Summary of Contents for Axis 25735
- Page 1 Product Instructions 25733 & 25735 C O M M U N I C A T I O N S 81-IN6210 Before attempting to connect or operate this product, 03/28/07 please read these instructions completely.
- Page 2 IMPORTANT SAFEGUARDS SAFETY PRECAUTIONS 1. Read Instructions - All the safety and operating instructions should be read before the unit is operated. CAUTION 2. Retain Instructions - The safety and operating instructions RISK OF should be retained for future reference. ELECTRIC SHOCK! 3.
-
Page 3: General Instructions
ELECTRICAL SPECIFICATIONS (OUTDOOR ONLY): 3, Open the dome assembly box. Note there is a protection film on the dome. DO NOT REMOVE the film until the product is fully assembled and installed. This film protects Power 24VAC, Class 2 Only the dome from scratches during installation. - Page 4 Installing Axis 213 Camera 2. In the kit there are (8) aluminum spacers - (4) 1" and (4) ½". Thread (2) spacers - (1) 1" and (1) ½" - on top of each of the (4) 1. Install the camera onto the quick release bracket using (2) 2"...
- Page 5 Installing Axis 213 Camera (cont.) CAMERA POWER Connect the power plug and the ethernet cable to the back of the camera. For Model 189 only If alarm connections are needed use the chart below for reference. CONTROL RJ45 Ethernet Connector...
- Page 6 1. Install the AXIS 214 camera to the 2685 mounting plate using the (3) 3mm x 12mm bolt and lock washers provided. 2. The AXIS 214 camera requires 2” of spacing for optimal position within the housing. Use the 8 (1”) spacers provided in the packet.
- Page 7 Installing Axis 231D/232D Camera 4. When the locking buttons hit the end of the keyhole slots. 1. Install the camera onto the quick release bracket. Loosen one of Tighten the locking screw. Then put the camera assembly aside. the screws on the bottom of the camera, see diagram below.
- Page 8 Installing Axis 231D/232D Camera (cont.) 7. Then start (3) 8-32x3/8” plillips head screws onto the 3 inch spacers inside the housing. Be sure to place the screws so that they line up with the (3) open slots on the quick release bracket, the screws on the bottom of the camera, see diagram below.
- Page 9 Installing Axis 231D/232D Camera 13. To manage the input cable running from the connector block to the camera use the (2) cable tie mounts and cable ties that are (cont.) located in the housing packet. Cable Tie Mounts 12. Make wiring connections to connector block assembly per camera instructions.
- Page 10 Installing Axis 231D/232D Camera (cont.) 14. Now grab the camera assembly and connector the RJ45 cable and the input cable to the camera. 15. Now attached the camera assembly to the housing by sliding the (3) open screw slots over the screws in the housing. Slide the bracket forward, and the tighten the captive screw on the bracket.
- Page 11 Installing Axis 233 Camera Keyhole Slots 1. Note the position of the mounting holes on the camera bracket (see diagram below). Mounting holes 4. Place the Quick Release plate onto the bottom of the camera, Make sure that the locking screws...
- Page 12 Two plug-in wall transformers are included with the housing. Use one to provide power for the heater and blower in the housing, For Model 25735 and the other for the camera. Determine where the transform- See camera instructions for wiring connections ers will be located, then run two sets of power wires into the wall mount bracket (Four total power wires).
-
Page 13: Installing The Housing Assembly
INSTALLING THE HOUSING ASSEMBLY: REMOVING AND ATTACHING THE DOME ASSEMBLY: Be sure the bracket is properly and securely 1. Attach the dome assembly to the housing top by lining up mounted to a supporting structure capable of rigidly the arrow on the dome assembly with the left arrow on the holding the weight of the entire unit. - Page 14 Exploded View for Replacement Parts - 1 -...
- Page 15 Replacement Parts List Part Number Description RPFD7501 LOWER TRIM RING (Long) 25740 TINTED REPLACEMENT CAPSULE 25741 CLEAR REPLACEMENT CAPSULE RPFD703 DOME CLAMPING BRACKET RPFD072 24 VAC HEATER RPFD080 BLOWER RPFD060 CAMERA BRACKET RPRH707 CONNECTION PCB RPFD040 HOUSING HARDWARE RPFD709 HOUSING TOP SD0160 PENDANT COUPLING KIT SD0170...
