- Page 1 VJ-1604 User Maintenance and Cleaning Guide Page 1 of 7...
-
Page 2: Section 1: Intervals
□ Replace Flushing Box PrintHead base Mesh □ Clean around cap □ Clean Flushing mesh Section 2: Supplies 1. Supplies for cleaning the VJ-1604 can be purchased as a kit P/N: 11606-0001 Item # Description Foam Swabs Tweezers Lint Free Cloth... -
Page 3: Section 3: Cleaning Procedures
Section 3: Cleaning Procedures ** Clean Wiper Do not touch Wiper. Oil from your hands may prevent the wiper from cleaning the head properly. 1. The wiper can be cleaned using either the foam swabs or the lint free cloth. Either Eco- cleaning solution or Isopropyl Alcohol may be used in conjunction with the cleaning utensil of choice.. - Page 4 3. Wipe the back of the wiper in a vertical motion. Foam Swab Lint Free Wipe Page 4 of 7...
- Page 5 ** Clean around cap Do not touch the Rubber Cap. Oil from your hands may prevent the cap from sealing properly. 1. Using either a foam swab or a lint free cloth soaked in Eco-cleaning solution or Isopropyl Alcohol, wipe around the edges of the rubber cap. This ensures a good seal is maintained during head cleaning process.
- Page 6 ** Clean around Print Head CAUTION • When cleaning around Print Heads Do Not Touch the Bottom of the heads. Do Not Clean the Nozzle Surface with the cleaning device. Do not use water to clean the head. Nozzle clogging may occur Do Not Re-use dirty foam swabs or lint free cloths 1.
- Page 7 2. Pay special attention to the areas on either side of the print head. The small gap between the print head and the guide ramps can build up large amounts of ink and dust. * Replace Flush Box Mesh 1. Open the front cover. 2.
