DIGITAL CAMERA
NX300
SERVICE
Manual
DIGITAL CAMERA
CONTENTS
1. Repair information
2. Product specifications
3. Disassembly and reassembly
4. Troubleshooting
5. PCB diagram
6. Block diagram
7. Firmware update
8. Adjustment
9. Exploded view and parts list

Advertisement

Table of Contents
loading

Related Manuals for Samsung NX300

Summary of Contents for Samsung NX300

  • Page 1 DIGITAL CAMERA NX300 SERVICE Manual DIGITAL CAMERA CONTENTS 1. Repair information 2. Product specifications 3. Disassembly and reassembly 4. Troubleshooting 5. PCB diagram 6. Block diagram 7. Firmware update 8. Adjustment 9. Exploded view and parts list...

  • Page 2: Table Of Contents

    Contents 1. Repair information 1-1 Customer satisfaction statement .......... 1-1 1-2 Warranty and repair service information ....... 1-1 1-3 Precaution for disassembly and reassembly ......1-4 2. Product specifications 2-1 Specifications ..............2-1 2-2 Product comparison ............2-2 2-3 Accessories information ............2-3 2-4 About the memory card ............
  • Page 3 Contents 7. Firmware update 7-1 Factory data reset ............... 7-1 7-2 Firmware update by using user menu ........7-4 7-3 Firmware update by using CS menu ........7-6 7-4 How to recover the MAIN PCB ..........7-9 8. Adjustment 8-1 Adjustment items ..............8-1 8-2 Test Mode ................

  • Page 4: Repair Information

    In the event that a valid date of purchase is not available, the warranty period will be determined by the date of manufacture. The warranty period shall be decreased to three months from the original product manufactured date. Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 5 Our liability under this warranty shall be limited to the following: a. In the event of a same malfunction problem within two months after repair service by Samsung authorized technician, we will repair or replace free of charge the component of the product which is found to be defective.
  • Page 6 Defect occurring after the expiration of the Warranty Period. b. Damage due to negligence, immersion in water, impact, loss and tampering. c. Repair or alteration performed by any party other than Samsung authorized technicians. d. Misuse or other improper use of the power button.

  • Page 7: Precaution For Disassembly And Reassembly

    The use wooden or plastic tweezers is recommended for manual placement. CONNECTOR Metal tip tweezer might make marks or damage. BARREL Always follow proper direction while assembling the components of the barrel. Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 8 Precautions Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 9: Product Specifications

    HDMI 1.4a Power Source Type Rechargeable battery: BP1130 (1130 mAh) Dimensions (W X H X D) 122 X 63.7 X 40.7 mm (without protrusions) Weight 284 g (without battery and memory card) Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 10: Product Comparison

    Rechargeable battery: BP1030 (1030 mAh) MobileLink, Remote Viewfinder, Auto Backup, Wireless Network Email, SNS & Cloud, AllShare Play, AutoShare, Wi-Fi Direct * This specifications can change without notice to upgrade a performance. Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 11: Accessories Information

    2-3 Accessories information • The illustrations may differ from your actual items. • You can purchase optional accessories at a retailer or a Samsung service center. Samsung is not responsible for any problems caused by using unauthorized accessories. Image Description Part No.
  • Page 12 ND Filter ED-LF52ND4/KR compatibility lens(60, 50200) ED-LF58ND4/KR compatibility lens(1855, 1224) ED-LF43PL/KR compatibility lens(30, 45, 16, 20) CPL Filter ED-LF52PL/KR compatibility lens(60, 50200) ED-LF58PL/KR compatibility lens(1855, 1224) CABLE (USB+C) EA-CB5MU05E CABLE (HDMI) EA-CBHD10D Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 13: About The Memory Card

    • The maximum recording time is 29 minutes and 59 seconds per file. • Available recording time may vary if you use the zoom. • The maximum playback time of For Sharing videos is 30 seconds per file. Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 14: About The Battery

    (Record videos at 1920X1080 resolution and 60 fps.) • The figures above are based on Samsung’s test standards. Your results may differ depending on your actual usage. • Available shooting time differs depending on background, shooting interval, and use conditions.

  • Page 15: Disassembly And Reassembly

    3. Disassembly and reassembly 3-1 Disassembly 1. We provide the general support. : Samsung Authorized Service Center will provide courteous service on Samsung products for which they are authorized. 2. We provide the technical expertise support. : After replacing the parts such as Main PBA, CMOS, Shutter, Mount, it is required to adjust these parts with the equipment specified below.
  • Page 16 Then remove it. ASSY BACK Fig. 3-2 3. Remove the FPCB from the connector as illustrated in Fig. Remove the FPCB from the connector. FPCB FPCB 2. Remove 1. Open. Fig. A Fig. 3-3 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 17 Disassembly and Reassembly 4. Remove the ASSY BACK. ASSY BACK Fig. 3-4 5. Remove the 4 screws. SCREW MACHINE 6001-002159 Fig. 3-5 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 18 7. Remove the ASSY TILT LCD. CAUTION Fold the upper right corner down as illustrated in Fig. 1 when removing the FPCB from the BACK COVER. BACK COVER Fig. 1 ASSY TILT LCD Fig. 3-7 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 19 9. Insert the tweezers into the hole of screw as illustrated in Fig. 2 10. Remove the FPCB as illustrated in Fig. Remove the FPCB. Fig. 3 1. It is installed. 2. Remove. LCD Panel Fig. 2 Fig. 3-9 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 20 11. Remove the LCD Panel. LCD Panel Fig. 3-10 12. Remove the following parts in the order indicated below. ① FRAME BACK ② MAGNET TILT A ① FRAME BACK ② MAGNET TILT A Fig. 3-11 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 21 FPCB 1. Open. 2. Remove. 1. Open. 2. Remove. SCREW TAP 6003-001739 ① Remove the FPCB. ④ Fig. D ② ③ FPCB ④ FPCB 1. It is installed. 2. Remove. Fig. 3-13 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 22 ① ② Fig. E Fig. F Remove the FPCB. Remove the WIRE. ① ② WIRE FPCB WIRE FPCB 1. It is installed. 2. Remove. 1. It is installed. 2. Remove. Fig. 3-15 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 23 19. Remove the ASSY SPEAKER-DRS PCB and HOLDER-TRIPOD as illustrated in Fig. G Fig. ① ASSY SPEAKER-DRS PCB ① ② ② HOLDER-TRIPOD Fig. H Fig. G Fig. 3-16 20. Remove the screw. SCREW MACHINE 6001-002159 Fig. 3-17 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 24 Disassembly and Reassembly 21. Remove the screw. SCREW MACHINE 6001-002282 Fig. 3-18 22. Remove the ASSY COVER-TOP. ASSY COVER-TOP Fig. 3-19 3-10 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 25 Use extra care when removing the FPCB from the connector. Remove the FPCB. Fig. I FPCB FPCB 1. It is installed. 2. Remove . SCREW TAPTYPE 6003-001660 SCREW TAPTYPE SCREW MACHINE SCREW TAPTYPE 6003-001739 6001-001914 6003-001739 Fig. 3-21 3-11 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 26 26. Remove the following parts in the order indicated below. ① PLATE-HOT SHOE BOTTOM ② ASSY PCB TOP ③ ASSY DIAL COMMAND ① PLATE-HOT SHOE BOTTOM ② ASSY PCB TOP ③ ASSY DIAL COMMAND Fig. 3-22 3-12 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 27 2. Remove the following parts in the order indicated below. ① PLATE-MOUNT LENS ② MOUNT-INNER ③ PLATE-MOUNT SPRING ④ SHAFT-LENS DETECT ⑤ SPRING-CS ⑤ SPRING-CS ④ SHAFT-LENS DETECT ③ PLATE-MOUNT SPRING ① PLATE-MOUNT LENS ② MOUNT-INNER Fig. 3-24 3-13 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 28 Disassembly and Reassembly 3. Remove the 3 screws. SCREW-MACHINE 6001-002662 Fig. 3-25 4. Remove the DECO RING-FRONT. DECO RING-FRONT Fig. 3-26 3-14 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 29 SCREW TAPTYPE 6003-001641 Fig. 3-27 6. Lift up the HOLDER INNER MOUNT in the direction of the green arrow. 7. Remove the ASSY-COVER FRONT. ASSY-COVER FRONT HOLDER INNER MOUNT Fig. 3-28 3-15 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 30 Disassembly and Reassembly 8. Remove the 2 screws. SCREW-TAPTYPE 6003-001739 Fig. 3-29 9. Remove the ASSY CHAMER. ASSY CHAMER Fig. 3-30 3-16 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 31 Disassembly and Reassembly 10. Remove the screw. SCREW 1440 TAPTYPE 6003-001739 Fig. 3-31 11. Remove the HOLDER STRAP L. HOLDER STRAP L Fig. 3-32 3-17 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 32 12. Remove the 3 locking parts marked in green circle as illustrated in Fig. A Fig. 13. Remove the PLATE BATTERY CHAMBER. Fig. B Fig. A PLATE BATTERY CHAMBER Fig. 3-33 14. Remove the SHEET-THERMAL FRONT. SHEET-THERMAL FRONT Fig. 3-34 3-18 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 33 ⑦ ASSY PCB SUB SCREW MACHINE ① 6001-002279 ② ASSY CMOS SCREW TAPTYPE ③ 6003-001679 ④ ASSY-SHUTTER ⑤ ASSY HOLDER INNER MOUNT ⑥ SPRING-CS ⑦ ASSY PCB SUB ASSY HOLER MOUNT Fig. 3-35 3-19 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 34: Reassembly

    ⑦ SCREW 3EA SCREW MACHINE ⑦ 6001-002279 ⑥ ASSY CMOS SCREW TAPTYPE ⑤ 6003-001679 ④ ASSY-SHUTTER ③ ASSY HOLDER INNER MOUNT ② SPRING-CS ① ASSY PCB SUB ASSY HOLER MOUNT Fig. 3-36 3-20 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 35 Disassembly and Reassembly 2. Install the SHEET-THERMAL FRONT. SHEET-THERMAL FRONT Fig. 3-37 3. Install the PLATE BATTERY CHAMBER. PLATE BATTERY CHAMBER Fig. 3-38 3-21 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 36 Disassembly and Reassembly 4. Install the HOLDER STRAP L. HOLDER STRAP L Fig. 3-39 5. Tighten the screw. SCREW 1440 TAPTYPE 6003-001739 Fig. 3-40 3-22 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 37 Disassembly and Reassembly 6. Install the ASSY CHAMER. ASSY CHAMER Fig. 3-41 7. Tighten the 2 screw. SCREW-TAPTYPE 6003-001739 Fig. 3-42 3-23 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 38 8. Turn the HOLDER INNER MOUNT over the ASSY-COVER FRONT in the direction of the green arrow. 9. Install the ASSY-COVER FRONT. ASSY-COVER FRONT HOLDER INNER MOUNT Fig. 3-43 10. Tighten the 2 screws. SCREW TAPTYPE 6003-001641 Fig. 3-44 3-24 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 39 11. Align the parts marked by ⓐ, ⓑ ⓒ respectively as illustrated in Then install the DECO RING-FRONT. DECO RING-FRONT ⓑ ⓒ ⓐ ⓐ Fig. A Fig. 3-45 12. Tighten the 3 screws. SCREW-MACHINE 6001-002662 Fig. 3-46 3-25 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 40 ④ MOUNT-INNER ⑤ PLATE-MOUNT LENS ① SPRING-CS ② SHAFT-LENS DETECT ③ PLATE-MOUNT SPRING ⑤ PLATE-MOUNT LENS ④ MOUNT-INNER Fig. 3-47 14. Tighten the 4 screws. as illustrated in SCREW-MACHINE 6001-002662 Fig. 3-48 3-26 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 41 Use extra care when connecting the FPCB to the connector. Fig. A Connect the FPCB. FPCB FPCB 1. Connect. 2. It is installed. SCREW TAPTYPE 6003-001660 SCREW TAPTYPE SCREW MACHINE SCREW TAPTYPE 6003-001739 6001-001914 6003-001739 Fig. 3-50 3-27 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 42 Disassembly and Reassembly 4. Tighten the screw. SCREW MACHINE 6001-002282 Fig. 3-51 5. Install the ASSY COVER-TOP. ASSY COVER-TOP Fig. 3-52 3-28 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 43 Disassembly and Reassembly 6. Tighten the screw. SCREW MACHINE 6001-002282 Fig. 3-53 7. Tighten the screw. SCREW MACHINE 6001-002159 Fig. 3-54 3-29 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 44 ① Fig. C Fig. D Connect the FPCB. Connect the WIRE. ① ② WIRE FPCB WIRE FPCB 1. Connect. 2. It is installed. 1. Connect. 2. It is installed. Fig. 3-56 3-30 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 45 1. Install. 2. Close. 1. Insatll. 2. Close. SCREW TAP 6003-001739 ① ④ Connect the FPCB. Fig. H ② ③ FPCB ④ FPCB 1. Install. 2. It is installed. Fig. 3-58 3-31 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 46 ①ASSY COVER BATTERY Fig. 3-59 15. Install the following parts in the order indicated below. ① MAGNET TILT A ② FRAME BACK ② FRAME BACK ① MAGNET TILT A Fig. 3-60 3-32 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 47 16. Install the FPCB as illustrated in Fig. LCD Panel Install the FPCB. 1. Install. 2. It is installed. Fig. I Fig. 3-61 17. Insatll the LCD Panel. LCD Panel Fig. 3-62 3-33 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 48 19. Install the ASSY TILT LCD. CAUTION Fold the upper right corner down as illustrated in Fig. J when connecting the FPCB to the BACK COVER. BACK COVER Fig. J ASSY TILT LCD Fig. 3-64 3-34 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 49 Disassembly and Reassembly 20. Attach the FPCB on the FRAME BACK. FRAME BACK Fig. 3-65 21. Tighten the 4 screws. SCREW MACHINE 6001-002159 Fig. 3-66 3-35 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 50 23. Connect the FPCB as illustrated in Fig. CAUTION Use extra care when connecting the FPCB to the connector. Connec the FPCB to the connector . FPCB 1. Install. FPCB 2. Close. Fig. K Fig. 3-68 3-36 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 51 Disassembly and Reassembly 24. Tighten the 1 screw on the left side, 2 screws on the right side and 5 screws on the bottom side. SCREW MACHINE 6001-002152 SCREW MACHINE 6001-002159 Fig. 3-69 3-37 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 52: Troubleshooting

    Recheck if the SD card is being recognized. Memory card is not recognized. Check the mechanical failure of SD card socket of Main PCB. Check the SMD and other surrounding components. Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 53: Regarding To Main Pcb Connection

    5. It does not display "F#" correctly on the bottom Check the connection of LENS FPCB of LCD screen. on MAIN PCB. (Instead it displays "F--" on the bottom of LCD screen.) Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 54: Regarding To Top

    Check the connection FPCB on TOP PCB. Check the connection between MAIN PCB and TOP PCB. 2. External Mic, External Flash and GPS do not work. Check the soldering of HOTSHOE on TOP. Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 55: Regarding To Image Display

    - Whether the wire is down or wire soldering comes off. There is sound Check the soldering of FPCB. when pressing button. - Whether it is connected negative or positive However, voice properly. recording - Where FPCB is torn. does not work. Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 56: Pcb Diagram

    R142 R111 C210 C170 C166 C236 R102 C194 NR28 R110 R261 NR49 C218 R229 R226 R227 C221 R213 TP20 TP33 TP27 C623 TP31 R101 R133 R135 R136 R134 R202 R203 C242 R108 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 57: Back Pcb

    PCB diagrams 5-3 BACK PCB 5-4 TOP PCB HOLE2 PAD_NV2_83T_HOLE_1_5_LAND3_0 100NF 0.01NF 0.01NF 33NF 0.01NF DLU-2012-25GS1-A1-AT DLU-1608-25GS1-A2-AT 100NF 0.47NF 2200NF 2200NF QTP01000009 PAD_NV2_83T_HOLE_1_5_LAND3_0 QTP01000009 ICVL0505101V150FR HOLE3 QTP01000009 QTP01000009 PAD_NV2_83T_HOLE_1_5_LAND3_0 0ohm NC_R BOTTOM BOTTOM Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 58: Hot Shoe Pcb

    PCB diagrams 5-5 HOT SHOE PCB 5-6 TILT PCB BOTTOM BOTTOM Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 59: Block Diagram

    DRIMe4 DRIMe4 (SEC) (SEC) PMIC PMIC 1ch-PMIC 1ch-PMIC PMIC_ON PMIC_ON MAX8682 MAX8682 MAX15066 MAX15066 (MAXIM) (MAXIM) (MAXIM) (MAXIM) XTAL XTAL XTAL XTAL (32KHz) (32KHz) (27MHz) (27MHz) 2-Cell Charger 2-Cell Charger (MCP) (MCP) Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 60: Firmware Update

    1. Copy files such as nx_cs.adj & nx_dev.adj into the root directory of the SD Card. Insert the SD Card into the camera. nx_cs.adj nx_dev.adj Fig. 7-1 2. Power on the camera. 3. Select the Smart Auto Mode. Mode dial Fig. 7-2 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 61 (6) Press and hol d the EV button and then press OK button. Fig. 7-3 5. After selecting the SYSTEM PARAMETER, press the OK button. 1. FW UPDATE 2. SYSTEM PARAMETER 3. ADJUSTMENT CONTROL 4. LENS CONTROL 5. CARD CONTROL MENU Cancel Fig. 7-4 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 62 OK button (5) DISABLE POWER SAVE MENU Cancel Fig. 7-5 7. Power off the camera. 8. Power on the camera and check the initialization setting to insure that it is successfully initialized. Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 63: Firmware Update By Using User Menu

    Since all the files stored in the internal memory will be deleted, ensure that important files are copied to other storage device. 1. Copy the latest firmware file such as nx300.bin into the root directory of the SD Card. Insert the SD Card into the camera.
  • Page 64 Screen seems to be turned off. During the update process please ensure that the camera is not turned off or operated. Once the update is complete, a confirmation screen will be displayed. Device Information Firmware Update 0.52 Firmware is updating... Back MENU Fig. 7-8 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 65: Firmware Update By Using Cs Menu

    1. Copy the nx_dev.adj file into the root directory of the SD Card. Insert the SD Card into the camera. 2. Power on the camera. 3. Select the Smart Auto Mode. Mode dial Fig. 7-9 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 66 Fig. 7-10 5. Select FW UPDATE-> Select BODY FW UPDATE. 1. FW UPDATE (1) BODY FW UPDATE (2) LENS FW UPDATE (3) DSP FW BACKUP (4) RESET USERDATA MENU Cancel Fig. 7-11 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 67 - Full Version : nx300_DSP_X_PV1_F1301261 [SD-CARD] - User Version : - Full Version : OK button [H/W] - Board Version : PV2 / Micom Version : -1 FW update by pressing the [OK] key. Fig. 7-12 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 68: How To Recover The Main Pcb

    2. Tweezer (It is used to short out the TP on MAIN PCB.) 3. The latest firmware files such as nx300.bin You can download the latest firmware file from the K-zone or Samsung website. 4. recovery file such as dnloader.bin Note that the name of the firmware file may vary depending on NX model.

  • Page 69: Adjustment

    NFC Writing <Table 8-1> 2. Adjustment Equipment - Light Source Box 1 : LV-1450DC (3200K±50, Lv12) - Light Source Box 2 : LSB-1/10 (5500K±100, Lv. 12) - PAF regulator - NFC Writer Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 70: Test Mode

    (2) Set the wide value of zoom lens (5) LENS MOUNT INFO (3) Set the telephoto(tele) value of zoom lens. (6) LENS COMM SEVE Do not move the lens during the LENS CONTROL process. <Table 8-2> Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 71: Cis Tilt Adjustment

    Adjust specification for Mount side and FLANGE BACK side : 25.55mm(-35mm/+15mm) Adjust specification for CMOS sensor TILT side from center: -30um/+30um * Caution : The above three screws for NX10/5/11, NX100, NX200 and NX300 may vary in model. Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 72: Cis Dot Data Input & Shutter Adjustment

    2. Double click the “libusb-win32-filter-bin-1.1.14.3.exe” to execute. (Please refer to on page 8-8 for installing module between the NX SET and PC communications(PTP). Follow the .) 3. Download the “nx300 SHUTTER 2.5.ZIP” file to a directory on your PC and extract it. Fig. 8-5...
  • Page 73 Right click on “My Computer” and click the “Manage”, and then click the “Device Manager”. The Device Manager opens as shown in Figure below. Check the connection status of the “COM” to the “Device Manager”. PORT Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 74 Recent Places START STOP ITEM DATA SENSOR A SENSOR A SENSOR B SENSOR C Desktop Libraries AutoStart Scanner Computer Network File name Open(O) shutter.txt Files of type Script file(*txt,*adi) Cancel Fig. 8-11 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 75 - When the process is not successful, the “FAIL” message will be displayed. Fig. 8-14 10) Navigate to the directory you extracted to the NXCISTEMP_NX200.zip” file such as C:\ CIS DOT_SHUTTER SPEED\nx300\nx300 SHUTTER 2.5\files\Ch1. Check whether the CSV file is created at the destination directory or not.
  • Page 76 Adjustment <How to run “libusb-win32-filter-bin-1.1.14.3.exe”> Fig. 8-15 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 77: Iso Adjustment

    2. Attach the camera with master lens to the 3200K Light Box as illustrated in the image below. Camera 3. When turning on the camera, the process will proceed automatically. <Set up a camera in front of the Light box> Fig. 8-17 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 78: Vfpn & Cmos Defact Adjustment

    VFPN adjustment. - Camera may heat up during the operation due to the camera being on for extended periods of time. (Tip. If you use hairdryer, you can heat it up faster.) 8-10 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 79: Color Shading Adjustment

    2. Attach the camera with master lens to the 5500K Light Box as illustrated in the image below. Light source Box Camera <Set up a camera in front of the Light box> Fig. 8-19 3. When turning on the camera, the process will proceed automatically. 8-11 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 80: Country Setting (Wi-Fi)

    3. When turning on the camera, the process will proceed automatically (How to check: Menu →Setting → info) appliance information Firmware information main body Firmware 1.00 lens Firmware 01.20 MAC address 1a:2b:3c:4d:5f:6a network number authentication 123456789012 Fig. 8-21 8-12 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 81: Paf (Phase Af) Adjustment

    2. Copy “info.tgw” file to SD card and insert the SD card into the camera. 3. Please attatch camera to PAF equipment and connect USB cable. Fig. 8-22 4. When turning on the camera, the process will proceed automatically. Fig. 8-23 8-13 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 82 3) Please revise and store port number in “Setup.ini” file. Input COM PORT NUMBER 3. Please execute “USBSet1.1.exe” file. 4. Please cut USB ID and move to Channel 5. ① MOVE TO CHANNEL 5 ② CLICK ③ CLICK Fig. 8-25 8-14 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 83: Nfc Tag Information Record

    3. After insert model name and last 6 numbers of Mac Address, please click the writer tap by cursor for storing the data to Tag. ① Input Model Name ② Last 6 number of MAC Address ③ CLICK WRITE Fig. 8-27 8-15 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 84 2. In case of WinXP , please install the driver provided with adjustment files. 3. Please install driver manually. Even though Win7 install the driver automatically, an error occurred working. Click Click Click Fig. 8-28 8-16 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 85 Adjustment Click Click ① Choose acr122.inf ※ Driver Location NFC Write → FC_Reader_Driver → ACR122U ① OPEN Click Fig. 8-29 8-17 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 86: Adjustment Data Image Storage

    1. Copy the below two script files to memory card and insert the memory card into the camera. info.tg nx300_snap.adj 2. When you turn on the power Adjustment data is stored in the Boot Image It takes about 3 minutes. 8-18 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 87 GHANA PARAGUAY UNITED_KINGDOM Greece PARAGUAY UNITED_STATES GSS_CO PHILIPPINES UNITEDARABEMIRATES GUINEA POLAND URUGUAY Guinea-Bissau PORTUGAL UZBEKISTAN HONGKONG REUNION VIETNAM ROMANIA HUNGARY YUGOSLAVIA INDIA RUSSIA ZAMBIA RWANDA INDONESIA ZIMBABWE IRAN SAMPLE <Table 8-3> 8-19 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 88: Exploded View And Parts List

    Loc. No. Parts No. Description Available Remark AD90-05300A ASSY BODY-NX300_BK BLACK AD90-05300B ASSY BODY-NX300_WH WHITE AD90-05300C ASSY BODY-NX300_BN BROWN AD97-23888A ASSY-SHUTTER AD97-23199A ASSY MAIN-NX300_BK BLACK AD97-23199B ASSY MAIN-NX300_WH WHITE AD97-23199C ASSY MAIN-NX300_BN BROWN Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 89 AD41-01958A FPC;NX300_DRS_IF_FPCB 6107-002736 SPRING-CS 6001-002152 SCREW-MACHINE (M1.4XL4,BLK) BLACK, BROWN 6001-002159 SCREW MACHINE (M1.4XL4,NI) BLACK, BROWN 6001-002159 SCREW MACHINE (M1.4XL4,NI) WHITE 6001-002279 SCREW MACHINE (M1.7XL4,BLK) 6001-002282 SCREW MACHINE (M1.7XL3,NI) 6003-001739 SCREW TAPTYPE (M1.4XL4,NI) Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 90: Assy Main

    Exploded view and parts list 9-2 ASSY MAIN Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 91 ASSY CHAMBER_BN BROWN 6003-001660 SCREW-TAPTYPE (M1.4XL3,NI) AD63-07508A CUSHION SHIELD FOAM CHAMBER AD97-23201B ASSY HOLDER MOUNT AD63-07460A CUSHION SHIELD FOAM MAIN 6003-001739 SCREW TAPTYPE (M1.4XL4,NI) AD97-23626A ASSY WIFI ANTENNA AD61-05861A HOLDER STRAP R Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 92: Assy Chamber

    AD66-00943A SHAFT BATTERY COVER 6107-003085 BATTERY PUSH SPRING AD61-05888A PLATE BATTERY CHAMBER AD63-07248A COVER JACK_BK BLACK AD63-07248B COVER JACK_WH WHITE AD63-07248C COVER JACK_BN BROWN AD61-05862A HOLDER STRAP L 6003-001739 SCREW TAPTYPE (M1.4XL4,NI) Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 93: Assy Cover Top

    6001-002282 SCREW MACHINE (M1.7XL3,NI) 6003-001660 SCREW-TAPTYPE (M1.4XL3,NI) AD61-05411B PLATE-HOT-SHOE AD97-23633A ASSY COVER TOP AS_BK BLACK AD97-23633B ASSY COVER TOP AS_WH WHITE AD97-23633D ASSY COVER TOP AS_BN BROWN AD63-07461A CUSHION SHIELD FOAM TOP Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 94: Assy Fpcb_Hotshoe

    Exploded view and parts list 9-5 ASSY FPCB_HOTSHOE Loc. No. Parts No. Description Available Remark AD92-02014A ASSY PCB SUB_HOTSHOE_FPCB AD67-02581A RUBBER MIC 3003-001198 MIC-CONDENSOR AD41-01956A NX300_HOTSHOE_FPCB Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 95: Assy Speaker

    9-6 ASSY SPEAKER Loc. No. Parts No. Description Available Remark AD97-23212A ASSY SPEAKER-DRS PCB-NX300 3001-002641 SPEAKER AD61-05860A HOLDER SPEAKER AD61-05920A BRACKET NUT AD92-02013A ASSY PCB SUB DRS HPCB 6003-001660 SCREW-TAPTYPE (M1.4XL3,NI) AD41-01958A FPC;NX300_DRS_IF_FPCB Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 96: Assy Cover Back

    GRIP-BACK_BN BROWN AD64-03841A BUTTON-FUNCTION_BK BLACK AD64-03841B BUTTON-FUNCTION_WH WHITE AD64-03841C BUTTON-FUNCTION_BN BROWN AD64-03840A BUTTON-BACK_BK BLACK AD64-03840B BUTTON-BACK_WH WHITE AD64-03840C BUTTON-BACK_BN BROWN AD63-07215A COVER BACK-NX300_BK BLACK AD63-07215B COVER BACK-NX300_WH WHITE AD63-07215C COVER BACK-NX300_BN BROWN Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 97: Assy Back

    Description Available Remark AD97-23204A ASSY BACK-NX300_BK BLACK AD97-23204B ASSY BACK-NX300_WH WHITE AD97-23204C ASSY BACK-NX300_BN BROWN AD63-07215A COVER BACK_BK BLACK AD63-07215B COVER BACK_WH WHITE AD63-07215C COVER BACK_BN BROWN AD64-03857A WINDOW ACCESS LAMP 9-10 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
  • Page 98 AD61-05966A MAGNET TILT A AD61-05897A FRAME BACK AD92-02040A ASSY PCB KEY 6003-001508 SCREW-TAPTYPE (M1.4XL3,NI) AD97-23205A ASSY TILT LCD_BK BLACK, BROWN AD97-23205B ASSY TILT LCD_WH WHITE 6001-003021 SCREW-MACHINE (M1.4XL1.6,BLK) AD63-07325A T/SHEET CAM2 9-11 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 99: Assy Tilt Lcd

    AD59-00209A TOUCH/PANEL(C-TYPE) AD63-07325A T/SHEET-CAM2 AD97-23628A ASSY-OLED-NX300 AD92-02015A ASSY PCB SUB AD61-05891A PLATE MAGNET_BK BLACK AD61-05891B PLATE MAGNET_WH WHITE AD61-05891C PLATE MAGNET_BN BROWN 6001-003021 SCREW-MACHINE (M1.4XL1.6,BLK) AD63-07501A SHEET TILT_BK AD61-05895A HOLDER FPCB_BK 9-12 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 100: Assy Cmos

    CUSHION CMOS AD61-05893A HOLDER OLPF AD61-05756A HOLDER CMOS AD67-02217A RUBBER CMOS B AD97-21669A ASSY PZT AD97-21628A ASSY PLATE PZT 6001-002159 SCREW MACHINE (M1.4XL4,NI) AD41-01765B FPC;NX200 CIS FPCB AD63-07448A SHEET CIS FPCB 9-13 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.

  • Page 101: Assy Lcd Sub

    BLACK, BROWN 6001-003022 SCREW-MACHINE (M1.4XL1.6,NI) WHITE AD61-05891A PLATE-MAGNET_BK BLACK AD61-05891B PLATE-MAGNET_WH WHITE AD61-05891C PLATE-MAGNET_BN BROWN AD63-07244A COVER DISPLAY_BK BLACK AD63-07244B COVER DISPLAY_WH WHITE AD63-07244C COVER DISPLAY_BN BROWN AD97-23107A ASSY TILT HINGE_BK 9-14 Copyrightⓒ since 1995 Samsung Electronics. All rights reserved.
