Summary of Contents for Toyota YARIS SEDAN 2011
- Page 1 YARIS SEDAN 2 0 1 1 QUICK REFERENCE GUIDE...
- Page 2 Owner’s Manual and supplementary manuals so you will have a better understanding of your vehicle’s capabilities and limitations. Your dealership and the entire staff of Toyota Motor Sales, U.S.A., Inc. wish you many years of satisfied driving in your new Yaris.
-
Page 3: Table Of Contents
Windshield wipers & washers Door locks-Power SAFETY AND Doors-Child safety locks EMERGENCY FEATURES Seat belts Seat belts-Shoulder belt anchor Spare tire & tools Trunk-Internal release Tire Pressure Monitoring (warning) System * Visit your Toyota dealer for information on this and other customizable options. - Page 4 OVERVIEW Instrument panel Instrument panel light control Power outside rearview mirror controls* Headlight, turn signal and front fog light* controls Cruise control* Ignition switch Wiper and washer controls Emergency flasher button Front passenger seat belt reminder light Clock adjust button Odometer/Trip meter switch and trip meter reset button...
- Page 5 “AIR BAG ON” and “AIR BAG OFF” indicator Audio system* Air Conditioning controls AUX port* Rear window defogger switch* Tilt steering lock release lever Hood release * If equipped...
-
Page 6: Instrument Cluster
Charging system warning If indicator does not turn off within a few seconds of starting engine, there may be a malfunction. Have vehicle inspected by your Toyota dealer. For details, refer to “If your vehicle overheats,” Section 5-2, 2011 Owner’s Manual. - Page 7 Malfunction/Check Engine indicator Low engine oil pressure warning Open door warning Airbag SRS warning Low windshield washer fluid level warning Electric power steering system warning Low fuel level warning Engine oil replacement reminder AIR BAG ON indicator AIR BAG OFF indicator Headlight low beam indicator Headlight high beam indicator Front fog light indicator...
-
Page 8: Fuel Tank Door Release And Cap
OVERVIEW Fuel tank door release and cap Driver seat Hang Pull up Turn NOTE: Tighten until one click is heard. If the cap is not tightened enough, Check Engine “ ” indicator may illuminate. Keyless entry (if equipped) Locking operation Unlocking operation Push ONCE: Driver door TWICE: All doors... -
Page 9: Engine Maintenance
Hood release Pull Pull up latch and raise hood Engine maintenance Windshield washer fluid tank Engine oil filler cap Engine oil level dipstick Engine coolant reservoir NOTE: Regularly scheduled maintenance, including oil changes, will help extend the life of your vehicle and maintain performance. Please refer to the “Warranty Maintenance Guide.”... -
Page 10: Automatic Transmission
FEATURES/OPERATIONS Automatic Transmission (if equipped) Park* Reverse Neutral Drive Third gear Second gear First gear * The engine switch must be “ON” and the brake pedal depressed to shift from Park. Downshifting increases power going uphill, or provides engine braking downhill. -
Page 11: Parking Brake
Parking brake Release Pull (2) Push (1) Pull slightly (3) Lower Windows-Power (if equipped) Driver side Window lock switch Down Window operation Automatic down operation (driver side only) Push the switch completely down and release to fully open. To stop window at any point, lightly pull the switch up. -
Page 12: Seat Adjustments-Rear
FEATURES/OPERATIONS Seat adjustments-Rear (fold-down type) Before folding (2) Remove (1) Push Fold To fold down the rear seatback (1) Slide the seatback security lock to the right unlock position from the trunk area. (2) Lower the seat head restraints. (3) Pull the lock release knob up. (4) Fold the seatback down. -
Page 13: Lights & Turn Signals
Lights & turn signals Headlights Headlights Parking lights Low beam High beam flasher High beam Turn signals Front fog lights (if equipped) Right turn Lane change Turn Lane change Left turn Front fog lights turn on only when the headlights are on low beam. -
Page 14: Audio
FEATURES/OPERATIONS Audio (if equipped) Push to turn ON/OFF Push to adjust tone & balance Eject CD Push to skip up Seek station/ /down folder CD track select Mode Mode Station/CD track scan Preset buttons - functions in other View CD text modes indicated beside number. -
Page 15: Air Conditioning/Heating
Air Conditioning/Heating Recirculate cabin air (fresh air when OFF) Fan speed Air Conditioning ON/OFF Airflow vent In “ ” mode, use fresh air to reduce window fogging. Temperature selector Rear defogger Power outlet Designed for 12V car accessories. Key must be in the “ACC” or “ON” position to be used. -
Page 16: Cruise Control
FEATURES/OPERATIONS Cruise control (if equipped) Turning system ON/OFF System ON/OFF Functions Cancel Resume /Increase speed Set/Decrease speed The set speed may also be cancelled by depressing the brake pedal or the clutch pedal (Manual Transmission). Unless vehicle speed drops below 10 mph, the set speed may be resumed once vehicle exceeds 25 mph. -
Page 17: Bottle Holders-Front Seat
Clock Clock adjust button (1) Push and hold the CLOCK button to enter adjustment mode. (2) Press CLOCK button to adjust hours. (3) Wait five seconds to adjust the minutes. (4) Wait another five seconds for process to complete. Cup holders Front Rear Rear seat armrest (if equipped) -
Page 18: Door Locks-Power
” indicator will illuminate. Correctly adjusting tire inflation will turn off the light after a few minutes. If the light does not turn off, have the system checked by your Toyota dealer. Refer to the Owner’s Manual for more details. -
Page 19: Seat Belts-Shoulder Belt Anchor
Seat belts-Shoulder belt anchor Pull the lock release knob out to lower FEAT Spare tire & tools Tool location Jack handle Spare tire Jack Tool bag Removing the spare tire SAFE Loosen and remove the bolt. Refer to the Owner’s Manual for tire changing and jack positioning procedures. - Page 20 CUSTOMER EXPERIENCE CENTER 1-800-331-4331 Printed in U.S.A. 8/10 10-TCS-04004 00505-QRG11-YARS...
