Tenda A6 User Manual

Wireless n150 mini ap/router
Hide thumbs Also See for A6:
Table of Contents

Advertisement

Quick Links

See also: Manual
Wireless N150 Mini AP/Router

Advertisement

Table of Contents
loading

Related Manuals for Tenda A6

Summary of Contents for Tenda A6

  • Page 1 Wireless N150 Mini AP/Router...

  • Page 2: Copyright Statement

    All photos and product specifications mentioned in this manual are for references only. Upgrades of software and hardware may occur; Tenda reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any person or organization of such revisions or changes.
  • Page 3 Wireless N150 Mini AP/Router Table of Contents...
  • Page 4 Wireless N150 Mini AP/Router...
  • Page 5 Wireless N150 Mini AP/Router...
  • Page 6 Wireless N150 Mini AP/Router...

  • Page 7: Chapter 1 Product Overview

    Thanks for purchasing this A6 Wireless N150 Mini AP/Router (hereunder referred to as device). A6 is a typically multi-purpose device that provides 5 working modes: Wireless AP Mode, Wireless Router Mode, WISP Mode, Client Mode and Universal Repeater Mode, meeting your diversified needs.

  • Page 8: Package Contents

    Please unpack the box and check the following items: ◆ A6 Wireless N150 Mini AP/Router ◆ Power Adapter ◆ USB Cable ◆ Quick Installation Guide ◆ CD-ROM If any of the above items are incorrect, missing, or damaged, please contact your Tenda reseller for immediate replacement.

  • Page 9: Panel Overview

    Wireless N150 Mini AP/Router 1.3 Panel Overview LED Overview Status Description A blue solid light Device is starting A blue blinking light Device is working normally...
  • Page 10 Wireless N150 Mini AP/Router LED/Button Overview  Reset: Reset button. Pressing it for about 7 seconds restores the device to factory defaults.  Power: Power receptacle for connection to power outlet via the included power adapter or to one USB port on your notebook using the included USB cable.

  • Page 11: Chapter 2 Hardware Installation

    Wireless N150 Mini AP/Router Chapter 2 Hardware Installation 2.1 Installation Before you start configuring the device, follow below steps to install device. For optimum wireless performance, it is advisable to place the device in the center of the coverage. 2.1.1 Connect the device to a power source Use the included power adapter or USB cable (with the other end connected to your notebook) to power the device.
  • Page 12 Wireless N150 Mini AP/Router 2.1.2 Connect your notebook to the device 2.1.2.1. If you are using a wired adapter, connect your notebook to the device using an Ethernet cable. 2.1.2.2. If you are using a wireless adapter, follow steps below to config your adapter: a.
  • Page 13 Wireless N150 Mini AP/Router “Not Connected”. b. Right click Wireless Network Connection and select “Connect/Disconnect” to display below screen. Click “Refresh” if you do not find “Tenda_××××××”, where “××××××” represents the last six characters in device MAC address.

  • Page 14: Wireless Ap Mode

    Wireless N150 Mini AP/Router c. Select “Tenda_××××××”and click “Connect”. Chapter 3 Working Modes Overview The device provides 5 working modes and is preset to wireless AP mode by default. You can select a mode that best fits yourself and the device delivers corresponding functions accordingly.

  • Page 15: Wireless Router Mode

    Wireless N150 Mini AP/Router 3.2 Wireless Router Mode In this mode，the device works as a wireless NAT router with DHCP feature. Simply connect the device to a DSL/cable modem, and a wireless network is created to be shared by multiple wireless clients.

  • Page 16: Wisp Mode

    Wireless N150 Mini AP/Router 3.3 WISP Mode In this mode, the device functions as a wireless signal amplifier, ideal for wifi hot spot access and bridging, and provides NAT and DHCP server features. You only need to config some simple settings on the device to wirelessly connect to the other Internet-enabled wireless device without configuring it, so that multiple users can share the Internet connection via the device.

  • Page 17: Universal Repeater Mode

    Wireless N150 Mini AP/Router the DHCP server is deactivated by default in this mode to avoid potential collision and the Ethernet port is working as a LAN port only, so you must config TCP/IP settings manually on your PC to connect to the device using an Ethernet cable.
  • Page 18 Wireless N150 Mini AP/Router Refer to below topology for deploying network devices involved when using this mode. For details, see section 5-5.

  • Page 19: Using A Wired Connection

    Wireless N150 Mini AP/Router Chapter 4 Login to Web Utility This chapter presents how to access device Web Utility. Follow below instructions if you are using Windows 7. 4.1 Using a wired connection 4.1.1 Config TCP/IP settings If you are connecting to the device via an Ethernet cable, do as follows to config TCP/IP settings on your PC.
  • Page 20 Wireless N150 Mini AP/Router 3. Right click “Local Area Connection” and select “Properties”. 4. Select “Internet Protocol (TCP/IP)” on the appearing window and click the “Properties” button.
  • Page 21 Wireless N150 Mini AP/Router 5. Select “Use the following IP address” or “Obtain an IP address automatically”. a. To “Obtain an IP address automatically” simply click the corresponding button.
  • Page 22 Wireless N150 Mini AP/Router b. “Use the following IP address” IP address: Enter 192.168.2.xxx (xxx can be any value from 2~253). Subnet mask: Enter 255.255.255.0. Default gateway: Enter 192.168.2.1. Preferred DNS server: Enter 192.168.2.1 in case that you don’t know the local DNS server address (Or contact your ISP for help). At last, click OK to save your settings.
  • Page 23 Wireless N150 Mini AP/Router 4.2 If you are connecting to the device wirelessly, do as follows (Note that you can only connect to the device wirelessly when using Wireless Router or AP mode.) 1. Click “Network”-“Properties” and then left click “Change adapter settings”...
  • Page 24 Wireless N150 Mini AP/Router 2. Click the “Wireless Network Connection”, select “Properties” and then refer to steps 4-5 above to config TCP/IP settings for the wireless adapter. 3. Right click “Wireless Network Connection” and select “Connect/Disconnect” to display all scanned wireless networks.
  • Page 25 Wireless N150 Mini AP/Router 4. Select the SSID entitled “Tenda_××××××” (where×××××× represents the last 6 characters in the device MAC address) and click “Connect”. If you don’t find it, please click “Refresh Network List”. 4.3 Login to Web Utility Launch a web browser, input “http：//192.168.2.1”and press “Enter”...
  • Page 26 Wireless N150 Mini AP/Router Enter “admin” (factory default password) in the Password field and click “Login”. You will see below screen if you entered a correct password.

  • Page 27: Chapter 5 Quick Setup For Internet Access In 5 Working Modes

    Wireless N150 Mini AP/Router Chapter 5 Quick Setup for Internet Access in 5 Working Modes 5.1 Quick Setup----Wireless AP Mode The device is in Wireless AP mode by default. So simply connect the device to Internet service at hotel, home or office without configuration required on the device and multiple users within coverage can share Internet access.
  • Page 28 Wireless N150 Mini AP/Router 5.2 Quick Setup----Wireless Router Mode In this mode，the device works as a wireless NAT router with DHCP feature. Simply connect the device to an Internet-enabled DSL/CABLE modem from your ISP side, and multiple wireless clients can share this single Internet connection using IP addresses obtained from the device’...
  • Page 29 Wireless N150 Mini AP/Router  SSID ：A SSID (Service Set Identifier) is the unique name of a wireless network.  Channel: Select a least interferential channel for your wireless network to operate on from the drop-down list. If you’re not sure of it, select auto. ...
  • Page 30 Wireless N150 Mini AP/Router Three Internet connection types are provided: PPPOE, Dynamic IP and Static IP. Select your connection type. If you are not sure about which to select, consult your ISP.  DHCP This is the default connection type. No configurations are required for this connection.
  • Page 31 Wireless N150 Mini AP/Router  PPPoE Select PPPoE, if your ISP is using a PPPoE connection, enter the PPPoE user name and password provided by your ISP in corresponding fields as seen below and then click “Next”. After the device is rebooted, go to “Status” to check the WAN connection status.
  • Page 32 Wireless N150 Mini AP/Router start surfing Internet now. For more settings, see later sections hereof.  Config WAN MAC address (Optional) Normally you don't need to change the default WAN MAC address. However, some ISP may bind a specific MAC address for Internet connection authentication.
  • Page 33 Wireless N150 Mini AP/Router have accessed below interface following instructions in Chapter 4 and then do as follows: 1. Select “WISP Mode” and click “Next” on “Quick Setup” section. 2. You shall come to below screen.
  • Page 34 Wireless N150 Mini AP/Router  Remote AP's SSID: Service Set Identifier), unique wireless network name; Enter a SSID of the link partner (to which your device is going to connect).  Remote AP's Channel: Select the channel which the link partner (to which the device is going to connect) is currently operating on.
  • Page 35 Wireless N150 Mini AP/Router For convenience purpose, it is advisable to use the “Open Scan” option to search and select the link partner to add certain settings to the device automatically. After you finish the above settings, click “Next”. 3. Below screen shall display. ...
  • Page 36 Wireless N150 Mini AP/Router 5.4 Client Mode To config Internet connection settings in the Client Mode, first make sure you have accessed below interface following instructions in Chapter 4 and then do as follows: 1. Select “Client Mode” and click “Next”. 2.
  • Page 37 Wireless N150 Mini AP/Router  Remote AP's SSID: Service Set Identifier), unique wireless network name; Enter a SSID of the link partner (to which your device is going to connect).  Remote AP's Channel: Select the channel which the link partner (to which the device is going to connect) is currently operating on.
  • Page 38 Wireless N150 Mini AP/Router option to search and select the link partner to add certain settings to the device automatically. After you finish the above settings, click “Finish” and reboot the device to activate new settings. 5.5 Universal Repeater Mode To config Internet connection settings in the Universal Repeater Mode (also referred to Client + AP Mode), first make sure you have accessed below interface following instructions in Chapter 4...
  • Page 39 Wireless N150 Mini AP/Router 2. Below screen shall display.  Remote AP's SSID: Service Set Identifier), unique wireless network name; Enter a SSID of the link partner (to which your device is going to connect).  Remote AP's Channel: Select the channel which the link...
  • Page 40 Wireless N150 Mini AP/Router partner (to which the device is going to connect) is currently operating on.  Remote AP's MAC Address: Enter the MAC address (also called BSSID) of the link partner (to which the device is going to connect). ...
  • Page 41 Wireless N150 Mini AP/Router  Channel: Select a channel from the drop-down menu for the device to operate on. There are 13 channels available. For security purpose, it is advisable to encrypt your wireless network with WPA-AES. Simply enter a security key made up of 8-63 numeric, alphabetic characters or signs like @, # and $, etc.

  • Page 42: Chapter 6 Network

    Wireless N150 Mini AP/Router Chapter 6 Network 6.1 LAN Settings This section allows you to config the TCP/IP settings for the device’s LAN interface. Settings to config vary depending on different working modes. If you are currently using the WISP/Wireless Router Mode, see below: ...

  • Page 43: Wan Settings

    Wireless N150 Mini AP/Router  IP Address: Device’s LAN IP, 192.168.2.1 by default. You can change it according to your needs; just remember to use the new one to log on to the device’s web utility if you changed it. ...
  • Page 44 Wireless N150 Mini AP/Router PPPoE  Internet connection Type: Displays the current Internet connection type.  User Name: Enter the User Name provided by your ISP.  Password: Enter the password provided by your ISP.  MTU: Maximum Transmission Unit. DO NOT change it from the factory default of 1480 unless necessary.
  • Page 45 Wireless N150 Mini AP/Router Static IP If your ISP assigns a fixed IP address to you, then select Static IP, and enter the IP address, subnet mask, primary DNS and secondary DNS(optional) info provided by your ISP in corresponding fields. ...

  • Page 46: Mac Clone

    Wireless N150 Mini AP/Router 6.3 MAC Clone The MAC clone feature is only available in Wireless Router mode. This section allows you to config the device WAN MAC address. Normally you don't need to change the default WAN MAC address. However, some ISP may bind a specific MAC address for Internet connection authentication.
  • Page 47 Wireless N150 Mini AP/Router 6.4 DNS DNS is short for Domain Name System or Domain Name Service. It resolves catchy domain names into corresponding IP addresses.  DNS: Check/uncheck to enable/disable the DNS feature.  Primary DNS Server: Enter the DNS address provided by your ISP.

  • Page 48: Chapter 7 Wireless

    Wireless N150 Mini AP/Router Chapter 7 Wireless 7.1 Basic Settings Note: Below screen will not be displayed when in “Client Mode”.  802.11 Mode: Select a right mode according to your wireless client.  11b mode：Select it if you have only Wireless-B clients in your wireless network.

  • Page 49: Wireless Security

    Wireless N150 Mini AP/Router  BSSID ：A BSSID, in IEEE 802.11 wireless network, is the MAC address of a wireless AP.  SSID Broadcast: Select “Enable”/“Disable” to make your wireless network visible/ invisible to any wireless clients within coverage when they perform a scan to see what’s available.
  • Page 50 Wireless N150 Mini AP/Router 7.2.1 WPA-PSK The WPA protocol implements the majority of the IEEE 802.11i standard. It enhances data encryption through the Temporal Key Integrity Protocol (TKIP) which is a 128-bit per-packet key, meaning that it dynamically generates a new key for each packet.
  • Page 51 Wireless N150 Mini AP/Router 7.2.2 WPA2-PSK The later WPA2 protocol features compliance with the full IEEE 802.11i standard and uses Advanced Encryption Standard (AES) in addition to TKIP encryption protocol to guarantee better security than that provided by WEP or WPA. ...
  • Page 52 Wireless N150 Mini AP/Router confidentiality comparable to that of a traditional wired network. Two methods of authentication can be used with WEP: Open System authentication and Shared Key authentication.  Security Mode: Select WEP from the drop-down menu.  Default Key: Select a currently valid key from keys 1-4. ...

  • Page 53: Mac-Based Wireless Access Control

    Wireless N150 Mini AP/Router 7.3 MAC-based Wireless Access Control The MAC-based Wireless Access Control feature can be used to allow or disallow clients at specific MAC addresses to connect to your wireless network.  Wireless Access Control: “Allow” only allows PCs at specified MAC addresses to connect to your wireless network while “Deny”...
  • Page 54 Wireless N150 Mini AP/Router  MAC Address: Displays MAC addresses of currently connected wireless clients.  Bandwidth: Displays bandwidth used currently connected wireless clients.

  • Page 55: Chapter 8 Dhcp Settings

    Wireless N150 Mini AP/Router Chapter 8 DHCP Settings The DHCP server feature is only available in WISP Mode and Wireless Router Mode. 8.1 DHCP Server The Dynamic Host Configuration Protocol (DHCP) is an automatic configuration protocol used on IP networks. If you enable the built-in DHCP server on the device, it will automatically configure the TCP/IP settings for all your LAN computers (including IP address, subnet mask, gateway and DNS...
  • Page 56 Wireless N150 Mini AP/Router server’s IP assignment.  Lease Time: The length of time for the IP address lease. Configuring a proper lease time improves the efficiency for the DHCP server to reclaim disused IP addresses. For example: If the lease time is set to one hour, then the DHCP server will reclaim disused IP addresses every hour.
  • Page 57 Wireless N150 Mini AP/Router  IP Address: Enter the IP address for static DHCP assignment.  MAC Address: Enter the MAC address of a computer to always receive the same IP address (the IP you just specified).  Host name: Displays name of a given host (DHCP client). ...

  • Page 58: Port Range Forwarding

    Wireless N150 Mini AP/Router Chapter 9 Advanced Applications The Port Range Forwarding feature is only available in WISP Mode and Wireless Router Mode. 9.1 Port Range Forwarding The Port Range Forwarding feature allows you to set up public services on your network, such as web servers, ftp servers, e-mail servers, or other specialized Internet applications.
  • Page 59 Wireless N150 Mini AP/Router by the server or Internet applications.  LAN IP: Enter an IP address of the computer to work as a server in LAN.  Protocol: Includes TCP, UDP and Both. Select “Both” when you are not sure about which protocol to use. ...

  • Page 60: Dmz Settings

    Wireless N150 Mini AP/Router 9.2 DMZ Settings The DMZ feature allows one network computer to be exposed to the Internet for use of a special-purpose service such as Internet gaming or videoconferencing. DMZ hosting forwards all the ports at the same time to one PC. The Port Range forwarding feature is more secure because it only opens the ports you want to have opened, while DMZ hosting opens all the ports of one computer, exposing the computer to the Internet.

  • Page 61: Upnp Settings

    Wireless N150 Mini AP/Router 9.3 UPnP Settings UPnP (Universal Plug and Play) works in Windows XP, Windows ME or later operational systems (NOTE: Operational system needs to be integrated with or installed with Directx 9.0) or in an environment with installed application software that supports UPnP.

  • Page 62: Chapter 10 Security

    Wireless N150 Mini AP/Router Chapter 10 Security The Security feature is only available in WISP Mode and Wireless Router Mode. 10.1 Client Filter To better manage PCs in LAN, you can allow or disallow such PCs to access certain ports on Internet using the Client Filter functionality.
  • Page 63 Wireless N150 Mini AP/Router  Filter Mode: Select Deny or Allow according to your own needs.  Deny Access to Internet: Disallow specified packets to pass through the device; other packets are processed according to default mode.  Allow Access to Internet: Allow specified packets to pass through the device;...
  • Page 64 Wireless N150 Mini AP/Router (“Both” includes TCP and UDP). Example: To prohibit PCs within the IP address range of 192.168.2.20-192.168.2.30 from accessing Internet from 8:00 to 18：00 during working days, do as follows: Click “Save” and you will find such entry in the List below.

  • Page 65: Mac Address Filter

    Wireless N150 Mini AP/Router Select “Allow” from the “Default Mode” drop-down list and check “Enable Client Filter” feature. 10.2 MAC Address Filter To better manage PCs in LAN, you can use the MAC Address Filter function to allow/disallow such PCs to access to Internet.
  • Page 66 Wireless N150 Mini AP/Router Click “Add” to enter page below:  Filter Mode: Select Deny or Allow according to your own needs. Deny Access to Internet: Disallow specified packets to pass through the router; other packets are processed according to default rule. ...
  • Page 67 Wireless N150 Mini AP/Router 00:B0:0C:77:88:00 from accessing Internet from 8:00 to18：00 everyday, config same settings on the screenshot below on your device: Click “Save” to display the following page. Select “Allow” from the “Default” drop-down list and check the...

  • Page 68: Url Filter

    Wireless N150 Mini AP/Router “Enable MAC Filter” feature. 10.3 URL Filter To better control LAN PCs, you can use the URL filter functionality to allow or disallowsuch PC to access certain websites within a specified time range.
  • Page 69 Wireless N150 Mini AP/Router Click “Add” to display page below: Filter Mode: Select Deny or Allow according to your own needs. Deny Access to Internet: Disallow specified packets to pass through the router; other packets are processed according to default rule. ...
  • Page 70 Wireless N150 Mini AP/Router For example: If you want to disallow only PCs within the IP range of 192.168.2.20~192.168.2.30 on your LAN to access only websites containing “yahoo” from 8 ： 00 to 18 ： 00 during working days: Monday- Fridaywhile not restricting other PCs, then config same settings as shown on below screenshot on your device: Click “Save”...

  • Page 71: Remote Web-Based Management

    Wireless N150 Mini AP/Router Select “Allow” from the “Default” drop-down list and check the “Enable URL Filter” feature. 10.4 Remote Web-based Management The Remote Web-based Management feature allows users to configure your device from Internet via a web browser.
  • Page 72 Wireless N150 Mini AP/Router  Enable: Check or uncheck to enable or disable the remote web-based management feature.  Port: Enter a port number for remote web-based management.  IP Address: Enter the IP address of a PC on Internet authorized to access and manage the device’s web-based utility remotely.

  • Page 73: Routing Table

    Wireless N150 Mini AP/Router Chapter 11 Routing Settings 11.1 Routing Table This page displays the device core routing table which lists destination IP, subnet mask, gateway, hop count and interface. The principal task for a router is to look for an optimal transfer path for each data packet passing through it, and transfer it to the specified destination.

  • Page 74: Chapter 12 Tools

    Wireless N150 Mini AP/Router Chapter 12 Tools 12.1 Time Settings This section assists you in setting the device’s system time; you can either select to set the time and date manually or automatically obtain the GMT time from Internet.  Sync with Internet time servers: Time and date will be updated automatically from Internet.
  • Page 75 Wireless N150 Mini AP/Router reconnect it to the Internet. Features/functions based on time (e.g. security settings) take effect only after Time and Date settings are configured or updated automatically from Internet. 12.2 DDNS Dynamic DNS or DDNS is a term used for the updating in real time of Internet Domain Name System (DNS) name servers.
  • Page 76 DDNS service provider (optional). For example: If you have registered a DDNS service in dyndns.org and are given tenda, 123456, tenda.dyndns.info respectively as username, password and domain name for a web server on your PC at 192.168.2.10, then configure port settings on port range forwarding interface under virtual server menu and enter this information on the above DDNS interface.

  • Page 77: Backup/Restore Settings

    Wireless N150 Mini AP/Router Username tenda Password 123456 Domain Name tenda.dyndns.info 12.3 Backup/Restore Settings This section allows you to backup current settings or to restore the previous settings configured on the device.
  • Page 78 Wireless N150 Mini AP/Router Backup Settings: Once you have configured the device the way you want it, you can save these settings to a configuration file on your local hard drive that can later be imported to your device in case that the device is restored to factory default settings.
  • Page 79 Wireless N150 Mini AP/Router And then click the "Restore" button to reset your device to previous settings.

  • Page 80: Restore To Factory Default Settings

    Wireless N150 Mini AP/Router 12.4 Restore to Factory Default Settings To restore all settings to the device's factory default values, click the "Restore to Factory Default” button: Factory Default Settings:  User Name: admin  Password: admin  IP Address: 192.168.2.1 ...
  • Page 81 Wireless N150 Mini AP/Router our website www.tendacn.com）to download the latest firmware to update your device. To update firmware, do as follows:  1. Click "Browse” to locate the firmware and "Upgrade” to update.  2. Router will reboot automatically when upgrade completes.

  • Page 82: Change Password

    Wireless N150 Mini AP/Router during reboot. To restart your device, click the “Reboot” button. 12.7 Change Password This section allows you to change login password for accessing device’s Web-based interface.
  • Page 83 Wireless N150 Mini AP/Router  Old Password: Enter the old password.  New Password: Enter a new password.  Confirm New Password: Re-enter the new password for confirmation. Click “Save” to save your new password. NOTE:For the sake of security, it is highly recommended that youchange default login password.

  • Page 84: Appendix 1：How To Connect To An Encrypted Wireless Network

    Wireless N150 Mini AP/Router Appendix 1：How to connect to an encrypted wireless network To connect to an encrypted wireless network, you must provide a valid security key. Follow steps below (Below explains how to connect to a WPA-encrypted wireless network in Windows 7 OS): 1.
  • Page 85 Wireless N150 Mini AP/Router 3. Double click or select the SSID entitled “Tenda_××××××” (where×××××× represents the last 6 characters in the device MAC address) and click “Connect”. Enter the security key on appearing window (Note that security key is case-sensitive. Here we assume it is tendatenda) and click “OK”.
  • Page 86 Wireless N150 Mini AP/Router 4. As seen below, display of “Connected” next to “Tenda_××××××” indicates a successful connection.

  • Page 87: Appendix 2: Glossary

    Wireless N150 Mini AP/Router Appendix 2: Glossary Channel A communication channel, also known as channel, refers either to a physical transmission medium such as a wire or to a logical connection over a multiplexed medium such as a radio channel. It is used to transfer an information signal, such as a digital bit stream, from one or more transmitters to one or more receivers.
  • Page 88 Wireless N150 Mini AP/Router WEP uses the stream cipherRC4 for confidentiality,[5] and the CRC-32 checksum for integrity. Standard 64-bit WEP uses a 40-bit key (also known as WEP-40), which is concatenated with a 24-bit initialization vector (IV) to form the RC4 key. The extended 128-bit WEP protocol uses a 104-bit key size (WEP-104).

  • Page 89: Appendix 3: Faqs

    Read the following if you are running into problems. If you cannot find solutions here, please go to our website www.tenda.cn (or www.tendacn.com) or E-mail to support@tenda.cn for help. 1. Q: I entered the device’s LAN IP address in the web browser but cannot access the utility.
  • Page 90 Wireless N150 Mini AP/Router Contact our technical support for help if the problem still exists after you tried all the above. 2. Q: What should I do if I forget the login password to my device (How do I reset my device)? A: Reset your device by pressing the Reset button for over 7 seconds.
  • Page 91 Wireless N150 Mini AP/Router IP address automatically, please ensure that the router's DHCP function is enabled. DHCP can automatically assign an IP address to your computer. If there is no DHCP, please set a static IP address and fill in gateway and DNS, otherwise you cannot access Internet.
  • Page 92 Wireless N150 Mini AP/Router access these servers and you need to know related service ports, for example, Web server’s port is 80; FTP is 21; SMTP is 25 and POP3 is 110. Step 2: Click “Virtual Server” and select “Port Range Forwarding” on the Router’s web interface.
  • Page 93 D: Make sure antenna on the device is not detached. If you still are unable to access Internet after you tried all the above steps, contact our technical staff for help. Add: Tenda Industrial Zone, No.34-1 ShilongRoad,ShiyanTown,BaoanDistrict,Shenzhen,China. 518108 General Inquiries Tel: (86)755-27657180 Fax: (86)755-27657178 Email: sales@tenda.com.cn...

  • Page 94: Safety Regulatory Statement

    Wireless N150 Mini AP/Router Safety Regulatory Statement CE Mark Warning This is a Class B product in a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. This device complies with EU 1999/5/EC.
  • Page 95 Wireless N150 Mini AP/Router installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference...
  • Page 96 Wireless N150 Mini AP/Router Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. NOTE: (1) The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment.

  • Page 97: Safety Instructions

    Wireless N150 Mini AP/Router Safety Instructions 1. Operation temperature range ：0-40℃ 2. For applicable power supplies see user manual Adapter information: Model: TEA09X-05120 (X=A or E or U or D) Input: 100-240V, 50/60Hz, 0.3A Output: DC5V 1.2A 3. USB output：5Vdc，0.5A...
