Snapper CP215017KWV, CP216017RV, CP214017R2 Safety Instructions & Operator's Manual

21” steel deck walk mowers commercial model series 17
Hide thumbs Also See for CP215017KWV, CP216017RV, CP214017R2:
Table of Contents

Advertisement

Quick Links

Download this manual
MODEL DESIGNATION
SELF-PROPELLED
CUTTING WIDTH
C – Commercial Model
21 – 21" Cutting Width
40 – 4.0 HP
60 – 6.0 HP (Engine Horse Power)
Thank you for buying a SNAPPER Product! Before operating your Walk Behind, read this manual carefully and pay
particular attention to the "IMPORTANT SAFETY INSTRUCTIONS" on Pages 2 & 3. Remember that all power equipment
can be dangerous if used improperly. Also keep in mind that SAFETY requires careful use in accordance with the
operating instructions and common sense.
COPYRIGHT © 2001
SNAPPER INC.
ALL RIGHTS RESERVED
Safety Instructions & Operator's Manual for
MODEL NUMBER EXPLANATION
C
P
P – Self Propelled Model
50 – 5.0 HP
21" STEEL DECK
WALK MOWERS
COMMERCIAL MODEL
21
60
17
17 - Series Designation
R – Robin Engine, KW – Kawasaki Engine
V – Over Head Valve Engine
2 – 2 Cycle Engine
SERIES 17
CP214017R2
CP216017RV
CP215017KWV
R
V
SERIES DESIGNATION
ENGINE HORSE POWER
MANUAL No. 7-4350 (I.R. 2/16/01)
PROPELLED
MODELS
ENGINE OPTIONS
