- Page 1 MICROMASTER 411 & COMBIMASTER 411 AS-i Module Operating Instructions Issue 01/03 User Documentation 6SE6400-5AT00-0BP0...
- Page 3 Description Installing the AS-i Module Commissioning MICROMASTER 411 & COMBIMASTER 411 Diagnostics and Troubleshooting AS-i Module Technical Data Operating Instructions User Documentation Valid for Issue 01/03 MICROMASTER 411 & COMBIMASTER 411 Issue 01/03...
- Page 4 No solvents have been used in the printing or binding process. Document subject to change without prior notice. Order Number. 6SE6400-5AT00-0BP0 Siemens-Aktiengesellschaft. Printed in the Federal of Germany MICROMASTER 411 & COMBIMASTER 411, AS-i Module Operating Instructions 6SE6400-5AT00-0BP0...
- Page 5 Customers can access technical and general information at: http://www.siemens.de/micromaster Contact address Should any questions or problems arise while reading this manual, please contact the Siemens office concerned using the form provided at the back this manual. MICROMASTER 411 & COMBIMASTER 411, AS-i Module Operating Instructions 6SE6400-5AT00-0BP0...
- Page 6 2. Trained in the proper care and use of protective equipment in accordance with established safety procedures. 3. Trained in rendering first aid. MICROMASTER 411 & COMBIMASTER 411, AS-i Module Operating Instructions 6SE6400-5AT00-0BP0...
- Page 7 Use for intended purpose only The equipment may be used only for the application stated in the manual and only in conjunction with devices and components recommended and authorized by Siemens. MICROMASTER 411 & COMBIMASTER 411, AS-i Module Operating Instructions 6SE6400-5AT00-0BP0...
-
Page 8: Table Of Contents
Commissioning ..................... 17 Parameter settings ....................17 AS-i Module Parameters ..................18 AS-i use data......................19 Diagnostics and Troubleshooting ............... 21 Technical Data ....................... 23 Technical Specifications..................23 EMC Information ..................... 23 MICROMASTER 411 & COMBIMASTER 411, AS-i Module Operating Instructions 6SE6400-5AT00-0BP0... -
Page 9: Description
Issue 01/03 Description Description The AS-i Module (Actuator sensor-Interface Communications Module) has been designed to control the COMBIMASTER 411 and MICROMASTER 411 inverters via: ON/OFF commands Fixed frequency selection Reverse commands Fault acknowledge commands In the standard AS-i system up to 31 slaves can be connected, each slave having up to 4 input and output bits. - Page 10 Description Issue 01/03 Figure 1-1 View of the COMBIMASTER 411 & MICROMASTER 411 AS-i Module MICROMASTER 411 & COMBIMASTER 411, AS-i Module Operating Instructions 6SE6400-5AT00-0BP0...
-
Page 11: Installing The As-I Module
Installing the AS-i Module Installing the AS-i Module WARNING Make sure that the MICROMASTER 411/COMBIMASTER 411 inverter is isolated from the electrical supply before you install or remove the AS-i Module. CAUTION Do not knock out cable gland blanking plates unless inverter ‘electronics’ (Filter &... -
Page 12: Preparation Of Inverter Terminal Housing
“knockout”. Figure 2-1 Removing Inverter cover Figure 2-2 Removing the Filter and I/O Boards Figure 2-3 Gland Plate or “knockout“ Figure 2-4 Fitting Gland Fixing Plates Removal MICROMASTER 411 & COMBIMASTER 411, AS-i Module Operating Instructions 6SE6400-5AT00-0BP0... -
Page 13: As-I Module Installation
Figure 2-6 AS-i Module Fixing to Inverter lead (attached to the fixing plate) to the earth stud (shown as in Figure 2-6 above) within the module housing. MICROMASTER 411 & COMBIMASTER 411, AS-i Module Operating Instructions 6SE6400-5AT00-0BP0... - Page 14 Size lbf.in Filter and I/O board screw. CSB Inverter Cover Screw, CSB & C Module Fixing, 10.6 Cover Retaining Screw. CSC Inverter Cover screws. 21.3 Options module earth wires 10.6 MICROMASTER 411 & COMBIMASTER 411, AS-i Module Operating Instructions 6SE6400-5AT00-0BP0...
-
Page 15: Addressing The As-I Module
The AS-I slave device has been designed with an external addressing connector on the upper housing of the module to allow the connection of a dedicated addressing unit. See Figure 2-10. Figure 2-10 AS-i Addressing & Diagnostic Instrument MICROMASTER 411 & COMBIMASTER 411, AS-i Module Operating Instructions 6SE6400-5AT00-0BP0... - Page 16 Installing the AS-i Module Issue 01/03 MICROMASTER 411 & COMBIMASTER 411, AS-i Module Operating Instructions 6SE6400-5AT00-0BP0...
-
Page 17: Commissioning
The following parameter descriptions are given to enable the user to control and monitor the correct functioning of the AS-i slave module and the COMBIMASTER 411 / MICROMASTER 411. For parameterization you need either an Operator panel (BOP or AOP) or a Commissioning software (DriveMonitor or Starter, delivered with with the inverter). -
Page 18: As-I Module Parameters
Detailed connection of commands to and from the Master through the AS-i Module optional board is parameterized in "r2050" and "P2051". The following table shows the parameters specific to the AS-i Module relating to the connection of process data: MICROMASTER 411 & COMBIMASTER 411, AS-i Module Operating Instructions 6SE6400-5AT00-0BP0... -
Page 19: As-I Use Data
0 acts as a forward or reverse bit. When all three FF selection bits are inactive then the inverter is stopped and bit 0 acts as a fault acknowledgement bit. MICROMASTER 411 & COMBIMASTER 411, AS-i Module Operating Instructions 6SE6400-5AT00-0BP0... - Page 20 To achieve this, set P2051[1] to 722. This maps r0722 (digital input states). Now set P2041[1] to 1 * 16 + 0 = 16. NOTE Bit 0 and Bit 3 are fixed. Example 1 and 2 are mutually exclusive. MICROMASTER 411 & COMBIMASTER 411, AS-i Module Operating Instructions 6SE6400-5AT00-0BP0...
-
Page 21: Diagnostics And Troubleshooting
30 V DC available Flashing No slave address coded AS-I slave has factory default address (0) Hardware failure in No communications with inverter. (inverter Flashing Flashing sensor/actuator circuitry power off) Flashing Internal Fault MICROMASTER 411 & COMBIMASTER 411, AS-i Module Operating Instructions 6SE6400-5AT00-0BP0... - Page 22 Diagnostics and Troubleshooting Issue 01/03 MICROMASTER 411 & COMBIMASTER 411, AS-i Module Operating Instructions 6SE6400-5AT00-0BP0...
-
Page 23: Technical Data
The board complies with the following standards governing radio emissions and interference immunity: Radio emissions in accordance with EN 55011 1991 Class A Interference immunity in accordance with IEC 801-3 and EN 61000-4-3 MICROMASTER 411 & COMBIMASTER 411, AS-i Module Operating Instructions 6SE6400-5AT00-0BP0... - Page 25 Suggestions and/or Corrections Suggestions Siemens AG Corrections Automation & Drives Group For Publication/Manual: SD VM 4 MICROMASTER 411 & P.O. Box 3269 COMBIMASTER 411 AS-i Module D-91050 Erlangen Federal Republic of Germany Email: User Documentation Technical.documentation@con.siemens.co.uk From Operating Instructions Name:...
