Samsung CZ29M64NSPXXEH Service Manual

Chassis : s56a(p) rev.1
Hide thumbs

Advertisement

Quick Links

Download this manual
COLOR TELEVISION RECEIVER
COLOR TELEVISION RECEIVER
Chassis :
S56A(P) REV.1
Model:
CZ29M64NSPXXEH
CZ28D83NSPXXEH
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
CONTENTS
Precautions
Troubleshooting
Exploded Views and Parts List

Advertisement

loading

Related Manuals for Samsung CZ29M64NSPXXEH

Summary of Contents for Samsung CZ29M64NSPXXEH

  • Page 1: Table Of Contents

    COLOR TELEVISION RECEIVER Chassis : S56A(P) REV.1 Model: CZ29M64NSPXXEH CZ28D83NSPXXEH COLOR TELEVISION RECEIVER CONTENTS Precautions Reference Information Specifications Alignment and Adjustments Troubleshooting Exploded Views and Parts List Electrical Parts List Block Diagrams Wiring Diagram Schematic Diagrams...

  • Page 2: Reference Information

    Millimeter Hour Millisecond Inches Per Second Millivolt Kilowatt-hour Nanofarad Ω Kilogram Kilohertz Picofarad kΩ Kilohm Pound Kilometer Revolutions Per Minute km/h Kilometer Per Hour Revolutions Per Second Kilovolt Second (Time) Kilovolt-ampere Volt Kilowatt Volt-ampere Liter Watt Megahertz Watt-hour Samsung Electronics...
  • Page 3 Fail Safe Voltage Controlled Oscillator Ground VCXO Voltage Controlled Crystal Oscillator Green-Y Very High Frequency High Video Intermediate Frequency High-Frequency Variable Resistor HI-FI High Fidelity Video Tape Recorder Inductance-Capacitance VTVM Vacuum Tube Voltmeter Integrated Circuit Transistor Intermediate Frequency Samsung Electronics...
  • Page 4 250V, 5A, DPST, -, JPW-2104B SWITCH-PUSH T401 OPTION 80mH, 520uH, E119 TRANS-HORIZ,DRIVE T444S FUH-29A001B(S), 25/29”, 130 OPTION TRANS FBT T801S CS21S5T, 80~280V. PM5, PL5, EER4245, 470UH, 125/16/9 OPTION TRANS SWITCHING TU01S TEDE9-203A, PAL, 181CH, 38.9MHz, 750ohm, DIN, ASYMM, 5V OPTION TUNER Samsung Electronics...
  • Page 5 15W x 2CH, 10W x 2CH, 5W x 2CH TDA7297 Table 2-3-4 TUNER REMARK FUNCTION SPEC Without LNA TECC0949PG35A SAMSUNG Without LNA TEDE9-203A TAEL-G671D With LNA ALPS Table 2-3-5 VIDEO OUTPUT AMP REMARK SPEC FUNCTION 25” Normal 29” Normal TDA6107Q 21” Flat 25” Flat TDA6108JF Samsung Electronics...

  • Page 6: Specifications

    IF Carrier PAL, SECM -B/G PAL, SECAM-D/K,K1 PAL-I NTSC-M Frequency Intermediate 38.90[MHz] 38.90[MHz] 38.90[MHz] 45.75[MHz] Picture Frequency 33.40[MHz] 32.40[MHz] 32.90[MHz] 41.25[MHz] Sound 34.47[MHz] 34.47[MHz] 34.47[MHz] 42.18[MHz] Chroma AC100~240V, 50/60Hz Power Antenna VHF, UHF : Telescopic dipole antenna)(75ohm unbalanced type) Samsung Electronics...

  • Page 7: Alignment And Adjustments

    2. Turn on the TV. Set the Brightness and Contrast controls to minimum (zero beam current). 3. Adjust the Brightness and contrast controls to both extremes. Ensure that the high voltage does not exceed 30 KV under any conditions. Samsung Electronics...
  • Page 8 PICTURE ON DISPLAY ( FACTORY 4-5-2 Factoy Mode OSD 4-5-2(A) ADJUST ETRP ADJUST OPTION 52 2A 48 G2-ADJUST RESET DPSR SPM-836EAN 2002/02/08 SCBT DNSR DSBT PSNS DCDL HPAR DBLR MVOL HBOW DBLB FMWS EWID AGCS1 EPAR EUCN ELCN Samsung Electronics...
  • Page 9 FM demodulator gain 0 ~ 3 19h(D7-D6) Peaking center frequency 0 ~ 1 20h(D1) Automatic color limiting 0 ~ 1 21h(D0) Forced color limiting SCBT 0 ~ 63 Screen brightness(different from INCH) 0 ~ 23 19h(D5-D0) Sub Sharpness gain adjustment Samsung Electronics...
  • Page 10 DVD Sub brightness(low light adjustment) DCDL 0 ~ 15 2Ah(D3-D5) DVD Cathode drive level DBLR 0 ~ 63 14h(D5-D0) DVD Black level offset R(low light R adjustment) DBLB 0 ~ 63 15h(D15-D0) DVD Black level offset B(low light B adjustment) Samsung Electronics...
  • Page 11 Entering G2-Adjust Mode Screen Adjust : Displyed As “NG”. ¡ Turn SCREEN VR OF FBT, Adjust Value Become To Be “OK”. ADJUST OPTION 52 2A 48 Screen Adjust : N.G G2-ADJUST RESET SPM-836EAN 2002/02/08 Screen Adjust : O.K Screen Adjust : N.G Samsung Electronics...
  • Page 12 Alignment and Adjustments 4-5-2(D) SCREEN CHANGE (I2C BUS GEOMETRIC ADJUSTMENT) V Shift V Amp V Slope V SC H EW H Trapizium H Symmetry H Parabola H Corner H Shift Samsung Electronics...
  • Page 13 SIFIN1/DVBIN1 SIF input 2 / DVB input 2 SIFIN2/DVBIN2 ground 2 for TV processor GND2 narrow band PLL filter SIFAGC/DVBAGCR Automatic Volume Leveling/subcarr reference output/sound IF input/external reference signal input for I signal mixer for DVB REFO/AMOUT/REFIN operation Samsung Electronics...
  • Page 14 XTLIN crystal oscillator output XTLOUT reset RESET digital supply to peryipher(+3.3 V) VDDP P1.0/INT1 port 1.0 or external interrupt 1 input P1.1/T0 port 1.1 or Counter/Timer 0 input port 1.2 or external interrupt 0 input P1.2/INTO Samsung Electronics...

  • Page 15: Electrical Parts List

    HA68-02179A LABEL-RATING;58MM,53MM,WHITE AA65-30113A CLAMPER CORE-D,COIL;-,NYLON 66,V2,-,BLK, ASSY CHASSIS 2 CF+SPK 6003-001024 SCREW-TAPTITE;RWH,+,B,M4,L12,ZPC(YEL),SW AA91-06540A ASSY CHASSIS;CZ29M64NSPXXEH,S56A,ELDOR ASSY COVER REAR AA94-13136A ASSY PCB MAIN;CZ29M64NSPXXEH,S56A,ELDOR 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb AA90-04722A ASSY COVER REAR;29M6,S56A 0202-000008 SOLDER-WIRE;S63S-W3.0,S63S,D3,63Sn/37Pb, 0204-000442 SOLVENT;1M-1000,C3H70H,96,- HA64-02344B CABINET BACK;29M6(SEH),VL-1823,SV012P-II 0204-001024 FLUX;DF-98TVS,-,20%,- AA81-00096A RESIN-A;VL-1823,G5433,A 3 D801S 0402-001399 DIODE-BRIDGE;GSIB660,600V,6A,SIP-4,BK...
  • Page 16 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW 4 IC852 1203-001217 IC-POSI.ADJUST REG.;431,TO-92,3P,4.58MIL AA62-30182E HEAT SINK-ES;-,A6063 EXTR,-,WHT,-,-,-,40 4 VP801S 1405-000187 VARISTOR;750V,1250A,12.5x7mm,TP HA68-02189A LABEL-WARNING;,33MM,18MM,WHITE 4 VX801S 1405-000187 VARISTOR;750V,1250A,12.5x7mm,TP AA97-14123A ASSY AUTO;CZ29M64NSPXXEH,S56A,ELDOR 4 R241 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm 4 D804 0401-000006 DIODE-SWITCHING;BAV21,250V,250mA,DO-35,T 4 R206 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3.2MM 4 D504 0402-000010 DIODE-RECTIFIER;RGP15G,400V,1.5A,DO-204A 4 R243 2001-000011 R-CARBON;75KOHM,5%,1/8W,AA,TP,1.8X3.2MM...
  • Page 17 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP,1.8X3.2MM 4 R203 2004-001914 R-METAL;39Kohm,2%,1/8W,AA,TP,1.8x3.5mm 4 R826 2001-000660 R-CARBON;33KOHM,5%,1/8W,AA,TP,1.8X3.2MM 4 R828 2004-001983 R-METAL(S);2.49Kohm,1%,1/2W,AA,TP,2.4x6. 4 R223 2001-000702 R-CARBON;39KOHM,5%,1/8W,AA,TP,1.8X3.2MM 4 RE02 2004-004029 R-METAL(S);10Kohm,1%,1/2W,AA,TP,2.5x6.5m 4 R228 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 4 RE10 2004-004029 R-METAL(S);10Kohm,1%,1/2W,AA,TP,2.5x6.5m 4 R908 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M 4 R825 2004-001889 R-METAL(S);127Kohm,1%,1/2W,AA,TP,2.5x6.5 Samsung Electronics...
  • Page 18 2301-001259 C-FILM,MPPF;100nF,5%,400V,TP,19x8x16,7.5 4 C604 2401-002075 C-AL;4.7uF,20%,50V,GP,TP,5x11,5 4 C808 2301-001435 C-FILM,PPF;1.5nF,5%,1.2kV,TP,15x8x12.5mm 4 C419 2401-002268 C-AL;2.2uF,20%,250V,LZ,TP,8X11,5 4 C303 2305-000149 C-FILM,MPEF;100nF,5%,100V,TP,12x12.5x6.5 4 C233 2401-002300 C-AL;47uF,20%,50V,GP,TP,6.3x11,5 4 C301 2305-000285 C-FILM,MPEF;220NF,5%,100V,TP,10.5X5.5X15 4 C840 2401-002594 C-AL;220uF,20%,16V,GP,TP,8x11.5,5 4 C217 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm 4 CE01 2401-002597 C-AL;220uF,20%,35V,GP,TP,10x12.5,5 Samsung Electronics...
  • Page 19 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J172 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J609 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J173 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J612 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J178 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 J615 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) Samsung Electronics...
  • Page 20 6042-000001 EYELET;ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 4 EY830 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 4 EL806 6042-000001 EYELET;ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 4 EY831 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 4 EL807 6042-000001 EYELET;ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 4 EY832 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 4 EL403 6042-000001 EYELET;ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 4 EY833 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 4 EL803 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 4 EY835 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H Samsung Electronics...
  • Page 21 AA60-40012D PIN-GT,ASSY;T1.6,6-12.5-,NYLON66 AA96-01127B ASSY POWER CORD;DP,AA39-10001M,CP2,H/C40 AA65-30009A CLAMPER CORE-FBT;-,ABS,V0,-,BLK,- AA39-10001M CBF POWER CORD;-,KJP-140,KLCE-2F,2.4m,HO AA65-30018A CLAMPER CORE-WIRE;DONG-A,NYLON-66,-,-,-, AA61-20284A HOLDER;P-CORD,PP,-,-,-,BLK,VO,KE-002 AA65-30111A CLAMPER CORE-WIRE;ALL MODEL,NYLON,V0,-,W AA94-12870A ASSY PCB MISC-CONTROL;CW21M63NSPXXEC,S56 3 Q804 0502-000242 TR-POWER;KSA614,PNP,25W,TO-220,TP,40-24 0202-000008 SOLDER-WIRE;S63S-W3.0,S63S,D3,63Sn/37Pb, 3 Q403 0502-001007 TR-POWER;KSC2073-H2,NPN,25W,TO-220,ST,6 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb Samsung Electronics...
  • Page 22 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 4 EY03 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 4 EY02 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 4 EY01 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 4 PCB AA41-00730A PCB-CONTROL;29M6/25M6,CEM-1,1L,A,1.6T,24 4 SW201C 3404-000282 SWITCH-TACT;12Vdc,50mA,120gf,6x6x5mm,SPS 4 SW202C 3404-000282 SWITCH-TACT;12Vdc,50mA,120gf,6x6x5mm,SPS 4 SW203C 3404-000282 SWITCH-TACT;12Vdc,50mA,120gf,6x6x5mm,SPS 4 SW204C 3404-000282 SWITCH-TACT;12Vdc,50mA,120gf,6x6x5mm,SPS 4 SW205C 3404-000282 SWITCH-TACT;12Vdc,50mA,120gf,6x6x5mm,SPS Samsung Electronics...
  • Page 23 Electrical Parts List You can search for the updated part code through ITSELF web site. URL : http://itself.sec.samsung.co.kr 7-2 CZ28D83NSPXXEH Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark ASSY CHASSIS AA62-30175D HEAT SINK-PS;-,SECC,T1.0,-,33X15X30 FT-2...
  • Page 24 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 4 R737 2001-000793 R-CARBON;47OHM,5%,1/8W,AA,TP,1.8X3.2MM 4 R641 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 4 R738 2001-000793 R-CARBON;47OHM,5%,1/8W,AA,TP,1.8X3.2MM 4 R645 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 4 R211 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP,1.8X3.2MM 4 R646 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 4 R715 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP,1.8X3.2MM 4 R703 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM 4 R205 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM 7-10 Samsung Electronics...
  • Page 25 2201-000138 C-CERAMIC,DISC;0.1NF,10%,50V,Y5P,TP,4X4M 4 C236 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m 4 C630 2201-000304 C-CERAMIC,DISC;0.001NF,0.25PF,50V,C0G,TP 4 C237 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m 4 C631 2201-000304 C-CERAMIC,DISC;0.001NF,0.25PF,50V,C0G,TP 4 C637 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m 4 C804 2201-000332 C-CERAMIC,DISC;2.2NF,20%,250V,Y5U,TP,9X4 4 C807 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m 4 C805 2201-000332 C-CERAMIC,DISC;2.2NF,20%,250V,Y5U,TP,9X4 4 C835 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m Samsung Electronics 7-11...
  • Page 26 2701-000142 INDUCTOR-AXIAL;1uH,10%,2.5x3.4mm 4 J202 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 L405 2701-000142 INDUCTOR-AXIAL;1uH,10%,2.5x3.4mm 4 J203 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 L201 2701-000158 INDUCTOR-AXIAL;22uH,10%,2.5x3.4mm 4 J204 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 L205 2701-000158 INDUCTOR-AXIAL;22uH,10%,2.5x3.4mm 4 J205 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 7-12 Samsung Electronics...
  • Page 27 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 EY409 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 4 J710 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 EY410 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 4 J800 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 EY411 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 4 J805 3812-000219 WIRE-NO SHEATH CU;TCWA,300V,52mm(TAPING) 4 EY412 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H Samsung Electronics 7-13...
  • Page 28 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 3 CNP02 AA39-00236A LEAD CONNECTOR-ASSY;,3(2)P,300MM,YHL500- 4 EY851 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 3 PFT01 AA27-00116A COIL CHOKE;CODE_NO,-,35mH,-0, +5%,-,2.8O 4 EY852 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H HA61-00995A HOLDER-PFC;ALLMODELL,HIPS 4 EY853 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H HA83-00006A LP-RESIN HIPS;,BASF495F,NTR,HB 4 EY854 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H HA83-00011A LP-RESIN;,M BATCH,WILSON 6007-GY-60,GRY 7-14 Samsung Electronics...
  • Page 29 HA83-00049A LP-ADHESIVE-HM;12MM,NTR AA64-03547A CABINET FRONT;28D8,HIPS,HB,SV012P,S56A HA83-00021A LP-MARKING PAINT;,WHITE,TPC180 HA83-00040A LP-MARKING PAINT;,METALLIC SILVER,SV-012 HA83-00006A LP-RESIN HIPS;,BASF495F,NTR,HB HA83-00011A LP-RESIN;,M BATCH,WILSON 6007-GY-60,GRY AA64-02316A KNOB-POWER;28D8(SEH),HIPS,HB,GRY HA83-00040A LP-MARKING PAINT;,METALLIC SILVER,SV-012 HA83-00006A LP-RESIN HIPS;,BASF495F,NTR,HB HA83-00011A LP-RESIN;,M BATCH,WILSON 6007-GY-60,GRY HA61-00711C HOLDER-PCB;29K8,HIPS,HB,GRY HA83-00006A LP-RESIN HIPS;,BASF495F,NTR,HB Samsung Electronics 7-15...

  • Page 30: Block Diagrams

    Block Diagrams 8. Block Diagrams Samsung Electronics...

  • Page 31: Wiring Diagram

    Wiring Diagram 9. Wiring Diagram TACT S/W RGB AMP CRT PCB POWER SOUND AMP MULTI TRANS NJM2235 TUNER 2 SCART OR RCA 9P Samsung Electronics...

  • Page 32: Schematic Diagrams

    Schematic Diagrams 10. Schematic Diagrams 10-1 MAIN 1 TP07 TP01 TP08 TP02 TP10 TP09 TP09 TP03 TP03 TP06 TP10 TP04 TP08 TP05 TP07 TP05 TP01 TP04 TP02 TP06 Samsung Electronics 10-1...
  • Page 33 Schematic Diagrams 10-2 MAIN 2 TP18 TP11 TP19 TP12 TP23 TP17 TP13 TP20 TP16 TP19 TP14 TP15 TP20 TP18 TP22 TP21 TP13 TP21 TP14 TP11 TP12 TP15 TP22 TP24 TP23 TP16 TP24 TP17 10-2 Samsung Electronics...
  • Page 34 Schematic Diagrams 10-3 MAIN 3 TP25 TP26 TP26 TP25 Samsung Electronics 10-3...
  • Page 35 Schematic Diagrams 10-4 MAIN 4 TP25 TP26 TP26 TP25 10-4 Samsung Electronics...
  • Page 36 Schematic Diagrams 10-5 MAIN 5 Samsung Electronics 10-5...
  • Page 37 Schematic Diagrams 10-6 MAIN 1(AA41-00785C/29”FLAT) 10-6 Samsung Electronics...
  • Page 38 Schematic Diagrams 10-7 MAIN 2(AA41-00785C/29”FLAT) Samsung Electronics 10-7...
  • Page 39 Schematic Diagrams 10-8 MAIN 3(AA41-00785C/29”FLAT) 10-8 Samsung Electronics...
  • Page 40 Schematic Diagrams 10-9 MAIN 4(AA41-00785C/29”FLAT) Samsung Electronics 10-9...
  • Page 41 Schematic Diagrams 10-10 MAIN 5(AA41-00785C/29”FLAT) 10-10 Samsung Electronics...
  • Page 42 Schematic Diagrams 10-11 MAIN 6(AA41-00785C/29”FLAT) Samsung Electronics 10-11...
  • Page 43 Schematic Diagrams 10-12 HORIZANTAL BLOCK, VIF BLOCK Horizantal Block VIF Block 10-12 Samsung Electronics...
  • Page 44 Schematic Diagrams 10-12 AUDIO SWITCHING, SYSTEM SWITCHING, SIF BLOCK Audio Switching SIF Block System Switching Samsung Electronics 10-13...
