and brightness of the screen can be adjusted. SCREEN FORMAT SETTINGS Press the “MENU” button. The screen format can be selected for Select “Setup”. USB video. Select “Audio”. Press the “MENU” button. Select “Common”.
Page 84: Voice Command System
1. BASIC OPERATION VOICE COMMAND SYSTEM Press this switch to operate the voice command system. BG063S  The voice command system and its list commands operated. (P.126) C-HR_Navi_USA_OM10581U_17CY...
Page 85: Radio Operation
2. RADIO OPERATION 1. AM/FM/SiriusXM (SXM)* RADIO OVERVIEW The radio operation screen can be reached by the following methods: P.79 ■ CONTROL SCREEN Entune Audio *: Entune Audio Plus/Entune Premium Audio only C-HR_Navi_USA_OM10581U_17CY...
Page 86 2. RADIO OPERATION Entune Audio Plus/Entune Premium Audio ■ CONTROL PANEL BG065S C-HR_Navi_USA_OM10581U_17CY...
Page 87 2. RADIO OPERATION Function Page  Select to display the audio source selection screen. Select to display the preset station screen. Select to display a list of receivable stations. Select to display the radio options screen. Select to display the sound setting screen. Select to tune to preset stations/channels.
Page 88: Presetting A Station
2. RADIO OPERATION PRESETTING A STATION CACHING A RADIO PROGRAM Radio mode has a mix preset function, which can store up to 36 stations (6 AM/FM* and SXM* radio program stations per page x 6 pages) from any can be cached and played back in a of the AM, FM or SXM bands.
Page 89 2. RADIO OPERATION AUTOMATIC PLAYBACK OF Function THE CACHE Returns to the live radio broadcast If the radio broadcast is interrupted by Displays the replay offset from the another audio output, such as an current time incoming phone call, the system will Skips backward 2 minutes (AM/FM) automatically cache the interrupted Select to change the current/previ-...
Page 90: Selecting A Station From The List
2. RADIO OPERATION REFRESHING THE STATION SELECTING A STATION LIST FROM THE LIST Select “Refresh”. Select “Station List”. “Cancel Refresh”: Select to cancel the Select “AM”, “FM” or “SXM”*. refresh. “Source”: Select to change to another au- FM and SXM* dio source while refreshing.
Page 91: Radio Options
2. RADIO OPERATION RADIO OPTIONS RADIO BROADCAST DATA SYSTEM Select “Options”. This audio/visual system is equipped Select the desired item. with Radio Broadcast Data Systems (RBDS). RBDS mode allows text mes- sages to be received from radio sta- tions that utilize RBDS transmitters. When RBDS is on, the radio can —...
Page 92: Using Hd Radio™ Technology
AVAILABLE HD Radio ™ to www.hdradio.com. TECHNOLOGY HD Radio features included in Toyota radios:  Digital Sound - HD Radio broadcasts MULTICAST deliver crystal-clear, digital audio quality to listeners.
Page 93: Hd Radio™ Troubleshooting Guide
2. RADIO OPERATION HD Radio™ TROUBLESHOOTING GUIDE Experience Cause Action Mismatch of time alignment The radio stations analog a user may hear a short pe- and digital volume is not None, radio broadcast issue. A riod of programming re- properly aligned or the sta- user can contact the radio station.
Page 94: How To Subscribe To Siriusxm Radio Services
2. RADIO OPERATION HOW TO SUBSCRIBE TO NOTICE SiriusXM Radio Services* ● It is prohibited to copy, decompile, disas- semble, reverse engineer, hack, manip- All SiriusXM services, including satel- ulate, or otherwise make available any lite radio and data services, plus technology or software incorporated in streaming services, require a subscrip- receivers compatible with the SiriusXM...
Page 95: Displaying The Radio Id
2. RADIO OPERATION DISPLAYING THE RADIO ID INFORMATION ● About SriusXM Services: Each SiriusXM tuner is identified with a Most in-car trials today include SiriusXM’s best package — All Access. unique radio ID. The radio ID is re- It includes every channel available on quired when activating an SiriusXM your radio, plus streaming.
Page 96: If The Satellite Radio Tuner Malfunctions
Message Explanation The SiriusXM antenna is not connected. Check whether the SiriusXM antenna cable is attached securely. Contact your Toyota dealer for assistance. “Check Antenna” A short circuit occurs in the antenna or the surrounding antenna ca- ble. Contact your Toyota dealer for assistance.
Page 97: Internet Radio
Other applications can be activated while listening to internet radio. ● Some parts of applications can be One of Toyota Entune App Suite Con- adjusted using the switches on the nect features is the ability to listen to in- steering wheel.
Page 98: Media Operation
3. MEDIA OPERATION 1. USB MEMORY OVERVIEW The USB memory operation screen can be reached by the following methods: P.79 Connect a USB memory P.80 When an Apple CarPlay connection is established, this function will be unavailable. ■ CONTROL SCREEN USB audio USB video ■...
Page 99 3. MEDIA OPERATION Function Select to display the audio source selection screen. Select to return to the top screen. Select to display a song list screen. Select to display the play mode selection screen. Select to display the sound setting screen. (P.81) Select to set repeat playback.
Page 100 3. MEDIA OPERATION WARNING ● Do not operate the player’s controls or connect the USB memory while driving. NOTICE ● Do not leave your portable player in the car. In particular, high temperatures inside the vehicle may damage the portable player. ●...
Page 101: Ipod/Iphone
3. MEDIA OPERATION 2. iPod/iPhone OVERVIEW The iPod/iPhone operation screen can be reached by the following methods: P.79 Connect an iPod/iPhone P.61, 80 When the iPod/iPhone connected to the system includes video, the system can only output the sound by selecting the browse screen. ■...
Page 102 3. MEDIA OPERATION ■ CONTROL PANEL BG065S Function Select to display the audio source selection screen. Select to return to the top screen. Select to display a song list screen. Select to display the play mode selection screen. Select to display the sound setting screen. (P.81) Select to display the audio control screen of Apple CarPlay.
Page 103 3. MEDIA OPERATION Function Displays cover art Select to change the artist. Select to change the playlist.  Press to change the track.  Press and hold to fast forward/rewind.  Turn to change the track.  Turn to move up/down the list. Also, the knob can be used to enter selections on the list screens by pressing it.
Page 104 3. MEDIA OPERATION WARNING ● Do not operate the player’s controls or connect the iPod/iPhone while driving. NOTICE ● Do not leave your portable player in the car. In particular, high temperatures inside the vehicle may damage the portable player. ●...
Page 105: Bluetooth ® Audio
3. MEDIA OPERATION ® 3. Bluetooth AUDIO ® The Bluetooth audio/visual system enables users to enjoy listening to music that is played on a portable player on the vehicle speakers via wireless communication. ® This audio/visual system supports Bluetooth , a wireless data system capable of playing portable audio music without cables.
Page 106 3. MEDIA OPERATION ■ CONTROL PANEL BG065S Function Select to display the audio source selection screen. Select to return to the top screen. Select to display a song list screen. Select to display the play mode selection screen. Select to display the portable device connection screen. (P.109) Select to display the sound setting screen.
Page 107 3. MEDIA OPERATION Function Select to change the album. Displays cover art  Press to change the track.  Press and hold to fast forward/rewind.  Turn to change the track.  Turn to move up/down the list. Also, the knob can be used to enter selections on the list screens by pressing it.
Page 108 3. MEDIA OPERATION INFORMATION ® ● Depending on the Bluetooth device that is connected to the system, the music may start playing when selecting while it is paused. Conversely, the music may pause when selecting while it is playing. ● In the following conditions, the system may not function: ®...
Page 109: Registering/Connecting A Bluetooth ® Device
3. MEDIA OPERATION REGISTERING/CONNECTING ® A Bluetooth DEVICE ® To use the Bluetooth audio system, it ® is necessary to register a Bluetooth device with the system. Registering an additional device ® Display the Bluetooth audio control screen. (P.105) Select “Connect”. Select “Add Device”.
Page 110: Aux
3. MEDIA OPERATION 4. AUX OVERVIEW The AUX operation screen can be reached by the following methods: P.79 Connect a device to the AUX port P.80 ■ CONTROL SCREEN Function Select to display the audio source selection screen. Select to return to the top screen. Select to display the sound setting screen.
Page 111 3. MEDIA OPERATION WARNING ● Do not connect portable audio device or operate the controls while driving. NOTICE ● Do not leave portable audio device in the vehicle. The temperature inside the vehicle may become high, resulting in damage to the player. ●...
Page 112: Audio/Visual Remote Controls
4. AUDIO/VISUAL REMOTE CONTROLS 1. STEERING SWITCHES Some parts of the audio/visual system can be adjusted using the switches on the steering wheel. Switch Volume control switch “MODE” switch Seek switch Volume control switch Mode Operation Function Press Volume up/down Press and hold Volume up/down continuously “MODE”...
Page 113 4. AUDIO/VISUAL REMOTE CONTROLS Seek switch Mode Operation Function Press Preset channel up/down Seek up/down(0.8 sec. or more) AM, FM Press and hold Seek up/down continuously while the switch is being pressed(1.5 sec. or more) Press Preset channel up/down Seek for stations in the relevant program type/channel SXM* Press and hold category (0.8 sec.
Page 114: Setup
5. SETUP 1. AUDIO SETTINGS Detailed audio settings can be pro- COMMON SETTINGS grammed. Display the audio settings screen. Press the “MENU” button. Select “Common”. Select the desired items to be set. BG054S Select “Setup”. Function Select “Audio”. Select to set the cover art display on/off.
Page 115 5. SETUP ■ REGISTERING MANAGE SMART RADIO SETTINGS (Entune FAVORITES Audio) Select “Manage Smart Favorites”. Display the audio settings screen. Select the desired channel to be set. Select “Radio”.  Displays the registered preset channels. Select the desired number of preset ra- ...
Page 116: Tips For Operating The Audio/Visual System
6. TIPS FOR OPERATING THE AUDIO/VISUAL SYSTEM 1. OPERATING INFORMATION NOTICE Fading and drifting stations: Generally, the ● To avoid damage to the audio/visual effective range of FM is about 25 miles (40 system: km). Once outside this range, you may no- •...
Page 117: Ipod/Iphone
6. TIPS FOR OPERATING THE AUDIO/VISUAL SYSTEM Station interference: When a reflected sig- iPod/iPhone nal and a signal received directly from a ra- dio station are very nearly the same frequency, they can interfere with each other, making it difficult to hear the broad- cast.
Page 118: High-Resolution Sound Source
6. TIPS FOR OPERATING THE AUDIO/VISUAL SYSTEM COMPATIBLE MODELS HIGH-RESOLUTION SOUND SOURCE ® ® The following iPod nano , iPod touch ® and iPhone devices can be used with this This device supports high-resolution system. sound sources. Made for The definition of high-resolution is based •...
Page 119: File Information
6. TIPS FOR OPERATING THE AUDIO/VISUAL SYSTEM ■ CORRESPONDING SAMPLING FILE INFORMATION FREQUENCY ■ COMPATIBLE USB DEVICES File type Frequency (kHz) communication USB 2.0 HS (480 MP3 files: 32/44.1/48 formats Mbps) MPEG 1 LAYER 3 File formats FAT 16/32 MP3 files: 16/22.05/24 MPEG 2 LSF LAYER 3 Mass...
Page 120 6. TIPS FOR OPERATING THE AUDIO/VISUAL SYSTEM ■ ■ COMPATIBLE CHANNEL MODES CORRESPONDING BIT RATES* File type Channel mode File type Bit rate (kbps) Stereo, joint stereo, dual MP3 files: MP3 files 32 - 320 channel and monaural MPEG 1 LAYER 3 WMA files MP3 files: 8 - 160...
Page 121 6. TIPS FOR OPERATING THE AUDIO/VISUAL SYSTEM  MP3 files are compatible with the ID3 Tag Ver. 1.0, Ver. 1.1, Ver. 2.2 and Ver. 2.3 for- mats. This system cannot display album Media device 001.mp3 title, track title and artist name in other for- 002.wma mats.
Page 122: Terms
6. TIPS FOR OPERATING THE AUDIO/VISUAL SYSTEM TERMS  WMA (Windows Media Audio) is an audio compression format developed ID3 TAG ® Microsoft . It compresses files into a size  This is a method of embedding track- smaller than that of MP3 files. The decod- related information in an MP3 file.
Page 123 6. TIPS FOR OPERATING THE AUDIO/VISUAL SYSTEM MPEG4  This product is licensed under the MPEG-4 patent portfolio license, AVC pat- ent portfolio license and VC-1 patent port- folio license for the personal use of a consumer or other uses in which it does not receive remuneration to (i) encode video in compliance with the MPEG-4 Visual Standard, AVC Standard...
Page 124: Error Messages
Please check your iPod/iPhone. “Music tracks not support- ® ® This indicates a problem in the Bluetooth Bluetooth ed. Please check your por- vice. audio table player.” INFORMATION ● If the malfunction is not rectified: Take your vehicle to your Toyota dealer. C-HR_Navi_USA_OM10581U_17CY...
Page 125 VOICE COMMAND SYSTEM VOICE COMMAND SYSTEM OPERATION 1. VOICE COMMAND SYSTEM..126 USING THE VOICE COMMAND SYSTEM..........126 VOICE COMMAND SYSTEM OPERATION ........127 2. NATURAL LANGUAGE UNDERSTANDING ....130 3. COMMAND LIST ......131 MOBILE ASSISTANT OPERATION 1. MOBILE ASSISTANT....137 C-HR_Navi_USA_OM10581U_17CY...
Page 126: Voice Command System Operation
1. VOICE COMMAND SYSTEM OPERATION 1. VOICE COMMAND SYSTEM The voice command system enables MICROPHONE the radio, phone dialing, etc. to be op- erated using voice commands. Refer to the command list for samples of voice commands. (P.131) USING THE VOICE COMMAND SYSTEM STEERING SWITCH ...
Page 127: Voice Command System Operation
1. VOICE COMMAND SYSTEM OPERATION VOICE COMMAND SYSTEM INFORMATION OPERATION ● Voice commands may not be recognized • Spoken too quickly. The voice command system is operat- • Spoken at a low or high volume. ed by saying commands which corre- •...
Page 128 1. VOICE COMMAND SYSTEM OPERATION  Selecting “Help” or saying “Help” INFORMATION prompts the voice command system to ● If the system does not respond or the offer examples of commands and oper- confirmation screen does not disappear, ation methods. press the talk switch and try again.
Page 129 “Tutorials” and “Voice To use the dictation function, a sub- Training” functions on the “Getting scription to the Toyota Entune is nec- Started with Voice” screen. These essary. Contact your Toyota dealer for functions are only available when the details.
Page 130: Natural Language Understanding
(If a Toyota Entune subscrip- tion has been entered, the system will be able to connect to the Toyota En- tune center and the range of naturally spoken English which can be recog- nized will be increased.) However, the system cannot recognize every varia- tion of each command.
Page 131: Command List
1. VOICE COMMAND SYSTEM OPERATION 3. COMMAND LIST Recognizable voice commands and their actions are shown below.  Frequently used commands are listed in the following tables.  For devices that are not installed to the vehicle, commands relating to that device may not be displayed on the screen.
Page 132 : Major national brands are always supported. Local brands are also supported with a subscrip- tion to the Toyota Entune. Contact your Toyota dealer for details. : When the language is set to French, the supported area is only Quebec City in Canada...
Page 133 1. VOICE COMMAND SYSTEM OPERATION Phone Command Action “Call <contact>”* Places a call to the specified contact from the phone book Places a call to the specified phone type of the contact “Call <contact> <phonetype>”* from the phone book “Dial <phone number>” Places a call to the specified phone number Places a call to the phone number of the latest outgoing “Redial”...
Page 134 1. VOICE COMMAND SYSTEM OPERATION Radio Command Action “Tune to <frequency> AM” Changes the radio to the specified AM frequency “Tune to <frequency> FM” Changes the radio to the specified FM frequency Changes the radio to an FM station of the specified “Play a <genre>...
Page 135 1. VOICE COMMAND SYSTEM OPERATION Audio* Command Action “Play playlist <name>” Plays tracks from the selected playlist “Play artist <name>” Plays tracks from the selected artist “Play song <name>” Plays the selected track “Play album <name>” Plays tracks from the selected album “Play genre <name>”...
Page 136 : Entune Premium Audio only : Only major US cities are supported by voice Apps Command Action Activates the Toyota Entune App Suite Connect applica- “Launch <application name>” tion INFORMATION ● When an application is opened and is in full screen mode, pressing the talk switch will start the voice command system and commands for the currently displayed application will be available.
Page 137: Mobile Assistant Operation
2. MOBILE ASSISTANT OPERATION 1. MOBILE ASSISTANT Type B The Mobile Assistant function is a voice input assist function. Mobile Press and hold the switch on the Assist supports the Siri Eyes Free steering wheel until Mobile Assistant Mode and Google App. (Google App screen is displayed.
Page 138 2. MOBILE ASSISTANT OPERATION INFORMATION ● The available features and functions may vary based on the iOS/Android ver- sion installed on the connected device. ● While a phone call is active, the Mobile Assistant cannot be used. ● If using the navigation feature of the cel- lular phone, ensure the active audio ®...
Page 139: Information
INFORMATION USEFUL INFORMATION 1. INFORMATION SCREEN.... 140 DISPLAYING INFORMATION SCREEN ........... 140 2. RECEIVING WEATHER INFORMATION ......141 DISPLAYING WEATHER SCREEN ..141 WEATHER GUIDANCE SERVICE ..143 3. DATA SERVICES SETTINGS..144 SETTING DOWNLOAD METHODS ..144 C-HR_Navi_USA_OM10581U_17CY...
Page 140: Useful Information
1. USEFUL INFORMATION 1. INFORMATION SCREEN* Select the desired item. Useful information, such as the fuel consumption, weather,etc.,is available on the information screen. DISPLAYING INFORMATION SCREEN Press the “MENU” button. Function Page Select to display “OWNER’S the fuel consump- MANUAL” tion screen.
Page 141: Receiving Weather Information
1. USEFUL INFORMATION 2. RECEIVING WEATHER INFORMATION* Weather information can be received Function via HD Radio broadcast or DCM (Data Select to display the current weather Communication Module). information. (P.142) Select to display a 3-day weather DISPLAYING WEATHER forecast for the currently displayed SCREEN location.
Page 142 1. USEFUL INFORMATION SELECTING A LOCATION INFORMATION ● This function is not made available in Display the weather screen. (P.141) some countries or areas. ● The weather for current location might Select “National/Local”. not show the closest city when it first dis- plays.
Page 143: Weather Guidance Service
1. USEFUL INFORMATION WEATHER GUIDANCE SERVICE When weather information for areas around current position, destination, or along the set route is available, important information will be output through the speakers and a pop-up message asking if you would like to view the full weather information will be displayed.
Page 144: Data Services Settings
1. USEFUL INFORMATION 3. DATA SERVICES SETTINGS* Select the desired item to be set. SETTING DOWNLOAD METHODS Data service information, which is comprised of traffic information and weather information, can be received via HD Radio broadcast or DCM (Data Communication Module). The receiv- ing method can be set to both or only via HD Radio broadcast.
Page 145: Peripheral Monitoring System
PERIPHERAL MONITORING SYSTEM REAR VIEW MONITOR SYSTEM 1. REAR VIEW MONITOR SYSTEM ........146 DRIVING PRECAUTIONS ....146 SCREEN DESCRIPTION ....148 2. REAR VIEW MONITOR SYSTEM PRECAUTIONS......149 AREA DISPLAYED ON SCREEN..149 THE CAMERA ........149 DIFFERENCES BETWEEN THE SCREEN AND THE ACTUAL ROAD ..........
Page 146: System
1. REAR VIEW MONITOR SYSTEM 1. REAR VIEW MONITOR SYSTEM The rear view monitor system assists WARNING the driver by displaying an image of the view behind the vehicle with fixed ● Never depend on the rear view monitor system entirely when backing up. The guide lines on the screen while backing image and the position of the guide lines up, for example while parking.
Page 147 1. REAR VIEW MONITOR SYSTEM WARNING ● In low temperatures, the screen may darken or the image may become faint. The image could distort when the vehi- cle is moving, or you may become unable to see the image on the screen. Be sure to visually check all around the vehicle both directly and using the mir- rors before proceeding.
Page 148: Screen Description
1. REAR VIEW MONITOR SYSTEM SCREEN DESCRIPTION Vehicles without a smart key system The rear view monitor system screen will be displayed if the shift lever is shifted to the “R” position while the engine switch is in the “ON” position. Vehicles with a smart key system The rear view monitor system screen will be displayed if the shift lever is shifted to the “R”...
Page 149: Rear View Monitor System Precautions
1. REAR VIEW MONITOR SYSTEM 2. REAR VIEW MONITOR SYSTEM PRECAUTIONS AREA DISPLAYED ON THE CAMERA SCREEN The camera for the rear view monitor system is located as shown in the illus- The rear view monitor system displays tration. an image of the view from the bumper of the rear area of the vehicle.
Page 150: Differences Between The Screen And The Actual Road
Doing so may result in the camera malfunctioning. ● Do not expose the camera to strong impact as this could cause a malfunc- tion. If this happens, have the vehicle inspected by your Toyota dealer as soon as possible. C-HR_Navi_USA_OM10581U_17CY...
Page 151 1. REAR VIEW MONITOR SYSTEM WHEN THE GROUND BEHIND WHEN THE GROUND BEHIND THE VEHICLE SLOPES UP THE VEHICLE SLOPES DOWN SHARPLY SHARPLY The distance guide lines will appear to The distance guide lines will appear to be closer to the vehicle than the actual be farther from the vehicle than the ac- distance.
Page 152: When Approaching Three-Dimensional Objects
1. REAR VIEW MONITOR SYSTEM WHEN ANY PART OF THE WHEN APPROACHING VEHICLE SAGS THREE-DIMENSIONAL OBJECTS When any part of the vehicle sags due to the number of passengers or the dis- The distance guide lines are displayed tribution of the load, there is a margin according to flat surfaced objects of error between the fixed guide lines (such as the road).
Page 153 1. REAR VIEW MONITOR SYSTEM VEHICLE WIDTH GUIDE LINES DISTANCE GUIDE LINES Visually check the surroundings and Visually check the surroundings and the area behind the vehicle. In the case the area behind the vehicle. On the shown below, the truck appears to be screen, it appears that a truck is park- outside of the vehicle width guide lines ing at point B.
Page 154: Things You Should Know
IF YOU NOTICE ANY SYMPTOMS If you notice any of the following symptoms, refer to the likely cause and the solution, and re-check. If the symptom is not resolved by the solution, have the vehicle inspected by your Toyota dealer. Symptom Likely cause Solution ...
Page 155: Phone Operation
PHONE ® 6. Bluetooth PHONE MESSAGE PHONE OPERATION FUNCTION ........ 170 (HANDS-FREE SYSTEM FOR DISPLAYING THE MESSAGE CELLULAR PHONES) SCREEN ........... 170 RECEIVING A MESSAGE ....170 1. QUICK REFERENCE....156 CHECKING RECEIVED 2. SOME BASICS ......157 MESSAGES ........171 REPLYING TO A MESSAGE REGISTERING/CONNECTING A ®...
Page 156: Cellular Phones)
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) 1. QUICK REFERENCE The phone top screen can be reached by the following methods: From the “PHONE” button Press the “PHONE” button. From the “MENU” button Press the “MENU” button, then select “Phone”. Function Page ®...
Page 157: Some Basics
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) 2. SOME BASICS The hands-free system enables calls NOTICE to be made and received without hav- ing to take your hands off the steering ● Do not leave your cellular phone in the vehicle.
Page 158: Registering/Connectinga Bluetooth ® Phone
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) ® Bluetooth PHONE CONDITION REGISTERING/CONNECTING ® DISPLAY A Bluetooth PHONE ® The condition of the Bluetooth phone To use the hands-free system for cellu- appears on the upper right side of the lar phones, it is necessary to register a screen.
Page 159: System
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) MICROPHONE INFORMATION ● The other party’s voice will be heard The microphone is used when talking from the front speakers. The audio/ on the phone. visual system will be muted during phone calls or when hands-free voice commands are used.
Page 160: About The Contacts In The Contact List
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) ABOUT THE CONTACTS IN THE CONTACT LIST  The following data is stored for every reg- istered phone. When another phone is connected, the following registered data cannot be read: • Contact data •...
Page 161: Placing A Call Using The Bluetooth Hands-Free System
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) ® 3. PLACING A CALL USING THE Bluetooth HANDS-FREE SYSTEM ® BY CALL HISTORY After a Bluetooth phone has been registered, a call can be made using the hands-free system. There are sev- Up to 30 of the latest call history items eral methods by which a call can be (missed, incoming and outgoing) can...
Page 162: By Favorites List
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) BY FAVORITES LIST BY CONTACTS LIST Calls can be made using registered Calls can be made by using contact contacts which can be selected from a data which is transferred from a regis- contact list.
Page 163 1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) ■ FOR PBAP INCOMPATIBLE BUT WHEN THE CONTACT LIST IS ® EMPTY COMPATIBLE Bluetooth PHONES ■ PBAP COMPATIBLE Select the desired item. ® Bluetooth PHONES When “Automatic Transfer” is set to on (P.178) ...
Page 164: By Keypad
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) BY KEYPAD INFORMATION ● Manual transfer operation cannot be Display phone screen. performed while driving. ● (P.156) If your cellular phone is neither PBAP nor OPP compatible, the contacts can- Select “Keypad” and enter the phone not be transferred.
Page 165: By Home Screen
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) BY HOME SCREEN Display the home screen. (P.35) Select the desired contact. Check that the “Dialing...” screen is displayed. REGISTERING A NEW CONTACT Select and hold the screen button to add a contact. Select the desired contact.
Page 166: Receiving A Call Using The Bluetooth Hands-Free System
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) ® 4. RECEIVING A CALL USING THE Bluetooth HANDS-FREE SYSTEM INCOMING CALLS When a call is received, this screen is displayed with a sound. Select “Answer” or press the switch on the steering wheel to talk on the phone.
Page 167: Talking On The Bluetooth
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) ® 5. TALKING ON THE Bluetooth HANDS-FREE SYSTEM While talking on the phone, this screen INFORMATION is displayed. The operations outlined ● Changing from hands-free call to cellular below can be performed on this phone call is not possible while driving.
Page 168 1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) ■ BY SELECTING “Release Tones” TRANSMIT VOLUME SETTING “Release Tones” appear when a con- Select “Transmit Volume”. tinuous tone signal(s) containing a (w) Select the desired level for the transmit is registered in the contact list. volume.
Page 169: Incoming Call Waiting
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) INCOMING CALL WAITING When a call is interrupted by a third party while talking, the incoming call screen is displayed. Select “Answer” or press the switch on the steering wheel to start talking with the other party.
Page 170: Bluetooth Phone Message Function
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) ® 6. Bluetooth PHONE MESSAGE FUNCTION Received messages can be forwarded RECEIVING A MESSAGE ® from the connected Bluetooth phone, enabling checking and replying using When an e-mail/SMS/MMS is re- the system. ceived, the incoming message screen pops up with sound and is ready to be ®...
Page 171: Checking Received Messages
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) CHECKING RECEIVED INFORMATION MESSAGES ● Depending on the cellular phone used for receiving messages, or its registra- tion status with the system, some infor- Display message screen. mation may not be displayed. (P.170) ●...
Page 172: Replying To A Message (Dictation Reply)
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) REPLYING TO A MESSAGE INFORMATION (DICTATION REPLY)* ● Reading a text message is not available while driving. Display the message screen.(P.170) ® ● Depending on the type of Bluetooth phone being connected, it may be Select the desired message from the necessary to perform additional steps on list.
Page 173: Replying To A Message (Quick Reply)
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) ■ EDITING QUICK REPLY MESSAG- REPLYING TO A MESSAGE (QUICK REPLY) This operation cannot be performed 15 messages have already been while driving. stored. Select corresponding to the de- Display message screen. sired message to edit.
Page 174: Calling The Message Sender
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES) ■ CALLING FROM A NUMBER WITH- CALLING THE MESSAGE IN A MESSAGE SENDER Calls can be made to a number identi- Calls can be made to an e-mail/SMS/ fied in a message’s text area. MMS message sender’s phone num- This operation cannot be performed ber.
Page 175: Setup
2. SETUP 1. PHONE SETTINGS Press the “MENU” button. Information Page ® Connecting a Bluetooth device and editing the ® Bluetooth device informa- tion Sound settings Notification settings Contact/call history set- BG054S tings Select “Setup”. Messaging settings Select “Phone”. *: This operation cannot be performed while Select the desired item to be set.
Page 176: Sound Settings Screen
2. SETUP SOUND SETTINGS SCREEN Function Select to set the desired ringtone. The call and ringtone volume can be adjusted. A ringtone can be selected. Select “-” or “+” to adjust the ring- tone volume. Display the phone settings screen. Select “-”...
Page 177: Notification Settings Screen
2. SETUP NOTIFICATION SETTINGS Function SCREEN Select to set the SMS/MMS notifica- tion popup on/off. Display the phone settings screen. Select to change the incoming SMS/ (P.175) MMS display. “Full Screen”: When an SMS/MMS Select “Notifications”. message is received, the incoming Select the desired item to be set.
Page 178: Contact/Call History Settings Screen
2. SETUP CONTACT/CALL HISTORY Function Page SETTINGS SCREEN PBAP compatible ® Bluetooth phones: Select Contacts can be transferred from a to change the contact/ his- tory transfer settings. ® Bluetooth phone to this system. Con- tacts and favorites can be added, edit- Select to update contacts from the connected phone ed and deleted.
Page 179 2. SETUP SETTING AUTOMATIC INFORMATION CONTACT/HISTORY ● Depending on the type of phone, certain TRANSFER functions may not be available. ● Contact data is managed independently The automatic contact/history function for every registered phone. When one is available for PBAP compatible phone is connected, another phone’s registered data cannot be read.
Page 180 2. SETUP ■ UPDATING CONTACTS FROM TRANSFERRING CONTACTS PHONE FROM DEVICE Select “Update Now”. ■ FROM PHONE (OPP COMPATIBLE  Contacts are transferred automatically. ® Bluetooth PHONES ONLY) Check that a confirmation screen is Select “Transfer Contacts from De- displayed when the operation is com- vice”.
Page 181 2. SETUP When the contact is registered Transfer the contact data to the system ® using a Bluetooth phone. Select “Replace Contacts” or “Add Contact”.  This operation may be unnecessary depending on the type of cellular phone. “Replace Contacts”: Select to transfer ...
Page 182 2. SETUP REGISTERING A NEW EDITING THE CONTACT DATA CONTACT TO THE CONTACT ® LIST PBAP compatible Bluetooth phones, this function is available when New contact data can be registered. “Automatic Transfer” is set to off. (P.178) Up to 4 numbers per person can be registered.
Page 183 2. SETUP ■ REGISTERING CONTACTS IN THE INFORMATION FAVORITES LIST IN A DIFFERENT ● Multiple data can be selected and WAY (FROM THE CONTACT DE- deleted at the same time. TAILS SCREEN) Display phone screen. SETTING FAVORITES LIST (P.156) Select “Contacts” and select the de- Up to 15 contacts (maximum of 4 num- sired contact.
Page 184 2. SETUP ■ DELETING CONTACTS IN THE FA- Function Page VORITES LIST IN A DIFFERENT Select to register a new WAY (FROM THE CONTACT DE- voice tag. TAILS SCREEN) Select to edit a voice tag. Display phone screen. (P.156) Select to delete a voice tag. Select “Favorites”...
Page 185: Message Settings Screen
2. SETUP ■ EDITING A VOICE TAG MESSAGE SETTINGS SCREEN Select “Edit”. Select the desired contact to edit. Display the phone settings screen. (P.175) Follow the steps in “REGISTERING A VOICE TAG” from “STEP 3”. (P.184) Select “Messaging”. ■ DELETING THE VOICE TAG Select the desired item to be set.
Page 186 2. SETUP INFORMATION ● Depending on the phone, these func- tions may not be available. EDITING VEHICLE SIGNATURE Select “Vehicle Signature”. Select “Edit Vehicle Signature”. Enter desired signature and select “OK”. Select “OK” on the preview screen. “Edit Again”: Select to edit the signature again.
Page 187: What To Do If
For a list of specific devices which operation been confirmed this system, check with The connected de- your Toyota dealer or vice may not be a the following website: compatible   http://www.toyota.com/ ® Bluetooth cellular Entune/ in the United phone.
Page 188 3. WHAT TO DO IF... When registering/connecting a cellular phone Page Symptom Likely cause Solution Cellular This phone system An incorrect pass- Enter the correct pass- code was entered   code on the cellular cellular phone. phone. Complete the registra- The registration op- tion operation on the eration has not been...
Page 189 3. WHAT TO DO IF... Page Symptom Likely cause Solution Cellular This phone system ® ® Bluetooth function Enable the Bluetooth   is not enabled on function on the cellular the cellular phone. phone. “The phone is not Delete the existing reg- Old registration in- istration information...
Page 190 For a list of specific devices which operation been confirmed this The profile version system, check with connected your Toyota dealer or cellular phone may the following website:   not be compatible http://www.toyota.com/ with transferring Entune/ in the United phonebook data. States, http:// www.toyota.ca/entune...
Page 191 3. WHAT TO DO IF... ® When using the Bluetooth message function Page Symptom Likely cause Solution Cellular This phone system Enable message trans- Message transfer is cellular   not enabled on the phone (approve mes- cellular phone. sage transfer on the Messages cannot be phone).
Page 192 3. WHAT TO DO IF... In other situations Page Symptom Likely cause Solution Cellular This phone system ® The Bluetooth con- nection status is dis- played at the top of the screen each time the engine switch is in following. Vehicles without Connection confir-...
Page 193 3. WHAT TO DO IF... Page Symptom Likely cause Solution Cellular This phone system The cellular phone Bring cellular   is not close enough phone closer to this to this system. system. ® Turn off Wi-Fi devices Radio interference ...
Page 194 ROUTE TRACE ........205 GUIDANCE........ 220 4. TRAFFIC INFORMATION .... 206 CONFIRM DESTINATION SCREEN ... 221 DISPLAYING TRAFFIC ROUTE OVERVIEW SCREEN .... 221 INFORMATION ON THE MAP..209 A ROUTE FROM THE Toyota Entune CENTER (VEHICLES WITH DCM) ..........224 C-HR_Navi_USA_OM10581U_17CY...
Page 195: Navigation System
NAVIGATION SYSTEM * ROUTE GUIDANCE SETUP 1. ROUTE GUIDANCE SCREEN..225 1. DETAILED NAVIGATION SETTINGS......... 243 SCREEN FOR ROUTE GUIDANCE ... 225 SCREENS FOR NAVIGATION DURING FREEWAY DRIVING.... 227 SETTINGS ........243 WHEN APPROACHING AN INTERSECTION ....... 229 2. TRAFFIC SETTINGS....247 TURN LIST SCREEN ......
Page 196: Basic Operation
1. BASIC OPERATION 1. QUICK REFERENCE MAP SCREEN To display this screen, press the “MAP” button. Name Function Page Indicates whether the map orientation is set to 2D North-up, 2D north-up or heading-up. The letter(s) under this heading-up or 3D symbol indicate the vehicle’s heading direction heading-up sym- (e.g.
Page 197 1. BASIC OPERATION Name Function Page Select to magnify or reduce the map scale. When Zoom in/out but- either button is selected, the map scale indicator bar appears at the bottom of the screen. Micro city map Select to display the micro city map screen. button Displays the distance with the estimated travel Route...
Page 198: Map Screen Operation
1. BASIC OPERATION 2. MAP SCREEN OPERATION CURRENT POSITION MAP SCALE DISPLAY Select to change the scale Press the “MAP” button. of the map screen.  The scale indicator bar appears at the bot- BG052S tom of the screen. Check that the current position map is ...
Page 199: Orientation Of The Map
1. BASIC OPERATION MICRO CITY MAP ORIENTATION OF THE MAP For areas covered by the micro city The orientation of the map can be map (some major cities), a micro city changed between 2D north-up, 2D map on a scale of 75 ft. (25 m) can be heading-up and 3D heading-up by se- selected.
Page 200: Map Scroll Operation
1. BASIC OPERATION MAP SCROLL OPERATION ADJUSTING LOCATION IN SMALL INCREMENTS The map can be scrolled to view loca- tions that are different than your cur- The cursor location can be adjusted in rent position. small increments. 8 directional arrows may appear in the following cases.
Page 201: Displaying Information About The Icon Where The Cursor Is Set
1. BASIC OPERATION DISPLAYING INFORMATION STANDARD MAP ICONS ABOUT THE ICON WHERE THE CURSOR IS SET Icon Name Park When the cursor is placed over an icon on the map screen, the name is dis- played at the top of the screen. If “In- Business facility fo”...
Page 202: Map Options Operation
1. BASIC OPERATION 3. MAP OPTIONS OPERATION Information such as POI icons, route SWITCHING THE MAP MODE trace, speed limit, etc. can be dis- played on the map screen. Select on the map screen. (P.196) Select on the map screen. (P.196) Select “Map Mode”.
Page 203 1. BASIC OPERATION DUAL MAP COMPASS The map on the left is the main map. Information about the destination, cur- The right side map can be edited. rent position and a compass are dis- played on the screen. Select any point on the right side map. INFORMATION ●...
Page 204: Selecting The Poi Icons
1. BASIC OPERATION SELECTING OTHER POI ICONS SELECTING THE POI ICONS TO BE DISPLAYED Select on the map screen. Select “Other POIs”. (P.196) Select the desired POI categories and Select “POI Icons”. select “OK”. “List All Categories”: Select to display all Select the desired POI category and POI categories.
Page 205: Route Trace
1. BASIC OPERATION ROUTE TRACE The traveled route can be stored and retraced on the map screen. This fea- ture is available when the map scale is 30 miles (50 km) or less. Select on the map screen. (P.196) Select “Route Trace”. ...
Page 206: Traffic Information
1. BASIC OPERATION 4. TRAFFIC INFORMATION* When the route has not been set Traffic data can be received via HD Radio broadcast or DCM (Data Com- munication Module) to display traffic information on the map screen. Press the “MENU” button. When the route has been set BG054S Select “Info”.
Page 207 1. BASIC OPERATION DISPLAYING TRAFFIC INFORMATION INFORMATION ● If a large amount of information is being received, it may take longer than normal A list of current traffic information can for the information to be displayed on the screen. be displayed along with information on ●...
Page 208 1. BASIC OPERATION DISPLAYING PREDICTIVE MY TRAFFIC ROUTES TRAFFIC INFORMATION Traffic information along the saved A map with predictive traffic data can routes can be displayed. To use this be displayed. function, it is necessary to register a route. (P.249) Display the traffic incidents screen.
Page 209: Displaying Traffic Information On The Map
1. BASIC OPERATION DISPLAYING TRAFFIC INFORMATION ON THE MAP Select on the map screen. Select “Traffic Information”. Check that the traffic information is dis- played. INFORMATION ● The icons indicate traffic incidents such as construction, accidents, etc. Select an icon to hear more detail by voice. ●...
Page 210: Destination Search
2. DESTINATION SEARCH 1. DESTINATION SEARCH OPERATION The destination screen enables to search for a destination. The destination screen can be reached by the following methods: From the “MENU” button Press the button, and then select “MENU” “Destination” From the “MAP” button Press the button, and then select “MAP”...
Page 211 Select to search for a destination by entering keywords. Select to search for a destination from a registered entry in “Favorites”. Select to search for a destination via the Toyota Entune center. Select to search for a destination from recent set destinations.
Page 212: Selecting Search Area
(vehicles with DCM) INFORMATION ● To search for a facility name using multi- ple search words, put a space between each word. ● Search results may differ depending on the Toyota Entune subscription status and communication status. C-HR_Navi_USA_OM10581U_17CY...
Page 213: Searching By Favorites List
2. DESTINATION SEARCH SEARCHING BY FAVORITES SEARCHING BY RECENT LIST DESTINATIONS Display destination screen. To use this function, it is necessary to (P.210) register a point as a favorites list entry. (P.238) Select “Recent”. Display destination screen. Select the desired destination. (P.210) “Sort/Delete”: Select to sort (date,　...
Page 214: Searching By Emergency
2. DESTINATION SEARCH SEARCHING BY SEARCHING BY ADDRESS EMERGENCY There are 2 methods to search for a destination by address. Display destination screen. (P.210) Display destination screen. Select “Emergency”. (P.210) Select the desired emergency catego- Select “Address”. Select the desired search method. Select the desired destination.
Page 215: Searching By Point Of Interest
2. DESTINATION SEARCH Select the desired street name. SEARCHING BY POINT OF INTEREST Enter a house number and select “Search”. There are 3 methods to search for a  If multiple locations with the same address destination by Points of Interest. exist, the address list screen will be dis- played.
Page 216 2. DESTINATION SEARCH ■ SELECTING A CITY TO SEARCH SEARCHING BY NAME Select “Sort/Category/City”. Select “Name”. Select “Enter a city name”. Enter name select “Search”. Enter city name select “Search”. Select the desired POI. “Any City”: Select to cancel the city set- “Sort/Category/City”: Select sort...
Page 217 2. DESTINATION SEARCH ■ WHEN “Near a City Center in XX ” SEARCHING BY CATEGORY IS SELECTED Select “Category”. Select “Near a City Center in XX”. Select the desired search point. Enter city name select “Search”. “Last 5 Cities”: Select the desired city name from the list of the last 5 cities.
Page 218: One-Touch Setting Home/ Favorite As Adestination
2. DESTINATION SEARCH SEARCHING BY PHONE ONE-TOUCH SETTING HOME/ NUMBER FAVORITE AS A DESTINATION Select “Phone #”. Enter a phone number and select To use this function, it is necessary to “OK”. register a home and/or a favorite location. Up to 2 favorites can be ...
Page 219 2. DESTINATION SEARCH Select the desired item. Function Select to set the registered home as the destination. Select to set a registered favorite as the destination. (Up to 2 favorites can be registered as preset destina- tions.)  The estimated time of arrival to the regis- tered home and preset destinations from the current position will be displayed.
Page 220: Starting Route Guidance
2. DESTINATION SEARCH 2. STARTING ROUTE GUIDANCE When the destination is set, the con- INFORMATION firm destination screen will be dis- ● The route for returning may not be the played. same as that for going. ● The route guidance to the destination Select “Go”...
Page 221: Confirm Destination Screen
 Select and hold to start the selected entry. demo mode. (P.222) *: This function is displayed only when there Displayed when the route is information from the Toyota Entune displayed is from the Toy- center. (P.212) ota Entune center. C-HR_Navi_USA_OM10581U_17CY...
Page 222 Distance of the freeway Distance of the ferry trip Information/Function Displayed when the route displayed is available from the Toyota Entune center. ( Select to display the quickest route. Select to display the route that is the shortest distance to the set destina- tion.
Page 223 2. DESTINATION SEARCH DISPLAYING TURN LIST EDITING ROUTE A list of turn information from the cur- Destinations can be added, reordered rent position to the destination can be or deleted, and conditions for the route displayed. to the destination can be changed. Select “Turn List”.
Page 224: A Route From The Toyota Entune Center (Vehicles With Dcm)
When starting route guidance or re- (P.210) routing, a route can be provided auto-  Up to 5 destinations can be set. matically by the Toyota Entune center. When the vehicle is stopped This function is available when dynam- ic route setting is enabled. (P.243) Select the “Add Destination Here”...
Page 225: Route Guidance
3. ROUTE GUIDANCE 1. ROUTE GUIDANCE SCREEN During the route guidance, various INFORMATION types of guidance screens can be dis- ● If the vehicle goes off the guidance played depending on conditions. route, the route will be recalculated. ● For some areas, the roads have not been completely digitized in our data- SCREEN FOR ROUTE base.
Page 226 3. ROUTE GUIDANCE  By selecting one of the number buttons, DISTANCE AND TIME TO the desired route information is displayed. DESTINATION INFORMATION When the vehicle is on the guidance ● When the vehicle is on the guidance route, the route information bar dis- route, the distance measured along the plays the distance with the estimated route is displayed.
Page 227: During Freeway Driving
3. ROUTE GUIDANCE WHEN APPROACHING DURING FREEWAY DRIVING FREEWAY EXIT OR JUNCTION During freeway driving, the freeway When the vehicle approaches an exit exit information screen will be dis- or junction, the freeway guidance played. screen will be displayed. No./ Information/Function Information/Function Icon...
Page 228 3. ROUTE GUIDANCE WHEN APPROACHING WHEN APPROACHING TOLLGATE JUNCTION When the vehicle approaches a toll- When the vehicle approaches a junc- gate, the tollgate guidance screen will tion, the real freeway junction guid- be displayed. ance screen with signage will be displayed.
Page 229: When Approaching An Intersection
3. ROUTE GUIDANCE WHEN APPROACHING AN TURN LIST SCREEN INTERSECTION Select “Turn List” on the map mode screen. (P.202) When the vehicle approaches an inter- section where it is necessary to turn, Check that the turn list screen is dis- the intersection guidance screen will played.
Page 230: Turn-By-Turn Arrow Screen
3. ROUTE GUIDANCE TURN-BY-TURN ARROW SCREEN On this screen, information about the next turn on the guidance route can be displayed. Select “Turn-by-Turn Arrow” on the map mode screen. (P.202) Check that the turn-by-turn arrow screen is displayed. Information/Function Exit number or street name Turn direction Distance to the next turn C-HR_Navi_USA_OM10581U_17CY...
Page 231: Typical Voice Guidance Prompts
3. ROUTE GUIDANCE 2. TYPICAL VOICE GUIDANCE PROMPTS As the vehicle approaches an intersec- tion, or point, where maneuvering the vehicle is necessary, the system’s voice guidance will provide various messages. WARNING ● Be sure to obey the traffic regulations and keep the road condition in mind especially when you are driving on IPD roads.
Page 232: Route Options Operation
3. ROUTE GUIDANCE 3. ROUTE OPTIONS OPERATION REORDERING Select on the map screen. DESTINATIONS (P.196) Select the desired item to be set. When more than 1 destination has been set, the arrival order of the desti- nations can be changed. Select on the map screen.
Page 233: Setting Route Preferences
GPS signals, it is automatically Select to select the alternative route. corrected. Select to select the route from the Toyota Entune center. *: This function is not available in some coun- tries and areas.  The entire route from the starting point to the (...
Page 234: Detour Setting
3. ROUTE GUIDANCE DETOUR SETTING INFORMATION ● This picture shows an example of how During the route guidance, the route the system would guide around a delay caused by a traffic jam. can be changed to detour around a section of the route where a delay is caused by road repairs, an accident, etc.
Page 235: Adjacent Road
3. ROUTE GUIDANCE ADJACENT ROAD When a freeway and a surface road run in parallel, the system may show the guidance route going on the free- way while driving on the surface road, or vice versa. If this happens, you can instantly choose the adjacent road for the route guidance.
Page 236: Memory Points
4. MEMORY POINTS 1. MEMORY POINTS SETTINGS Select the desired item to be set. Home, Favorites, areas to avoid can be set as memory points. The regis- tered points can be used as the desti- nations. (P.210) Registered areas to avoid, will be avoided when the system searches for a route.
Page 237: Memory Points
4. MEMORY POINTS EDITING HOME SETTING UP HOME Select “Edit”. If home has been registered, that infor- mation can be recalled by selecting Select the desired item to be edited. on the destination screen. (P.212) Display the navigation settings screen. (P.236) Select “Home”.
Page 238: Setting Up Favorites List
4. MEMORY POINTS REGISTERING FAVORITE LIST SETTING UP FAVORITES ENTRIES LIST Select “New”. Points on the map can be registered. Select the desired item to search for Display the navigation settings screen. the location. (P.210) (P.236) Select “Enter” when the setting map Select “Favorites”.
Page 239 4. MEMORY POINTS EDITING FAVORITE LIST Function Page ENTRIES Select to edit the favorites list entry name. The icon, name, location and/or phone number of a registered favorites list en- Select to set display of the  favorites list entry name on/ try can be edited.
Page 240 4. MEMORY POINTS ■ When “With Sound” is selected CHANGING THE NAME Select “Name”. A sound for some favorites list entries can be set. When the vehicle ap- Enter a name and select “OK”. proaches the location of the favorites list entry, the selected sound will be ■...
Page 241: Setting Up Areas To Avoid
4. MEMORY POINTS REGISTERING AREAS TO SETTING UP AREAS TO AVOID AVOID Select “New”. Areas to be avoided because of traffic jams, construction work or other rea- Select the desired item to search for sons can be registered as “Areas to the location.
Page 242 4. MEMORY POINTS ■ CHANGING THE NAME EDITING AREAS TO AVOID Select “Name”. The name, location and/or area size of a registered area can be edited. Enter a name and select “OK”. ■ Select “Edit”. CHANGING THE LOCATION Select the desired area. Select “Location”.
Page 243: Setup
5. SETUP 1. DETAILED NAVIGATION SETTINGS Settings are available for pop-up infor- SCREENS FOR NAVIGATION mation, favorite POI categories, low SETTINGS fuel warning, etc. Press the “MENU” button. BG054S Select “Setup”. Select “Navigation”. Select “Detailed Navi. Settings”. Select the desired items to be set. C-HR_Navi_USA_OM10581U_17CY...
Page 244 Select to set favorite POI categories that are used for Select to enable/disable POI selection to display on routes sourced from the the map screen. Toyota Entune center. Select to adjust the current Select to reset all setup  position mark manually or items.
Page 245 5. SETUP FAVORITE POI CATEGORIES CURRENT POSITION/TIRE (SELECT POI ICONS) CHANGE CALIBRATION Display the detailed navigation settings Up to 6 POI icons, which are used for ( selecting POIs on the map screen, can screen. P.243 be selected as favorites. Select “Calibration”.
Page 246 5. SETUP ■ POSITION/DIRECTION CALIBRA- LOW FUEL WARNING TION When the fuel level is low, a warning When driving, the current position message will pop up on the screen. mark will be automatically corrected by GPS signals. If GPS reception is poor Display the detailed navigation settings due to location, the current position (...
Page 247: Traffic Settings
5. SETUP 2. TRAFFIC SETTINGS* Traffic information such as traffic con- Function gestion or traffic incident warnings can Select to set specific routes (such as be made available. frequently used routes) on which you wish to receive traffic informa- Press the “MENU” button. tion.
Page 248: Avoid Traffic
5. SETUP ■ CHANGING THE ROUTE MANUAL- AVOID TRAFFIC Display the traffic setting screen. When the navigation system calcu- (P.247) lates a new route, the following screen will be displayed. Select “Avoid Traffic”. Select the desired item. Select the desired item. Function Function Select...
Page 249: My Traffic Routes
5. SETUP REGISTERING PERSONAL MY TRAFFIC ROUTES TRAFFIC ROUTES Specific routes (such as frequently Select “New”. used routes) on which you wish to re- ceive traffic information can be regis- Select “Name”. tered as “My Traffic Routes”. A route is Enter the name and select “OK”.
Page 250 5. SETUP EDITING PERSONAL TRAFFIC SETTING PREFERRED ROADS ROUTES “My Traffic Routes” can be adjusted by Select “Edit”. setting up to 2 preferred roads. Select the desired traffic route. Select “Set Preferred Roads”. Select the desired item to be edited. Select the desired item.
Page 251 5. SETUP ■ ■ ADDING PREFERRED ROADS MODIFYING PREFERRED ROADS Select “Add”. Select “Modify”. Scroll the map to the desired point Select the desired preferred road to be (P.200) and select “OK”. modified if 2 preferred roads have been set. Select “OK”...
Page 252: Use Of Information Accumulated By Navigation System (Vehicles With Dcm)
5. SETUP 3. USE OF INFORMATION ACCUMULATED BY NAVIGATION SYSTEM* (VEHICLES WITH DCM) When enabled, information collected by the navigation system will be ana- lyzed to give advice for safe driving. Press the “MENU” button. BG054S Select “Setup”. Select “Navigation”. Select “Useful Navi.
Page 253: Tips For The Navigation System
6. TIPS FOR THE NAVIGATION SYSTEM 1. GPS (GLOBAL POSITIONING SYSTEM) LIMITATIONS OF THE NOTICE NAVIGATION SYSTEM ● The installation of window tinting may obstruct the GPS signals. Most window This navigation system calculates the tinting contains some metallic content current position using satellite signals, that will interfere with GPS signal recep- various vehicle signals, map data, etc.
Page 254 6. TIPS FOR THE NAVIGATION SYSTEM  Accurate current position may not be  Inappropriate route guidance may occur in shown in the following cases: the following cases: • When driving on a small angled Y- • When turning at an intersection off the shaped road.
Page 255: Map Database Version And Covered Area
DCM) (P.196) Select “Map Data”. If the map data has been provided from the Toyota Entune center for any of the Check that the map data screen is dis- following areas and the map data in the played. system is older than what has been...
Page 256 6. TIPS FOR THE NAVIGATION SYSTEM C-HR_Navi_USA_OM10581U_17CY...
Page 257: Toyota Entune
OR DCM........259 ENTERING KEYWORD BEFORE USING THE FUNCTION..261 OPERATION ........270 PREPARATION BEFORE USING Toyota Entune App Suite Connect..262 SETUP 3. TYPE B: FUNCTION ACHIEVED BY USING DCM AND THE 1. Toyota Entune App Suite SYSTEM........263 Connect SETTINGS ....
Page 258: Toyota Entune-Overview
Assist Connect, Dynamic Navigation, Wi-Fi Hotspot and Safety Connect.  The functions included in Toyota Entune are classified into the following three types. Type A: Function achieved by using a smart phone or an embedded cellular de- vice in the vehicle (DCM: Data Communication Module)
Page 259: Type A: Function Achieved By Using A Smart Phone Or Dcm
DCM. Using a smart phone  Toyota Entune App Suite Connect enables applicable apps installed on a smart phone to ® be displayed on and operated from the screen via a Bluetooth and USB.
Page 260 System vider servers is displayed on the screen. The system is equipped with an application player to run applications. *: For known compatible phones, refer to http://www.toyota.com/Entune/ in the United States, http://www.toyota.ca/entune in Canada, and http://www.toyotapr.com/entune in Puerto Rico. C-HR_Navi_USA_OM10581U_17CY...
Page 261: Before Using The Function
INFORMATION to the system, and the registration ● Data usage fees may apply while using steps for the Toyota Entune App Suite Toyota Entune App Suite Connect func- tion. Confirm data usage fees before Connect are explained in this section.
Page 262: Preparation Before Using Toyota Entune App Suite Connect
Register the smart phone with the or the system. system. Enter the information required into the In order to use Toyota Entune App Suite Toyota Entune App Suite Connect ap- Connect, the following must first be per- plication. Login to the application.
Page 263: Type B: Function Achieved By Using Dcm And The System
AVAILABILITY OF FUNCTIONS by the Toyota Entune center, which op- erates 24 hours a day, 7 days a week.  These functions are not made available in some countries or areas.
Page 264: Destination Assist Connect
Press the “MAP” button. Destination Assist Connect provides you with live assistance for finding des- tinations via the Toyota Entune center. You can request either a specific busi- ness, address, or ask for help locating your desired destination by category,...
Page 265: Type C: Function Achieved By Using Dcm
The functionality of Safety Connect is complies with the FCC guidelines in addition to those standards. made possible by the use of a DCM. ● Contact with the Toyota Entune center is details, refer “OWNER’S dependent upon the telematics device MANUAL”.
Page 266 1. Toyota Entune-OVERVIEW ACTIVATION OF FUNCTION(S)  Enrollment in Safety Connect (via your dealership) is required to activate all functions. C-HR_Navi_USA_OM10581U_17CY...
Page 267: Toyota Entune Operation
2. Toyota Entune OPERATION 1. Toyota Entune App Suite Connect From the “APPS” button USING Toyota Entune App Press the “APPS” button. Suite Connect App Suite is a function that enables certain apps installed on a smart phone or the system to be displayed on and operated from the system screen.
Page 268 INFORMATION “Cancel”: Select to cancel updating. ● The Toyota Entune App Suite Connect function cannot be operated while Check that downloading is complete. installing. “Later”: Select to install later. When this screen button is selected, the screen will REORDERING THE return to the last displayed screen.
Page 269 States, http://www.toyota.ca/ The smart phone cannot be shooting assistance, please entune in Canada, and http:// connected. visit the Toyota website or www.toyotapr.com/entune in contact your dealer.” Puerto Rico, to confirm if the phone is compatible or not. “This feature is unavailable...
Page 270: Entering Keyword Operation
2. Toyota Entune OPERATION ENTERING A KEYWORD USING ENTERING KEYWORD THE SOFTWARE KEYBOARD OPERATION Display application screen. A keyword can be entered to an appli- (P.267) cation by the software keyboard or Select the desired application screen voice recognition function. For details about the functions and services pro- button.
Page 271: Setup
3. SETUP 1. Toyota Entune App Suite Connect SETTINGS The settings of Toyota Entune App Toyota Entune App Suite Suite Connect can be changed. Connect SETTINGS SCREEN Press the “MENU” button. Function BG054S Select to set the pop up reminder for Select “Setup”.
Page 272 POP-UP SETTINGS The data use notification pop-up, which indicates that the system will use an internet connection, can be en- abled/disabled. Display the Toyota Entune App Suite Connect settings screen. (P.271) Select “Data Usage Message”. Change the setting as desired. C-HR_Navi_USA_OM10581U_17CY...
Page 273: Appendix/Index
APPENDIX/INDEX APPENDIX ........274 ALPHABETICAL INDEX ....286 C-HR_Navi_USA_OM10581U_17CY...
Page 274: Appendix
APPENDIX APPENDIX Map database information and updates C-HR_Navi_USA_OM10581U_17CY...
Page 275 C-HR_Navi_USA_OM10581U_17CY...
Page 276 APPENDIX C-HR_Navi_USA_OM10581U_17CY...
Page 277 C-HR_Navi_USA_OM10581U_17CY...
Page 278 APPENDIX C-HR_Navi_USA_OM10581U_17CY...
Page 279 C-HR_Navi_USA_OM10581U_17CY...
Page 280 APPENDIX C-HR_Navi_USA_OM10581U_17CY...
Page 281 C-HR_Navi_USA_OM10581U_17CY...
Page 282 APPENDIX Certification For vehicles sold in the U.S.A., Hawaii, Guam and Puerto Rico C-HR_Navi_USA_OM10581U_17CY...
Page 283 For vehicles sold in Canada C-HR_Navi_USA_OM10581U_17CY...
Page 284 APPENDIX Gracenote C-HR_Navi_USA_OM10581U_17CY...
Page 285 For U.S. owners C-HR_Navi_USA_OM10581U_17CY...
Page 286: Alphabetical Index
ALPHABETICAL INDEX ALPHABETICAL INDEX AM/FM/SiriusXM (SXM) radio....85 Basic function........12, 29 Available HD Radio™ technology ..92 Basic information before operation ...30 Caching a radio program....... 88 Basic operation .........78, 196 ® Displaying the radio ID ......95 Bluetooth audio ........105 HD Radio™...
Page 287 Data services settings......144 Function index........... 26 Setting download methods....144 Functional overview ........258 Destination search ........210 Destination search operation ....210 One-touch setting home/favorite as General settings........64 a destination ........218 General settings screen ......64 Searching by address ......214 GPS (Global Positioning System) ...253 Searching by contact......
Page 288 ALPHABETICAL INDEX Linking multi-information display and the Natural language understanding .....130 system ........... 42 Navigation operation .........22 Navigation system........195 Map database version and covered area ............. 255 Operating information......116 Map information........255 Error messages ........124 Temporary updates of the map File information ........119 (Vehicles with DCM) ......
Page 289 Registering favorite destinations....23 Registering home........22 Quick guide..........11 ® Registering/connecting a Bluetooth Quick reference ....20, 78, 156, 196 device ............ 43 Map screen ......... 196 Profiles ..........46 ® Registering a Bluetooth audio player for the first time ........45 ®...
