Panasonic NE-1853QPQ Service Manual

TABLE OF CONTENTS
1 Safety Precautions----------------------------------------------- 2
2 Specifications ----------------------------------------------------- 2
3 Location of Controls and Components ------------------- 3
4 Operating Instructions------------------------------------------ 4
5 Test Mode ----------------------------------------------------------16
6 Troubleshooting Guide ----------------------------------------18
7 Disassembly and Assembly Instructions ---------------20
8 Measurements and Adjustments---------------------------24
9 Wiring Connection Diagram ---------------------------------25
10 Schematic Diagram ---------------------------------------------26
11 Exploded View and Replacement Parts List -----------27
Model No.
Destination: Australia, New Zealand
PAGE
© Panasonic Corporation 2014 Unauthorized copy-
ing and distribution is a violation of law.
Order Number MOD1407414CE
Microwave Oven
NE-1853QPQ
