Super Wash
This option offers a high-performance wash due to the greater quantity of
water used in the initial phase of the cycle, and due to the increased wash
cycle duration, is particularly useful for the removal of stubborn stains.
Slow Spin
By selecting this function, reduces the spin speed.
Timer Saver
If you select this option, the wash cycle duration will be reduced by up to
50%, depending on the selected cycle, thereby guaranteeing simultaneous
water and energy saving. Use this cycle for lightly soiled garments.
Eco Wash
The Eco Wash option saves energy by not heating the water used to wash
your laundry – an advantage both to the environment and to your energy
bill. Instead, intensified wash action and water optimisation ensure great
wash results in the same average time of a standard cycle. For the best
washing results we recommend the usage of a liquid detergent.
By also turning the DRYING knob to the
automatically activates at the end of the wash cycle that also helps to
reduce energy consumption, thanks to an optimal combination of air
temperature and cycle duration.
Temperature
Turn the TEMPERATURE knob to set the wash temperature (see Table of
wash cycles).
The temperature may be lowered, or even set to a cold wash ( ). The
washer-dryer will automatically prevent you from selecting a temperature
which is higher than the maximum value set for each wash cycle.
Drying
Turn the DRYING knob to set the desired drying type.
Two options are available:
A - Based on time: from 40 to 180 minutes.
B - Based on the how damp the clothes are once they have been dried:
Iron
: slightly damp clothes, easy to iron.
Hanger
: dry clothes to put away.
Cupboard
: very dry clothes, recommended for towelling and
bathrobes.
If your laundry load to be washed and dried is much greater than the
maximum stated load (see adjacent table), perform the wash cycle, and
when the cycle is complete, divide the garments into groups and put
some of them back in the drum. At this point, follow the instructions
provided for a "Drying only" cycle. Repeat this procedure for the
remainder of the load.
N.B: when the drying is complete there is a cooling period, even though
the DRYING knob is in the
Drying only
Turn the WASH CYCLE knob to one of the drying settings (12-13-14)
according to the type of fabric, then select the desired drying duration
using the DRYING knob.
Selecting the cotton drying cycle (
selector knob and pressing the "Eco" button activates an automatic drying
cycle that allows for saving energy, thanks to an optimal combination of air
temperature and cycle duration.
TIPS AND SUGGESTIONS
Divide the laundry according to:
Type of fabric (cotton, mixed fibres, synthetics, wool, garments to be
hand-washed). Colour (separate coloured garments from whites, wash
new coloured garments separately). Delicates (small garments – such as
nylon stockings – and items with hooks – such as bras: insert them in a
fabric bag).
Empty the pockets:
Objects such as coins or lighters can damage the washer-dryer and the
drum. Check all buttons.
CARE AND MAINTENANCE
Before performing cleaning and maintenance, switch the washer-dryer off
and disconnect it from the mains power. Do not use flammable liquids to
clean the washer-dryer.
Cutting off the water and electricity supplies
Close the water tap after every wash. This will limit wear on the hydraulic
system inside the washer-dryer and help to prevent leaks.
Unplug the washer-dryer when cleaning it and during all maintenance
work.
Cleaning the washer-dryer
The outer parts and rubber components of the appliance can be cleaned
using a soft cloth soaked in lukewarm soapy water. Do not use solvents or
abrasives.
The washer-dryer has a "Auto-Clean" cycle for its internal parts; it must be
run without any load in the drum.
To optimise this cycle, it is possible to use either detergent (10% of the
quantity specified for lightly soiled garments) or special additives to clean
the washer-dryer. We recommend running a cleaning cycle every 40 wash
cycles.
To start the cycle press buttons "Super Wash" and "Slow Spin"
simultaneously for 5 seconds.
The cycle will start automatically and will run for about 70 minutes. To
stop the cycle, press the START/PAUSE
position, a drying cycle
position.
position) through the programme
button.
Cleaning the detergent dispenser drawer
Remove the dispenser drawer by lifting and pulling it outwards. Wash it
under running water; this procedure should be effected regularly.
Caring for the door and drum
Always leave the porthole door ajar in order to prevent unpleasant odours
from forming.
Cleaning the pump
The washer-dryer is fitted with a self-cleaning pump that does not require
any maintenance. Small items (such as coins or buttons) may sometimes
fall into the protective pre-chamber situated at the base of the pump.
! Make sure that the wash cycle has ended and unplug the appliance.
To access the pre-chamber:
1. remove the covering panel on the front side of the machine by
inserting a screwdriver in the centre and sides of the panel and using it as
a lever;
2. loosen the drainage pump cover by turning it anti-clockwise: it is
normal for some water to leak out;
3. clean the inside thoroughly;
4. screw the cover back on;
5. put the panel back in place, making sure the hooks slot in place before
pushing the panel onto the appliance.
Checking the water inlet hose
Check the water inlet hose at least once a year. If it is cracked or broken, it
must be replaced: during wash cycles, the high pressure of the water
could suddenly split the hose open.
! Never use hoses that have already been used.
LOAD BALANCING SYSTEM
Before every spin cycle, to avoid excessive vibrations before every
spin and to distribute the load in a uniform manner, the drum rotates
continuously at a speed which is slightly greater than the washing
rotation speed. If, after several attempts, the load is not balanced
correctly, the machine spins at a reduced spin speed. If the load is
excessively unbalanced, the washer-dryer performs the distribution
process instead of spinning. To encourage improved load distribution and
balance, we recommend small and large garments are mixed in the load.
ACCESSORIES
Contact our Technical Assistance Service to check whether the following
accessories are available for this washer-dryer model.
Stacking kit
With this accessory you can secure the tumble dryer to the upper part of
your washer-dryer to save space and facilitate loading and unloading of
the tumble dryer.
TRANSPORT AND HANDLING
Do not lift the washer-dryer by gripping it from the upper section.
Unplug the appliance and close the water tap. Check that the door and
detergent dispenser drawer are tightly closed. Detach the filling hose
from the water tap then detach the drain hose. Empty all the water
remaining in the hoses and secure the latter so that they do not get
damaged during transport. Apply the transport bolts back on. Repeat, in
reverse order, the transport bolt removal procedure described in the
"Installation instructions".
Important: Not emptying contents from pockets may cause pump or drain
blockages, or may damage the machine.
Do not wash items which do not have a wash label, or wash items that are
not intended as machine washable.
