- Page 1 TRACEABLE® RADIO-SIGNAL REMOTE THERMOMETER INSTRUCTIONS...
-
Page 2: Specifications
SPECIFICATIONS Display— Main unit: two-line 1" LCD " LCD Remote unit: Temperature— Main unit IN range: –9.9 to 158.0°F (–9.9 to 70.0°C) Main unit OUT range: –58.0 to 158.0°F (–50.0 to 70.0°C) Main unit resolution: 0.1° Main unit accuracy: ±1.0°C Main unit ambient operating range: 23.0 to 122.0°F (–5.0 to 50.0°C) Remote unit OUT (probe): –50.0 to 70.0°C only Remote unit resolution: 0.1°... - Page 3 FEATURES • The unit is an easy-to-use, state-of-the-art thermometer. The basic pack- age comes with a main unit, which is the temperature receiver, and a remote unit with an internal sensor and external sensor. • The main unit has extra-large readouts for indoor temperatures and temperatures transmitted by the remote unit.
- Page 4 Figure 1 Main unit configuration...
-
Page 5: Quick Reference
QUICK REFERENCE Main Unit (see fig. 1) A. EXTRA-LARGE LCD Facilitates easy reading of remote and indoor temperatures. B. CHANNEL button Selects among different channels. C. MEM button Recalls the maximum or minimum temperature of individual channels. D. CLEAR button Clears the maximum and minimum temperatures of individual channels. - Page 6 Remote Unit (see fig. 2) A. LCD Displays the current temperature monitored by the remote unit. B. LED indicator Flashes when the remote unit transmits a reading. Figure 2 Remote unit configuration...
-
Page 7: Before Beginning
D. CHANNEL switch Designates the remote unit Channel 1, Channel 2 or Channel 3. E. RESET button Returns all settings to default values. F. Battery compartment Accommodates two AAA batteries. G. Battery door H. Removable stand For standing the remote unit on a flat surface. BEFORE BEGINNING 1. - Page 8 4. Insert the batteries strictly according to the polarities shown. 5. Replace the battery compartment door and secure its screws. Replace the batteries when the low-battery indicator of the particular channel lights up on the main unit. (Repeat the steps described in section, “Before Beginning”.) Note: Once a channel is assigned to a remote unit, it can only be changed by removing the batteries or resetting the unit.
-
Page 9: Getting Started
Replace the batteries when the low-battery indicator of the indoor tempera- ture lights up. (Repeat the steps described in section, “Before Beginning”.) TWO SENSORS Each remote module has two sensors. The internal (ambient) sensor is located inside the case toward the bottom of the remote module. It is ideal for monitoring air temperatures. - Page 10 If no signals are received, blanks “- - -” will be displayed and the kinetic wave icon will show “ ”. Press CHANNEL and MEM simultaneously to force another search for 30 seconds. This is useful in synchronizing the transmission and reception of the remote and main unit. Repeat this step whenever you find discrepancies between the reading shown on the main unit and that on the respective remote unit.
-
Page 11: Maximum And Minimum Temperatures
HOW TO READ THE KINETIC WAVE DISPLAY The kinetic wave display shows the signal receiving status of the main unit. There are three possible forms. The unit is in searching mode. Temperature readings are registered. No signals. MAXIMUM AND MINIMUM TEMPERATURES The maximum and minimum recorded indoor temperatures and those of each channel will automatically be stored in memory. -
Page 12: Disconnected Signals
3. Use the ADVANCE () button to set the upper or lower temperature. If this is the first time setting limits, the lower limit will start from -58 °F (-50°C) and the upper limit 158°F (+70°C). Otherwise, the reading will start from the temperature last selected. -
Page 13: Transmission Collision
The remote unit comes with a wall-mount holder and a removable stand. Use either to hold the unit in place. TRANSMISSION COLLISION Signals from other radio devices may interfere with those of this product and cause temporary reception failure. This is normal and does not affect the general performance of the product. -
Page 14: The Reset Button
THE RESET BUTTON This button is only used then the unit is operating in an unfavorable way or malfunctioning. Use a blunt stylus or straightened paper clip to hold down the button. All settings will return to default values. PRECAUTIONS This product is engineered to provide years of satisfactory service if handled carefully. -
Page 15: Operational Difficulties
5. Only use fresh batteries as specified. Do not mix new and old batteries. 6. Read the user’s manual thoroughly before operating the unit. OPERATIONAL DIFFICULTIES If this temperature meter does not function properly for any reason, please replace the batteries with new, high-quality batteries (see “Battery Installa- tion”... - Page 16 main receiver. Observe on the receiver LCD a momentary reset to “888” on the display, release the RESET button. First make certain that the unit will pick up a nearby signal. Do this by placing the remote transmitter in a vertical position. Place the main receiver (large digital display) in a vertical position approximately 6 feet away from the remote transmitter.
- Page 17 2. Place the remote transmitter in a vertical or stand-up position. 3. Place the main receiver in a vertical or stand-up position. 4. Place the remote transmitter and the main receiver in locations where the radio signal does not need to be sent through metal panels, thick walls, multilevels, etc.
- Page 18 Control Company is ISO 9001 Quality-Certified by NV and ISO 17025 accredited as a Calibration Laboratory by A2LA Cat. No. 4115 Traceable® Radio-Signal Remote Thermometer Instructions 92-4115-00 Rev. 3 083116 Traceable® is a registered trademark of Control Company © 2016 CONTROL COMPANY...
