- Page 1 COROLLA iM 2 0 1 7 QUICK REFERENCE GUIDE...
- Page 2 Owner’s Manual. Each box contains safe operating instructions to help you avoid injury or equipment malfunction. All information in this Quick Reference Guide is current at the time of printing. Toyota reserves the right to make changes at any time without notice.
- Page 3 Power outlet Rear view monitor system 16-18 Seat adjustments-Front Seat-Folding down rear seat Seats-Head restraints Steering wheel switches Tilt steering wheel Trip information/meter light control Windows Windshield wipers & washers * Visit your Toyota dealer for information on customizing this feature.
-
Page 4: Instrument Panel
OVERVIEW Instrument panel Multi-Information Display (MID) controls Lane Departure Alert (LDA) switch Multimedia controls Cruise control switch Voice Steering wheel controls command switch Wiper and washer controls Headlight and turn signal controls Pre-Colllision System (PCS) switch Power outside rearview Hood lock release lever mirror controls Tilt and telescopic steering lock release lever... - Page 5 For more information, refer to Toyota.com to download the Toyota Audio System Owner’s Manual. If equipped. Emergency flasher button Front passenger occupant classification indicator/ Front passenger seat belt reminder light Air conditioning controls Tire pressure warning reset switch (inside glovebox) “VSC OFF”...
-
Page 6: Instrument Cluster
Driver seat belt reminder (alarm will sound if speed is over 12 mph) * If indicator does not come on or turn off within a few seconds of starting engine, there may be malfunction. Have vehicle inspected by your Toyota dealer. - Page 7 ECO driving indicator light* Electric power steering system warning* Engine immobilizer indicator Front passenger occupant classification indicator* Fuel tank door position Headlight high beam indicator Headlight low beam indicator Lane Departure Alert (LDA) indicator Low fuel level warning Low outside temperature indicator Low Tire Pressure Warning* Malfunction/Check Engine indicator* Master warning*...
-
Page 8: Keyless Entry
OVERVIEW Keyless entry UNLOCKING OPERATION LOCKING OPERATION Push Push ONCE: Driver door TWICE: All doors PANIC BUTTON Push and hold NOTE: If a door is not opened within 60 seconds of unlocking, all doors will relock for safety. Fuel tank door release & cap Turn to open Pull up Store... -
Page 9: Hood Release
Hood release Pull Pull up latch and raise hood Engage support rod Engine maintenance Engine coolant reservoir Engine oil filler cap Engine oil level dipstick Windshield washer fluid tank NOTE: Regularly scheduled maintenance, including oil changes, will help extend the life of your vehicle and maintain performance. Please refer to the “Warranty Maintenance Guide.”... -
Page 10: Automatic Transmission - If Equipped
FEATURES & OPERATIONS Automatic transmission (if equipped) Shift lever Park* Reverse Neutral Drive + (“M” mode) “M” mode - (“M” mode) “M” * The ignition switch must be “ON” and the brake pedal depressed to shift from Park. “M” 7-SPEED SPORT SEQUENTIAL SHIFTMATIC MODE Push shift lever to the left from “D”... -
Page 11: Multi-Information Display (Mid)
Multi-Information Display (MID) Outside temperature Shift position Multi-information display > Push “ ” or “ ” and “ ” on steering wheel to change and select information displayed: Drive information 1: Current fuel consumption/ Average fuel economy Drive information 2: Distance (driving range)/ Average vehicle speed Lane Departure Alert operational status. -
Page 12: Steering Wheel Switches
Push to select within the Use to search within the selected Multi-Information Display screens. Multi-Information Display screens. For details, refer to Toyota.com to download the Toyota Audio System Owner’s Manual or Toyota Navigation System Owner’s Manual. Lights & turn signals HEADLIGHTS... -
Page 13: Windshield Wipers And Washer
HIGH BEAMS Low beam High beam flasher (Original position) (Pull) High beam (Push) TURN SIGNALS Right turn Lane change Lane change Left turn Windshield wipers & washer FRONT Mist Adjust frequency Interval wipe Slow Fast Pull to wash and wipe REAR Push lever to wash and wipe Interval wipe... -
Page 14: Cruise Control
FEATURES & OPERATIONS Windows Driver side Window lock switch Down Automatic operation (driver’s window only) Push the switch completely down and release to fully open. To stop the window partway, operate the switch in the opposite direction. Window lock switch Deactivates all passenger windows. Driver’s window remains operable. -
Page 15: Tilt Steering Wheel
Use this port to connect a portable audio device and listen to it through the vehicle’s speakers. For more information, refer to Toyota.com to download the Display Audio System Owner’s Manual or Display Audio with Navigation Owner’s Manual. Power outlet... -
Page 16: Automatic Air Conditioning/Heating
FEATURES & OPERATIONS Automatic air conditioning/heating Airflow mode display Fan speed Passenger side temperature Driver side temperature Recirculate cabin air Outside air Auto Front window defogger Sync driver side and passenger side “ ” and “ ” mode uses outside air, use “ ”... -
Page 17: Seat Adjustments-Front
Seat adjustments-Front Seat position (forward/backward) Pull lever up to move seat forward/backward, release to set Seatback angle Height crank (driver side only) Seats-Head restraints Bottle holders Cup holders Front Rear Front Rear Front Rear Front Rear Seats-Folding down rear seat Stow the seat belt buckles Entire seatback Driver-side or passenger-side... -
Page 18: Rear View Monitor System
FEATURES & OPERATIONS Rear view monitor system The rear view monitor system assists the driver by displaying an image of the camera’s view behind the vehicle when in reverse. To see the camera’s image of the view behind the vehicle on the monitor screen, the vehicle ignition switch must be in the ON position and the gear selector must be in the REVERSE position. - Page 19 ” on the left side of screen and select “Display” on the setup screen. Then select “Camera” to adjust the screen brightness and contrast. For more information, refer to Toyota.com to download the Display Audio System Owner’s Manual or Display Audio with Navigation Owner’s Manual.
- Page 20 If contact is made with one of these substances wipe it off as soon as possible. When replacing tires on the vehicle, please consult your Toyota dealer. If you replace the tires, the area displayed on the screen may change.
-
Page 21: Quick Overview-Toyota Safety Sense™ C (Tss-C)
TOYOTA SAFETY SENSE ™ Quick overview-Toyota Safety Sense™ C (TSS-C) Toyota Safety Sense C (TSS-C) is a set of active safety technologies designed to ™ help mitigate or prevent collisions across a wide range of traffic situations, in certain conditions. TSS-C is designed to help support the driver’s awareness, decision making and vehicle operation contributing to a safe driving experience. -
Page 22: Pre-Collision System (Pcs)
Refer to a Toyota Owner’s Manual for a list of additional situations in which the system may not operate properly. Pre-Collision Warning... - Page 23 CHANGING THE PRE-COLLISION ALERT TIMING Middle Near (default) Each time the PCS switch is pressed, the response to the PCS alert timing changes. DISABLING THE PRE-COLLISION SYSTEM (PCS) To disable the system Press the PCS switch for 3 seconds or more. will turn on and a message will be displayed on the Multi-Information Display (MID).
-
Page 24: Lane Departure Alert (Lda)
Note: Operation of the LDA system and setting adjustments continues in the same condition regardless of Ignition cycle until changed by the driver or the system is reset. Refer to the Toyota Owner’s Manual for additional information on LDA operation, settings adjustments, limitations, and precautions before attempting to use it. - Page 25 For example, LDA may not function on the side(s) where white/yellow lines are not detectable. Refer to the Toyota Owner’s Manual for additional information on LDA operation, settings adjustments, limitations, and precautions before attempting to use it.
-
Page 26: Automatic High Beams (Ahb)
By using high beams more frequently, the system may allow earlier detection of pedestrians and obstacles. Refer to the Toyota Owner’s Manual for additional information on AHB operation, settings adjustments, limitations, and precautions before attempting to use it. -
Page 27: Doors-Child Safety Locks
SAFETY & EMERGENCY FEATURES Doors-Child safety locks Rear door Unlock Lock Moving the lever downward will allow the door to be opened only from the outside. Seat belts-Shoulder belt anchor Push lock release to lower Push up to raise... -
Page 28: Seat Belts
SAFETY & EMERGENCY FEATURES Seat belts Take up slack Too high Keep as low on hips as possible NOTE: If a passenger’s seat belt is fully extended, then retracted even slightly, the Automatic locking retractor (ALR) will prevent it from being re-extended beyond that point, unless fully retracted again. -
Page 29: Spare Tire And Tools
Spare tire & tools TOOL LOCATION Towing eyelet Wheel nut wrench Jack Spare tire Tool bag Jack handle REMOVING THE SPARE TIRE (1) Remove the spare tire cover. (2) Loosen and remove the bolt. Refer to the Owner’s Manual for jack positioning and tire changing procedures. -
Page 30: Star Safety System
Traction Control helps maintain traction on loose gravel and wet, icy, or uneven surfaces by applying brake force to the spinning wheel(s). Toyota’s TRAC sensors are activated when one of the drive wheels starts to slip. TRAC limits engine output and applies the brakes to the spinning wheel. This transfers power to the wheels that still have traction to help keep you on track. -
Page 31: Floor Mat Installation
Floor mat installation There are two types of Toyota floor mats: carpeted and all-weather. Each vehicle has model-specific floor mats. Installation is easy. To keep your floor mat properly positioned, follow these steps: •... - Page 32 PAIRING BLUETOOTH PHONE FOR THE FIRST TIME ® Touch Screen Display Audio and Display Audio with Navigation ®2 To use the hands-free system , it is necessary to pair a Bluetooth phone with the system. Once the phone has been paired, it is possible to use the hands-free system .
- Page 33 See Owner’s Manual for details. 2. The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth® SIG, Inc. and any use of such marks by Toyota is under license. A compatible Bluetooth® enabled phone must first be paired.
- Page 34 NOTES...
- Page 35 Power outlet Rear view monitor system 16-18 Seat adjustments-Front Seat-Folding down rear seat Seats-Head restraints Steering wheel switches Tilt steering wheel Trip information/meter light control Windows Windshield wipers & washers * Visit your Toyota dealer for information on customizing this feature.
- Page 36 CUSTOMER EXPERIENCE CENTER 1-800-331-4331 Printed in U.S.A. 9/16 0061617CORIMQRG 16-MKG-09543...
