3.4.5 Temperature setting hot water generation
The hot water set temperatures for hot water generation for each
individual timer programme are determined in the rotary switch
setting
.
● Place the rotary switch in the "DHW Set Temp"
The end figures of the parameter designations (1 - 3)
within this rotary switch setting designate the associ-
ation with each individual cycle of the timer programme.
● Select the temperature block to be set with the rotary switch.
● Confirm the changes with a brief push of the rotary switch.
Settings are displayed.
● Set the temperature.
● Confirm the changes with a brief push of the rotary switch.
Change has been accepted. Jump back to previous dis-
play.
More detailed explanations and possible setting values for this rotary switch setting
can be seen in chapter 5.7.
3.4.6 Unplanned hot water generation
You can charge the hot water up manually outside a hot water
timer programme to the preset temperature set in parameter
[T-DHW Setpoint 1] in the rotary switch position
is carried out as a priority and independently of any other heating
programmes.
● Place the rotary switch in the "DHW Install"
An overview is displayed.
● Select the parameter to be set with the rotary switch.
– [1x Hot Water]: Activating one-off hot water generation.
● Confirm the changes with a brief push of the rotary switch.
● Setting parameters.
● Confirm the changes with a brief push of the rotary switch.
Start unplanned hot water generation.
After this temporary function has expired, the Control
automatically jumps back to the previously active oper-
ating mode. The rotary switch should therefore be re-
turned to the position "Info"
The function is subject to time limits.
It is interrupted at the latest after the time set in the pa-
rameter [Max DHW loading time] and cannot be re-
started once more until the time set in the parameter
[DHW Off Time] has passed.
Possible setting values for this rotary switch setting can be seen in chapter 5.3.
3.4.7 Switching time program
Various different timer programmes are available, that are set in
the factory, but which can be adjusted to suit, to provide conven-
ient and individual room and hot water temperature control.
The timer programmes regulate the associated heating circuit,
the storage tank charging circuit and an option connected circu-
lation pump in accordance with the stipulated switching times.
Adjustment
In the rotary switch position
the heating circuit, the integrated hot water generation and the
optional circulation pump.
Daikin RoCon HP
Daikin Control
008.1420844 – 05/2014
position.
. Heating up
position.
after activation.
we set the time intervals for
● Place the rotary switch in the "Time Program"
position.
An overview is displayed.
● Select the timer programme to be set with the rotary switch.
● Confirm the changes with a brief push of the rotary switch.
Settings are displayed.
● Select and change the value to be set with the rotary switch.
● Confirm the changes with a brief push of the rotary switch.
More detailed explanations and possible setting values for this rotary switch setting
can be seen in chapter 5.8 "Rotary switch setting: Time Program".
Permanent timer programmes
For the connected heating circuits and the storage tank charging
circuit, timer programmes regulate the heating circuit tempera-
tures or the operating times for the circulation pump in ac-
cordance with the stipulated switching cycles. The switching
cycles are saved in time blocks for which various different set
temperatures apply.
In the switching cycles the heating system is regulated differen-
tiated into day and economy mode.
The target room temperatures for these timer programmes are
set in "Set Temp Day"
, "Set Temp Night"
.
Set Temp"
The following timer programmes are available:
– 2 timer programmes for the heating circuit, each with 3
possible time cycles
– [HC Program 1]
– [HC Program 2]
A separate input for each individual day of the week is
possible, or in blocks of "Monday to Friday", "Saturday
to Sunday" and "Monday to Sunday".
Programme
Time period
Single day of the week
(Monday, Tuesday ...)
HC Program 1
Working week
(Monday to Friday)
Weekend
(Saturday to Sunday)
Entire week
(Monday to Sunday)
HC Program 1
HC Program 2
Tab. 3-8 Menu structure heating circuit timer programme
3
x
Operation
and "DHW
Switching cycle
1.
06:00 -> 22:00
2.
--:-- -> --:--
3.
--:-- -> --:--
1.
06:00 -> 22:00
2.
--:-- -> --:--
3.
--:-- -> --:--
1.
07:00 -> 23:00
2.
--:-- -> --:--
3.
--:-- -> --:--
1.
06:00 -> 22:00
2.
--:-- -> --:--
3.
--:-- -> --:--
See
1.
See
2.
HC Program 1
3.
Operating instructions
13
