Grizzly T28366 Owner's Manual

10'' slow speed cold cut saw
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MODEL T28366
10" SLOW SPEED
COLD CUT SAW
OWNER'S MANUAL
(For models manufactured since 04/18)
Shown with optional stand:
Model T28367
COPYRIGHT © MAY, 2018 BY GRIZZLY INDUSTRIAL, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
V1.05.18
#ESAB19337 PRINTED IN CHINA

Advertisement

Table of Contents
loading

Related Manuals for Grizzly T28366

Summary of Contents for Grizzly T28366

  • Page 1 Shown with optional stand: Model T28367 COPYRIGHT © MAY, 2018 BY GRIZZLY INDUSTRIAL, INC. WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC. V1.05.18 #ESAB19337 PRINTED IN CHINA...
  • Page 2 This manual provides critical safety instructions on the proper setup, operation, maintenance, and service of this machine/tool. Save this document, refer to it often, and use it to instruct other operators. Failure to read, understand and follow the instructions in this manual may result in fire or serious personal injury—including amputation, electrocution, or death.

  • Page 3: Table Of Contents

    Table of Contents INTRODUCTION ..........2 SECTION 5: ACCESSORIES ......29 Contact Info............ 2 SECTION 6: MAINTENANCE ......30 Manual Accuracy ........... 2 Schedule ............30 Identification ........... 3 Cleaning & Protecting ........30 Controls & Components ......... 4 Checking Coolant......... 30 Machine Data Sheet ........

  • Page 4: Introduction

    ID label (see below). This information is required for us to provide proper tech support, and it helps us determine if updated documenta- tion is available for your machine. Manufacture Date Serial Number Model T28366 (Mfd. Since 04/18)

  • Page 5: Identification

    Vise Handwheel Depth Stop Miter Blade Lock Guards Lever Miter Angle Gauge Vise Coolant Flow Control Valve Coolant Hose Coolant Reservoir To reduce your risk of serious injury, read this entire manual BEFORE using machine. Model T28366 (Mfd. Since 04/18)

  • Page 6: Controls & Components

    Miter Lock Lever: Releases or locks rotation Twist clockwise to reset. of saw base for angled cuts. D. Master Power Switch: Supplies power to machine for operation. E. Depth Stop: Stops blade at specific depth to produce multiple same-depth cuts. Model T28366 (Mfd. Since 04/18)

  • Page 7: Machine Data Sheet

    Machine Data Sheet Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901 MODEL T28366 10" SLOW SPEED COLD CUT SAW Product Dimensions: Weight ................................... 143 lbs. Width (side-to-side) x Depth (front-to-back) x Height .................18-1/2 x 27 x 38 in.
  • Page 8 Four Individually Adjustable Clamping Jaws on Vise for Safe and Secure Workpiece Control Push-Button Start Control on Handle Recommended Accessories: T28367 Stand for T28366 T28368 160T Cold Saw Blade 250 x 32mm Model T28366 (Mfd. Since 04/18) Page 2 of 2 Model T28366...

  • Page 9: Section 1: Safety

    Everyday ery. Never operate under the influence of drugs or eyeglasses are NOT approved safety glasses. alcohol, when tired, or when distracted. Model T28366 (Mfd. Since 04/18)
  • Page 10 Make sure they are properly installed, you experience difficulties performing the intend- undamaged, and working correctly BEFORE ed operation, stop using the machine! Contact our operating machine. Technical Support at (570) 546-9663. Model T28366 (Mfd. Since 04/18)

  • Page 11: Additional Safety For Metal Cutting Saws

    Accidents are frequently caused by lack of familiarity or failure to pay attention. Use this machine with respect and caution to lessen the possibility of operator injury. If normal safety precautions are overlooked or ignored, serious personal injury may occur. Model T28366 (Mfd. Since 04/18)

  • Page 12: Section 2: Power Supply

    To reduce the risk of these hazards, avoid over- loading the machine during operation and make sure it is connected to a power supply circuit that meets the specified circuit requirements. -10- Model T28366 (Mfd. Since 04/18)
  • Page 13 Minimum Gauge Size ......14 AWG electrician install the proper outlet with a Maximum Length (Shorter is Better)..50 ft. verified ground. -11- Model T28366 (Mfd. Since 04/18)

  • Page 14: Section 3: Setup

    Grizzly or the shipping agent. You MUST have the original pack- Inventory (Figure 5) aging to file a freight claim.

  • Page 15: Cleanup

    Figure 6. T23692 Orange Power Degreaser. Repeat Steps 2–3 as necessary until clean, then coat all unpainted surfaces with a quality metal protectant to prevent rust. -13- Model T28366 (Mfd. Since 04/18)

  • Page 16: Site Considerations

    (see Figure 9). seriously injured if unsuper- vised around this machine. Lock entrances to the shop or unplug power connection prevent unsupervised Rope use. Figure 9. Headstock secured in downward position. -14- Model T28366 (Mfd. Since 04/18)

  • Page 17: Bench Mounting

    Mount machine workbench using following instruction in Bench Mounting or to optional stand following instructions included with Model T28367. Lag Screw Flat Washer Machine Base Workbench Figure 12. "Direct Mount" setup. -15- Model T28366 (Mfd. Since 04/18)

  • Page 18: Assembly

    — If oil level is not halfway up sight glass, refer to Gearbox Oil on Page 32. — If oil level is at least halfway up sight glass, no further action is required. Continue to Step 6. Figure 14. Location of temporary plug. -16- Model T28366 (Mfd. Since 04/18)

  • Page 19: Test Run

    Operating an improperly set up machine may result in malfunction or unexpect- ed results that can lead to serious injury, death, or machine/property damage. Figure 18. T28368 blade for T28366 Cold Cut Saw. -17- Model T28366 (Mfd. Since 04/18)
  • Page 20 Press start button on lever arm. Blade should saw. The Emergency Stop button may not begin spinning. be working properly. The safety feature must work properly before proceeding with regular operations. Refer to Troubleshooting on Page 34 for help. -18- Model T28366 (Mfd. Since 04/18)

  • Page 21: Section 4: Operations

    Read books/magazines or get formal training before beginning any proj- ects. Regardless of the content in this sec- tion, Grizzly Industrial will not be held liable for accidents caused by lack of training. -19- Model T28366 (Mfd. Since 04/18)

  • Page 22: Using Coolant System

    Water The Model T28366 has a built-in coolant solution could cause a system that can extend the life of your blades by magnesium-chip fire. preventing them from overheating. Use only water soluble coolants, such as H9240...

  • Page 23: Selecting Blades

    Selecting Blades Blade Pitch The most important consideration when selecting a blade for the Model T28366 is blade pitch, which is typically measured in "teeth per inch" (TPI). Selecting the right blade for the cut requires an Proper TPI for any cut depends on the cross-sec- understanding of various blade characteristics.
  • Page 24 If you feel your machine is not functioning properly or performing to your standards, check that the blade pitch is correct for the cut. The procedure that follows is a basic starting point for choosing blade pitch (TPI) for standard HSS blades. -22- Model T28366 (Mfd. Since 04/18)

  • Page 25: Breaking In Blades

    H =Height L =Length D =Diameter )² x π A = ( ⁄ Th =Material Thickness π =3.14 D x π x Th 2H + 2L x Th Figure 29. Calculating cut area for break-in. -23- Model T28366 (Mfd. Since 04/18)

  • Page 26: Installing/Changing Blades

    (see Figure 30). This releases tension on retractable blade guards (see Figure 31). Blade Guard Linkage Figure 32. Removing retaining ring. Screws Figure 30. Location of blade guard linkage and cap screws. -24- Model T28366 (Mfd. Since 04/18)
  • Page 27 Figure 34. Blade order of installation. Blade Arbor Attach retaining ring to retractable guard hub. Figure 33. Blade flange and blade removed and blade arbor exposed. 10. Lower blade guard and reconnect blade guard linkage. -25- Model T28366 (Mfd. Since 04/18)

  • Page 28: Evaluating Cutting Performance

    & curled tightly powdery Figure 35. Chip inspection chart. thin & curled tightly powdery thin & curled tightly powdery thin & curled tightly thin & curled tightly thin & curled tightly thin & curled tightly -26- Model T28366 (Mfd. Since 04/18)

  • Page 29: Adjusting Vise

    Blade (1 of 4) Figure 37. Correct blade clearance setting. Tighten cap screw for each jaw. Turn vise handwheel clockwise until jaws clamp workpiece in desired position. Repeat Step 3 to re-check blade clearance. -27- Model T28366 (Mfd. Since 04/18)

  • Page 30: Adjusting Miter Angle

    Ensure blade clearance by lowering saw blade. If necessary, adjust vise jaw to provide adequate clearance, as outlined in Adjusting Vise on Page 27. Return saw to upright position. -28- Model T28366 (Mfd. Since 04/18)

  • Page 31: Section 5: Accessories

    Figure 41. H9240 Rustlick WS5050 Heavy- Duty Soluble Oil. T26685—ISO 32 Moly-D Machine Oil, 1 Gal. Figure 39. T28368 blade for T28366 Cold Cut T27914—ISO 68 Moly-D Machine Oil, 1 Gal. Saw. Moly-D oils are some of the best we've found for maintaining the critical components of machinery T28367—Stand for T28366 Cold Cut Saw...

  • Page 32: Section 6: Maintenance

    Lubricate column hinge-pin (see Page 33). • Follow federal, state, Lubricate saw base pivot (see Page 33). • and fluid manufacturer requirements for proper Every Six Months disposal. Change gearbox oil (see Page 32). • -30- Model T28366 (Mfd. Since 04/18)
  • Page 33 Pour coolant into reservoir until pump is swarf inside reservoir. submerged (approximately ⁄ full). Place pump back into coolant reservoir. Close coolant reservoir lid. Add coolant (refer To add coolant procedure on This Page for instructions). -31- Model T28366 (Mfd. Since 04/18)

  • Page 34: Lubrication

    We do not recommend using metal needle or lance- type tips, as they can push the ball too far into the oiler, break the spring seat, and lodge the ball in the oil galley. -32- Model T28366 (Mfd. Since 04/18)
  • Page 35 (see Figure 47). Move the saw headstock back-and- forth several times to distribute oil evenly. Oil Access (1 of 2) Figure 47. Location of column hinge pin. -33- Model T28366 (Mfd. Since 04/18)

  • Page 36: Section 7: Service

    5. Test all legs for power; replace if necessary. 6. Motor bearings at fault. 6. Test by rotating shaft; rotational grinding/loose shaft requires bearing replacement. 7. Gearbox at fault. 7. Rebuild gearbox for bad gear(s)/bearing(s). -34- Model T28366 (Mfd. Since 04/18)
  • Page 37 2. Workpiece is not properly secured in vise. 3. Set cutting angle according to scale (Page 28). 3. Cutting angle not properly set. 4. Debris on vise. 4. Clean vise. 5. Sharpen/replace blade (Page 24). 5. Dull/warped blade. -35- Model T28366 (Mfd. Since 04/18)

  • Page 38: Adjusting Miter Lock Lever

    Note: Check lock lever clearance to ensure Miter Lock it does not interfere with the vise handwheel Lever rotation when fully locked. Figure 49. Location of miter lock lever. -36- Model T28366 (Mfd. Since 04/18)

  • Page 39: Section 8: Wiring

    Technical Support at (570) 546-9663. The photos and diagrams included in this section are best viewed in color. You can view these pages in color at www.grizzly.com. -37- Model T28366 (Mfd. Since 04/18)

  • Page 40: Electrical Components

    Figure 51. Power switch. Figure 54. Emergency Stop and On button. Figure 52. Connector. Figure 55. Transformer. Figure 53. Start and run capacitors. Figure 56. Coolant pump motor. READ ELECTRICAL SAFETY -38- Model T28366 (Mfd. Since 04/18) ON PAGE 37!

  • Page 41: Wiring Diagram

    Capacitor 14NO 500uF 65uF 125V 250V MASTER Cansen POWER SWITCH LW30-20 CONTACTOR Telemecanique 115V Neutral Pump Motor SongLong SL-401 110 VAC 120V 15W 760 L/H 5-15 Plug Ground READ ELECTRICAL SAFETY -39- Model T28366 (Mfd. Since 04/18) ON PAGE 37!

  • Page 42: Section 9: Parts

    SECTION 9: PARTS We do our best to stock replacement parts when possible, but we cannot guarantee that all parts shown are available for purchase. Call (800) 523-4777 or visit www.grizzly.com/parts to check for availability. Motor 18 19 22-1 14-1...
  • Page 43 KEY 6 X 6 X 15 PT28366015 HEX NUT M4-.7 PT28366037 BALL BEARING 6006-2RS PT28366016 MOTOR GUARD PT28366038 BALL BEARING BUSHING PT28366017 ELECTRICAL BOX BUY PARTS ONLINE AT GRIZZLY.COM! -41- Model T28366 (Mfd. Since 04/18) Scan QR code to visit our Parts Store.

  • Page 44: Headstock

    PT28366068 GASKET 56 X 2.65MM PT28366101 CAP SCREW M10-1.5 X 30 PT28366069 ARBOR SHAFT BUSHING PT28366102 CUTTING LABEL PT28366070 ARBOR SHAFT BUY PARTS ONLINE AT GRIZZLY.COM! -42- Model T28366 (Mfd. Since 04/18) Scan QR code to visit our Parts Store.

  • Page 45: Base

    PT28366125 FLAT WASHER 4MM PT28366150 MESH FILTER PT28366126 CAP SCREW M4-.7 X 10 PT28366151 HOSE CLAMP 12MM PT28366127 VISE GUIDE SHAFT BUY PARTS ONLINE AT GRIZZLY.COM! -43- Model T28366 (Mfd. Since 04/18) Scan QR code to visit our Parts Store.

  • Page 46: Electrical

    PT28366156 R CAPACITOR 65UF 250V 1-1/2" X 3-1/4" PT28366162 AVIATION PLUG 2 PIN PT28366157 S CAPACITOR 500UF 125V 1-1/2" X 3-1/4" BUY PARTS ONLINE AT GRIZZLY.COM! -44- Model T28366 (Mfd. Since 04/18) Scan QR code to visit our Parts Store.

  • Page 47: Labels & Cosmetics

    MUST maintain the original location and readability of the labels on the machine. If any label is removed or becomes unreadable, REPLACE that label before using the machine again. Contact Grizzly at (800) 523-4777 or www.grizzly.com to order new labels. BUY PARTS ONLINE AT GRIZZLY.COM! -45- Model T28366 (Mfd.
  • Page 49 Would you recommend Grizzly Industrial to a friend? _____ Yes _____No Would you allow us to use your name as a reference for Grizzly customers in your area? Note: We never use names more than 3 times. _____ Yes _____No 10.
  • Page 50 FOLD ALONG DOTTED LINE Place Stamp Here GRIZZLY INDUSTRIAL, INC. P.O. BOX 2069 BELLINGHAM, WA 98227-2069 FOLD ALONG DOTTED LINE Send a Grizzly Catalog to a friend: Name_______________________________ Street_______________________________ City______________State______Zip______ TAPE ALONG EDGES--PLEASE DO NOT STAPLE...

  • Page 51: Warranty And Returns

    WARRANTY AND RETURNS Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of maintenance.
