MODEL
SAFETY PRECAUTIONS ........................................ 2
SPECIFICATIONS ................................................... 2
DISASSEMBLY .................................................... 3~5
SERVICE MODE SPECIFICATIONS .................. 6~8
SEMICONDUCTORS ........................................ 9~13
NOTE FOR PARTS LIST ....................................... 18
PARTS LIST OF P.W.B. UNIT ......................... 19~28
EXPLODED VIEW ................................................. 29
PARTS LIST OF EXPLODED VIEW ...................... 30
PACKING VIEW ..................................................... 31
BLOCK DIAGRAM ................................................. 32
LEVEL DIAGRAM .................................................. 33
Some illustrations using in this service manual are slightly different from the actual set.
14-14, AKASAKA 4-CHOME, MINATO-KU, TOKYO 107-8011 JAPAN
SERVICE MANUAL
DN-X400
DJ MIXER

- TABLE OF CONTENTS -

WIRING DIAGRAM ................................................ 34
SCHEMATIC DIAGRAMS ................................ 35~38
Telephone: 03 (3584) 8111
For U.S.A., Canada, Europe,
Oceania & Asia model
(1/4) GU-3402-1 MAIN UNIT (1/2) ............................ 35
(2/4) GU-3402-1 MAIN UNIT (2/2) ............................ 36
GU-3402-2 POWER UNIT ................................ 36
GU-3402-3 PANEL 2 UNIT ............................... 36
GU-3402-4 LINE SELECTOR UNIT ................. 36
GU-3402-5 CROSS FADOR UNIT ................... 36
GU-3402-6 ZONE/EFFECT UNIT .................... 36
(3/4) GU-3403-1 PANEL 1 UNIT ............................... 37
GU-3403-3 DISPLAY UNIT .............................. 37
GU-3403-5 REGULATOR UNIT ....................... 37
(4/4) GU-3403-2 ANALOG I/O UNIT ......................... 38
GU-3403-4 H/P JACK UNIT ............................. 38
Hi-Fi Component
X0126 1134 NC 0109
