OPERATING GUIDE
dPMR446/PMR446 TRANSCEIVER
|F29SDR
INTRODUCTION
1
ACCESSORIES
2
PANEL DESCRIPTION
3
BASIC OPERATION
4
ADVANCED OPERATION
5
USER SET MODE
6
dPMR
OPERATION

Advertisement

Table of Contents
loading

Summary of Contents for Icom dPMR446

  • Page 1 OPERATING GUIDE INTRODUCTION ACCESSORIES dPMR446/PMR446 TRANSCEIVER PANEL DESCRIPTION |F29SDR BASIC OPERATION ADVANCED OPERATION USER SET MODE dPMR OPERATION ™...
  • Page 2 MoU Association. • The use of Icom transceivers with any equipment that is All other products or brands are registered trademarks or not manufactured or approved by Icom. trademarks of their respective holders.
  • Page 3 Section ACCESSORIES Attaching or detaching accessories ��������������������������������������������������������1-2 D Battery pack ������������������������������������������������������������������������������������1-2 D Belt clip �������������������������������������������������������������������������������������������1-2 D Jack cover ���������������������������������������������������������������������������������������1-3...
  • Page 4 ACCESSORIES Attaching or detaching accessories D Battery pack D Belt clip Attaching: Attaching: 1� Slide the battery pack in the direction of the arrow� 1� Remove the battery pack from the transceiver, if it ( 1 ) is attached� 2� Push the battery pack until the battery sliding 2�...
  • Page 5 ACCESSORIES Attaching or detaching accessories D Jack cover CAUTION: DO NOT use the transceiver without the connector cover or optional equipment attached� The transceiver meets IP67/IP55/IP54 requirements for dust-tight and waterproof protection only when the connector cover or the HM-168LWP, HS-94LWP, or HS-95LWP is attached�...
  • Page 6: Table Of Contents

    Section PANEL DESCRIPTION Front, top and side panels ����������������������������������������������������������������������2-2 D Status indicator �������������������������������������������������������������������������������2-2 D About the Software Key functions ���������������������������������������������������2-2 Function display��������������������������������������������������������������������������������������2-3 Status indicator ���������������������������������������������������������������������������������������2-4 Assignable Software Key functions ��������������������������������������������������������2-6...
  • Page 7: Section 2 Panel Description

    PANEL DESCRIPTION Front, top and side panels D Status indicator • Lights red: Transmitting� • Lights green: Receiving or squelch is open� • Lights or blinks orange: A matching signal is received, Antenna [Rotary Selector] depending on the presetting� • Slowly blinks green: The battery should be charged� [VOL] •...
  • Page 8: Function Display

    PANEL DESCRIPTION Function display 1 2 3 4 5 6 BATTERY INDICATOR 1 SIGNAL STRENGTH INDICATOR Displays the remaining battery charge� Displays the relative receive signal strength level� Indication 2 AUDIBLE ICON Battery Charging Battery Displayed when the channel is in the ‘Audible’ Full Status required...
  • Page 9: Status Indicator

    PANEL DESCRIPTION Status indicator The Status indicator indicates the status of various parameters of the transceiver, as described below� (Reference: R=Red, G=Green, O=Orange) • Programming: Blinks while reading or writing data� • Programming Error: Continuously blinks green and red if programming fails�...
  • Page 10 PANEL DESCRIPTION Status indicator (Continued) • CH Access: Blinks orange while making a call� • Audible: Blinks orange while in the Audible mode� • Power ON: Lights orange, then blinks red, orange, and green O O O R O G R O G twice at transceiver startup�...
  • Page 11: Assignable Software Key Functions

    PANEL DESCRIPTION Assignable Software Key functions Category Assignable function Reference Digital (dPMR446) Analog Null p� 2-7 ✓ ✓ Clear p� 2-7 ✓ ✓ Auto CH p� 2-7 ✓ ✓ CH Up, CH Down p� 2-7 ✓ ✓ CH Up/Zone UP p�...
  • Page 12 PANEL DESCRIPTION Assignable Software Key functions (Continued) Null Category: Channel/Scan No function� Auto CH z Push to automatically search a clear channel Clear during� z Push to return to the inaudible mode and automatically send a Clear Down signal� (Digital CH Up, CH Down operation only) z Push to select an operating channel�...
  • Page 13 PANEL DESCRIPTION Assignable Software Key functions (Continued) Category: Signaling/Call Code/Select z Push to enter the Code Select mode which is the A-Ring Common ID for the Digital mode� Hold down to transmits the alert signal to other stations� z Hold down for 1 second to turn the Status Select •...
  • Page 14 PANEL DESCRIPTION Assignable Software Key functions (Continued) Category: Functions My Name Push to display the programmed “My Name�” Announce Push to turn the Channel Announce function ON or Siren OFF� Hold down to emit a siren sound from the speaker L You can also turn ON this function by holding down [ to let surrounding people know that you are in an when you turn ON the transceiver�...
  • Page 15 Section BASIC OPERATION Turning ON the transceiver ��������������������������������������������������������������������3-2 D Turning ON the transceiver �������������������������������������������������������������3-2 D Adjusting the audio level �����������������������������������������������������������������3-2 D Entering the password ��������������������������������������������������������������������3-2 Selecting a Zone�������������������������������������������������������������������������������������3-3 D Selecting a Zone �����������������������������������������������������������������������������3-3 Selecting a channel ��������������������������������������������������������������������������������3-3 D Selecting an operating channel ������������������������������������������������������3-3 D Favorite CH function �����������������������������������������������������������������������3-3 Call procedure ����������������������������������������������������������������������������������������3-4 Receiving and transmitting ���������������������������������������������������������������������3-5...
  • Page 16: Section 3 Basic Operation

    BASIC OPERATION Turning ON the transceiver D Turning ON the transceiver NOTE: Before using the transceiver for the fi rst time, the battery pack must be fully charged for optimum [Rotary Selector] life and operation� See the BASIC MANUAL for details�...
  • Page 17: Selecting A Zone

    BASIC OPERATION Selecting a Zone Selecting a channel D Selecting a Zone D Selecting an operating channel To select a channel: TIP: What is a “Zone”? z Rotate [Rotary Selector] to select the Favorite CH� Certain channels are grouped together and assigned z Push [CH Up], [CH Down], [CH Up/Zone Up], or to a Zone according to their intended use�...
  • Page 18: Call Procedure

    BASIC OPERATION Call procedure When your system uses tone signaling, a call procedure may be necessary prior to voice transmission� The tone signaling employed may be a selective calling system, which enables you to call only specifi c stations, and prevents unwanted stations from contacting you�...
  • Page 19: Receiving And Transmitting

    BASIC OPERATION Receiving and transmitting D Transmitting notes Receiving: 1� Turn ON the transceiver. (p. 3-2) Transmit inhibit function 2� Select a channel. (p. 3-3) The transceiver has several inhibit functions which 3� When receiving a call, rotate [VOL] to adjust the restrict transmission under the following conditions: audio output level to a comfortable listening level�...
  • Page 20 Section ADVANCED OPERATION Alert-Ring call �����������������������������������������������������������������������������������������4-2 D Transmitting an Alert-Ring call ��������������������������������������������������������4-2 Sounding a Siren ������������������������������������������������������������������������������������4-3 AquaQuake™ Water Draining function ��������������������������������������������������4-3 Scan Operation���������������������������������������������������������������������������������������4-3 D Scan types ��������������������������������������������������������������������������������������4-3...
  • Page 21 ADVANCED OPERATION Alert-Ring call • The Lone Worker function D Transmitting an Alert-Ring call 1� When no operation occurs, the ON Timer presets When the transceiver enters the Alert-Ring mode, a time� countdown starts� The transceiver counts down during 2� When the transceiver is put into the Alert-Ring the Repeat Timer set time�...
  • Page 22 ADVANCED OPERATION Sounding a Siren Scan Operation Hold down [Siren] to emit a siren sound from the D Scan types speaker to let surrounding people know that you are in an Emergency situation� Scanningisanefficientwaytolocatesignalsquickly over all channel� The siren will sound continuously until the transceiver Selecting Zone Scan mode speeds up the scanning is turned OFF�...
  • Page 23 Section USER SET MODE User Set mode description ���������������������������������������������������������������������5-2 D Operation in the User Set mode ����������������������������������������������������5-2 User Set mode items ������������������������������������������������������������������������������5-3 D Ringer Type of Digital Ringer and Smart Ringer �����������������������������5-6...
  • Page 24 USER SET MODE User Set mode description The user can enter the “User Set Mode” to customize D Operation in the User Set mode certain transceiver settings without using the Example: Changing the Ringer level from 3 to 5� programming software� 1�...
  • Page 25 USER SET MODE User Set mode items Item Description Display Reference Backlight Sets the Key Backlight status� LIGT p� 5-4 Beep Turns the key-touch beeps ON or OFF� BEEP p� 5-4 Beep Level Sets the beep and announce output level� BEEPV p�...
  • Page 26 USER SET MODE User Set mode items (Continued) Backlight VOX Gain Sets the Backlight status� Sets the VOX gain� • OFF: Turns OFF the backlight� The VOX function automatically switches between • OFF Auto: When pushing any key (except [PTT]), receive and transmit by detecting sounds�...
  • Page 27 USER SET MODE User Set mode items (Continued) Code Type Sets the display format in the CTCSS tone or DTCS code selection mode� • Code: Displays CTCSS tone or DTCS code� • Num: Displays CTCSS or DTCS CH No� Power Save Sets the Power Save function ON or OFF�...
  • Page 28 USER SET MODE User Set mode items (Continued) D Ringer Type of Digital Ringer and Smart Ringer Options Ringer Type Description Null The state of the ringer does not change� Turns OFF the ringer� One high ring sounds once� PiPi Two high rings sound once�...
  • Page 29 USER SET MODE User Set mode items (Continued) Options Ringer Type Description PiPiPi Three high rings sound once� 50 mSec 50 mSec 50 mSec High 1 High 1 High 1 Freq Freq Freq 50 mSec 50 mSec PiPiPiPi Four high rings sound once� 50 mSec 50 mSec 50 mSec...
  • Page 30 USER SET MODE User Set mode items (Continued) Options Ringer Type Description Pi-Pi-Pi-Pi- Four high long rings sound once� Bu-Ro-Pi- One low, one mid and one high long rings sound once� 250 mSec 250 mSec 250 mSec High (Low Freq) (High 1 Freq) (High 2 Freq) Pi-Ro-Bu-...
  • Page 31 Section dPMR™ OPERATION Receiving a call ��������������������������������������������������������������������������������������6-2 D Receiving a call �������������������������������������������������������������������������������6-2 D Receiving a Status message ����������������������������������������������������������6-2 D Receiving a Break-in request call ���������������������������������������������������6-3 Transmitting a call ����������������������������������������������������������������������������������6-4 D General �������������������������������������������������������������������������������������������6-4 D Transmitting a call ���������������������������������������������������������������������������6-4 D Transmitting a Status message ������������������������������������������������������6-4 D Transmitting a Break-in request call �����������������������������������������������6-4 D Transmitting an Alert-Ring call �������������������������������������������������������6-4...
  • Page 32 dPMR™ OPERATION Receiving a call D Receiving a call When a call is received: • Mute is released� • The Status indicator lights green� 1� Hold down [PTT] to speak� 2� Release [PTT] to receive� D Receiving a Status message When a Status message is received: •...
  • Page 33 dPMR™ OPERATION Receiving a call (Continued) D Receiving a Break-in request call When a Break-in call is received: • The Status indicator lights green� • Beeps sound� • “BREAK” blinks on the display� TIP: What is Break-in call? The Break-in request call announces to the other stations on the channel that the user wants to break into the current communication in the group�...
  • Page 34 dPMR™ OPERATION Transmitting a call D Transmitting a Status message You can make a call to a station that has the same Common ID� Other digital mode transceivers on the You can transmit a preset simple message� You channel will not receive a call that does not match cannot transmit a voice signal at the same time�...
