Snapper EMRP216517B Parts Manual page 5

HANDLES & CONTROLS (2002 & EARLIER)
Item Part No Qty
1 72931 1
2 36350 1
3 46502 1
4 35342 1
5 47011 1
6 34872 1
7 72933 1
8 32826 1
9 14307 1
-- 29775 1
10 72932 1
11 12121 1
12 12122 1
13 41871 1
14 91238 1
15 12093 1
16 90188 1
17 29383 1
18 24087 1
-- 29783 1
19 32408 1
20 23790 1
-- 51698 1
20a 15752 1
20b 15753 1
20c 90095 1
21 10937 1
22 90895 1
23 12114 1
24 90595 2
25 90238 1
26 91026 1
27 91070 10
28 46202 1
29 24641 2
30 91189 4
31 35744 4
32 41870 1
33 90391 4
34 76978 1
Footnotes
21" STEEL DECK WALK BEHIND MOWER
"MR" SERIES 17
Description
HANDLE, Upper
HANDLE, Middle- 1990
HANDLE, Lower Left Hand
HANDLE, Lower Right Hand
BAIL, Blade Control
CLIP, Blade Control
CABLE, Blade Control (49-1/4" long)
HANDLE, Wheel Drive
GRIP, Wheel Drive Handle
GRIP,Wheel Drive Handle (Euro)
CABLE, Clutch Pull (Z-Bend, 38-5/8" long)
COVER, Vinyl
SPRING, Clutch
SECTOR, Speed
BOLT, 5/16-18 x 1" Square Neck Carriage GR 5
SPRING, Speed Control
WASHER, 3/8" Flat
GRIP, Speed Control Handle
DECAL, Speed Select
DECAL, Speed Select (Euro)
GUIDE, Lower V-Belt
ROD, Transfer
ASSY., Transfer Rod (Incl. indented items below)
LINK, Transfer
BALL JOINT, 1/4-28
NUT, 1/4-28 Hex
CLIP, Transfer Rod 1/4"
TEE-NUT, 5/16-18
BUSHING, Differential
BOLT, 5/16-18 x 3/4" Hex Flange Lock GR5
SCREW, 5/16-24 x 1" Hex Head Cap GR5
BOLT, 5/16-18 x 5/8" Short Neck Carriage GR5
NUT, 5/16-18 Hex Flange Lock GR5
BRACKET, Speed Control Rod
WIRE TIE, 1.29" Long (Black)
SCREW, 5/16-18 x 1-7/8" Curved Head GR2
T-KNOB, 5/16-18 (BLACK)
LEVER, Speed Control
WASHER, 5/16" Internal Tooth Lock
NUT, 1/4-28 Hex GR5 or B
Note
used on All
used on All
used on All
used on All
used on All
used on All
used on All
used on Self-Propelled
used on Self-Propelled
used on Self-Propelled (Euro)
used on Self-Propelled
used on Self-Propelled
used on Self-Propelled
used on Self-Propelled
used on All
used on Self-Propelled
used on Self-Propelled
used on Self-Propelled
used on Self-Propelled
used on Self-Propelled (Euro)
used on Self-Propelled
used on Self-Propelled
used on Self-Propelled (Euro)
used on Self-Propelled (Euro)
used on Self-Propelled (Euro)
used on Self-Propelled (Euro)
used on Self-Propelled
used on Self-Propelled
used on Self-Propelled
used on All
used on All
used on All
used on All
used on Self-Propelled
used on All
used on All
used on All
used on Self-Propelled
used on All
used on All
5
Manual No. 06135
TP 400-5001-03-WB-N
