KV-36FS76U
Thank you for choosing this
Sony Trinitron Television.
This step by step guide will help you to:
Connect an aerial to the TV,
Connect a video cassette recorder (VCR) to the TV,
Insert batteries into the remote control,
Switch on the TV,
Tune the TV,
Watch TV programmes,
Watch video tapes.
© 2002 Sony Corporation
1
Connecting an aerial and VCR to the TV
Scart lead
(not supplied)
Inserting batteries into
2
the remote control
1
3
Always remember to:
•
observe the correct polarity when inserting batteries,
•
dispose of batteries in an environmentally friendly way.
4-089-904-01
1.
2.
3.
RF lead
Connecting an aerial only
(not supplied)
OUT
VCR
1.
IN
2
Connect your aerial lead to the IN* socket on your VCR.
Connect an RF lead from the OUT* socket on your VCR to the aerial socket
labelled 8 on the rear of the TV.
Connect a fully wired 21-pin scart lead from the scart socket marked
i3/r3 on the rear of the TV to a scart socket on your VCR**
Notes: *Socket names may vary depending on make and model of VCR. Refer to your VCR
instruction manual for details.
**If your VCR does not have a scart socket follow the connecting instructions above
ignoring the scart lead connection.
You will also need to manually tune the VCR to a spare TV channel (ideally channel 0,
refer to the 'Manual Programme Preset menu' section of the main instruction manual).
Connect your aerial lead to the aerial socket labelled 8 on the rear of the TV.
3
Switching on the TV
1.
Connect the TV plug to your mains socket and switch on.
2.
The TV is usually switched on. If not, push in the On/Off button ! on the front
of the TV.
If the red standby mode indicator on the front of the TV is lit, press the
TV I/1 button on the remote control to switch on the TV set. Please be
patient as the picture may take a few moments to appear on the TV screen.
On/Off button
