Summary of Contents for Sony 500WSPL
- Page 1 3-866-520-13(1) Digital Camcorder Operating Instructions Before operating the unit, please read this manual thoroughly and retain it for future reference. DSR-500WSL/500WSPL 2000 Sony Corporation...
- Page 2 Owner’s Record The model and serial numbers are located on the top. Record these numbers in the spaces provided below. Refer to them whenever you call upon your Sony dealer regarding this product. Model No. Serial No. LITHIUM BATTERY Replace the battery with a Sony CR2032 lithium battery.
-
Page 3: Table Of Contents
Table of Contents Chapter 1 Overview Chapter 2 Fitting and Connections Product Configurations ... 7 Features ... 8 Features on Camera Section ... 8 Features on VCR Section ... 10 Location and Function of Parts ... 12 Front View ... 12 Right Side View ... - Page 4 Basic Procedure for Shooting... 49 Using DynaLatitude Function ... 50 Recording ... 51 Cassettes for the DSR-500WSL/500WSPL ... 51 Recording on the Internal VCR ... 52 Recording an External Video Signals ... 56 Recording on an External VCR Using the VTR Connector (26-pin) ...
- Page 5 Chapter 5 Adjustments and Settings Viewfinder Normal Indications ... 76 Status Indications ... 79 Viewfinder Basic Menu ... 80 Basic Menu Operations ... 80 Contents and Settings of Each Menu Page ... 80 Viewfinder Advanced Menu ... 86 Advanced Menu Operations ... 86 Contents and Settings of Each Menu Page ...
- Page 6 Table of Contents Appendix Table of Contents Menu 221 Using Setup Remove (for DSR-500WSL Only) ... 111 White Balance Adjustment ... 112 Saving an Appropriate White Balance Value in Memory ... 112 Using the Preset White Balance Settings ... 113 Light Sources and Color Temperature ...
-
Page 7: Product Configurations
Camcorder • Lens mount cap • Binding tie • Operating instructions * The switch guard can be removed. (See page 12.) The DSR-500WSL/500WSPL consists of the following items: Microphone (with the wind screen attached) Test chart for flange Shoulder strap... -
Page 8: Features
Features Features on Camera Section -inch IT type Power HAD WS CCD The DSR-500WSL/500WSPL Digital Camcorder uses a newly developed 520,000-pixel Power HAD WS (wide screen) CCD, for outstanding sensitivity and picture quality. • Sensitivity: F11.0 (at 3200 K, 2000 lux) •... - Page 9 1 can be set to the levels ranging from 70 to 90 IRE on the DSR-500WSL (or from 70 to 90% on the DSR-500WSPL) and the zebra 2 indicates the levels of 100 IRE or more for the DSR-500WSL (or the levels of 100% or more for the DSR-500WSPL).
-
Page 10: Features On Vcr Section
DSR-500WSL/500WSPL. (Cassettes recorded in LP mode cannot be played back.) (See page 51.) DVCAM cassettes (page 51) • The DSR-500WSL/500WSPL can use both standard- size and mini-size DVCAM cassettes. According to cassette size, the DSR-500WSL/500WSPL automatically corrects reel position. - Page 11 (two-channel) audio output connectors. (See pages 24 and 25.) is a trademark of Sony Corporation and indicates that this product is in agreement with IEEE 1394-1995 specifications and their revisions.
-
Page 12: Location And Function Of Parts
Location and Function of Parts Front View 0 Switch guard How to remove the switch guard 1. Detach the two screws (M3). 2. Remove the switch guard, and replace the screws detached in step 1. Switch guard 1 MIC (microphone) IN +48 V connector (XLR 3- pin, female) Connect the supplied microphone or an optional microphone (operable with a 48 V supply). -
Page 13: Right Side View
Note If the “easy focus” function is still on when you press the VTR button on the camcorder or the lens, it turns off automatically and recording starts about one second later. 1 EZ FOCUS button... - Page 14 Press this button (EZ mode on) when you want to be able to shoot immediately, with automatic adjustment of the camcorder settings to standard values. (See page 91 for EZ mode settings.) When this function is used, the iris and the white balance are adjusted automatically.
-
Page 15: Rear Section
Rear section EJECT STOP 1 EJECT Z button Press to open the cassette holder (1 on page 24) when the camcorder is powered. 2 Tape transport buttons and indicators These buttons transport the tape as shown below. Buttons Operation REW m Rewinds the tape. - Page 16 Location and Function of Parts 7 AUDIO LEVEL (CH-1/CH-2) (audio recording level adjustments for channels 1 and 2) knobs When the AUDIO SELECT (CH-1/CH-2) switches (4 on page 20) are set to MAN, these knobs adjust the audio levels being recorded on channels 1 and 2. S Time value indication R Clip remaining...
- Page 17 Indication Description J Lithium backup battery warning Appears when the voltage of the internal lithium backup battery (CR2032) is low. If this indication appears, replace the lithium backup battery immediately. For further information about replacing lithium battery, see “Inserting and Replacing the Lithium Battery”...
- Page 18 Location and Function of Parts Indication Q Tape remaining indication R Clip remaining indication S Time value indication 9 RESET/(MENU SET) (counter reset/VCR menu) button Resets the time value shown in the display window. This button operates differently depending on settings of the DISPLAY switch (6 on page 15), and the TC mode switches 1 (9 on page 20) and 2 (8 on page 20).
-
Page 19: Right Side
qa ALARM (alarm tone volume adjustment) knob Controls the volume of the warning tone that is output via the speaker (0 on page 18) or the EARPHONE connector (3 on page 15). Turning this knob to the minimum setting mutes the alarm tone. Operation panel under the cover Right side REC TIME SKIN DTL... - Page 20 Sets the mode for advancing time code values when the TC mode switch 1 9 has been set to PRESET. F-RUN: The time code advances continuously whether or not the camcorder is recording. Use this setting to align the time code value with real time.
- Page 21 Selects the recording time indication in the viewfinder. TTL (TOTAL): Displays the total recording time. The total recording time is not reset even when you stop the VCR and power off the camcorder, for example, to replace the battery pack. DUR (DURATION): Displays the recording time of the current cut.
- Page 22 COMPONENT/VBS: Component/composite video signal Y/C: S-video signal 4 VTR TRIGGER switch Sets the function of the VTR button on the camcorder or lens when a VCR is connected to the VTR connector (0 on page 26). PARALLEL: Operates both internal and external VCRs.
-
Page 23: Left And Upper View
0 LENS connector qa VIDEO OUT connector qs REMOTE connector 2 If you connect the optional cable (Sony part number: 1-790-779-11) to this connector, you can control the zoom using the optional RM-VJ1 Remote Control Unit (equipped with microphone and monitor), even if you use the conventional lens. - Page 24 • EZ mode cannot be used if the RM-M7G is connected to the camcorder. • Be sure to turn off the power of the camcorder before connecting the RM-M7G/VJ1. • Be sure to turn off the power of the camcorder before disconnecting the equipment connected to this connector.
-
Page 25: Rear And Bottom
Note Use a jitterless LTC signal.Using an LTC signal reproduced by other equipment may cause the camcorder to malfunction. 4 TC OUT (time code output) connector (BNC) This outputs time code signals from the built-in time code generator.When a time code signal is input to the TC IN connector (3 on page 24), this output signal is synchronized to it. - Page 26 Audio System” (page 39). 4 DC IN (DC power input) connector (XLR 4-pin, male) To use the camcorder with an AC power supply, connect an optional AC-550/550CE or CMA-8A/ 8ACE AC Adaptor. 5 AUDIO IN CH-1/CH-2 (audio input channel 1...
-
Page 27: Vcl-918By Zoom Lens (Not Supplied)
VCL-918BY Zoom Lens (not supplied) When using a lens other than VCL-918BY, see page 121 (“Designating the lens”). 1 Iris ring 2 Zoom ring 3 Focus ring 4 Lens hood qa RET button !™ !£ qs VTR button 5 M button 6 F.B adjustment ring and F.B fixing screw 7 MACRO ring... - Page 28 9 Zoom remote control connector (8-pin) Connect the optional LO-26 lens remote control unit for remote control of zooming. When connecting the optional lens cable (Sony product number: 1-790-779-11) to this connector, you can control the zoom from the RM-VJ1 Remote Control Unit (equipped with microphone and monitor).
-
Page 29: Dxf-801/801Ce Viewfinder
The light lights the lens and the switch controls the light as follows. HIGH/LOW: Turn the light on and control the brightness. OFF: Turns the light off. in accordance with the aspect ratio selected on the camera or camcorder. 4 TAKE/TALLY indicator TALLY TAKE BATT 5 BATT indicator... - Page 30 • From the time when you press the VTR button (9 on page 12 and qs on page 28) on the lens (not supplied) or camcorder, this flashes until recording starts, then stays on continuously during recording. • This is also used to indicate a fault. (See page 127.) •...
-
Page 31: Inserting And Replacing The Lithium Battery
• Use only CR2032 Lithium Batteries. Other types of lithium batteries may come loose when the camcorder is moved. If you have difficulty finding CR2032 Lithium Batteries, contact your Sony dealer. POWER switch Press down and pull out toward you. -
Page 32: Fitting The Lens
With the lens fixing lever turned fully counterclockwise, push in the lens, aligning the projection on the lens with the cutout on the camcorder. Supporting the lens, turn the lens fixing lever fully clockwise. Replace the retaining rubber on the lens mount. - Page 33 Fitting optional filters Loosen the lens hood fixing knob to remove the lens hood, then attach the filter. Remove lens hood Filter (optional) Lens hood fixing knob Chapter 2 Fitting and Connections...
-
Page 34: Using Accessories
Note You cannot stow the camcorder with a left eye adaptor attached in the carrying case. For details, consult your Sony dealer. Chapter 2 Fitting and Connections VF connector Retaining catch Viewfinder left-to-right... -
Page 35: Fitting The 4-Inch/5-Inch Electronic Viewfinder
Remove the cover of the grip and attach the shoe and stopper screw (accessory shoe kit). Fitting to a Tripod First fit the VCT-U14 Tripod Adaptor to the tripod, then mount the camcorder on the tripod adaptor. VCT-U14 Tripod Adaptor Side the camcorder forward along the slot, until it clicks firmly into place. -
Page 36: Using An Optional Microphone
Using an Optional Microphone To use a long microphone such as the optional ECM-670/672, fit an optional CAC-12 Microphone Holder to the camcorder, then mount the microphone in this holder. Fitting the optional CAC-12 Microphone Holder Remove the two retaining screws (M3 8) for the... -
Page 37: Using A Video Light
VCR operation. • The output of the video light connector on the DSR- 500WSL/500WSPL is controlled to 12 V even when the camcorder is supplied with 12 V or more power (through the DC IN connector or battery pack). The brightness or color temperature of the light will not change according to voltage increase. -
Page 38: Fitting The Shoulder Strap
Using Accessories Fitting the Shoulder Strap This section describes the procedure for fitting the supplied shoulder strap to the camcorder. Fit one of the clips to a shoulder strap fitting. Fit the other clip to the shoulder strap fitting on the other side of the grip in the same way. -
Page 39: Connecting To Audio System
Connecting to Audio System The DSR-500WSL/500WSPL is able to record sound not only from the microphone attached but also from a wireless microphone or an external audio system. Using a wireless microphone system You can use the wireless microphone system... - Page 40 (one for the upper position and the other for the lower position). Mount the tuner on the WRR tuner fitting. For details about the WRR tuner fitting (Part No. A-8278- 057-A), contact your Sony dealer. AUDIO IN (CH-1/CH-2) switches: Set to REAR. CH-1 CH-2...
-
Page 41: Using The Optional Rm-Vj1 Remote Control Unit (Equipped With Microphone And Monitor)
When using conventional lens, such as VCL-918BY, you can control the zoom if you use the optional lens cable (Sony product number: 1-790-779-11). For details on the cable, consult your Sony dealer. The connection for controlling the zoom when using conventional lens RM-VJ1 Remote... -
Page 42: Using The Rm-Lg1 Remote Control Unit
Using Accessories Using the RM-LG1 Remote Control Unit You can control the camcorder using the supplied RM-LG1 Remote Control Unit. Location and Function of Parts 1 Cable with mini-plug 2 Switches 1 and 2 3 Switch name displays 1 Cable with mini-plug Connect to the REMOTE connector 1 (5 on page 23) on the DSR-500WSL/500WSPL. -
Page 43: Using The Optional Lc-Ds500 Carrying Case
For details on using the carrying case, refer to the instruction manual supplied with the carrying case. For detail on the time that the carrying case will appear on the market, consult your Sony dealer. Using the Optional LC-DS300SFT Soft Carrying Case For details on using the soft carrying case, refer to the instruction manual supplied with the soft carrying case. -
Page 44: Connections
When using two or more synchronized camcorders, connect an external sync signal to the GEN LOCK IN connector, supplying a VBS or BS signal. The camcorder will then operate synchronized to this signal. You can adjust the synchronization using the basic menu. -
Page 45: Connecting The Dsr-70/70P Digital Videocassette Recorder (Optional Dsbk-140 Is Required)
(DV connecting cable). DSR-500WSL/500WSPL Notes • The camcorder does not support the noiseless function of the various speed playback. • The slow playback will be automatically released to protect the tape if the slow playback lasts for about one minute. -
Page 46: Power Supply
• If you use the BP-L40/L40A at temperatures of 0°C (32°F) or below, when power consumption of the camcorder and accessories is 40 W or higher (due to using a video light, for example), power may break after a short time (a few minutes). To increase the... - Page 47 When the external battery begins to fail and an internal battery pack is not used First load the camcorder with a fully charged internal battery pack, then remove the DC output cable of the external battery from the DC IN connector. The power source will switch to the internal battery pack.
-
Page 48: Using An Ac Adaptor
When the camcorder is used with an Anton Bauer Digital Magnum series battery, the remaining battery capacity is shown numerically in the viewfinder display. To AC power source Contact your Sony dealer for more information. CAMERA/CCU To AC power source... -
Page 49: Basic Procedure For Shooting
2 or 4, and iris is set to fully open. In such case: when the FILTER control is set to 4, set it to 2; when set to 2, set it to 3. Check the switch settings on the camcorder. (See pages 12 to 26). neutral density If there is not sufficient time to check the camcorder settings, you can use “easy mode”... -
Page 50: Using Dynalatitude Function
Using DynaLatitude Function This function enables detailed adjustment of contrast control in each pixel in accordance with a histogram of luminance signal levels. If use this function, the camcorder automatically adjusts contrast control by detecting luminance levels of each subject. DL OFF However, if a subject moves in shooting, the brightness of the subject may be changed;... -
Page 51: Recording
(ClipLink log data) is stored. The DSR-500WSL/ 500WSPL can record or play back the cassettes with cassette memory of 16 Kbits or less. For details of ClipLink log data, see “ClipLink Shooting”... -
Page 52: Recording On The Internal Vcr
See page 53 on how to insert a cassette. Paper clip, etc. • When using a tape recorded by the DSR-500WSL/ 500WSPL to transfer digital (video/audio/time code) signals at four times normal speed from the DSR-85/ 85P Digital Videocassette Recorder to the ES-7... - Page 53 Make sure that the cassette’s REC/SAVE switch is set to REC, then check for tape slack before loading the cassette. For details on handling cassettes, see “Cassettes for the DSR-500WSL/500WSPL” on page 51. Inserting a standard-size cassette Indication “PUSH” Cassette holder window Insert the cassette with the cassette window (on the front) facing outward.
- Page 54 • Internal parts of the camcorder may become bent or otherwise damaged if you attempt to close the cassette holder after inserting a mini-size cassette in...
- Page 55 The recordings at switching points prevent editing. Avoid changing the audio mode once you have started recording. Set up the camcorder to suit your recording objectives, and press the VTR button on the camcorder or lens. Manually adjusting audio recording level In step 3 above (“Recording on the Internal...
-
Page 56: Recording An External Video Signals
Recording an External Video Signals When the optional DSBK-501/501P Analog Composite Input Board is fitted to this camcorder, you can record the external video signals. Connect the external video signals to the GEN LOCK IN/VIDEO IN connector. -
Page 57: Recording On An External Vcr Using The Dv Out Connector
Note After replacing the cassette on the external VCR, do not press the VTR button on the camcorder or lens, as this will pause the internal VCR. To operate either VCR during recording, change the VTR TRIGGER switch setting. Both VCRs continue recording at the time of switching. -
Page 58: Back Space Editing
(user-definable) period of time and then automatically switches to standby-off mode. When the camcorder is in standby-off mode, it takes time for the recording to start after pressing the VTR button. For details on setting the timeout value for automatic switching to standby-off mode, see “Menu 207 Setting... -
Page 59: Using The Edit Search Function While Back Space Editing
Note also that the recording continuity is lost in the following cases. • If the POWER switch is turned on and off repeatedly. • If the camcorder is left powered off for several hours. • If the camcorder is subject to severe vibration while powered off. -
Page 60: Using The Freeze Mix Function
The VCR enters recording pause mode. Press the VTR button on the camcorder or the lens. The VCR starts recording. Using the Freeze Mix Function The freeze mix function superimposes a freeze-frame image of a previously recorded shot on the shooting image displayed on the viewfinder screen. -
Page 61: Playback - Checking Recorded Contents
The camcorder may not be able to find the continue point. • If you press the VTR button on the camcorder or lens during recording review, the camcorder stops the recording review and starts recording. In this case (when ClipLink mode is oFF), it is impossible to start back space editing. -
Page 62: Setting Time Values
Setting Time Values The camcorder uses three types of time values: counter values, time code values, and user bits. The time value is displayed in the viewfinder screen and in the display window. WARNING PB DATE NDF EXT-LK HOLD Time value... -
Page 63: Setting The User Bit Value
Setting the User Bit Value You can set the user bits as eight-digit hexadecimal values (base 16) to have the date, time, scene number, and other information inserted into the time code. When using both the time code and user bits, set up the user bits first. -
Page 64: Setting The Time Code Value
CONTINUE CHARACTER 2 3,6 The time code value can be set anywhere in the range of “00:00:00:00” to “23:59:59:29” (DSR- 500WSL) or “23:59:59:24” (DSR-500WSPL). For the DSR-500WSL, use menu 204 to select the frame mode. Operation Adjust the discrepancy bestrewn... - Page 65 Press the VTR button on the camcorder or lens to restart back space editing. Setting the time code to the real time clock bU calendar Set the TC mode switch 1 to DATE/TIME.
-
Page 66: Synchronization With External Time Code Signals - Gen-Lock
Reference camcorder Locked camcorder a) The output signal from the MONITOR OUT connector on the DSR-500WSL/500WSPL may discontinue when switching the operation between recording and playback. Use the output signal from the VIDEO OUT connector. Chapter 3 Shooting... - Page 67 Locking the internal time code generator to the reference time code Perform the following steps to synchronize the camcorder’s internal time code generator to an external time code. Set the TC mode switch 1 to PRESET. Set the TC mode switch 2 to F-RUN.
-
Page 68: Cliplink Shooting
• When an external equipment, such as VCR, is connected to the DV OUT connector, you cannot shoot with ClipLink. • On the DSR-500WSL/500WSPL, you can also use the ClipLink function without recording Index Pictures. However, if you perform ClipLink shooting... - Page 69 198 clips (Index Pictures) can be recorded in a 16-Kbit cassette memory. Set the AUDIO SELECT (CH-1/CH-2) switch to AUTO or MAN (see page 54). Press the VTR button on the camcorder or the lens. F5.6 Recording begins when the TALLY indicator stays 56ND lit after blinking for a moment.
-
Page 70: Setting Editing Points While Shooting
2) Set the cassette name or number if necessary. For details of menu operations, see “Basic Menu Operations” (page 80). Press the VTR button on the camcorder or lens. The camcorder starts recording, and the REC/ TALLY indicator(s) light(s) in the viewfinder. - Page 71 2) Set the cassette name or number if necessary. For details of menu operations, see “Basic Menu Operations” (page 80). Press the VTR button on the camcorder or the lens. The camcorder starts recording, and the REC/ TALLY indicator lights in the viewfinder.
-
Page 72: Resuming Recording In Cliplink Mode
ClipLink Shooting To finish shooting, press the VTR button on the camcorder or the lens. This stops recording operation. Resuming Recording in ClipLink Mode During recording pause in ClipLink mode, pressing the STOP/PLAY/F FWD/REW buttons, performing edit search, or ejecting the cassette will interrupt the ClipLink shooting. - Page 73 If the recording stop point cannot be found, the indication flashes in the display window. CONT Press the VTR button on the camcorder or the lens. This starts the recording function. When the recording is finished, set recording pause mode (or specify a Mark OUT point).
- Page 74 ClipLink Shooting When recording in ClipLink mode is started and previous recording is overwritten Previous recording recording Previous Index Pictures: New Index Pictures are erased recorded (when the DSBK-301A is fitted). ClipLink log data: overwritten by new data When recording in ClipLink mode is started after a previous recording Previous recording...
-
Page 75: Viewfinder Screen Indications
16:9/4:3 mode is added before the basic menu page 1. b) The menu configuration differs according to the camcorder’s switch settings, the connected VCR, and the type of input signal. A nine-page configuration results when all of the basic menu pages are displayed. -
Page 76: Viewfinder Normal Indications
Viewfinder Normal Indications During normal operation, the following items can be indicated in the viewfinder. 1 VCR operation status indication 2 TAKE/CUE indication 3 Recording time or time data indication 4 NG indication 5 Clip mode indication 6 Clip remaining indication 7 Status display area 8 EZ FOCUS indication 9 LOW LIGHT indication... - Page 77 ClipLink function for recording. 7 Status display area One of the following values or messages is displayed to indicate the camcorder’s current status or its operation status. • New values when changing camcorder’s settings • Messages indicating progress or results of adjustments •...
-
Page 78: Viewfinder Normal Indications
Impossible to record any more clip CLIP END shots. Note If the message appears other than above, contact your Sony dealer. qd External VCR (connected to the VTR connector ) status indication (when an external (26-pin) VCR is connected) Shows the external VCR operation status. -
Page 79: Status Indications
If an error message appears, contact your Sony dealer. If using an Anton Bauer Intelligent Battery System The remaining battery capacity is shown as a percentage. -
Page 80: Viewfinder Basic Menu
1/2000, EVS, CLS (60.4 Hz to setting. (see page 200.3 Hz) 116.) DSR-500WSPL: 1/60 (normal value), 1/250, 1/500, 1/1000, 1/2000, EVS, CLS (50.3 Hz to 201.4 Hz) This selects either the shutter speed, the scan frequency, or EVS for the clear scan function. - Page 81 IN: CAM Item Settings CAM (normal value) VIDEO Records the signal shot by this camcorder. Selects Records the signal input from the GEN LOCK IN/ signal VIDEO IN connector. The image on the to be viewfinder and the signal output from the...
- Page 82 Viewfinder Basic Menu Basic menu page 6 M A R K E R : O N mD U R T I M E : M M : S S 0 0 : 0 0 Item Settings MARKER ON (normal value), OFF Sets marker display ON/OFF.
- Page 83 Turn the MENU dial until the desired character appears, and press it. The character cycles through the following sequence. ABCDEFGHIJKLMNOPQRSTUVWXYZ0123456789?;x/: Turn the MENU dial to move the text entry arrow. Return to step 3 and repeat the text entry procedure. After completing text entry, move the text entry cursor to the parenthesis position.
- Page 84 This displays basic menu page 8 again. The title created is retained, even when you power the camcorder off. Chapter 4 Viewfinder Screen Indications and Menus To record a title (basic menu page 9) Access basic menu page 9 (title display).
- Page 85 Example: If an abnormality is detected in the DSP circuit. DIAGNOSIS : ERROR MEMORY: OK DIAG ERROR The error message “DIAG ERROR” appears when the normal indications are displayed. If this message appears, contact your Sony dealer. Chapter 4 Viewfinder Screen Indications and Menus...
-
Page 86: Viewfinder Advanced Menu
Viewfinder Advanced Menu Advanced Menu Operations See also the figure on next page. To display the advanced menu Move the POWER switch to the ON position while holding down the MENU dial. To change the page Align the cursor to the page number and press the MENU dial so that the page number is blinking. -
Page 87: Contents And Settings Of Each Menu Page
Move the POWER switch to the ON position with the MENU dial held down. Advanced menu page 1 mP A G E 1 ( N E X T m$ P R E V m4) A L L R E S E T ( Y E S mP U S H ) E X I T M E N U ( Y E S mP U S H ) Align the cursor to... - Page 88 BARS : SMPTE REMOTE1 : REC REMOTE2 : MARK BAUD RATE: 38400 EXIT MENU (YESmPUSH) a) For DSR-500WSPL: EBU75 Item Settings AWB MEM 2 (normal value): No Selects whether or not correspondence with FILTER to make the FILTER control settings. Only two...
- Page 89 : OFF mZEBRA ZEBRA1 : 70IRE REC TIME: INT VF TALLY: LENS SEL: 1 EXIT MENU (YES mPUSH) a) For DSR-500WSPL: 70% Item Settings MARKER CENT/90% (normal value): Selects ON/OFF Displays center marker and safety setting for center zone marker at 90% size.
- Page 90 Viewfinder Advanced Menu Advanced menu page 6 PAGE6 (NEXTm$ PREVm4) mAUDIO IND: ON TAPE IND: ON IND: ON IND: OFF SET: (ABC EXIT MENU (YESmPUSH) Item Settings AUDIO IND ON (normal value): Selects whether or not to Displays. show the audio level OFF: Not display.
- Page 91 EZ mode settings The following settings are set for the camcorder when EZ mode has been selected. Item Settings Setup file Detail level ±0 Master black ±0 Black stretch ±0 Skin detail Shutter OFF (AE mode) OFF (AE mode) Freeze mix...
- Page 92 Viewfinder Advanced Menu Advanced menu page 9 PAGE9 (NEXTm$ PREVm4) m16:9/4:3 : 16:9 WIDE ID : ON VF SCAN : AUTO MENU MODE: 1 EXIT MENU (YESmPUSH) Item Settings 16:9/4:3 16:9 (normal value) Selects whether to put the camera in 16:9 mode or 4:3 mode.
-
Page 93: Video Output And Viewfinder Picture
Video Output and Viewfinder Picture The video output and viewfinder picture of this camera vary as shown below according to the settings of the 16:9/ 4:3 item and the VF SCAN item of the advanced menu page 9. Subject -inch optics 4:3 effective area 16:9 effective area Item... -
Page 94: Setup Files
Note on using an RM-M7G Remote Control Unit When an RM-M7G is connected to the camcorder, the setup file function cannot be used. To make it possible to use this function, power OFF the camcorder after disconnecting the RM-M7G, then power ON the camcorder again. - Page 95 D O N E E X I T M E N U ( Y E SmP U S H ) The settings of the camcorder are now replaced by the settings in the called file. Chapter 4 Viewfinder Screen Indications and Menus...
-
Page 96: Changing File Settings
Setup Files Changing File Settings When using advanced menu page 11 or 12, you can change the settings about picture quality in setup files. (In basic menu page 1, a part of items are changeable.) The changes are accepted only until another file is called up, after which the original settings are restored. - Page 97 Access advanced menu page 13. mP A G E 1 3 ( N E X Tm$ P R E Vm4) F I L E S T O R E F I L E : * H I S A T D E S T I N A T I O N F I L E U S E R 1 S T O R E F I L E...
- Page 98 Setup Files Press the MENU dial to store the file. To abort the save operation, press the MENU switch (the screen returns to the screen shown in step 2). The tape automatically rewinds and recording starts. The display changes as shown below. (“CAN NOT WRITE”...
-
Page 99: Using Setupnavi And Setuplog
Note on using an RCP-TX7/RM-M7G Remote Control Unit When an RCP-TX7/RM-M7G is connected to the camcorder, you can use neither the SetupNavi function nor the SetupLog function. To make it possible to use these functions, power OFF the camcorder after disconnecting the RCP-TX7/RM- M7G, then power ON the camcorder again. -
Page 100: Recording The Menu Settings Onto A Tape
Using SetupNavi and SetupLog Recording the Menu Settings Onto a Tape Load the tape onto which the settings are to be recorded. Turn the camcorder power on. Make your basic menu settings. For details of this operation, see “Basic Menu Operations” (page 80). -
Page 101: Viewing Setuplog Data
• The former setupnavi data or the recorded contents of the tape are overwritten. Viewing SetupLog Data The SetupLog function records camcorder settings every few seconds at shooting and displays the recorded data in the viewfinder during playback. Note Setup log data is not displayed when external analog video signals are being recorded. -
Page 103: Setting On The Vcr Section - Vcr Menu
Fade-in/fade-out setting for the audio recording start and stop points Use setup add (DSR-500WSL only) Use setup remove (DSR-500WSL only) If you want to change the following setting, consult your Sony dealer. • Outputs the playback time code signals from the TC OUT connector during playback. Menu No. -
Page 104: Vcr Menu Operation
VCR Menu Operation Basic Operation REC TIME SKIN DTL COMPONENT. TTL RESET PARALLEL INT ONLY EXT ONLY HYPER SETUP FRONT MIC GAIN LOW CUT FILE Press the MENU button. “DIAG” appears in the display window and the time data display in the display window switches to the menu display. -
Page 105: Menu 101 Setting The Real Time Clock And Calendar
The date set can be displayed in the time value indication (see page 62) in the following way. On the DSR-500WSL: Displayed in mmddyyyy format (Example: 10081999) On the DSR-500WSPL: Displayed in ddmmyyyy format (Example: 08101999) Checking the Total Menu 201 Operating (Power-On) Hours Display menu 201 and press the SHIFT button. -
Page 106: Menu 206 Selecting Battery Capacity Indication
Setting Standby-On Menu 207 Period At recording pause state or playback pause state, the camcorder waits for a certain standby-on period and then automatically switches to standby-off mode. This standby-on period can be set in advance. Display menu 207. The selected menu number is displayed, along with... -
Page 107: Menu 210 Using Auto-Check Function
VCR menu. Using Auto-Check Menu 210 Function On the DSR-500WSL/500WSPL, the internal check can be automatically performed using the auto-check function. Meanwhile, a test recording and playback are also performed for about one minute. - Page 108 Sony dealer. Check whether a cassette is inserted. If not, insert a cassette and repeat the auto-check. If the result is the same, contact your Sony dealer. If the video and audio recording qualities are normal, the unit is ready for use. However, the unit requires service.
-
Page 109: Menu 211 Selecting Cliplink Function
Selecting ClipLink Menu 211 Function This setting must be made when not using the ClipLink function. For details of the ClipLink function, see “ClipLink Shooting” (page 68). Display menu 211. The ClipLink function is factory-set to on. 211 on Blinking ClipLink function on/oFF indication If the setting does not need to be changed, press... -
Page 110: Menu 213 Selecting Audio Reference Level
The audio reference level can be set to either of the following. –20 dB (factory setting for DSR-500WSL) or –18 dB (factory setting for DSR-500WSPL): Audio reference level for professional use –12 dB: Audio reference level commonly used for consumer DV (The maximum level is 0 dB.) Display menu 213. -
Page 111: Menu 220 Using Setup Add (For Dsr-500Wsl Only)
VCR menu. Note During recording the signal of the image being shot contains setup add, when it is output from the camcorder’s S VIDEO OUT and MONITOR OUT connectors. During playback, the setup is removed from the output video signal. -
Page 112: White Balance Adjustment
A and B. Unless changed, the saved values are retained for approximately ten years, even when the camcorder is powered off. Once a value is saved, you can automatically restore the adjustment by moving the W. BAL switch to the A or B position. -
Page 113: Using The Preset White Balance Settings
To recall a white balance value from memory Before beginning shooting, set the W. BAL switch to the A or B position. This automatically sets the camcorder to the white balance adjustment saved in the corresponding memory. If white balance adjustment cannot be completed automatically The warning message “AUTO WHITE -NG-”... -
Page 114: Light Sources And Color Temperature
The color of a light source is indicated as a color temperature in kelvins (K). It is higher for bluish light, and lower for reddish light. When the camcorder is shipped it is adjusted for use with video lights (studio lamps with a color temperature of 3200 K). -
Page 115: Black Balance Adjustment
Correct adjustment of the black balance is important for optimum operation of a camcorder. It is necessary when using the camcorder for the first time or after a significant period out of use, and also when there has been a sudden change in temperature. -
Page 116: Shutter Settings
Shutter speeds There are five shutter speeds, from 500WSL) or s (DSR-500WSPL) to Increasing the shutter speed reduces blurring when shooting a fast-moving subject. It is also possible to reduce flicker when shooting under fluorescent lighting by changing the shutter speed. - Page 117 When using the clear scan function Watching the monitor screen, adjust the frequency to give minimum interference. If there is a black band in the monitor image, reduce the frequency, and if there is a white band, increase the frequency. To return from the basic menu to the normal indications Press the MENU switch repeatedly until the normal...
-
Page 118: Viewfinder Screen Adjustments
Using an optional part allows you to modify the adjustment range to –2 to +1 diopters or –0.5 to +3 diopters. For details, consult your Sony dealer. 1) Diopter: A unit to indicate the degree of convergence or divergence of a bundle of rays. -
Page 119: Adjusting The Lens
Adjusting the Lens Flange Focal Length Adjustment It is necessary to adjust the flange focal length (the distance from the lens flange to the plane of the image along the optical axis) in the following cases. 4,11 Set the IRIS selector to the M position. Turn the iris ring to F/1.8 (fully open). -
Page 120: Iris Adjustments
Adjusting the Lens Iris Adjustments Iris ring There are three ways of adjusting the iris: automatically, manually, and with the instant automatic iris adjustment function. Iris adjustment Adjustment method Automatic adjustment mode The iris is adjusted automatically to adapt to changes in the brightness of the subject. -
Page 121: Adjusting The Iris Sensitivity
• When using the lens with the extender, set it to 2. • When using the lens with the ratio converter, set it to 2. You can also set it more precisely at Sony dealer, according to your lens. In this case, set it to 4. -
Page 122: Settings For Special Cases
Settings for Special Cases Shooting conditions The background is very bright, and the subject is too dark. The subject is under a spotlight. The subject is completely still (e.g. when shooting documents, drawings, etc.). When you wish to give a lush effect, as when shooting a wedding or similar occasion. -
Page 123: Skin Detail Correction
Skin Detail Correction The DSR-500WSL/500WSPL provides an easy push- button function that designates an active skin tone area. Note The SKIN DTL SET button is disabled while a title is displayed in basic menu page 8 or color bars are displayed. -
Page 125: Appendix
In the event of operating problems If you should experience problems with the unit, contact your Sony dealer. Characteristics of CCD Sensors The following effects may appear in the image. They are characteristic of camcorders using CCDs (charge- coupled devices), and do not indicate a malfunction. -
Page 126: Cleaning The Video Heads
Keep a check of the hours of head drum operation: with normal use, the heads should need replacing after about 1,500 hours of use. When the heads need replacement, contact your Sony dealer. Check the hours of head drum operation using the VCR menu. -
Page 127: Warning System
Warning System When the camcorder is powered on, or if a fault occurs during operation, a warning is given in the following ways: • By warning indications in the display window. • By means of the WARNING indicator together with a warning tone from the speaker or earphone. -
Page 128: Condensation
Warning System Condensation If you move a camcorder suddenly from a very cold place to a warm place, or use it in a very humid location, condensation may form on the head drum. If it is operated in this state, the tape may adhere to the drum, and cause a failure or even permanent damage. -
Page 129: Troubleshooting
The indication “Er91-13F” appears in the display window. The cassette is automatically ejected. sending the unit for repair. If a problem persists, contact your Sony dealer. Troubleshooting chart Cause There is no battery pack loaded. The battery pack has reached the end of its usable life. -
Page 130: Troubleshooting
Troubleshooting Symptoms The time code setting is not possible. The time code value does not advance though the TC mode switch 1 or 2 is set to the F-RUN or DATE/TIME. Appendix Troubleshooting chart (continued) Cause At the recording, the ClipLink function is set to on (meaning ClipLink shooting is allowed) in menu 211, CONT is displayed in the display window and the time code... -
Page 131: Specifications
1) For details on measuring horizontal resolution, see page 134. Video S/N ratio (output from the VIDEO OUT connector) 63 dB (typical) (DSR-500WSL) 61 dB (typical) (DSR-500WSPL) Registration 0.05% for all zones, without lens Input connectors AUDIO IN CH-1/CH-2:XLR-3 pin 2, female –60 dBu, 3 k... - Page 132 Video system (at playback with the DSR-85/ 85P) Bandwidth Luminance (Y) DSR-500WSL: 30 Hz to 5.0 MHz ±1.0 dB DSR-500WSPL: 25 Hz to 5.5 MHz +1.0/–2.0 dB Chrominance DSR-500WSL: 30 Hz to (R–Y/B–Y) 1.5 MHz +1.0/–5.0 dB DSR-500WSPL: 25 Hz to 2.0 MHz +1.0/–2.0 dB...
-
Page 133: Related Products
Binding tie (4) Operating Instructions (1) Design and specifications are subject to change without notice. Related Products There is a range of Sony products available to meet every conceivable video shooting requirement. For details, consult your Sony sales representative or supplier. Lenses... -
Page 134: Measuring Horizontal Resolution
Specifications Measuring Horizontal Resolution Horizontal resolution in 16:9 mode When the horizontal image frame of this camera is aligned with the width of the 4:3 resolution chart, the resolution is about 935 TV lines (see Figure A). However, to measure the resolution of a video camera precisely, the vertical image frame must be aligned with the height of the chart. -
Page 135: Chart Of Optional Components And Accessories
550/550CE AC Adaptor CA-WR855 Camera Adaptor a) Optional accessory shoe kit is required for fitting. For details, consult your Sony dealer. b) Use when power consumption of the DSR-500WSL/500WSPL and accessories is 38 W or lower. c) When power consumption is 38 W or higher due to fiting a video light (with power consumption of 30 W or lower) to the DSR-500WSL/500WSPL, use the AC-DN2A (150 W or lower). -
Page 136: What Is Cliplink
40 minutes). Note When using a tape recorded by the DSR-500WSL/ 500WSPL to transfer digital (video/audio/time code) signals at four times normal speed from the DSR-85/ 85P Digital Videocassette Recorder to the ES-7 EditStation for editing purposes, there must be about at least 40 seconds of recording on the tape before the IN point. -
Page 137: Cliplink Operation Flow
ClipLink function. ClipLink operation is possible even with a system containing existing analog equipment. However, note that a part of functions are disabled. Shooting DSR-500WSL/ 500WSPL Digital Camcorder ClipLink log data transfer DSR-60 /80/85 DSR-60P /80P/85P... -
Page 138: Data Generated When Shooting
This is the time code that indicates the cue points (valid up to the frame digit). This time code is recorded when the camcorder has been set to CUE mode. When in this mode, the time codes at the start and end of a recording (the Rec IN and Rec OUT time codes) are automatically recorded as Mark IN/OUT points. - Page 139 OK/NG status To designate a scene as “NG”, press the NG button on the camcorder while shooting the scene or at any time before you begin shooting the next scene. All scenes that do not receive an “NG” designation are recorded as “OK”...
- Page 140 ClipLink Operation Flow Time codes recorded for Mark IN/OUT points There is a gap between actual time codes and Mark IN/ OUT time codes recorded in the cassette memory, as shown in the figure below. The frame digit is incremented at each Mark IN point and is decremented at each Mark OUT point.
-
Page 141: Glossary
Return video This refers to a video signal returned from the VCR to the camcorder or from the CCU to one camcorder in a multi-camera system, allowing the camcorder operator to monitor the image output from the camcorder or shot on other camcorders. - Page 142 Striped patterns which appear in the viewfinder to indicate areas of the image where the video level is about 70 IRE (NTSC) or 70% (PAL). The DSR-500WSL/ 500WSPL can show areas where the video level is 100 IRE (NTSC) or 100% (PAL).
