Model Numbers:
IDV34 - Stock Numbers: IDV34N, IDV34NE, IDV34NE2, IDV34LP, IDV34LPE, IDV34LPE2
Minimum Fireplace Opening Required: 28-5/8"W x 21-1/2"H x 17-3/4"D
–
IDV44
Stock Numbers: IDV44N, IDV44NE, IDV44NE2, IDV44LP, IDV44LPE, IDV44LPE2
Minimum Fireplace Opening Required: 32-7/8"W x 25-3/4"H x 18"D
Are Certified to: ANSI Z21.88-2017 • CSA 2.33-2017
Installation Instructions
Gas Fireplace Insert Heater
Listed Certified for USA. and Canada
This appliance may be installed in an
aftermarket, permanently located,
manufactured home (USA only) or mobile
home, where not prohibited by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certified kit is used.
⚠
WARNING: The IDV34 / IDV44 Fireplace Insert
was designed for installation in a solid fuel
fireplace that has been installed in accordance
with national, provincial / state and local building
codes and is constructed of noncombustible
materials. Do not remove any refractory materials
from any masonry solid fuel fireplace.
The IDV34 / IDV44 Fireplace Insert was designed for
installation in a zero clearance type listed solid fuel
burning factory built fireplace. It may be necessary to
remove the damper plate, refractory liners, log grates,
glass door, and screen rails/mesh. Removal of the
smoke baffle is necessary in most cases.
INSTALLER: Leave this manual with the
appliance.
CONSUMER: Retain this manual for
future reference.
CAPRI
A Division of R-Co. Inc.
2340 Logan Avenue
Winnipeg, Manitoba, Canada R2R 2V3
Ph: (204) 632-1962
Printed in Canada February 5, 2019
Part # 34IDV-MAN17
Advertisement
Table of Contents
Related Manuals for Marquis Capri IDV34 Series
Summary of Contents for Marquis Capri IDV34 Series
- Page 1 Installation Instructions Gas Fireplace Insert Heater Listed Certified for USA. and Canada Model Numbers: CAPRI IDV34 - Stock Numbers: IDV34N, IDV34NE, IDV34NE2, IDV34LP, IDV34LPE, IDV34LPE2 Minimum Fireplace Opening Required: 28-5/8”W x 21-1/2”H x 17-3/4”D – IDV44 Stock Numbers: IDV44N, IDV44NE, IDV44NE2, IDV44LP, IDV44LPE, IDV44LPE2 Minimum Fireplace Opening Required: 32-7/8”W x 25-3/4”H x 18”D Are Certified to: ANSI Z21.88-2017 •...
-
Page 2: Table Of Contents
- TABLE OF CONTENTS - Table of Contents............................... Safety Screen Installation............................Pre-installation Questions and Answers........................Operations and Maintenance Instructions........................Annual Inspection List..............................Important Information..............................Warnings, Installations and Operations........................Installation Requirements for the Commonwealth of Massachusetts................. Mobile Home/Manufactured Housing Installation....................... IDV34 Section IDV34 Fireplace Openings and Dimensions………………………………………………………………………………... - Page 3 Troubleshooting the Gas Control System........................Remote Control Operation............................Proflame 1 IPI Overview / Components............................. Junction Box Location..............................IPI Electronic Ignition Parts List – Standard System....................Configuration1 / Configuration 2..........................Operating the Receiver Without Batteries For GT / EGT / GTM / EGTM Remote Controls........Proflame 2 IPI Proflame 2- Parts List..............................
-
Page 4: Safety Screen Installation
Safety Screen Installation- IDV34 / IDV44 – CV1BL & MQCV2BL Kits ⚠ SLOT WARNING: Wait until unit is GLASS DOOR IS COMPLETELY cool INSTALLED ON HOOK FIREPLACE. before touching glass or attempting to install or SHOWN REMOVED remove Child Safety FOR CLARITY ONLY Screens. -
Page 5: Pre-Installation Questions And Answers
Pre-installation Questions and Answers About curing of the paint Your stove or fireplace has been painted with the highest quality silicone stove paint. This paint dries quickly in 15-20 minutes when first applied at the factory. However, due to the high temperature silicone components, the paint will cure when heat is applied to the appliance as it is first used. -
Page 6: Annual Inspection List
Annual Inspection List for Determining Safe Operation of a Direct Vent Gas Fireplace Refer to this checklist for proper maintenance, safe use, and operation. See each section for more specific information. 1. Inspect and operate all pressure relief mechanisms (i.e., explosion dampers, spring loaded door latches) installed on your appliance to verify relief mechanisms are free from obstruction to operate. -
Page 7: Important Information
Important Information INSTALLATIONS The following label (supplied with the gas fireplace insert) must be attached with rivets or screws to the inside of the firebox of the fireplace into which it is installed: Cutting any sheet-metal parts of the fireplace, in which the gas fireplace insert is to be installed, is prohibited. -
Page 8: Warnings, Installations And Operations
Warnings, Installations and Operations - Installation Regulations This gas appliance must be installed by a qualified installer in accordance with local building codes, or in the absence of local codes, with the current CAN/CSA-B149.1 or .2 Installation Code (in Canada) or the current National Fuel Gas Code Z223.1- NFPA 54 when installed in the United States. This appliance, when installed, must be electrically connected and grounded in accordance with local codes, or in the absence of local codes, with the current CSA C22.1 Canadian Electrical Code or with the National Electrical Code;... -
Page 9: Installation Requirements For The Commonwealth Of Massachusetts
Installation Requirements for the Commonwealth of Massachusetts In the Commonwealth of Massachusetts, the installer or service agent shall be a plumber or gas fitter licensed by the Commonwealth. When installed in the Commonwealth of Massachusetts or where applicable codes; the unit shall be installed with a CO detector per the requirements listed below. -
Page 10: Mobile Home/Manufactured Housing Installation
Mobile Home/Manufactured Housing Installation This Direct Vent System Appliance must be installed in accordance with the manufacturer’s installation instructions and the Manufactured Home Construction and Safety Standard Title 24 CFR, Part 3280, or the current Standard for Fire Safety Criteria for Manufactured Home Installation, Sites, and Communities ANSI/NFPA 501A, and with CAN/CSA Z240 MH Mobile Home Standard in Canada. -
Page 11: Idv34 Section Idv34 Fireplace Openings And Dimensions
IDV34 Fireplace Openings REQUIRED DIMENSION A Front Width 28-5/8” “D” B Height 21-1/2” “C” C Depth 17-3/4” “B” D Back Width 21-1/4 “A” IDV34 Fireplace Dimensions 28-5/8”... -
Page 12: Idv34 Clean Views And Surround Options
IDV34 Clean Views and Surround Options IDV34 Opening Requirements: Width 28-5/8” x Height 21-1/2” x Depth 17-3/4” I34CV1BL I34S3927 I34SPF4131 I34SU4541 C/W Safety Screen WIDTH 35-1/4” 39” 41-1/8” 45” HEIGHT 24-3/16” 27-5/16” 31-3/8” 41” DEPTH 13/16” 1/2” 1/2” 1/16”- To be Custom Cut and Bent MQ34CV2BL I34S3927 I34SPF4131... -
Page 13: Idv34 Clean Views
IDV34 Clean Views 1-5/16” I34CV1 WITH I34S3927 1-13/16” 1-5/16” MQ34CV2 MQ34CV2 WITH I34S3927 2” MQ34CV3 MQ34CV3 WITH WITH MQ34DD1 or I34S3927 MQ34SF1 DOOR 2” MQ34CV4PF MQ34CV4PF WITH WITH MQ34DD1 or I34SPF4131 MQ34SF1 DOOR NOTE: Clean View Hooks are adjustable (1/4”) for uneven wall surface. -
Page 14: I34Su4541 Universal Surround Worksheet
I34SU4541 -Universal Surround- IDV34 For use with I34CV1BL, MQ34CV2BL, MQ34CV3BL, and MQ34CV4PFBL. This Surround can be custom cut and bent. Cut Surround at dotted line shown above to make the bottom flush with the fireplace bottom. -
Page 15: Mantel Heights
IDV34 Mantel Heights ⚠ WARNING: Combustible objects must not be placed on a non-combustible mantel unless the non-combustible mantel meets the minimum height and width requirements for a combustible mantel. I34CV1 Combustible Mantel Heights I34CV1 Only I34CV1 with Mantel or with Surround and I33CS Dimension Depth... -
Page 16: Idv44 Section Idv44 Fireplace Openings And Dimensions
IDV44 Fireplace Openings REQUIRED DIMENSION A Front Width 32-7/8” B Height 25-3/4” “D” C Depth 18” D Back Width 25-3/4 “C” “B” “A” IDV44 Fireplace Dimensions... -
Page 17: Idv44 Clean Views And Surround Options
IDV44 Clean Views and Surround Options IDV44 Opening Requirements: Width 32-7/8” x Height 25-3/4” x Depth 18” I44CV1BL I44S4432 I44SPF4436 I44SU4742 C/W Safety Screen WIDTH 39-9/16” 44” 44” 47” HEIGHT 28-1/2” 32-1/16” 36” 42” DEPTH 13/16” 1/2” 1/2” 1/16”- To be Custom Cut and Bent MQ44CV2BL I44S4432 I44SPF4436... -
Page 18: Idv44 Clean Views
IDV44 Clean Views 1-5/16” I44CV1 WITH I44S4432 1-13/16” 1-5/16” MQ44CV2 MQ44CV2 WITH I44S4432 2” 1-7/16” MQ44CV3 WITH MQ44CV3 MQ44DD1 WITH MQ44SF1 DOOR I44S4432 NOTE: Clean View Hooks are adjustable (1/4”) for uneven wall surface. -
Page 19: I44Su4742 Universal Surround Worksheet
I44SU4742 -Universal Surround- IDV44 For use with I44CV1BL, MQ44CV2BL, and MQ44CV3BL. This Surround can be custom cut and bent. Cut Surround at dotted line shown above to make the bottom flush with the fireplace bottom. -
Page 20: Mantel Heights
IDV44 Mantel Heights ⚠ WARNING: Combustible objects must not be placed on a non-combustible mantel unless the non-combustible mantel meets the minimum height and width requirements for a combustible mantel. I44CV1 Combustible Mantel Heights I44CV1 with I44CV1 Surround Only Mantel or with I33CS Mantel Dimension... -
Page 21: Wall Coverings, Side Walls And Hearth Requirements
IDV34 / IDV44 – Wall Coverings, Side Walls and Hearth Requirements Refer to Mantel Heights Charts for your minimum mantel height. Combustible Mantel Line Combustibles must be above Combustible Mantel Line This area must have Non-Combustible Floor beneath Combustible materials ONLY appliance must be Hearth Allowed non-combustible. -
Page 22: Leveling Instructions / Riser Kit
Leveling Instructions When installing insert it may be necessary to support back of unit. There are two leveling legs at the back sides of the appliance. Measure the height of the space to be leveled. Remove screws and set leveling legs to proper height. Replace screws. -
Page 23: Surround Installation
IDV34 / IDV44 – Surround Installation IDV34 Surrounds: I34S3927, I34SPF4131, 134SU4541 PARTS LIST: -Surround IDV44 Surrounds: I44S4432, I44SPF4436, I44SU4742 - [Qty 4] #6 Black Screws All surrounds attach to the back of the Clean View. CV1 / CV2 Attachment: STEP 2: Fold Tabs on Clean View over STEP 1: surround and install with [4]... -
Page 24: Clean View Attachment
IDV34 / IDV44 Clean View Attachment Note: Vent adapter and venting must be connected to the unit before Clean Views and Surrounds are attached. Refer to Installation of Vent Pipe section of this manual for venting information. SECTION 1: Optional Surrounds are fastened to the Clean View. If a surround is to be used, install onto the CV Kit before it is mounted. -
Page 25: Mqsf1Bl Or Mqdd1Bl Attachment
MQSF1BL / MQDD1BL - Attachment to MQI34 / MQI44 CV3 or CV4PF MQI34 / I44 SFIBL and MQDD1BL Parts List: Door with Screen MQSF1BL MQDD1BL Door Door Optional MQCV3 Surround MQCV4PF MQSF1BL MQDD1BL Clean View Mount Slots Step Three: Align Top Slot and reinsert screw. -
Page 26: I33Cs -Mantel Clearance Shield
I33CS Mantel Clearance Shield Instructions Contents of Kit: [1] Mantel Clearance Shield c/w Screws Place I33CS upside down on a protected surface. Loosen screws. Center surround onto I33CS. Tighten screws to hold surround in place. Surround is now ready to install onto Clean View. -
Page 27: Rlt / Rlh - Brick Liner Panels
RLT / RLH - Brick Liner Panels- Parts List -1 Back Panel -1 Right Side Panel -1Left Side Panel Preparation 1. Lift Log Supports out of fireplace. 2. Remove the 2 Screws in the Back Panel. 3. Slide and tilt Back Panel to remove. Log Supports Back Panel To Install... -
Page 28: Prl- Porcelain Liner Panels
PRL- Porcelain Liner Panels- Parts List -1 Back Panel -1 Right Side Panel -1Left Side Panel Preparation: 1. Lift Log Supports out of fireplace. 2. Remove the 2 Screws in the Back Panel. 3. Slide and tilt Back Panel to remove. Log Supports Back Panel To Install... -
Page 29: Log Placement - Logf35 For Idv33/34
IDV33/34 Log Placement – LOGF35 Rear Log Holder This illustration shows the Rear Log Holder and 4 Log Pins. LOGF35 Log Set. Glowing Embers supplied with appliance. Log A Log B Log A has 2 locating holes. Position those 2 holes over the 2 Log B has 2 locating holes. -
Page 30: Log Placement - Logf36 For Idv44
Log Placement – LOGF36 LOGF36 Log Set includes Glowing Embers, Lava Rock, and Place Log #1 onto rear log holder and center. Vermiculite. Place Log #2 onto left side of Log #1. Place Log #3 onto right Locate 2 holes on bottoms of Logs #4 and #5, and position onto side of Log #1. -
Page 31: Mqrsp4 / Mqrsp8 Rock And Glass Support Platform
MQRSP4 / MQRSP8 Rock and Glass Support Platform Installation Base Unit (As Shipped) Preparation: Remove Grate Bar and replace screws. Remove Ember Plates. Do not remove existing Pilot Shield. Installation: Place MQRSP4 or MQRSP8 over burner. One screw from the Fan Access Cover Plate is all that is required to mount the... -
Page 32: Mqrock2 / Mqrock3 - Must Use Mqrsp4
MQROCK2 / MQROCK3 -MQRSP4 MQRSP4 Parts List Remove the ember plates and the grate bar by removing the 2 left 1Ea Rock Support and right screws on the grate bar. 1Ea Ember Plates Assembly Reinstall screws after removing parts. Step 1: Place Rocks #4 into position as shown. Be sure not to Place the MQRSP4 Rock Platform and ember plates into place as shown in the illustration above. - Page 33 MQROCK2/ MQROCK3 -MQRSP4 (continued) Step 4: Place Rocks #6 into position as shown above. Step 5: Place Rocks #3 into position as shown above. Step 6: Place Rocks #1 into position as shown above. Step 7: Place Rocks #3 and #4 into position as shown above. Finished Rock Set and Burn NOTE: If flame impingement on the rocks causes sooting then you may have to move, or remove, one or more rocks.
-
Page 34: Mqstone - Must Use Mqrsp8
MQSTONE -Requires- MQRSP8 Optional Decorative Stone Set. Place smaller stones around outside of burner tube. Begin by placing larger stones inside burner tube area. Add smaller stones to center. Cover back and center of burner tube with assorted stones. Pilot Area MUST be visible at ALL times. -
Page 35: Mq Ember Installation -Mqrsp8 / Rsp10
MQ EMBER -Requires -MQRSP8 or RSP10 MQ DEALER ONLY Spread glass or ember chunks onto tray and burner. Ensure that layer of glass embers is not excessively thick as this will affect the flame pattern. See below. Pilot Shield* Must Be Kept Clear. MQRSP8 RSP10 (With Glass Retainer in Place) Note: Do not place all the glass embers onto the tray. -
Page 36: Rsp10 Glass Support Platform
RSP10 Glass Support Platform -Installation Base Unit (As Shipped) Preparation: Remove Grate Bar and replace screws. Remove Ember Plates. Do not remove existing Pilot Shield. Installation: Install RSP10 by placing over burner. Use existing screws at front of firebox bottom to attach Glass Retainer. Parts List Pilot Shield* RSP10: Tray and 1 Pilot Shield*... -
Page 37: Mqrsp11 Support Platform
MQRSP11 Support Platform -Installation Base Unit (As Shipped) MQRSP11 Parts List: [1] Tray and 1 Pilot Shield* [1] Glass Retainer (25-1/2" for IDV33) (30" for IDV43) [2] Small Bags Lava Rock [1] Bag 350 Ember Preparation: Remove Grate Bar and replace screws. Remove Ember Plates. Do not remove existing Pilot Shield. Installation: Install RSP by placing over burner. -
Page 38: Mqrsp11 With Mqlogf33 (34Idv) Or Mqlogf453 (44Idv)
MQRSP11 With MQLOGF33 (IDV34) or MQLOGF453 (IDV44) Must be used with MQRSP11. NOTE: Lava Rock and 350 Embers supplied with fireplace and MQRSP11. ⚠ WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury. - Page 39 EMBERS LOG 5 LOG 2 STEP 5: Place LOG 5 in front of LOG 2 as shown. STEP 5: Place 350 Embers on and around burner. Sprinkle Vermiculite onto Lava Rock on firebox bottom.
-
Page 40: Fan Removal / Installation
IDV34 / IDV44 Fan Removal / Installation Fan System WARNING Electrical Grounding Instructions This appliance is equipped with a three prong (grounding) plug for your protection against shock hazard and should be plugged directly into a properly grounded three-prong receptacle. Do not cut or remove the grounding prong from this. -
Page 41: Glass Door Information
IDV34 / IDV44 Glass Door Information Glass Cleaning It will be necessary to clean the glass periodically. During start-up condensation will form, and cause dust and lint to cling to the surface of the glass. Furthermore, the initial burn cures the paint but also leads to the deposit of a filmy residue. It is therefore recommended that the glass be cleaned two or three times, initially, with non-abrasive common household glass cleansers and warm water. -
Page 42: Gas Section Burner Removal / Installation
IDV34 / IDV44 Burner Installation/Removal Burner System 1. Remove glass door assembly and logs (if installed). Be careful with logs as they become fragile after being heated. 2. Remove log supports off burner assembly. 3. The burner or burner assembly can now be removed. a. -
Page 43: Burner System Maintenance
Burner System Maintenance It is recommended to annually inspect and clean the Burner System to prevent malfunction and / or sooting. This operation should be performed by your dealer or a qualified technician. -CAUTION- Before servicing the burner system ensure that the gas supply is turned OFF and disconnect all electrical connections to the appliance. -
Page 44: Conversion Kit Instructions - Part A
Conversion Kit Instructions – PART A Caution The gas supply shall be shut off prior to disconnecting the electrical power, before proceeding with the conversion. PLEASE CONFIRM THAT STEP 4 IS UNDERSTOOD BEFORE PROCEEDING WITH CONVERSION. WARNING: This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer's instructions and all applicable codes and requirements of the authority having jurisdiction. -
Page 45: Gas Conversion For Top Convertible Pilot - Part B
Gas Conversion for Top Convertible Pilot – Part B (series 0190XYZ) Instructions for converting SIT 190 series pilot burner injector from NG to LPG and from LPG to NG only. This information should be considered as supplemental to the Appliance Manufacturer's Instructions. WARNING! The installation of this conversion kit must only be undertaken by a qualified and certified gas appliance installer. -
Page 46: Gas Conversion For Modulator - Part C
Gas Conversion for Modulator – PART C... -
Page 47: Gas Line Installation
Gas Line Installation This gas appliance should be installed by a qualified installer in accordance with local building codes and with current CAN/CSA - B149.1 installation codes for Gas Burning appliances and equipment in Canada and the National Fuel Gas Code ANSI Z223 in the U.S.A. -
Page 48: Millivolt System, Lighting, And Burner Control
Millivolt System, Lighting, and Burner Control FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. BEFORE LIGHTING This appliance has a pilot which must be lighted by hand. When ... -
Page 49: Troubleshooting The Gas Control System
Troubleshooting the Gas Control System WARNING BEFORE DOING ANY GAS CONTROL SERVICE WORK, REMOVE THE GLASS FRONT. Before troubleshooting the gas control system, be sure external gas shut off is in the "On" position. Problem Possible Causes Corrective Action Spark igniter will not light. Defective or misaligned Check for spark at electrode and pilot: if no spark and electrode wire is electrode at pilot. -
Page 50: Remote Control Operation
-Remote Control Operation- The Proflame GTM is configured to control the on/off main burner operation, its flame levels, and provides on/off and Smart thermostatic control of the appliance. Transmitter Remote Receiver Transmitter Room Thermostat ( Transmitter Operation) The Transmitter is powered by 3 AAA type batteries. A Mode The Remote Control can operate as a room thermostat. -
Page 51: Proflame 1 Ipi Overview / Components
IPI Electronic Ignition System Overview CPI / IPI The IPI system is an advanced burner controller that Switch provides you with the option of having either a Standing-Pilot, or an intermittent igniting system. This Cover alternating mode is controlled by the CPI/IPI Switch (Continuous Pilot Ignition/Intermittent Pilot Ignition) located on the IPI System Box. -
Page 52: Junction Box Location
IPI Electronic Ignition System NOTE: The Remote Receiver module can also be located outside of the appliance to a maximum of 6ft away installed in a certified deep wall switch electrical box (2-3/4” depth). For this configuration an extension wiring harness (P/N: 1001-P904SI) is required. Electrical Supply in Series: The entire IPI system can be powered by a single power source (i.e. -
Page 53: Ipi Electronic Ignition Parts List - Standard System
IPI Electronic Ignition Parts List – Standard System ITEM NO. PART NO. DESCRIPTION 1006-P002si Valve IPI Hi/Lo NG 1006-P003si Valve IPI Hi/Lo LP *1002-P047si Pilot Assembly-LP -24” Wire *1002-P033si Pilot Assembly-NG -24” Wire 1002-P017si Spark Electrode (with wire) *1002-P119si Spark Electrode (with wire- 35” Length) 1002-P903si Electrode Flame Sensor *1002-P910si... -
Page 54: Configuration1 / Configuration 2
Configuration #1: Basic manual HI/LO and manual ON/OFF capabilities. Receiver Module 0.584.523/521/221 1001-P221SI Configuration #2: Remote ON/OFF and manual HI/LO capabilities. OPTIONAL: For units with remote HI/LO capabilities, a modulating servo is required to be installed on the valve. The connectors to this servo must be connected to the Remote Harness as shown in the figure above. -
Page 55: Operating The Receiver Without Batteries For Gt / Egt / Gtm / Egtm Remote Controls
Operating the Receiver Without Batteries For GT / EGT / GTM / EGTM Remote Controls -Wiring Harness P/N 1002-P906si required for both IPI & Millivolt systems. -Millivolt Systems will also require Power Adapter P/N 1002-P850si. The Remote Receiver & IPI or Millivolt system can be powered by the AC Adapter. This is advantageous if you do not want to use batteries. -
Page 56: Proflame 2- Parts List
Proflame 2- Parts List- Basic System, Parts List, Configuration GTMFL ITEM PART DESCRIPTION NUMBER 1005-P001si IPI Valve NG with Stepper Motor 885.001 1005-P002si IPI Valve LP with Stepper Motor 885.001 1006-P002si IPI Valve NG Hi / Lo 1006-P003si IPI Valve LP Hi / Lo 1002-P033si Pilot NG IPI 199.059 1005-P325si... -
Page 57: Proflame 2 Ifc Module And Remote Control
Proflame 2 IFC Module and Remote Control LCD Display ON / OFF Key Thermostat Key Batteries UP / DOWN Arrow Key Mode Key IFC Module Button Within 10 seconds press the button again until Pairing Remote Control: you hear it beep. ... -
Page 58: Cold Climates - Cpi Setting
Cold Climates – CPI Setting - Proflame 2 Remote Control Use the CPI setting during cold weather, otherwise the fireplace may have a hard time starting up and establishing a LCD Display flame. The CPI (Continuous Pilot Ignition) setting will keep the ON / OFF Key firebox and fireplace exhaust vent warm during cold weather. -
Page 59: Proflame 2 Remote Control Operation
Proflame 2 Remote Control... - Page 60 Note: When Smart Thermostat is activated, manual flame height adjustment is disabled. Note: This function is only available in Room Thermostat or Smart Thermostat Control Mode.
-
Page 62: Electronic Ignition Lighting Instructions
Electronic Ignition Lighting Instructions If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. Always light the pilot whether for the first time or if the gas supply has ran out with the glass door opened or removed. FOR YOUR SAFETY READ BEFORE LIGHTING: A. -
Page 63: Venting Idvvt / Idvvt43 Venting Installation
IDVVT36 / IDVVT43 Venting Installation PARTS LIST: Vertical Venting in Cold Climates [1] – Co-linear In cold climate conditions where temperatures go below -10°C [14°F], we recommend that the chase be termination insulated and where the vent pipe enters into the attic space that the pipe be wrapped with an insulated Mylar sleeve. -
Page 64: Installation Of Vent Pipe
Vent Pipe Installation IDV34 / IDV44 1. Remove the Top Filler and adapter plate from the unit by removing the five [5] screws as shown below. (Fig. 3) Attach the vent pipes to the termination with Millpac and 4 screws per pipe joint. Be sure to label the exhaust and intake flex pipes. -
Page 65: Insulation Of Chimney Cavity
Chimney Cavity Insulation IDV34 / IDV44 If You Live In A Cold Climate Zone And Your Chimney Is On The Side Of Your House In cold climates, especially where the chimney is NON-COMBUSTIBLE located on the outside of the home it may be INSULATION necessary to insulate the chimney cavity with (Vermiculite, etc.) -
Page 66: Idv34 Parts List
RSP10 Glass Support Platform with bronze glass I34CSS Safety Screen Barrier (Replacement) ‐ 36IDV-204 Pilot Shield for RSP10 MQ34SF1/MQ34DD1 MARQUIS OPTIONS I34CV1SS Safety Screen Barrier (Replacement) ‐ MQRSP4 Rock Support Platform (IDV26 / IDV33 / I34CV1/CV2 IDV43) BRICK AND PORCELAIN LINERS... -
Page 67: Idv44 Parts List
Glass Support Platform with bronze glass 36IDV-CKLP Conversion Kit - Liquid Propane 36IDV-204 Pilot Shield for RSP10, MQRSP11 (IDV44LP) [Millivolt] -Replacement Part MARQUIS OPTIONS 36IDV-CKNGI Conversion Kit Natural Gas (IDV44NE) MQRSP4 Rock Support Platform - IDV34 / IDV44 [IPI] (Requires MQROCK2 or 3) -
Page 68: Parts And Venting For Idv34/ Idv44
COMMON PARTS FOR IPI ELECTRONIC IGNITION PARTS 1006-P002SI Valve IPI Proflame PF1 886.002 NG - IDV34 & IDV44 HI/LO RISER KITS 1006-P003SI Valve IPI Proflame PF1 886.003 LP - I33R40 2-1/2” Riser 40” HI/LO I33R45 2-1/2” Riser 45” 1002-P322SI IPI Module PF1 - 584.322 REMOTE CONTROL - MILLIVOLT 1002-P850SI IPI Power Adapter IPI - 584.850 AC... - Page 69 1000-215 #PAL Nut (18mm x 1.5mm) Blk (1364.03) 1000-216 Gold Contact ON/OFF Switch 1000-255 #Orifice Brass - #37 Natural Gas 1000-255 #Orifice Brass - #51 Liquid Propane 350-EMBER #Embers 2000-P5637 #Spring Extension for Grills 6000-150 #Ceramic Robax Glass (For IDV34 – 27-1/2” x 16”) 36HB-310 #Ceramic Robax Glass (For IDV44 –...
-
