JVC KT-SR3000 Manual

Hide thumbs Also See for KT-SR3000:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual

Advertisement

Table of Contents
loading

Related Manuals for JVC KT-SR3000

Summary of Contents for JVC KT-SR3000

  • Page 2 Pressing DISP will switch between these two display views. Search Modes (Category, Channel, Artist, Song Title) The KT-SR3000 Receiver has four ways to search for and select music: by category, by channel, by artist, and by song title. Searching Categories...

  • Page 3: Searching Channels (Channel List Mode)

    1. Use the CATEGORY buttons to scroll through music and entertainment categories. 2. When the category (ex. Rock) you want is displayed, use the Up/Down key to search available channels within the category. • Pressing the DISP button while in the Category Search mode will change between Channel Name, Artist Name, and Song Title to be able to preview what is playing on other channels before selecting.
  • Page 4 Press DISP again to show the Artist Name Press DISP again to show the Song Title Press DISP again to go back to Channel List Note: If you are in Channel List Mode and viewing a sports category channel list (NFL Zone, NHL Zone), pressing the DISP button will toggle between the team names and the current score of any live play-by-play game.

  • Page 5: Setting Channel Presets

    Jump Preset Button The KT-SR3000 Receiver includes a special preset button labeled Jump. It can be used for channels that are accessed frequently and temporarily such as traffic, weather, news or sports. This button allows you to quickly tune to one specific channel and then tune back to the original channel.

  • Page 6: Searching For A Channel Preset (P.tune Mode)

    Searching for a Channel Preset (P.TUNE Mode) It is possible to quickly search through all of your presets using Up/Down key. 1. Press and hold the BAND button to enter the Preset Tune Mode (P.TUNE). 2. The bottom right portion of the display will change to highlight the current preset. 3.

  • Page 7: Memory (Memo) And Song Seek (S-Seek) Functions

    P.TUNE Channel Name List Display P.TUNE Artist Name List Display P.TUNE Song Title List Display Memory (MEMO) and Song Seek (S-Seek) Functions This feature allows the user to capture and store information about the programming (Artist/Song, sports team, or traffic city) on the currently tuned channel, up to a total of 20 listings.
  • Page 8 2. Sports Games: If the current tuned channel is an NFL , NBA , NHL , or College play-by-play sports broadcast, ® ® ® pressing the MEMO button will allow you to select one of the teams playing to be stored in memory. Press Up/Down key to highlight the team you wish to store in memory and press the Select key to select.

  • Page 9: Viewing Program Information Stored In Memory

    Use Up/Down key to choose the item that you would like to overwrite with the new Artist/Song Title, sports game, or traffic city. After highlighting the selected item in the list, press the Select key to delete the stored Artist/Song Title, sports team, or traffic city and replace it with the updated information.
  • Page 10 2. Use Up/Down key to highlight the “Delete” option. 3. Press the Select key and a Delete confirmation screen will appear. 4. To permanently delete the program from your list, select “Yes” using the Up/Down and press the Select key to confirm.

  • Page 11: Activating The Song (S-Seek) Alert

    Select key to confirm (below right). Whenever the KT-SR3000 Receiver is turned on, it automatically searches the incoming channels to determine if a match exists with the program information stored in receiver’s memory. If one or more matches are found, a pop-up screen momentarily appears for 2 seconds and displays “S-Seek Alert”.

  • Page 12: Game Alert

    Game Alert The KT-SR3000 Receiver can automatically identify when your favorite team is playing. When a game is found, the Game Alert screen is displayed, followed by tuning information for that game. Use the Up/Down buttons to select and tune to the desired channel.

  • Page 13: Instant Replay

    Instant Replay The KT-SR3000 Receiver is capable of storing the audio of the channel to which you are listening for later playback, approximately up to 44 minutes depending upon the channel to which you are tuned. As soon as you tune to a channel, the Receiver automatically begins storing the audio, enabling you to rewind at any time to replay the audio again.
  • Page 14 The Instant Replay mode icon that is displayed at the bottom left of the screen indicates the current mode. Pause mode. This indicates that the Receiver is paused and muted. Play mode. This indicates that you are in the playback mode, listening to stored audio. Fast Forward mode.
  • Page 15 The Progress Bar is a visual indicator of the status of the Instant Replay memory. As the memory fills, progress Bar begins to fill from the left side providing a visual indication of how much of the Instant Replay memory is filled. The end of the bar indicates the end of the stored audio, where the live broadcast begins.

  • Page 16: Menu Display Options

    Should you press the Play/Pause button to pause the playback, the play position indicator will stop moving and continue to provide a visual indication of your current position in the Instant Replay memory. When paused and the Instant Replay memory is 10 seconds from becoming full, two beeps will be heard (if the Confirmation Tone option is enabled).
  • Page 17 Sirius ID Displays your 12 digit Sirius ID (SID) number. The SID is unique to every KT-SR3000 Receiver and is required to activate your service. It is recommended that you write this number in the space provided on the last page of this user guide.

  • Page 18: Jump Settings

    When the SIRIUS receiver is powered on, and while it is playing, “Initial Game Alert” will sound an alert when the team you have chosen is playing a game. “All Score Updates” does the same but also sounds an alert when the scores are updated for the chosen team.

  • Page 19: Display Settings

    Confirm Tone Options The KT-SR3000 Receiver will sound an Audio “Tone” alert when the unit powers ON and OFF as well as when the S- Seek Alert is activated. The default is ON. To change the tone options, perform the following: 1.

  • Page 20: Channel Add Or Skip

    Channel Add or Skip The KT-SR3000 Receiver will allow you to skip selected channels when changing channels via Up/Down buttons. At any time you may select to add or skip specific channels. While in the “Menu Options” List mode, follow the steps below to Add or Skip a channel: 1.

  • Page 21: Lock Options

    Lock Options The KT-SR3000 Receiver has the ability to lockout the use of any channel, or channels you do not want others to access without your permission. Like the Skip feature, the locked channel will not appear when the user changes channels with the Up/Down buttons.

  • Page 22: Audio Level

    Audio Level The audio output of the KT-SR3000 Receiver can be adjusted to fine-tune the audio signal level for maximum performance. This is important when using either the optional Home Docking Station or the optional Mobile Docking Station. The following setting affects both the line output and FM output levels. To change the Audio Level, perform the following procedure while in the “Menu Options”...

  • Page 23: Memory Options

    Memory Options In this mode, the user can turn the Memory Search Function (S-Seek) ON or OFF. In addition, all 30 Preset Memory Locations can be cleared. To change the Memory Options, use the following procedure while in the “Menu Options” List mode: 1.

  • Page 24: Factory Default

    selected channel at a specific time. Press the Select key to enter the Program Alert Menu, The following adjustment options are available: • Program Time/Day: Using the Up/Down key toggles between Time and Day. If Time is selected, use the Category buttons and Up/Down buttons to set the hours and minutes.
  • Page 25 • All Presets revert to empty • All Game Alerts Cleared • Auto Dimming On • Display Contrast to 50% • Display Mode to Auto • FM Modulator to On • FM Frequency to 88.1 MHz • Audio Output Level to 70% •...
